Quick Reference Guide (Terms and Conditions) SM-A145FB/DS Read this document before operating the mobile device, accessories, or software (defined collectively and individually as the “Product”) and keep it for future reference. This document contains important Terms and Conditions. Electronic acceptance, opening the packaging, use, or retention of the Product constitutes acceptance of these Terms and Conditions. Visit www.samsung.com/us to view device information, the user manual, and more. You may incur additional charges for accessing the Internet. DRAFT Device Layout To turn on the device, press and hold the Side key for a few seconds. The charger should remain close to the electric socket and easily acc essible while charging. Installing a nano-SIM card Nano-SI M cards are sold separately. Contact us Questions? Visit us.community.samsung.com Get Support Call 1.800.SAMSUNG Service locations Find a service location near you at Samsung.com/us/support/service/locations Switching made simple Whether you are coming from an iOS or Android platform, you can easily transfer your data with Smart Switch. Back up your old phone Back up your old phone using your favorite back-up app. Samsung Smart Switch 1. From your new Galaxy device, tap Settings > Accounts and backup > Smart Switch. 2. Tap Receive data. 3. Select your old device type. 4. Tap Cable (Android) or Wireless (Android and iOS) and follow the prompts to connect your phones. Customize Tap Settings to personalize your phone. Flight mode This disables all wireless functions on your device. You can use only non- network services On the setting screen, tap Flight mode. NOTE: The use of mobile devices on an aircraft or a ship may be subject to federal and local guidelines and restrictions. Check with appropriate author and always follow crew instructions regarding when and how you may use your device. Important legal information Arbitration Agreement - This Product is subject to a binding arbitration agreement between you and SAMSUNG ELECTRONICS AMERICA, INC. (“Samsung”). You can opt out of the agreement within 30 calendar days of the first consumer purchase by emailing [email protected] or calling 1-800-SAMSUNG (726-7864) and providing the applicable information. The full Arbitration Agreement, Standard One-year Limited Warranty, End User License Agreement (EULA), and Health & Safety Information for your device are available online: P hone •English: www.samsung.com/us/Legal/Phone-HSGuide •Spanish: www.samsung.com/us/Legal/Phone-HSGuide-SP This information can also be found on the device in the “About device” or “About phone” or “About tablet” section, for example: •Settings > About phone or About device or About tablet > Legal information > Samsung legal •Or,Search “Legal” I f your device required Federal Communications Commission (FCC) approval, you can view the FCC certification by opening Settings > About phone or About device or About tablet> Status. Health and Safety WARNING! To avoid electri c shock and damage to your device, do not charge device whil e i t is wet or in an area where it co uld get wet. Do not handle device, c harger or cords with wet hands whil e charging. Maint aining dust and water resistance The device is not impervious to dust and water damage in any situation. It is important that all c ompartments are closed tightly. Follow these tip s carefully to prevent damage to the device and maintain dust and water resistance performance: •Water resistant based on IP68 rating, which tests submers ion in fresh water deeper than 1.5 meters or keep it submerged for more than 30 minut es. If device is expo sed to fresh water, dry it thoroughly with a clean, soft cloth; if exposed to liquid other than fresh water, rinse with fresh water and dry as directed. •Any device which uses acces sible compar tments or por t s that can be opened should have th ese se aled or closed tightly to prevent li quid from entering th e system. •If th e device has been immersed i n water or th e microphone or speaker is wet, sound may not be heard clearly during a call. After wipi ng th e device with a dry cloth, dry it thoroughly before using it. •Do not expose t he device to water at high pressure. •If th e device is dropped or receives an impact, th e water and dust resistant features of th e device may be damaged. Note: Liquid other than fresh water may enter th e device fa ster. Failure to rinse th e device in fresh water and dry it as instructed may cause th e device to suffer from operability or cosmetic issues. Samsung Knox Samsung Knox is Samsung’s security platform. Additional licensing fees may be required for enterprise use. For more information about Knox, pl ease refer to: www.samsung.com/us/knox Specific Absorption Rate (SAR) certification information For information about SAR, visit : •https://www.fcc.gov/general/radio-frequency-safety-0 •w ww.fcc.gov/encyclopedia/ s pecific-absorption-rate-sar-cellular-telephones •www.samsung.com/sar Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5cm separation between the device and the user's body. S amsung Wireless Power Sharing feature allows device -to -device charging without the need for a charger. If your device supports the wireless power sharing function, this equipment should be operated with a minimum distance of 20 cm between the device and your body. Note: Foldable devices can be stored in an environment with ambient temperatures of -10°C / 14.0°F to 50°C / 122°F safely; prolonged exposure to temperatures outside these recommended temperatures can pose a high risk of damage to the device. Samsung mobile products and recycling WARNING! Never dispose of batterie s in a fire because th ey may explode. Do not disassemble, crush, puncture, heat, burn or reuse. F or battery and cell phone recycling, go to call2re cy cle. org or call 1- 800-822-8837. F or more recycling info…

Text truncated - open the document above for the full version.

CFR 47 §2.911 (d)(5) Attestation Date: 02-14-2023 FCC ID: A3LSMA145F To: Federal Communications Commission 7435 O akland Mills Road Columbia, MD 21046 USA 1.S amsung Electronics Co., Ltd. (“the applicant”) certifies that the equipment for which aut horization is sought is not “covered” equipment prohibited from receivin g an equi pment authorization pursuant to section 2.903 of the FCC rules. 2. Samsung Electronics Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. S incerely yours, Name: Ms. Jenni Chun Job Title: General Manager Regulatory & Environmental Affairs Company Name: Samsung Electronics Co., Ltd.

47 CFR §2.911 (d)(7) Agent Designation Attestation Date: 02-07-2023 FCC ID: A3LSMA145F To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Samsung Electronics Co., Ltd. (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: Contact Person : Ms. Jenni Chun Company Name : Samsung Electronics Co., Ltd. Company Address : 19 Chapin Rd., Building D, Pine Brook, NJ 07058 Email : [email protected] FRN : 0027908797 Sincerely yours, Name: Ms. Jenni Chun Job Title: Head of Regulatory & Environmental Affairs Company Name: Samsung Electronics Co., Ltd.

February 14, 2023 Federal Comm unications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMA145F To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0. 457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary informati on in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Date: February 14, 2023 UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea To whom it may concern: I, the undersigned, hereby authorize UL Korea, Ltd. Suwon Laboratory, to ac t on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Korea, Ltd. Suwon Laboratory on our behalf shall have the same effect as acts of our own. In authorizing UL Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. l) the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

External Photo Applicant : SAMSUNG ELECTRONICS CO., LTD. 129 SAMSUNG-RO, YEONGTONG-GU, SUWON-SI, GYEONGGI-DO, 16677, KOREA Model : SM-A145FB/DS FCC ID : A3LSMA145F Date Of Issue: 2023-02-06 Prepared by: UL Korea, Ltd. 26th floor, 152, Teheran-ro, Gangnam-gu Seoul, 06236, Korea Suwon Test Site: UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 Testing Laboratory TL-637 FCC ID: A3LSMA145F DATE: 2023-02-06 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. External Photo FCC ID: A3LSMA145F DATE: 2023-02-06 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. FCC ID: A3LSMA145F DATE: 2023-02-06 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. The End

Description of E-label on the A3LSMA145F Feb. 20, 2023 FCC ID : A3LSMA145F This model is applied E-label, please find description of E-label below. Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission(FCC). If your device is approved by the FCC, you can view the FCC ID or the device. To view the FCC ID, tap Settings > About phone > Status information <Device Display Screen> FCC Certification FCC ID : A3LSMA145F

Internal Photo Applicant : SAMSUNG ELECTRONICS CO., LTD. 129 SAMSUNG-RO, YEONGTONG-GU, SUWON-SI, GYEONGGI-DO, 16677, KOREA Model : SM-A145FB/DS FCC ID : A3LSMA145F Date Of Issue: 2023-02-06 Prepared by: UL Korea, Ltd. 26th floor, 152, Teheran-ro, Gangnam-gu Seoul, 06236, Korea Suwon Test Site: UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 Testing Laboratory TL-637 DATE: 2023-02-06 FCC ID: A3LSMA145F UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. I nternal Photo DATE: 2023-02-06 FCC ID: A3LSMA145F UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. DATE: 2023-02-06 FCC ID: A3LSMA145F UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. DATE: 2023-02-06 FCC ID: A3LSMA145F UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. DATE: 2023-02-06 FCC ID: A3LSMA145F UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. DATE: 2023-02-06 FCC ID: A3LSMA145F UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd.

Measurement Report for Device, Touch, GSM 850, UID 10028 DAC, Channel 190 (836.6MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Right Head, HSL Touch, 0.00 GSM 850 GSM, 10028-DAC 836.6, 190 10.3 0.933 41.9 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2022-Dec-22 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-22 2022-12-22 psSAR1g [W/kg] 0.350 0.381 psSAR10g [W/kg] 0.243 0.304 Power Drift [dB] -0.03 Measurement Report for Device, Rear, GSM 850, UID 10028 DAC, Channel 190 (836.6MHz) Device under Test Properties Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL Rear, 15.00 GSM 850 GSM, 10028-DAC 836.6, 190 10.3 0.933 41.9 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2022-Dec-22 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-22 2022-12-22 psSAR1g [W/kg] 0.388 0.409 psSAR10g [W/kg] 0.272 0.250 Power Drift [dB] -0.02 Measurement Report for Device, Rear, GSM 850, UID 10028 DAC, Channel 190 (836.6MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL Rear, 10.00 GSM 850 GSM, 10028-DAC 836.6, 190 10.3 0.933 41.9 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2022-Dec-22 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-22 2022-12-22 psSAR1g [W/kg] 0.760 0.796 psSAR10g [W/kg] 0.492 0.459 Power Drift [dB] -0.02 Measurement Report for Device, Touch, PCS 1900, UID 10024 DAC, Channel 661 (1880.0MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Left Head, HSL Touch, 0.00 PCS 1900 GSM, 10024-DAC 1880.0, 661 8.57 1.43 41.0 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2022-Dec-21 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-22 2022-12-22 psSAR1g [W/kg] 0.198 0.223 psSAR10g [W/kg] 0.115 0.143 Power Drift [dB] -0.02 Measurement Report for Device, Rear, PCS 1900, UID 10024 DAC, Channel 661 (1880.0MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL Rear, 15.00 PCS 1900 GSM, 10024-DAC 1880.0, 661 8.57 1.43 41.0 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2022-Dec-21 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-22 2022-12-22 psSAR1g [W/kg] 0.306 0.318 psSAR10g [W/kg] 0.184 0.186 Power Drift [dB] 0.01 Measurement Report for Device, Rear, PCS 1900, UID 10024 DAC, Channel 810 (1909.8MHz) Device under Test Properties Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL Rear, 10.00 PCS 1900 GSM, 10024-DAC 1909.8, 810 8.57 1.43 40.9 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2022-Dec-21 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-22 2022-12-22 psSAR1g [W/kg] 0.367 0.380 psSAR10g [W/kg] 0.219 0.219 Power Drift [dB] -0.02 Measurement Report for Device, Touch, Band 5, UTRA/FDD, UID 10011 CAB, Channel 4183 (836.6MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Right Head, HSL Touch, 0.00 Band 5, UTRA/FDD WCDMA, 10011-CAB 836.6, 4183 10.3 0.933 41.9 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2022-Dec-21 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 120.0 x 210.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 15.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-21 2022-12-21 psSAR1g [W/kg] 0.281 0.294 psSAR10g [W/kg] 0.193 0.226 Power Drift [dB] -0.00 Measurement Report …

Text truncated - open the document above for the full version.

Plot No. 1 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2023-02-10 20230210_SystemPerformancecheck D2450V2 SN960 Frequency: 2450 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used (interpolated): f = 2450 MHz; σ = 1.778 S/m; ε r = 38.883; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Electronics: DAE4 Sn1447; Calibrated: 2022-03-25 - Probe: EX3DV4 - SN7314; ConvF(7.54, 7.54, 7.54) @ 2450 MHz; Calibrated: 2022-05-31 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: Left_Twin-SAM V8.0 (30deg probe tilt)221014; Type: QD 000 P41 Ax; Serial: xxxx Head/2450MHz/Pin=100mW/Area Scan (6x8x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 7.88 W/kg Head/2450MHz/Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 64.60 V/m; Power Drift = -0.00 dB Peak SAR (extrapolated) = 11.4 W/kg SAR(1 g) = 5.43 W/kg; SAR(10 g) = 2.54 W/kg Maximum value of SAR (measured) = 9.05 W/kg 0 dB = 7.88 W/kg = 8.97 dBW/kg Plot No. 2 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2023-01-26 20230126_SystemPerformanceCheck D5GHzV2 SN 1184 Frequency: 5250 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used (interpolated): f = 5250 MHz; σ = 4.83 S/m; ε r = 35.151; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Electronics: DAE4 Sn1468; Calibrated: 2022-08-18 - Probe: EX3DV4 - SN7645; ConvF(4.92, 4.92, 4.92) @ 5250 MHz; Calibrated: 2022-11-15 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: Twin-SAM V5.0 (20deg probe tilt); Type: QD 000 P40 CD; Serial: 1751 Head/5.25 GHz, Pin=100mW/Area Scan (7x7x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 17.5 W/kg Head/5.25 GHz, Pin=100mW/Zoom Scan (9x9x8)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 58.51 V/m; Power Drift = 0.13 dB Peak SAR (extrapolated) = 34.5 W/kg SAR(1 g) = 8.45 W/kg; SAR(10 g) = 2.4 W/kg Maximum value of SAR (measured) = 20.8 W/kg 0 dB = 17.5 W/kg = 12.43 dBW/kg Plot No. 3 Measurement Report for Device, , , UID 0 -, Channel 0 (835.0MHz) Device under Test Properties Model, Manufacturer Dimensions [mm] IMEI DUT Type Device, 50.0 x 10.0 x 8.0 Phone Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL , , 0-- 835.0, 0 10.3 0.932 41.9 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000 Charge:xxxx, 2022-Dec-20 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 90.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-20 2022-12-20 psSAR1g [W/kg] 0.987 0.993 psSAR10g [W/kg] 0.649 0.652 Power Drift [dB] -0.03 Plot No. 4 Measurement Report for Device, , , UID 0 -, Channel 0 (1900.0MHz) Device under Test Properties Model, Manufacturer Dimensions [mm] IMEI DUT Type Device, 50.0 x 10.0 x 8.0 Phone Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL , , 0-- 1900.0, 0 8.57 1.43 40.9 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000 Charge:xxxx, 2022-Dec-20 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 90.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 15.0 6.0 x 6.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-20 2022-12-20 psSAR1g [W/kg] 4.06 3.93 psSAR10g [W/kg] 2.10 2.03 Power Drift [dB] -0.04 Plot No. 5 Measurement Report for Device, , , UID 0 -, Channel 0 (2600.0MHz) Device under Test Properties Model, Manufacturer Dimensions [mm] IMEI DUT Type Device, 50.0 x 10.0 x 8.0 Phone Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL , , 0-- 2600.0, 0 8.16 1.89 40.6 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000 Charge:xxxx, 2022-Dec-26 EX3DV4 - SN7646, 2022-03-29 DAE4 Sn1494, 2022-07-18 Scan Setup Area Scan Zoom Scan Grid Extents [mm] 40.0 x 80.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 10.0 5.0 x 5.0 x 1.5 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan Date 2022-12-26 2022-12-26 psSAR1g [W/kg] 5.99 5.87 psSAR10g [W/kg] 2.69 2.65 Power Drift [dB] -0.00

Head Tissue Simulating Liquids Head Tissue Parameters according to IEEE Std 1528-2013 / IEC 62209 / FCC KDB 865664 D01 Narrow- Band Solutions (±5% tolerance) Product HSL300V2 HSL450V2 HSL750V2 HSL900V2 HSL1450V2 HSL1750V2 HSL1800V2 HSL1900V2 HSL1950V2 HSL2450V2 Test Frequency (MHz) 300 450 750 835, 900 1450, 1500, 1640 1750 1800, 1900 1900 1950, 2000 2450, 2600 Main Ingredients Water, Sugar Water, Sugar Water, Sugar Water, Sugar Water, DGBE Water, DGBE Water, DGBE Water, DGBE Water, DGBE Water, DGBE Broad- Band Solutions (±5% tolerance) Product HBBL30-250V3 HBBL1350-1850V3 HBBL1550-1950V3 HBBL1900-3800V3 HBBL3500-5800V5 Test Frequency (MHz) 30-250 1400-1800 1750-1900 1950-3000 3500-5800 Main Ingredients Water, Tween Water, Tween Water, Tween Water, Tween Water, Oil

Justification for Extended SAR Dipole Calibrations Instead of the typical annual calibration recommended by measurement standards, longer calibration intervals of up to three years may be considered when it is demonstrated that the SAR target, impedance and return loss of a dipole have remain stable according to the following requirements KDB 865664 D01v01r04 requirements a ) return loss : < - 20 dB, within 20% of previous measurement b ) impedance : within 5 Ω from previous measurement Dipole Antenna Head/Body Date of Measurement Return Loss (dB) Δ % Impedance (Ω) Δ Ω D2600V2-SN : 1097 Head 2021.09.29 -24.5 -2.4 50.1 0.2 2022.08.29 -25.1 50.5 c ) extrapolated peak SAR : within 10% of that reported in the calibration data Dipole Antenna Head/Body Date of Measurement extrapolated peak SAR (W/kg) Δ % D2600V2-SN : 1097 Head 2021.09.29 29.3 6 2022.09.19 31.3
