A3LSGHZ360Single-Band PCS GSM/ EDGE Phone with Bluetooth

* Depending on the software installed or your service provider or country, some of the descriptions in this guide may not match your phone exactly. * Depending on your country, your phone and accessories may appear different from the illustrations in this guide. World Wide Webhttp://www.samsungmobile.com Printed in Korea Code No.:GH68-xxxxA English (ORA) . 07/2006. Rev. 1.0 SGH-Z360User’s Guide Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Drive safely at all timesDo not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuellingDo not use the phone at a refuelling point (service station) or near fuels or chemicals.Switch off in an aircraftWireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.Switch off the phone near all medical equipmentHospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force.InterferenceAll wireless phones may be subject to interference, which could affect their performance. 1 Important safety precautions Be aware of special regulationsMeet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.Water resistanceYour phone is not water-resistant. Keep it dry. Sensible useUse only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.Emergency callsKey in the emergency number for your present location, then press . Keep your phone away from small childrenKeep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteriesUse only Samsung-approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorised accessories could damage you or your phone and may be dangerous.Qualified serviceOnly qualified service personnel may repair your phone.For more detailed safety information, see "Health and safety information" on page 107. • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions. At very high volumes, prolonged listening to a headset can damage your hearing. 2 About this GuideThis User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your phone, please refer to “Get started” and “Step outside the phone.”In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features.  Indicates that you can get more information on the referenced page. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [ ] Indicates a key on the phone. For example, [] < > Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu > •3G Your phone is capable of operating in a 3G environment, allowing much greater data transfer speed, video streaming, and video conferencing. Special features of your phone • Camera and camcorder Use the camera module on your phone to take a photo or record a video. • Media player Play media files on your phone. You can enjoy high quality videos and music. 3 Special features of your phone •Bluetooth Transfer media files and personal data and connect to other devices using free, wireless Bluetooth technology. •Web browser Access the wireless web to get up-to-the-minute information and a wide variety of media content. • Get personal with photo caller ID See who’s calling you with their very own photo displays. •Name card Create name cards with your number and profile. Whenever introducing yourself to others, use this convenient electronic name card. • Multimedia Message Service (MMS) Send and receive MMS messages with a combination of text, images, video, and audio. •Email Send and receive e-mails with images, video, and audio attachments. •Java Enjoy Java™-based embedded games and download new games. •Calendar Keep track of your daily, weekly, and monthly schedule. • Voice recorder Record memos or sounds. 4 Contents Unpack 6 Make sure you have each itemYour phone 6 Keys, features, and locationsGet started 7 First steps to operating your phoneInstall and charge the phone ...................... 7Power on or off......................................... 8Keys and display ...................................... 9Access menu functions ............................ 12Use Shortcut icons .................................. 13Customise your phone ............................. 14Make/Answer calls .................................. 16Step outside the phone 16 Begin with your camera, the media player, the web, and other special featuresUse the camera ...................................... 16Play media files ...................................... 17 Browse the web ...................................... 19Use Address book.................................... 19Send messages....................................... 21View messages ....................................... 22Use Bluetooth ......................................... 23Use a memory card ................................. 24Switch applications .................................. 26 Enter text 27 T9, ABC, Number, and Symbol modesCall functions 29 Advanced calling featuresMenu functions 35 All menu options listedSolve problems 105 Help and personal needsHealth and safety information 107 Index 129 5 1 Call History  p. 35 1 Missed calls2 Dialled calls3 Received calls4 Current contacts5 Delete all6 Data calls7 Calls cost 1 8 Calls time  p. 35  p. 36  p. 36  p. 36  p. 36  p. 36  p. 37  p. 37 2 Address book  p. 38 1 Search contact2 New contact3 Groups4 Speed dial5 My name card6 Copy all7 Own number8 Service number 1 9 …
