A3LSHWA250KPCS GSM Phone with Bluetooth

* Some of the contents of this manual may differ from your phone, depending on the software installed or your service provider. World Wide Web http://www.anycall.com SHW-A250K User’s Guide  Be aware of special regulations Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger. Water resistance Your phone is not water-resistant. Keep it dry. Sensible use Use only in the normal position (held to your ear). Avoid unnecessary contact with the antenna when the phone is switched on. Emergency calls Key in the emergency number for your present location, then press [ ]. Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteries Use only Samsung-approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorised accessories could damage you or your phone and may be dangerous. Qualified service Only qualified service personnel may repair your phone. For more detailed safety information, see “Health and safety information” on page 20. Drive safely at all times Do not use a hand-held phone while driving. Park your vehicle first. Switch off the phone when refuelling Do not use the phone at a refuelling point (service station) or near fuels or chemicals. Switch off in an aircraft Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous. Switch off the phone near all medical equipment Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Interference All wireless phones may be subject to interference, which could affect their performance. Failure to comply with the following precautions may be dangerous or illegal. Copyright information Bluetooth? is a registered trademark of the Bluetooth SIG, Inc. worldwide. JavaTM is a trademark or registered trademark of Sun Microsystems, Inc. Picsel and Picsel ViewerTM are trademarks of Picsel Technologies, Inc. At very high volumes, prolonged listening to a headset can damage your hearing. Important safety precautions • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions.  Contents Make sure you have each item • Phone • Adapter • Stereo headset • Battery • Battery travel holder • User’s manual You can obtain the following accessories for your phone from your local Samsung dealer. • Multi adapter • Travel charger • Car charger • PC data cable • Portable battery kit • Portable PC data cable • Music controller • Bluetooth mono/ stereop headset kit Unpack Unpack .............................................................. 3 Make sure you have each item Get started ....................................................... 4 First steps to operate your phone Overview of menu functions .................... 7 To access Menu mode, press [메뉴] in Idle mode. Menu functions .............................................. 8 All menu options listed Solve problems ........................................... 18 Help and personal needs Health and safety information ............... 20  Power on or off Power on Do not turn on the phone when mobile phone use is prohibited. 1 Open the phone. 2 Press and hold [ ] to turn on the phone. 3 If necessary, enter the PIN and press [확인]. Power on 1 Open the phone. 2 Press and hold [ ]. Keys and display Key(s)Description SoftkeysPerform the function indicated on the bottom line of the display. Navigation keysIn Standby mode, access menu options directly. In Menu mode, scroll through the menu options. 확인 keyIn Idle mode, enters Menu mode. In Menu mode, selects the highlighted menu option. key Sends or answers a call. In Standby mode, retrieves the last number dialed, missed, or received. Install and charge the phone 1 Install the battery: 2 Plug the adapter into the phone. 3 Plug the adapter into a standard AC wall outlet. 4 When the phone is completely charged (the battery icon stops blinking), unplug the adapter from the power outlet. 5 Remove the adapter from the phone. Low battery indicator When the battery is low: • a warning tone sounds, • the battery low message displays, and • the empty battery icon [ ] blinks. If the battery level becomes too low, the phone automatically turns off. Recharge your battery. Get started First steps to operate your phone To remove the battery, slide the battery catch toward the top of the phone and hold it.  Get started Key(s)Description 취소 keyDeletes characters from the display. In Menu mode, returns to the previous menu level. key Ends a call. Hold down to switch the phone on and off. In Menu mode, cancels input and returns the phone to Idle mode. Numeric keysEnter numbers, letters, and some special characters. * /# keyEnter special characters. Use for some special functions. Key(s)Description Volume keys (on the left) Adjusts the phone volume. In Standby mode, with the phone open, adjusts the master volume. With the phone closed, hold down to turn on the display. In Menu mode, scrolls through the menu options. Camera keyIn Standby mode, with the phone open, turns on the camera. With the phone closed, hold down to turn on the camera. In Capture mode, takes a photo. 1 T Service 1 Global Roaming 2 M Help Desk 3 T Optional Service 4 NATE 5 W 6 MONETA 2 Sounds 1 Ring Tone Settings 2 Download Melody 3 Alert Tones 4 Key Tones/Others 5 Volume 6 Hourly Chime 3 Display 1 Wall Paper 2 Download Image 2 Main Menu Style 3 Font Type/Size 4 Dial Number Style 5 Lighting 4 Contents box 1 Melodies 2 Images 3 Photos/Movies 4 MMS Attached Files 5 mPlayon 6 june contents box 7 Key Jjang Album 8 Anycall.com Files 9 Memory 5 Exciting Anycall 1 Camera 2 MP3 3 VOD 4 Bluetooth 5 Game 6 Voice Functions 7 Anycall.com 8 Anycall SOS 6 Organizer 1 Wake-up/Alar…

Text truncated - open the document above for the full version.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 18600 Broadwick St. Rancho Dominguez, CA 90220 Date: May 10, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, http Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSHWA250K To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Description 3 Schematics PERMANENT 4 Parts List & Tune-Up Procedure 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Peter Ra General Manager American QA Lab SAMSUNG Electronics America INC.

WHITE 한성 김준섭 100329100329 김태훈 100329 조경환 1. 기기의 명칭(모델명):이동통신용 무선설비의 기기(SHW-A250K) 2. 인증번호: 3. 인증받은 자의 상호:삼성전자(주) FCC ID : A3LSHWA250K 960 정격 : 3.7 V mA 4. 제조년월일: 5. 제조자/제조국가:삼성전자(주)/대한민국 ※ 일련번호: o 해당 무선설비는 운용 중 전파혼신 가능성이 있음. o 애니콜 A/S 문의 전화번호:1588-7285/www.3366.co.kr PP + OPP (T=0.08) SHW-A250K (KT_수정1) 23 32 * RATED 값 변경 : 1000 mA -> 960 mA (100126) 1. 기기의 명칭(모델명):이동통신용 무선설비의 기기(SHW-A250K) 2. 인증번호: 3. 인증받은 자의 상호:삼성전자(주) FCC ID : A3LSHWA250K 정격 : 3.7 V 960 mA 4. 제조년월일: 5. 제조자/제조국가:삼성전자(주)/대한민국 ※ 일련번호: o 해당 무선설비는 운용 중 전파혼신 가능성이 있음. o 애니콜 A/S 문의 전화번호:1588-7285/www.3366.co.kr The label is placed inside the battery compartment

Reviewed by: FCC ID: A3LSHWA250K SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1004190660.A3L 04/19/10 1900 GSM Phone with Bluetooth Page 1 of 30 © 2010 PCTEST Engineering Laboratory, Inc. REV 8.0M 4/9/2010 Applicant Name: Date of Testing: Samsung Electronics, Co. Ltd. 04/19/10 18600 Broadwick St. Test Site/Location: Rancho Dominguez, CA 90220 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0Y1004190660.A3L FCC ID: A3LSHWA250K APPLICANT: SAMSUNG ELECTRONICS, CO. LTD. EUT Type: 1900 GSM Phone with Bluetooth Application Type: Certification FCC Rule Part(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [June 2001] FCC Classification: Licensed Transmitter Held to Ear (PCE) Model(s): SHW-A250K Tx Frequency: 1850.20 - 1909.80 MHz (GSM 1900) Conducted Power: 29.8 dBm GSM 1900 Max. SAR Measurement: 0.46 W/kg GSM 1900 Head SAR 0.19 W/kg GSM 1900 Body SAR Test Device Serial No.: Pre-Production [S/N: FH-064-C] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com SAR COMPLIANCE EVALUATION REPORT Reviewed by: FCC ID: A3LSHWA250K SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1004190660.A3L 04/19/10 1900 GSM Phone with Bluetooth Page 2 of 30 © 2010 PCTEST Engineering Laboratory, Inc. REV 8.0M 4/9/2010 TABLE OF CONTENTS 1 INTRODUCTION ............................................................................................................................. 3 2 TEST SITE LOCATION ................................................................................................................... 4 3 SAR MEASUREMENT SETUP ....................................................................................................... 5 4 DASY E-FIELD PROBE SYSTEM .................................................................................................. 7 5 PROBE CALIBRATION PROCESS ................................................................................................ 8 6 PHANTOM AND EQUIVALENT TISSUES...................................................................................... 9 7 DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................... 10 8 DEFINITION OF REFERENCE POINTS ...................................................................................... 11 9 TEST CONFIGURATION POSITIONS ......................................................................................... 12 10 RF EXPOSURE LIMITS ................................................................................................................ 15 11 MEASUREMENT UNCERTAINTIES ............................................................................................ 16 12 SYSTEM VERIFICATION.............................................................................................................. 17 13 FCC MULTI-TX AND ANTENNA SAR CONSIDERATIONS......................................................... 19 14 FCC 3G MEASUREMENT PROCEDURES .................................................................................. 20 15 SAR DATA SUMMARY ................................................................................................................. 21 16 EQUIPMENT LIST......................................................................................................................... 23 17 CONCLUSION............................................................................................................................... 24 18 REFERENCES .............................................................................................................................. 25 19 SAR TEST SETUP PHOTOGRAPHS ........................................................................................... 27 Reviewed by: FCC ID: A3LSHWA250K SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1004190660.A3L 04/19/10 1900 GSM Phone with Bluetooth Page 3 of 30 © 2010 PCTEST Engineering Laboratory, Inc. REV 8.0M 4/9/2010 1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz[2] and Health Canada RF Exposure Guidelines Safety Code 6 [26]. The measurement procedure described in IEEE/ANSI C95.3-2002 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave [3] is used for guidance in measuring the Specific Absorption Rat…

Text truncated - open the document above for the full version.

SAMSUNG FCC ID: A3LSHWA250K 1900 GSM Phone with Bluetooth

Reviewed by: FCC ID: A3LSHWA250K SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1004190660.A3L 04/19/10 1900 GSM Phone with Bluetooth Page 27 of 30 © 2010 PCTEST Engineering Laboratory, Inc. REV 8.0M 4/9/2010 19 SAR TEST SETUP PHOTOGRAPHS Reviewed by: FCC ID: A3LSHWA250K SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1004190660.A3L 04/19/10 1900 GSM Phone with Bluetooth Page 28 of 30 © 2010 PCTEST Engineering Laboratory, Inc. REV 8.0M 4/9/2010 Figure 19-1 SAR Test Setup Photo 1 Figure 19-2 SAR Test Setup Photo 2 Reviewed by: FCC ID: A3LSHWA250K SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1004190660.A3L 04/19/10 1900 GSM Phone with Bluetooth Page 29 of 30 © 2010 PCTEST Engineering Laboratory, Inc. REV 8.0M 4/9/2010 Figure 19-3 SAR Test Setup Photo 3 Figure 19-4 SAR Test Setup Photo 4 Reviewed by: FCC ID: A3LSHWA250K SAR COMPLIANCE REPORT Quality Manager Filename: Test Dates: EUT Type: 0Y1004190660.A3L 04/19/10 1900 GSM Phone with Bluetooth Page 30 of 30 © 2010 PCTEST Engineering Laboratory, Inc. REV 8.0M 4/9/2010 Figure 19-5 SAR Test Setup Photo 5 Figure 19-6 SAR Test Setup Photo 6
