A3LSGHX530Single-Band PCS GSM Phone

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Nov 05, 2006
Application Purpose: Original Equipment
Date of Application: Nov 05, 2006
Equipment Note: Single-Band PCS GSM Phone
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

World Wide Webhttp://www.samsungmobile.com Printed in Korea Code No.:GH68-XXXXXA English(EU). 09/2006. Rev 1.0 * Depending on the software installed or your service provider or country, some of the descriptions in this guide may not match your phone exactly. * Depending on your country, your phone and accessories may appear different from the illust rations in this guide. SGH-X530User’s Guide Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Drive safely at all timesDo not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuellingDo not use the phone at a refuelling point (service station) or near fuels or chemicals.Switch off in an aircraftWireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.Switch off the phone near all medical equipmentHospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force.InterferenceAll wireless phones may be subject to interference, which could affect their performance.. Important safety precautions 1 Be aware of special regulationsMeet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.Water resistanceYour phone is not water-resistant. Keep it dry. Sensible useUse only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.Emergency callsKey in the emergency number for your present location, then press . Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteriesUse only Samsung-approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorised accessories could damage you or your phone and may be dangerous.Qualified serviceOnly qualified service personnel may repair your phone.For more detailed safety information, see "Health and safety information" on page 61. • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions. At very high volumes, prolonged listening to a headset can damage your hearing. 2 About this GuideThis User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your ph one, please refer to “Get started” and “Step outside the phone.”In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features. Indicates that you can get more information on the referenced page. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [ ] Indicates a key on the phone. For example, [] < > Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu > •Tri-band operation Use your phone in worldwide GSM networks, in any of 900, 1800, and 1900 bands. Special features of your phone • Simple, compact design with Intenna Samsung’s powerful intenna technology allows the best call quality without an annoying external antenna. •IrDA Send and receive Phonebook entries via an infrared port. 3 Special features of your phone •Web browser Access the wireless web to get current information and up-to-the-minute a wide variety of media content. •Java Enjoy Java ™ -based embedded games and download new games. •Phonebook Store home, office, or cellular phone numbers for your contacts. • Multimedia Message Service (MMS) Send and receive MMS messages with a combination of text, images, and sounds. • Calendar and to do list Keep track of your daily and monthly schedules and tasks. •Alarm Use your phone as an alarm clock to wake you up in the morning or notify you to an event. •Calculator Perform basic calculations and do currency conversions. • Voice recorder Record memos or sounds. 4 Contents Unpack 6 Your phone 6 Buttons, features, and locationsGet started 7 First steps to operating your phoneInstall and charge the phone ..................................... 7Power on or off........................................................ 8Keys and display ..................................................... 9Access menu functions ............................................ 11Customise your phone ............................................. 12Make/Answer calls .................................................. 13Step outside the phone 14 Begin with games, web, messages, and other special featuresPlay games ............................................................ 14Browse the web...................................................... 14 Use Phonebook ...................................................... 15Send messages ...................................................... 16View messages....................................................... 17 Enter text 18 Pinyin, Stroke, Quick English(T9), English, Number, and Symbol modesCall functions 24 Advanced calling featuresMenu functions 28 All menu options listedSolve problems 59 Help and personal needsHealth and safety information 61 5 Overview of menu functions To access Menu mode, press < Menu > in Idle mode. 1 SIM AT * p. 28 2 2 Call records p. 29 1 Missed calls2 Received calls3 Dialled calls4 Delete all5 Call time6 Call cost * p. 29 p. 29 p. 29 p. 29 p. 29 p. 30 3 Network services p. 30 1 Call diverting2 Call barring3 Call waiting4 Network selection5 Caller ID6 Closed user group7 Band selection p. 30 p. 31 p. 32 p. 32 p. 32 p. 32 p. 33 4 Sound settings p. 33 1 Ring tone2 Ring volume3 Alert type4 Keypad tone5 Message tone6 Ontime alarm7 Alert on call8 Folder tone9 Power on/off0 Extra tones p. 33 p. 33 p. 33 p. 34 p. 34 p. 34 p. 3…

Text truncated - open the document above for the full version.

Attestation Statements

18600 Broadwick Street October 30, 2006 !"# $%&' ( &) "* +,- . / (0+1+//2(34 (5 /5 ///5 /4(0+1+// 2( 34(5555,4 .(5(65(5 / (5 1 # )57/(5)8 )94144 *4 1 1: ;&/ 1&19<;3<4 SAMSUNG ELECTRONICS CO.,LTD. 416 Maetan3-Dong Yeongtong-gu, Suwon city, Gyeonggi-Do, Korea 442-742 Date: October 30, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LS GHX530 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 45 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, SEOUNG HO PARK SAMSUNG ELECTRONICS CO.,LTD.

Attestation Statements

Federal Communications Commission. 7435 Oakland Mills Road Columbia, MD 21046 DATE: October 26, 2006 Re: Data cable for SGH-X530 FCC ID: A3LSGHX530 DOC to FCC ID: A3LSGHX530 To Whom It May Concern: This letter is to confirm to all concerned parties that FCC ID: A3LSGHX530 has never use any oscillator or active device on the PBA of the Data cable It does not have any oscillator or active device on the PBA of the data cable. There is just passive device. Data cable M/N: PCB093LBE Should you have any questions or comments concerning the above, Please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group . SAMSUNG ELECTRONICS CO., LTD 416,Maetan-3dong,Yeongtong-gu, Suwon-si,Gyeonggi-do,442-600 Korea

External Photos

SAMSUNG FCC ID: A3LSGHX530 EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone NVLAP Lab Code: 100431-0 SAMSUNG FCC ID: A3LSGHX530 EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone NVLAP Lab Code: 100431-0 SAMSUNG FCC ID: A3LSGHX530 EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone NVLAP Lab Code: 100431-0

Internal Photos

Test Report

Reviewed by: FCC ID: A3LSGHX530 FCC Pt. 15B CERTIFICATION TEST REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0610300951 November 01, 2006 Single-Band PCS GSM Phone Page 1 of 13 © 2006 PCTEST Engineering Laboratory, Inc. Ver. 2.33 Applicant Name: Date of Testing: SAMSUNG ELECTRONICS CO., LTD. November 01, 2006 416 Maetan-3 Dong, Paldal-Ku Test Site/Location: Suwon City, Kyungki-Do 441-742, Korea PCTEST Lab, Columbia, MD, USA Test Report Serial No.: 0610300951 FCC ID: A3LSGHX530 APPLICANT: SAMSUNG ELECTRONICS CO., LTD. EUT Type: Single-Band PCS GSM Phone FCC Rule Part(s): FCC Part 15 Subpart B FCC Classification: FCC Class B Digital Device (JBP) Test Procedure: ANSI C63.4-2003 / EN55022: 1998 w/ A1 (2000) + A2 (2003) The device bearing the FCC Identifier specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and has been tested in accordance with the measurement procedures specified in ANSI C63.4-2003 (See Test Report). These measurements were performed with no deviation from the standards. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE Reviewed by: FCC ID: A3LSGHX530 FCC Pt. 15B CERTIFICATION TEST REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0610300951 November 01, 2006 Single-Band PCS GSM Phone Page 2 of 13 © 2006 PCTEST Engineering Laboratory, Inc. Ver. 2.33 TABLE OF CONTENTS ATTACHMENT A. ATTESTATION STATEMENT(S) ATTACHMENT B. TEST REPORT FCC Class B MEASUREMENT REPORT....................................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 EVALUATION PROCEDURE................................................................................................................ 4 1.2 SCOPE .................................................................................................................................................. 4 1.3 PCTEST TEST LOCATION ................................................................................................................... 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION ................................................................................................................ 5 2.2 OPERATION MODE.............................................................................................................................. 5 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ............................................................................. 5 3.0 DESCRIPTION OF TEST.................................................................................................................6 3.1 CONDUCTED EMISSIONS ................................................................................................................... 6 3.2 RADIATED EMISSIONS........................................................................................................................ 7 4.0 SAMPLE CALCULATIONS ..............................................................................................................8 4.1 CONDUCTED EMISSION MEASUREMENT SAMPLE CALCULATION: .............................................. 8 4.2 RADIATED EMISSION MEASUREMENT SAMPLE CALCULATION:................................................... 8 5.0 UNCERTAINTY OF MEASUREMENT .............................................................................................9 5.1 LINE CONDUCTED MEASUREMENT UNCERTAINTY CALCULATIONS: .......................................... 9 5.2 RADIATED EMISSIONS MEASUREMENT UNCERTAINTY CALCULATIONS: ................................. 10 6.0 TEST EQUIPMENT CALIBRATION DATA ....................................................................................11 7.0 ENVIRONMENTAL CONDITIONS .................................................................................................12 8.0 CONCLUSION................................................................................................................................13 ATTACHMENT C. SUMMARY OF TEST RESULTS RADIATED TEST DATA LINE-CONDUCTED TEST DATA/PLOT(S) TEST SUPPORT EQUIPMENT ATTACHMENT D. FCC ID LABEL & LOCATION ATTACHMENT E. BLOCK(S)/ SCHEMATIC(S) DIAGRAM ATTACHMENT F. OPERATIONAL DESCRIPTION ATTACHMENT G. TEST SETUP PHOTOGRAPHS ATTACHMENT H. EXTERNAL PHOTOGRAPHS ATTACHMENT I. INTERNAL PHOTOGRAPHS ATTACHMENT J. USER’S MANUAL Reviewed by: FCC ID: A3LSGHX530 FCC Pt. 15B CERTIFICATION TEST REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0610300951 November 01, 2006 Single-Band PCS GSM Phone Page 3 of 13 © 2006 PCTEST Engineering Laboratory, Inc. Ver. 2.33 MEASUREMENT REPORT FCC Part 15B – Unintentional Radiators A. § 2.1033 General Information APPLICANT: SAMSUNG ELECTRONICS CO., LTD. APPLICANT ADDRESS: 416 Maetan-3 Dong, Paldal-Ku Suwon City, Kyungki-Do 441-742, Korea TEST SITE: PCTEST ENGINEERING LABORATORY, INC. TEST SITE ADDRESS: 6660-B Dobbin Road, Columbia, MD 21045 USA FCC RULE PART(S): FCC Part 15 Subpart B FCC ID: A3LSGHX530 Test Device Serial No.: FD-206-C Production Pre-Production Engineering…

Text truncated - open the document above for the full version.

Test Setup Photos
