A3LSMC105SGSM/WCDMA/LTE Phone + Bluetooth & WLAN (2.4GHz & 5GHz) and NFC

* Some of the contents of this manual may differ from your phone, depending on the software installed or your service provider. World Wide Web http://www.anycall.com S User's Guide  Be aware of special regulations Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger. Water resistance Your phone is not water-resistant. Keep it dry. Sensible use Use only in the normal position (held to your ear). Avoid unnecessary contact with the antenna when the phone is switched on. Emergency calls Key in the emergency number for your present location, then press [ ]. Keep your phone away from small children Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteries Use only Samsung-approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorised accessories could damage you or your phone and may be dangerous. Qualified service Only qualified service personnel may repair your phone. For more detailed safety information, see “Health and safety information” on page 20. Drive safely at all times Do not use a hand-held phone while driving. Park your vehicle first. Switch off the phone when refuelling Do not use the phone at a refuelling point (service station) or near fuels or chemicals. Switch off in an aircraft Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous. Switch off the phone near all medical equipment Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force. Interference All wireless phones may be subject to interference, which could affect their performance. Failure to comply with the following precautions may be dangerous or illegal. Copyright information Bluetooth? is a registered trademark of the Bluetooth SIG, Inc. worldwide. JavaTM is a trademark or registered trademark of Sun Microsystems, Inc. Picsel and Picsel ViewerTM are trademarks of Picsel Technologies, Inc. Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audiosource and use only the minimum volume setting necessary to hear your conversation or music. Important safety precautions • The phone could explode if the battery is replaced with an incorrect type. • Dispose of used batteries according to the manufacturer’s instructions.  Contents Make sure you have each item • Phone • Adapter • Stereo headset • Battery • Battery travel holder • User’s manual You can obtain the following accessories for your phone from your local Samsung dealer. • Multi adapter • Travel charger • Car charger • PC data cable • Portable battery kit • Portable PC data cable • Music controller • Bluetooth mono/ stereop headset kit Unpack Unpack .............................................................. 3 Make sure you have each item Get started ....................................................... 4 First steps to operate your phone Overview of menu functions .................... 7 To access Menu mode, press [메뉴] in Idle mode. Menu functions .............................................. 8 All menu options listed Solve problems ........................................... 18 Help and personal needs Health and safety information ............... 20  Power on or off Power on Do not turn on the phone when mobile phone use is prohibited. 1 Open the phone. 2 Press and hold [ ] to turn on the phone. 3 If necessary, enter the PIN and press [확인]. Power on 1 Open the phone. 2 Press and hold [ ]. Keys and display Key(s)Description SoftkeysPerform the function indicated on the bottom line of the display. Navigation keysIn Standby mode, access menu options directly. In Menu mode, scroll through the menu options. 확인 keyIn Idle mode, enters Menu mode. In Menu mode, selects the highlighted menu option. key Sends or answers a call. In Standby mode, retrieves the last number dialed, missed, or received. Install and charge the phone 1 Install the battery: 2 Plug the adapter into the phone. 3 Plug the adapter into a standard AC wall outlet. 4 When the phone is completely charged (the battery icon stops blinking), unplug the adapter from the power outlet. 5 Remove the adapter from the phone. Low battery indicator When the battery is low: • a warning tone sounds, • the battery low message displays, and • the empty battery icon [ ] blinks. If the battery level becomes too low, the phone automatically turns off. Recharge your battery. Get started First steps to operate your phone To remove the battery, slide the battery catch toward the top of the phone and hold it.  Get started Key(s)Description 취소 keyDeletes characters from the display. In Menu mode, returns to the previous menu level. key Ends a call. Hold down to switch the phone on and off. In Menu mode, cancels input and returns the phone to Idle mode. Numeric keysEnter numbers, letters, and some special characters. * /# keyEnter special characters. Use for some special functions. Key(s)Description Volume keys (on the left) Adjusts the phone volume. In Standby mode, with the phone open, adjusts the master volume. With the phone closed, hold down to turn on the display. In Menu mode, scrolls through the menu options. Camera keyIn Standby mode, with the phone open, turns on the camera. With the phone closed, hold down to turn on the camera. In Capture mode, takes a photo. 1 T Service 1 Global Roaming 2 M Help Desk 3 T Optional Service 4 NATE 5 W 6 MONETA 2 Sounds 1 Ring Tone Settings 2 Download Melody 3 Alert Tones 4 Key Tones/Others 5 Volume 6 Hourly Chime 3 Display 1 Wall Paper 2 Download Image 2 Main Menu Style 3 Font Type/Size 4 Dial Number Style 5 Lighting 4 Contents box 1 Melodies 2 Images 3 Photos/Movies 4 MMS Attached Files 5 mPlayon 6 june contents box 7 Key Jjang Album 8 Anycall.com …

Text truncated - open the document above for the full version.

Date: April 1, 2013 UL LLC Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL LLC to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL LLC on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL LLC as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang Kyung (Peter), RA Head of QA Lab (General Manager) Samsung Electronics America, Inc 19 Chapin Rd, Bldg. D, Pine Brook, NJ 07058

Label and Location Samsung Model: SM-C105S FCC ID: A3LSMC105S Label: Location: Top Back of device Bottom Upper part of label is placed on the front between lens & grip. Smaller label at inside of battery cover.

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea August 26, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMC105S Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy of KDB 784748 D01. The label statement is as follows: The FCC ID label is located in the battery compartment. While the battery cover is installed when the unit is shipped from the factory, the battery is never installed prior to sale, so the user must remove the cover in order to install the battery and operate the device. At this time the FCC ID is readily visible to the user. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

Plot No. 1 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/8/2013 20130808 SystemPerformanceCheck-D2450V2 SN 899 Frequency: 2450 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 2450 MHz; σ = 1.92 S/m; ε r = 52.223; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Averaged Fast SAR: Polynomial fit - Electronics: DAE4 Sn1259; Calibrated: 2/7/2013 - Probe: EX3DV4 - SN3929; ConvF(6.66, 6.66, 6.66); Calibrated: 6/24/2013; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: ELI-B v5.0; Type: QDOVA002AA; Serial: TP:1195 Body/Pin=100 mW/Area Scan (71x71x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Reference Value = 61.840 V/m; Power Drift = -0.03 dB Fast SAR: SAR(1 g) = 5.4 W/kg; SAR(10 g) = 2.38 W/kg Maximum value of SAR (interpolated) = 7.77 W/kg Body/Pin=100 mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 61.840 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 11.4 W/kg SAR(1 g) = 5.55 W/kg; SAR(10 g) = 2.59 W/kg Maximum value of SAR (measured) = 7.88 W/kg 0 dB = 7.88 W/kg = 8.97 dBW/kg Plot No. 2 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/8/2013 20130808 SystemPerformanceCheck-D2450V2 SN 899 Frequency: 2450 MHz; Duty Cycle: 1:1 Body/Pin=100 mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 7.24 W/kg Plot No. 3 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/9/2013 20130809_SystemPerformanceCheck-D5GHzV2 SN 1138 Frequency: 5200 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 5200 MHz; σ = 4.441 S/m; ε r = 36.861; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Averaged Fast SAR: Polynomial fit - Electronics: DAE4 Sn1259; Calibrated: 2/7/2013 - Probe: EX3DV4 - SN3929; ConvF(4.83, 4.83, 4.83); Calibrated: 6/24/2013; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 Head/5.2 GHz, Pin=100mW/Area Scan (61x61x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Reference Value = 57.273 V/m; Power Drift = 0.07 dB Fast SAR: SAR(1 g) = 7.85 W/kg; SAR(10 g) = 2.22 W/kg Maximum value of SAR (interpolated) = 20.0 W/kg Head/5.2 GHz, Pin=100mW/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 57.273 V/m; Power Drift = 0.07 dB Peak SAR (extrapolated) = 33.4 W/kg SAR(1 g) = 8.47 W/kg; SAR(10 g) = 2.44 W/kg Maximum value of SAR (measured) = 20.2 W/kg 0 dB = 20.2 W/kg = 13.05 dBW/kg Plot No. 4 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/9/2013 20130809_SystemPerformanceCheck-D5GHzV2 SN 1138 Frequency: 5200 MHz; Duty Cycle: 1:1 Head/5.2 GHz, Pin=100mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 13.4 W/kg Plot No. 5 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/9/2013 20130809_SystemPerformanceCheck-D5GHzV2 SN 1138 Frequency: 5500 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 5500 MHz; σ = 4.748 S/m; ε r = 36.467; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Averaged Fast SAR: Polynomial fit - Electronics: DAE4 Sn1259; Calibrated: 2/7/2013 - Probe: EX3DV4 - SN3929; ConvF(4.56, 4.56, 4.56); Calibrated: 6/24/2013; - Sensor-Surface: 1.4mm (Mechanical Surface Detection (Locations From Previous Scan Used)), Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 Head/5.5 GHz, Pin=100mW/Area Scan (61x61x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Reference Value = 57.066 V/m; Power Drift = 0.07 dB Fast SAR: SAR(1 g) = 8.16 W/kg; SAR(10 g) = 2.25 W/kg Maximum value of SAR (interpolated) = 21.8 W/kg Head/5.5 GHz, Pin=100mW/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 57.066 V/m; Power Drift = 0.07 dB Peak SAR (extrapolated) = 36.1 W/kg SAR(1 g) = 8.82 W/kg; SAR(10 g) = 2.49 W/kg Maximum value of SAR (measured) = 21.2 W/kg 0 dB = 21.2 W/kg = 13.26 dBW/kg Plot No. 6 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/9/2013 20130809_SystemPerformanceCheck-D5GHzV2 SN 1138 Frequency: 5500 MHz; Duty Cycle: 1:1 Head/5.5 GHz, Pin=100mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 13.9 W/kg Plot No. 7 Test Laboratory: UL Verification Services Inc., SAR Lab 1 Date: 8/9/2013 20130809_SystemPerformanceCheck-D5GHzV2 SN 1138 Frequency: 5800 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 5800 MHz; σ = 5.034 S/m; ε r = 36.081; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Averaged Fast SAR: Polynomial fit - Electronics: DAE4 Sn1259; Calibrated: 2/7/2013 - Probe: EX3DV4 - SN3929; ConvF(4.2, 4.2, 4.2); Calibrated: 6/24/2013; - Sensor-Surface: 1.4mm (Mechanical Surface Detection (Locations From Previous Scan Used)), Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000P40CD; Serial: TP 1751 Head/5.8 GHz, Pin=100mW/Area Scan (61x61x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Reference Value = 54.718 V/m; Power Drift = 0.09 dB Fast SAR: SAR(1 g) = 7.77 W/kg; SAR(10 g) = 2.15 W/kg Maximum value of SAR (interpolated) = 21.4 W/kg Head/5.8 GHz, Pin=100mW/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 54.718 V/m; Power Drift = 0.09 dB Peak SAR (extrapolated) = 35.3 W/kg SAR(1 g) = 8.4 W/kg; SAR(10 g) = 2.39 W/kg Maximum value of SAR (m…

Text truncated - open the document above for the full version.

FCC 47 CFR Parts 1 & 2 Published RF Exposure KDB Procedures IEEE Std 1528-2003 and IEEE 1528a-2005 SAR EVALUATION REPORT For 1x1 802.11abgn+BT4.0+Basic+EDR+HS,GSM1900,WCDMA1900, LTE B5+NFC Model: SM-C105S and SM-C105L FCC ID: A3LSMC105S Report Number: 13U15830-9B Issue Date: 9/18/2013 Prepared for Samsung Electronics Co., Ltd. 416, Maetan 3-Dong, Yeongtong-Gu Suwon-City, GyeonGggi-Do 443-742, South Korea Prepared by UL Verification Services Inc. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 Report No.: 13U15830-9B Issue Date: 9/18/2013 FCC ID: A3LSMC105S Page 2 of 50 UL Verification Services Inc. FORM NO: CCSUP4031G 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 8/27/2013 Initial Issue -- A 9/9/2013 1. Sec. 7.1., 7.4.: Added WiFi Direct mode. 2. Sec. 7.3.: Updated LTE Band Output Power Tune-up Tolerance. 3. Sec. 9.3.: Updated 5MHz Bandwidth output power. 4. Sec. 9.4. and 9.5.: Added Power measurements to determine worst-case data rates. 5. Sec. 12.4., 14.1., 14.2. and 14.3.: Added WiFi Direct mode SAR test results. Devin Chang B 9/18/2013 Sec. 9.3: Updated 10MHz Bandwidth output power. Peng Zhang Report No.: 13U15830-9B Issue Date: 9/18/2013 FCC ID: A3LSMC105S Page 3 of 50 UL Verification Services Inc. FORM NO: CCSUP4031G 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Table of Contents 1. Attestation of Test Results ............................................................................................................. 5 2. Test Methodology ........................................................................................................................... 6 3. Facilities and Accreditation ........................................................................................................... 6 4. Calibration and Uncertainty ........................................................................................................... 7 4.1. Measuring Instrument Calibration .............................................................................................. 7 4.2. Measurement Uncertainty .......................................................................................................... 7 5. Measurement System Description and Setup ............................................................................... 8 6. SAR Measurement Procedure ........................................................................................................ 9 6.1. Normal SAR Measurement Procedure ....................................................................................... 9 6.2. Volume Scan Procedures ........................................................................................................ 11 7. Device Under Test ......................................................................................................................... 12 7.1. General Information ................................................................................................................. 12 7.2. Wireless Technologies ............................................................................................................. 13 7.3. Output Power Tune-up Tolerance ............................................................................................ 14 7.4. Simultaneous Transmission Condition ..................................................................................... 15 7.5. General LTE SAR Test and Reporting Considerations ............................................................. 15 8. RF Exposure Conditions .............................................................................................................. 16 8.1. Head Exposure Conditions ...................................................................................................... 16 8.2. Body-worn Accessory Exposure Conditions ............................................................................. 16 8.3. Hotspot Exposure Conditions ................................................................................................... 16 8.4. Hotspot Exposure Conditions & WiFi Direct ............................................................................. 16 9. RF Output Power Measurement ................................................................................................... 17 9.1. GSM ........................................................................................................................................ 17 9.2. W-CDMA ................................................................................................................................. 18 9.3. LTE Band ................................................................................................................................. 20 9.4. WiFi (2.4 GHz Band) ................................................................................................................ 22 9.5. WiFi (5 GHz Bands) ................................................................................................................. 23 9.6. Bluetooth ................................................................................................................................. 26 10. Tissue Dielectric Properties ..................................................................................................... 27 10.1. Composition of Ingredients for the Tissue Material Used in the SAR Tests .......................... 28 10.2. Tissue Dielectric Parameter Check Results .......................................................................... 29 11. System Performance Check .....................................…
