User's Guide COMBO DRIVESM-316 FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.These limits are designed to provide reasonable protection against harmfulinterference in a residential installation.This equipment generates, uses, and can radiate radio frequency energy and,if not installed and used in accordance with the instructions, may causeharmful interference to radio communications. However, there is no guaranteethat interference will not occur in a particular installation. If this equipmentdoes cause harmful interference to radio or television reception, which can be deter-mined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: β’ Re-orient or relocate the receiving antenna.β’ Increase the separation between the equipment and receiver.β’ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. β’ Consult the dealer or an experienced radio/TV technician for help. 01.SM-308-GB 1/3/02 6:27 PM Page 1 Contents 3 Safety Precautions 2 The following diagrams illustrate the precautions to be taken when usingyour COMBO drive. You must not use the drive in any manner other than that specified in this guide. Avoid exposing your eyes or skin to direct or scattered radiation. CAUTION Do not attempt to repair the COMBO drive yourself. Contactyour dealer or local SAMSUNG representative for all repairs.If you make any adjustments or perform any operations otherthan those specified in this guide, you run the risk of exposure tohazardous radiation. WARRANTY Please refer to the Samsung limited warranty statements . Precautions 1. To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. 2. Always check each disc for cracks before using it. If there are cracks on the surfaces, especially around the border of thecenter hole, we recommend that you make a copy of the discimmediately and then stop using it. If you continue using thedisc, it will probably develop more cracks and eventually causeirreparable damage. 3. Do not use poor quality discs: From unknown sources Without any copyright Scratched or damaged in any way Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2Your COMBO Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4Upgrading the Firmware Flash Memory . . . . . . . . . . . . . . . . . . . . . . . . .5System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5Installing the COMBO Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5Connecting the Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6Installing the CD Record Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8Installing the Device Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8Setting Up the Device Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9Using the COMBO Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10Storing and Cleaning Your Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10Solving Recording Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11Recommended Disc Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13Solving Technical Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 * All product names mentioned in this document are trademarks or registered trademarks of their respective owners. β± Changes or modifications not expressly approved by the party responsible for compliancecould void the userβs authority to operate the equipment 01.SM-308-GB 1/3/02 6:27 PM Page 2 Installing the COMBO DriveUpgrading the Firmware Flash Memory 5 The product firmware can be upgraded by downloading the updated file from thefollowing Web site: http://www.samsungodd.com To install your COMBO drive in the PC, proceed as follows.1 Make sure that the PC is powered off and disconnected from any power source. 2 If necessary, attach a horizontal bracket to both sides ofthe drive. COMBO drive Use of the brackets depends on your computermodel; you can purchase these accessoriesseparately from your computer dealer. 3 Remove the cover from a free expansion slot and installthe COMBO drive, as shown in the illustration. If you have no free expansion slot, install the drive inplace of the diskette drive. Before you install the COMBO drive, we strongly recommend that youcheck that your setup meets the system requirements listed below.System Requirements Item Description Computer Intel Pentium II 300MHz/Celeron 333A ( or higher), 32 MB of RAM (or higher) with an IDE interface Free expansion unit 5.25 inch Disk space 700 MB minimum Windows version Windows 95/98/2000/ME/NT4.0 OSR2 (or higher) (For Windows NT, we recommend Service Pack2,and Version is over 4.00.1381) MS-DOS 5.0 or higher (For MS-DOS, The CD-R/CD-RW driver can only read a disc without premaster Software.) DVD Video playback PC with Windows 95/98/2000/ME/XP/NT4.0 OSR2 DVD-Video playback software and appropriate hardware (the Power DVD MPEG software is included in the COMBO drive package) Your Combo Drive 4 12 3 456 1 23 4 5 1. Earphone connection terminal2. Volume control3. Disc compartment4. Emergency eject hole (if the compartment does not open when you press the Eject button, insert a pin or unfolded paper clip in thehole and push firmly) 5. Indicator light (when it is green, a disc is being read or recorded)6. Eject button1. Digital output terminal2. Sound output terminal3. Master/slave select terminal4. Interfaβ¦
Text truncated - open the document above for the full version.
Block Diagram RF-AMP TA1329F (TOSHIBA) SPINDLE MOTOR PICK-UP ACTURATOR /STEP / SPINDLE DRIVE M63024FP LOADINGMOTOR SERVO/DSP TC94A08F (TOSHIBA) SYSTEM CONTROL H8S/2350 (HITACHI) INTERFACE RL5E849A (RICOH) HOST INTERFACE (IDE) HEADPHONE FLASH ROM 512KB 39SF040 (SST) STEP MOTOR 4M DRAM M11B416256A (EliteMT) APA3541 22.57MHz 33.86MHz 20MHz RF-AMP AK8569A (AKM) 16M DRAM 12L16161 (EliteMT)
ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. EMI TEST REPORT Test report no. : ERI-FCC-0090 Type of equipment : CD-RW / DVD Drive Model no. : SM-316 FCC ID : A3LSM316 Applicant. : SAMSUNG ELECTRONICS Co., Ltd. Test standards : FCC Part15 Subpart B (Class B) Test result : Complied This equipment has been tested for FCC Part 15 standard. The results in this report apply only to the sample tested. This test report shall not be reproduced except in full, Without the written approval of ERI Laboratory. Date of test: 2002. 1. 2 Issued date: 2002. 1. 5 Tested by : approved by: YOUNG-SIK, KIM MIN-SEOK, CHUNG This laboratory is registered by KOLAS, KOREA. This test report have been performed in accordance with Its terms of registration. ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. Contents 1. client information 2. Laboratory information 3. TEST SYSTEM CONFIGURATION 3.1 Operation Environment 3.2 Measurement Uncertainty 3.3 sample calculation 4. Description of e.u.t. 4.1 Product Description 4.2 Peripherals 4.3 used cables 4.4 e.u.t. test configuration 4.5 operating conditions 5. Test Results 5.1 Conducted Emission 5.1.1 Measurement procedure 5.1.2 Used equipments 5.1.3 measurement uncertainty 5.1.4 Test data 5.1.5 Result 5.2 Radiated Emission 5.2.1 Measurement procedure 5.2.2 Used equipments 5.2.3 measurement uncertainty 5.2.4 Test data 5.2.5 Result ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. 6. Photographs Radiated Emission Test Conducted Emission test 1. Client information Applicant : SAMSUNG ELECTRONICS Co., Ltd. Address : 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 Telephone Number : 82-31-200-4252 Facsimile Number : 82-31-200-7890 Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Address : 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 Telephone Number : 82-31-200-4252 Facsimile Number : 82-31-200-7890 ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. 2. Laboratory information Address The open area test site and EMC facilities are used for these testing. This facility was accredited by KOLAS, EK of Korea, MIC, FCC. EMC RESEARCH INSTITUTE . 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA Telephone Number : 82- 31- 336- 1186 Facsimile Number : 82- 31- 336 -1184 KOLAS No. : 111 EK : J MIC : KR0030 FCC Filing No. : 96753 ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. MAP IC(), TG , 17 (42 ) FA TG TG 3km (ERI) ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. 3. TEST SYSTEM CONFIGURATION 3.1 Operation Environment Temperature Humidity pressure 3m OATS (Radiated Emission) : 2C 25 % 1003hPa Shielded room (Conducted Emission) : 23C 45 % 1003hPa 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, specially in field of EMC. The factors contributing to uncertainties are test receiver, Cable loss, antenna factor calibration, Antenna directivity, antenna factor variation with height, antenna phase center variation, antenna Frequency interpolation, measurement distance variation, site imperfection, mismatching and system repeatability. Based on NIS 80,81, The measurement uncertainty level with a 95% confidence level were applied. 3.3 sample calculation radiated emission The field strength is calculated adding the antenna Factor, cable loss and, Antenna pad adding, subtracting the amplifier gain from the measured reading. The sample calculation is as follows : ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. FS = MR + AF + CL + AT -AG MR = Meter Reading AF = Antenna Factor CL = Cable Loss AP = Antenna Pad AG=Amplifier Gain If MR is 30dB, AF 12dB, CL 5dB, AP 10dB, AG 35dB The result (MR) is 30 + 12 + 5 + 10 β35 = 22dBuV/m Conducted emission The field strength is calculated by adding the LISN factor, cable loss from the measured reading. The sample calculation is as follows : FS = MR + LF + CL MR = Meter Reading LF = LISN Factor CL = Cable Loss If MR is 30dB, LISN insertion loss Factor 1dB, CL 1dB The result (MR) is 30 + 1 + 1 = 32dBuV ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. 4. Description of e.u.t. 4.1 Product Description Manufactured By SAMSUNG ELECTRONICS Co., Ltd. Address 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 Test Requested By SAMSUNG ELECTRONICS Co., Ltd. Model SM-316 Serial Number N/A Power Supply DC 5V/12V Electric Current 2.7A/1.5A Clock EN/DEC : 33.86MHz, DSP : 22.5792MHz, RF IC : 28.2MHz General Description This EUT(Equipment Under Test) is CD-RW / DVD Drive Speed CD-ROM : 40X, DVD-ROM : 12X CD-R :β¦
