129, Samsung-Ro, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, KOREA Date : October 22 nd , 2013 UL Verification Services Inc. Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our agent, we still recognize that we are responsible to: comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; 129, Samsung-Ro, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, KOREA f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang Kyung (Peter), RA Head of QA Lab (General Manager) Samsung Electronics America, Inc 19 Chapin Rd, Bldg D Pine Brook, NJ 07058

Label and Location Samsung Phone Model: SM*+8'6 FCC ID: $/60*+8 Label: Location: Top Back of device Bottom Label is placed inside of the battery compartment. ࢿݨback ViewձphotoԻ঴ɼ؂ԇТЬ. The FCC ID label is located in the battery compartment. While the battery cover is installed when the unit is shipped from the factory, the battery is never installed prior to sale, so the user must remove the cover in order to install the battery and operate the device. At this time the FCC ID is readily visible to the user. The label is permanently attached by acrylic glue and not easily removed from the device.”

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea June 21 , 2014 Federal Communication s Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMG313HU Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy of KDB 784748 D01. The label statement is as follows: The FCC ID label is located in the battery compartment. While the battery cover is install ed when the unit is shipped from the factory, the battery is never installed prior to sale, s o the user must remove the cover in order to install the battery and operate the device. A t this time the FCC ID is readily visible to the user. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Sang Kyung (Peter), Ra/ General Manager Samsung Electronics CO. LTD TEL: 973-808-6362 FAX: 973-808-6361 E-mail: [email protected]

FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCT-R-1406-F031 Date of Issue: June 18, 2014 EUT Type: Mobile Phone FCC ID: A3LSMG313HU Page 2 of 75 Version TEST REPORT NO. DATE DESCRIPTION HCT-R-1406-F031 June 18, 2014 - First Approval Report FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCT-R-1406-F031 Date of Issue: June 18, 2014 EUT Type: Mobile Phone FCC ID: A3LSMG313HU Page 3 of 75 Table of Contents 1.GENERAL INFORMATION ....................................................................................................................... 4 2.EUT DESCRIPTION .................................................................................................................................. 4 3.TEST METHODOLOGY ............................................................................................................................ 5 3.1EUT CONFIGURATION ............................................................................................................. 5 3.2EUT EXERCISE ......................................................................................................................... 5 3.3GENERAL TEST PROCEDURES ............................................................................................. 5 3.4DESCRIPTION OF TEST MODES ............................................................................................ 6 4.INSTRUMENT CALIBRATION .................................................................................................................. 6 5.FACILITIES AND ACCREDITATIONS ...................................................................................................... 6 5.1FACILITIES ................................................................................................................................ 6 5.2EQUIPMENT .............................................................................................................................. 6 6.ANTENNA REQUIREMENTS.................................................................................................................... 6 7.SUMMARY OF TEST RESULTS ............................................................................................................... 7 8.FCC PART 15.247 REQUIREMENTS ....................................................................................................... 8 8.1PEAK POWER ........................................................................................................................... 8 8.2BAND EDGES .......................................................................................................................... 15 8.3FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) ................................... 23 8.4NUMBER OF HOPPING FREQUENCY .................................................................................. 32 8.5TIME OF OCCUPANCY (DWELL TIME) ................................................................................. 36 8.6SPURIOUS EMISSIONS .......................................................................................................... 43 8.6.1CONDUCTED SPURIOUS EMISSIONS .......................................................................... 43 8.6.2RADIATED SPURIOUS EMISSIONS .............................................................................. 52 8.6.3RADIATED RESTRICTED BAND EDGES ...................................................................... 66 8.7POWERLINE CONDUCTED EMISSIONS ............................................................................... 69 9.LIST OF TEST EQUIPMENT ................................................................................................................... 74 9.1LIST OF TEST EQUIPMENT(Conducted Test) ..................................................................... 74 9.2LIST OF TEST EQUIPMENT(Radiated Test) ......................................................................... 75 FCCPT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCT-R-1406-F031 Date of Issue: June 18, 2014 EUT Type: Mobile Phone FCC ID: A3LSMG313HU Page 4 of 75 1. GENERAL INFORMATION Applicant: SAMSUNG Electronics Co., Ltd. Address: 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Rep. of Korea FCC ID: A3LSMG313HU EUT Type: Mobile Phone Model name(s): SM-G313HU/DS Date(s) of Tests: May 31, 2014 ~ June 12, 2014 Place of Tests: HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION FCC Model Name SM-G313HU/DS EUT Type Mobile Phone Power Supply DC 3.8 V Battery type Li-ion Battery(Standard) Frequency Range 2402 MHz - 2480 MHz (Bluetooth) Transmit Power 8.69 dBm (7.40 mW) BT Operating Mode Normal, EDR, AFH Modulation Type GFSK(Normal), π/4DQPSK and 8DPSK(EDR) Modulation Technique FHSS Number of Channels 79Channels, Minimum 20 Channels(AFH) Antenna Specification Manufacturer: ethertronics .com Antenna type: INTERNAL ANTENNA Peak Gain : -0.6 dBi 15.247 Requirements for Bluetooth transmitter ▪ This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudo-randomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. FCCPT.15.247 TEST REPO…
