User manual A3LSMA55F Only for Approval using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to “int roducing your mobile phone, Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note —notes, usage tips, or additional information Refer to—pages with related information; for example:p. 12 (represents “see page 12”) « Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages « Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [](represents the Power/ Menu exit key) < >Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners: Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide Java™ is a trademark of Sun Microsystems, Inc. Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM or USIM card Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone. Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones. Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated. Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or permanent battery damage. Never use…

Text truncated - open the document above for the full version.

SM-A525F/DS SM-A525F Package content • Device • USB cable • Ejection pin • USB power adaptor • Quick start guide The items supplied with the device may vary by region. Accessing more information To view the full user manual on your device, launch the Settings app and tap User manual. Visit www.samsung.com to view device information, the user manual, and more. • The user manual may not be available depending on the web browser or service provider. • You may incur additional charges for accessing the Internet. To turn on the device, press and hold the Power key for a few seconds. Installing a nano-SIM card and a microSD card Insert the ejection pin into the hole next to the tray to loosen the tray. Gently press the card into the tray to secure it. • Use only a nano-SIM card. • Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged. • If the card is not fixed firmly into the tray, the card may leave or fall out of the tray. Nano-SIM cards and microSD cards are sold separately. Charging the battery Before using the device for the first time, you must charge the battery. Use only USB Type-C cable supplied with the device. The device may be damaged if you use Micro USB cable. The charger should remain close to the electric socket and easily accessible while charging. Using the Home button When you turn on the screen, the Home button will appear at the bottom of the screen as a soft button. Correct disposal This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. This product is RoHS compliant. This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste. Safety information Read all safety information before using the device to ensure safe and proper use. Warning Follow the warning information provided below to prevent incidents such as fire or explosion • Do not expose the device to physical impact or damage. • Use manufacturer-approved batteries, chargers, accessories, and supplies. • Prevent the multipurpose jack and battery terminals from contacting conductive elements, such as metal or liquids. • If any part of the device, such as the glass or acrylic body, is broken, smokes, or emits a burning odor, stop using the device immediately. Use the device again only after it has been repaired at a Samsung Service Centre. • Do not turn on or use the device when the battery compartment is exposed. Follow the warnings below to prevent injury to people or damage to the device • Do not allow children or animals to chew or suck the device. • If the device has a camera flash or light, do not use it close to the eyes of people or animals. • The device can be used in locations with an ambient temperature of 0 °C to 35 °C. You can store the device at an ambient temperature of -20 °C to 50 °C. Using or storing the device outside of the recommended temperature ranges may damage the device or reduce the battery’s lifespan. • Do not use your device in a hot environment or near fire. • Comply with all safety warnings and regulations regarding mobile device usage while operating a vehicle. To prevent possible hearing damage when using a headset, do not listen to sound at high volume for long periods. You can view more safety information, including device and battery disposal instructions, in the safety information menu of the Settings app. • It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods. Doing so may result in afterimages (screen burn-in) or ghosting. Specific Absorption Rate (SAR) certification information THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES Your mobile is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. The guidelines were developed by an independent scientific organisation (ICNIRP) and include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg. The highest SAR values under the ICNIRP guidelines for this device model are: SAR values for European countries: The SAR values below are only for devices developed for use in European countries. Maximum SAR for this model and conditions under which it was recorded Head SAR X.XXX W/kg Body-worn SAR X.XXX W/kg Body-worn SAR testing has been carried out at a separation distance of 1.5 cm. To meet RF exposure guidelines during body-worn operation, the device should be positioned at least this distance away from the body. For SAR values for all other countries: For SAR values specific to your model, visit www.samsung.com/sar and search for your region and device with the model number. The use of WLAN band is restricted to indoor use only. This restriction will be applied in all countries below. Only for Approval •To transfer data of the previous device to a new device: Visit ww.samsung.com/smartswitch for more information. • If your device is frozen and unresponsive, press nd hold the Power key and the Volume Down key simultaneously for more than 7 seconds to restart it. Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. Copyright © 2019 Samsung Electronics Specific Absorption Rate (SAR) Certification Information Your device is a radio transmitter and receiver. It is designed and manufactured not to exceed the exposure limits for Radio Frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These FCC RF exposure limits are derived from the recommendations of two expert organizations: the National Council on Radiation Protect…

Text truncated - open the document above for the full version.

Date: November 19, 2020 UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea To whom it may concern: I, the undersigned, hereby authorize UL Korea, Ltd. Suwon Laboratory, to ac t on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Korea, Ltd. Suwon Laboratory on our behalf shall have the same effect as acts of our own. In authorizing UL Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. l) the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 16677, Korea Federal Communi cations Commission 7435 Oakland Mills Road Columbia, MD 21046 E-label Attestation Letter - FCC ID : A3LSMA525F - Model : SM-A525F/DS, SM-A525F To Whom It Ma y Concern We hereby provi de the following attestations according to CFR 2.935 and FCC KDB 784748 D02: At the time of purchase, the FCC ID is readily and physically visible to the purchaser on the exterior package per CFR 2.935(f). The FCC ID will be readily legible without the aid of magnification according to CFR 2.935(d). The literature in the package describes how to access the electronic display to find FCC ID per CFR 2.935(b) and FCC KDB 784748. Per CFR 2.935(c), the user will be able to access this information within a maximum of 3 steps. The user will be able to access this information without a SIM card, special accessories or supplemental plug-ins. Per CFR 2.935(e), We, Samsung Electronics Co., Ltd., have programmed the e-label and it is not able to be modified by any third party. Per CFR 2.93 5(f), the FCC ID will be able to survive normal shipping and handling so it is visible for inspection at the time of import. Should you h ave any questions or comments concerning the above, please contact the undersigned. Sincerely, Ms. Jenni Chun G eneral Manager Regulatory & Environmental Affairs Samsung Electronics Co., Ltd. TEL : +1-973-808-6375 E- mail : [email protected]

January 6, 2021 Federal Comm unications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMA525F To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0. 457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeontong-gu, Suwon-si, Gyeonggi-do, 16677, Korea MPR Attestation letter for UMTS -FCC ID : A3LSMA525F -Model : SM-A525F/DS, SM-A525F To Whom it May Concern We attest the following regarding FCC ID A3LSMA525F. 1.MPR is permanently implemented for HSDPA, HSUPA, and DC-HSDPA mode. 2.It is expected by the manufacturer that MPR for some HSPA subtests may be up to 2dB more than specified by 3GPP, but also as low as 0dB according to the chipset implementation in this model. 3.We confirm the specific MPR targets and tolerances shown in the SAR Report. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeontong-gu, Suwon-si, Gyeonggi-do, 16677, Korea MPR Attestation letter for LTE -FCC ID : A3LSMA525F -Model : SM-A525F/DS, SM-A525F To Whom it May Concern We attest the following regarding FCC ID A3LSMA525F. 1.MPR is permanently implemented for all channel BWs, modulations, frequency bands and RB sizes. 2.A-MPR was disabled for all SAR test samples for SAR testing purposes only. 3.We confirm the specific MPR targets and tolerances shown in the SAR Report. All deviations in the power measurements from the specific MPR targets shown in the SAR Report are expected and within factory tolerances. 4.LTE Release 12 implementation is limited. The uplink does not support enhanced SC-FDMA. Features such as CoMP, HetNet, Relay, SON, cross carrier scheduling, eICIC, enhanced downlink MIMO, MBMS, M2M/D2 are also not supported. SVLTE is not supported as described in the operational description. 5.This device complies with FCC Part 27.75(a)(1) requirements: Mobile and portable stations that operate on any portion of frequencies in the paired 1755-1780 MHz and 2155-2180 MHz band must be capable of operating on all frequencies in the paired 1710-1780 MHz and 2110-2180 MHz band, using the same air interfaces that the equipment utilizes on any frequencies in the paired 1710-1780 MHz and 2110-2180 MHz band. 6.This device complies with FCC Part 27.77 requirements: Mobile and portable stations in the 1695-1710 MHz and 1755-1780 MHz bands may operate only when under the control of a base station. Base stations that enable mobile or portable equipment to operate in the 1695-1710 MHz and 1755-1780 MHz band are subject to prior coordination requirements. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Description of E-Label and Location FCC ID : A3LSMA525F Model : SM-A525F/DS, SM-A525F This model is applied E-label, please find description of E-label below. 1. FCC ID (E-label): Settings > About Phone > Status <Device Display Screen> 2. Insturction of E-label on the User manual (online manual) FCC certification FCC ID: A3LSMA525F

FCC ID : A3LSMA525F

Plot No. 1 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 1/27/2021 GSM 850 Frequency: 824.2 MHz; Duty Cycle: 1:1.99986; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used: f = 825 MHz; σ = 0.923 S/m; ε r = 41.022; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Electronics: DAE4 Sn1343; Calibrated: 8/25/2020 - Probe: EX3DV4 - SN3871; ConvF(9.83, 9.83, 9.83) @ 824.2 MHz; Calibrated: 8/28/2020 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: SAM (20deg probe tilt) with CRP v5.0; Type: QD000P40CD; Serial: 1751 RHS/Touch GPRS ch.128 4slot/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.303 W/kg RHS/Touch GPRS ch.128 4slot/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 17.70 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 0.333 W/kg SAR(1 g) = 0.256 W/kg; SAR(10 g) = 0.195 W/kg Maximum value of SAR (measured) = 0.304 W/kg 0 dB = 0.304 W/kg = -5.17 dBW/kg Plot No. 2 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-21 GSM 850 Frequency: 824.2 MHz; Duty Cycle: 1:1.99986; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used: f = 825 MHz; σ = 0.928 S/m; ε r = 41.596; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Electronics: DAE4 Sn1343; Calibrated: 2020-08-25 - Probe: EX3DV4 - SN3871; ConvF(9.83, 9.83, 9.83) @ 824.2 MHz; Calibrated: 2020-08-28 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: Twin-SAM V5.0 (20deg probe tilt); Type: QD 000 P40 CD; Serial: 1751 Rear/GPRS 4 slots ch.128/Area Scan (8x14x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.387 W/kg Rear/GPRS 4 slots ch.128/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 19.80 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 0.432 W/kg SAR(1 g) = 0.326 W/kg; SAR(10 g) = 0.249 W/kg Maximum value of SAR (measured) = 0.394 W/kg 0 dB = 0.394 W/kg = -4.05 dBW/kg Plot No. 3 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-21 GSM 850 Frequency: 824.2 MHz; Duty Cycle: 1:1.99986; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used: f = 825 MHz; σ = 0.928 S/m; ε r = 41.596; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Electronics: DAE4 Sn1343; Calibrated: 2020-08-25 - Probe: EX3DV4 - SN3871; ConvF(9.83, 9.83, 9.83) @ 824.2 MHz; Calibrated: 2020-08-28 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: Twin-SAM V5.0 (20deg probe tilt); Type: QD 000 P40 CD; Serial: 1751 Rear/GPRS 4 slots ch.128/Area Scan (8x14x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.428 W/kg Rear/GPRS 4 slots ch.128/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 20.74 V/m; Power Drift = 0.00 dB Peak SAR (extrapolated) = 0.465 W/kg SAR(1 g) = 0.358 W/kg; SAR(10 g) = 0.275 W/kg Maximum value of SAR (measured) = 0.426 W/kg 0 dB = 0.426 W/kg = -3.71 dBW/kg Plot No. 4 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-21 GSM 1900 Frequency: 1909.8 MHz; Duty Cycle: 1:1.99986; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used: f = 1910 MHz; σ = 1.406 S/m; ε r = 40.45; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Electronics: DAE4 Sn1494; Calibrated: 2020-07-23 - Probe: EX3DV4 - SN7313; ConvF(8.36, 8.36, 8.36) @ 1909.8 MHz; Calibrated: 2020-02-25 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: Twin-SAM V5.0 (Right); Type: QD 000 P40 CD; Serial: 1855 LHS/Touch GPRS 4 slots ch.810/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.151 W/kg LHS/Touch GPRS 4 slots ch.810/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.11 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 0.180 W/kg SAR(1 g) = 0.117 W/kg; SAR(10 g) = 0.075 W/kg Maximum value of SAR (measured) = 0.156 W/kg 0 dB = 0.156 W/kg = -8.07 dBW/kg Plot No. 5 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-18 GSM 1900 Frequency: 1909.8 MHz; Duty Cycle: 1:1.99986; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used: f = 1910 MHz; σ = 1.412 S/m; ε r = 39.717; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Electronics: DAE4 Sn1494; Calibrated: 2020-07-23 - Probe: EX3DV4 - SN7313; ConvF(8.36, 8.36, 8.36) @ 1909.8 MHz; Calibrated: 2020-02-25 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: Twin-SAM V5.0 (Right); Type: QD 000 P40 CD; Serial: 1855 Rear/GPRS 4 slots ch.810/Area Scan (8x14x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.206 W/kg Rear/GPRS 4 slots ch.810/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 11.88 V/m; Power Drift = 0.00 dB Peak SAR (extrapolated) = 0.251 W/kg SAR(1 g) = 0.151 W/kg; SAR(10 g) = 0.087 W/kg Maximum value of SAR (measured) = 0.217 W/kg 0 dB = 0.217 W/kg = -6.64 dBW/kg Plot No. 6 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-18 GSM 1900 Frequency: 1909.8 MHz; Duty Cycle: 1:1.99986; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used: f = 1910 MHz; σ = 1.412 S/m; ε r = 39.717; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Electronics: DAE4 Sn1494; Calibrated: 2020-07-23 - Probe: EX3DV4 - SN7313; ConvF(8…

Text truncated - open the document above for the full version.

Plot No. 1 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-16 20201216_SystemPerformanceCheck-D5GHzV2 SN 1209 Frequency: 5250 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used (interpolated): f = 5250 MHz; σ = 4.718 S/m; ε r = 35.542; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Averaged Fast SAR: Polynomial fit - Electronics: DAE4 Sn1468; Calibrated: 2020-08-25 - Probe: EX3DV4 - SN7376; ConvF(5.15, 5.15, 5.15) @ 5250 MHz; Calibrated: 2020-07-31 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: SAM (20deg probe tilt) with CRP v5.0_Back; Type: QD000P40CD; Serial: TP:1882 Head/5.25 GHz, Pin=100mW/Area Scan (7x7x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 19.3 W/kg Head/5.25 GHz, Pin=100mW/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 69.48 V/m; Power Drift = -0.04 dB Peak SAR (extrapolated) = 30.5 W/kg SAR(1 g) = 7.29 W/kg; SAR(10 g) = 2.09 W/kg Maximum value of SAR (measured) = 17.4 W/kg 0 dB = 17.4 W/kg = 12.41 dBW/kg Plot No. 2 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-16 20201216_SystemPerformanceCheck-D5GHzV2 SN 1209 Frequency: 5250 MHz; Duty Cycle: 1:1 Head/5.25 GHz, Pin=100mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 13.0 W/kg Plot No. 3 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-27 20201227_SystemPerformanceCheck-D1900V2 SN 5d199 Frequency: 1900 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 23.0C; Liquid Temperature: 22.0C Medium parameters used: f = 1900 MHz; σ = 1.395 S/m; ε r = 40.032; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.012W/kg - Averaged Fast SAR: Polynomial fit - Electronics: DAE4 Sn1494; Calibrated: 2020-07-23 - Probe: EX3DV4 - SN7313; ConvF(8.36, 8.36, 8.36) @ 1900 MHz; Calibrated: 2020-02-25 - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: Twin-SAM V5.0 (Right); Type: QD 000 P40 CD; Serial: 1855 Head/Pin=100 mW/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 5.01 W/kg Head/Pin=100 mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 60.66 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 6.89 W/kg SAR(1 g) = 3.84 W/kg; SAR(10 g) = 2.03 W/kg Maximum value of SAR (measured) = 5.10 W/kg 0 dB = 5.10 W/kg = 7.08 dBW/kg Plot No. 4 Test Laboratory: UL Korea, Ltd. Suwon Laboratory Date: 2020-12-27 20201227_SystemPerformanceCheck-D1900V2 SN 5d199 Frequency: 1900 MHz; Duty Cycle: 1:1 Head/Pin=100 mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 4.98 W/kg Plot No. 5 Test Laboratory: UL Korea, L…
