*Depending on the software installed or your service provider or country, some of the descriptions in this guide may not match your phone exactly. * Depending on your country, your phone and accessories may appear different from the illustrations in this guide. World Wide Web http://www.samsungmobile.com Printed in Korea Code No.:GH68-xxxxxA English (EU). 05/2006. Rev. 1.0 SGH-Z620 User’s Guide Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Drive safely at all times Do not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuelling Do not use the phone at a refuelling point (service station) or near fuels or chemicals. Switch off in an aircraft Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous. Switch off the phone near all medical equipment Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Interference All wireless phones may be subject to interference, which could affect their performance. Important safety precautions 1 Be aware of special regulations Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger. Water resistance Your phone is not water-resistant. Keep it dry. Sensible use Use only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on. Emergency calls Key in the emergency number for your present location, then press . Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteries Use only Samsung-approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorised accessories could damage you or your phone and may be dangerous. Qualified service Only qualified service personnel may repair your phone. For more detailed safety information, see "Health and safety information" on page 104. • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions. At very high volumes, prolonged listening to a headset can damage your hearing. 2 About this Guide This User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your phone, please refer to “Get started” and “Step outside the phone.” In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features.  Indicates that you can get more information on the referenced page. → Indicates that you need to press the Navigation keys to scroll to the specified option and then select it. [] Indicates a key on the phone. For example, [] <> Indicates a soft key, whose function is displayed on the phone screen. For example, < Menu> •3G Your phone is capable of operating in a 3G environment, allowing much greater data transfer speed, video streaming, and video conferencing. Special features of your phone • Camera and camcorder Use the camera module on your phone to take a photo or record a video. • Media player Play media files on your phone. You can enjoy high quality videos and music. 3 Special features of your phone •Bluetooth Send photos, images, videos, and other personal data, and connect to other devices using free, wireless Bluetooth technology. • File viewer Open documents in various formats on the phone without corruption. •Web browser Access the wireless web to get up-to-the-minute information and a wide variety of media content. • Name card Create name cards with your number and profile. Whenever introducing yourself to others, use this convenient electronic name card. • Multimedia Message Service (MMS) Send and receive MMS messages with a combination of text, images, video, and audio. •Email Send and receive e-mails with images, video, and audio attachments. •Java Enjoy Java™-based embedded games and download new games. •Calendar Keep track of your daily, weekly, and monthly schedule. • Voice recorder Record memos or sounds. 4 Contents Unpack 6 Make sure you have each item Your phone 6 Keys, features, and locations Get started 7 First steps to operating your phone Install and charge the phone ..................................... 7 Power on or off........................................................ 8 Keys and display ..................................................... 9 Access menu functions ............................................ 12 Customise your phone ............................................. 13 Step outside the phone 16 Begin with your camera, the media player, the web, and other special features Use the camera ...................................................... 16 Play music ............................................................. 17 Browse the web...................................................... 19 Use Phonebook ...................................................... 19 Send messages ...................................................... 21 View messages....................................................... 22 Use Bluetooth ........................................................ 23 Switch applications ................................................. 24 Use a memory card................................................. 25 Enter text 27 ABC, T9, Number, and Symbol modes Call functions 29 Advanced calling features Menu functions 35 All menu options listed Solve problems 102 Help and personal needs Health and safety information 104 Index 112 5 1 Call logp. 35 1 Recent contacts 2 Missed calls 3 Dialled calls 4 Received calls p. 35 p. 37 p. 37 p. 37 2 Phonebookp. 38 1 Search for contacts 2 Create contact 3 Groups 4 My na…
