A3LSMG3502UMobile phone

User manual SM-G3502U Draft 6 2011-12-23 Only for Marketing using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to “introducing your mobile phone, Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note—notes, usage tips, or additional information  Refer to—pages with related information; for example:  p. 12 (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [](represents the Power/ Menu exit key) < > Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary or per…

Text truncated - open the document above for the full version.

August 27, 2013 Federal Comm unications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: A3L SMG3502U To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Sang Kyung (Peter), Ra/ General Manager Samsung Electronics CO. LTD TEL: 310-900-5250 FAX: 310-537-5500 E-mail: [email protected]

Date: April 1, 2013 UL LLC Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL LLC to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL LLC on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL LLC as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang Kyung (Peter), RA Head of QA Lab (General Manager) Samsung Electronics America, Inc 19 Chapin Rd, Bldg. D, Pine Brook, NJ 07058

Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 1 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 1. External Photograph of EUT Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 2 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 3 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 4 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 5 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 6 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 7 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 List of Accessory: Specification of Accessory AC Adapter Brand Name SAMSUNG Model Name ETA0U42CBC Battery Brand Name SAMSUNG Model Name B150AC USB Cable Brand Name SAMSUNG Model Name APCBU20BBC Signal Line Type 1.2m, shielded cable, without core Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 8 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 9 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 AC Adapter Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 10 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Battery Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 11 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea August 26, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMG3502U Gentlemen: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy of KDB 784748 D01. The label statement is as follows: The FCC ID label is located in the battery compartment. While the battery cover is installed when the unit is shipped from the factory, the battery is never installed prior to sale, so the user must remove the cover in order to install the battery and operate the device. At this time the FCC ID is readily visible to the user. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

Label and Location Samsung Phone Model: SM-3502U FCC ID: A3LSMG3502U Label: Location: Top Back plate of device Bottom Label is placed inside of the battery compartment. Label

Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 12 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 3. Internal Photograph of EUT Bluetooth & WLAN Antenna <Tx / Rx> WWAN Antenna <Tx / Rx> GPS Antenna <Rx> Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 13 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 14 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 15 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 16 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 17 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 18 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 19 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 20 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 21 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 22 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 23 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 24 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 25 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 26 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 27 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 28 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 29 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 30 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 WWAN Antenna <Tx / Rx> Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 31 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 Bluetooth & WLAN Antenna <Tx / Rx> Photographs of EUT Report No.: EP381902 Brand Name: SAMSUNG; Model Name: SM-G3502U SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 32 of 32 TEL : 86-755- 3320-2398 Report Issued Date : Aug. 30, 2013 FCC ID : A3LSMG3502U Report Version : Rev. 01 GPS Antenna <Rx>

N SPORTON INT TEL : 86-755-8 FAX : 86-755-8 FCC ID : A3LS The p (SHEN accor stand The t writte be rep No. 101, Com A Revie TERNATIONAL 8637-9589 8637-9595 SMG3502U FCC SA product tes NZHEN) INC rdance with dards. test results en approval produced ex SP mplex Buildi pproved by ewed by: Eri L (SHENZHEN) AR Test Re FCC APPLICANT EQUIPMEN BRAND NA MODEL NA FCC ID STANDAR D ting was co C., would li the proced in this rep of SPORTO xcept in full PORTON ing C, Guanl : Jones Tsa ic Huang / D INC. eport C SAR T : SAM NT : Sma AME : SAM AME : SM- : A3L D : FCC ANS IEEE ompleted o ke to decla dures and s port apply e ON INTERNA . INTERNA long Village ai / Manager Deputy Mana R Tes MSUNG ELE art Phone MSUNG -G3502U LSMG3502U C 47 CFR Pa SI/IEEE C95. E 1528-2003 on Sep. 05, are that the hown the c exclusively ATIONAL (SH NATIONAL e, Xili Town, ager st Re ECTRONICS art 2 (2.1093) .1-1992 3 2013. We, e tested sam ompliance w to the test HENZHEN) L (SHEN Nanshan D Page Numb Report Issu Report Vers eport CO., LTD. ) SPORTON mple has b with the app ed model / INC., the tes NZHEN) IN District, Shen ber : 1 o ued Date : Se sion : Re Report No. t INTERNAT been evalua plicable tec / sample. W st report sh NC. nzhen, Guan of 41 ep. 10, 2013 ev. 03 : FA381902 IONAL ated in chnical Without all not ngdong, P.R 2 R.C. SPORTON INTERNATIONAL (SHENZHEN) INC. Page Number : 2 of 41 TEL : 86-755-8637-9589 Report Issued Date : Sep. 10, 2013 FAX : 86-755-8637-9595 Report Version : Rev. 03 FCC ID : A3LSMG3502U FCC SAR Test Report Report No. : FA381902 Table of Contents 1. Statement of Compliance ..............................................................................................................................................4 2. Administration Data .......................................................................................................................................................5 2.1 Testing Laboratory ...................................................................................................................................................5 2.2 Applicant .................................................................................................................................................................5 2.3 Manufacturer ...........................................................................................................................................................5 2.4 Application Details ...................................................................................................................................................5 3. General Information .......................................................................................................................................................6 3.1 Description of Equipment Under Test (EUT) ...........................................................................................................6 3.2 Maximum RF output power among production units ...............................................................................................7 3.3 Applied Standard .....................................................................................................................................................8 3.4 Device Category and SAR Limits ............................................................................................................................8 3.5 Test Conditions ........................................................................................................................................................8 4. Specific Absorption Rate (SAR) ....................................................................................................................................9 4.1 Introduction .............................................................................................................................................................9 4.2 SAR Definition .........................................................................................................................................................9 5. SAR Measurement System ..........................................................................................................................................10 5.1 E-Field Probe ........................................................................................................................................................ 11 5.2 Data Acquisition Electronics (DAE) ....................................................................................................................... 11 5.3 Robot ....................................................................................................................................................................12 5.4 Measurement Server .............................................................................................................................................12 5.5 Phantom ................................................................................................................................................................13 5.6 Device Holder .......................................................................................................................................................13 5.7 Data Storage and Evaluation ................................................................................................................................14 5.8 Test Equipment List ...............................................................................................................................................16 6. Tissue Simulating Liquids ...........................................................................................................................................17 7. System Verification Procedures .................................................................................................................................18 7.1 Purpose of System Perform…

Text truncated - open the document above for the full version.

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2013.08.20 System Check_Head_835MHz_130820 DUT: D835V2 - SN: 4d091 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_835_130820 Medium parameters used: f = 835 MHz; σ = 0.904 mho/m; ε r = 41.212; ρ = 1000 kg/m 3 Ambient Temperature： 23.5 °C; Liquid Temperature：22.8 °C DASY5 Configuration: - Probe: EX3DV4 - SN3819; ConvF(9.56, 9.56, 9.56); Calibrated: 26.11.2012; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1303; Calibrated: 22.11.2012 - Phantom: SAM2; Type: QD000P40CD; Serial: TP:1671 - Measurement SW: DASY52, Version 52.8 (2); SEMCAD X Version 14.6.6 (6824) Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 3.19 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 60.389 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 3.786 mW/g SAR(1 g) = 2.51 mW/g; SAR(10 g) = 1.64 mW/g Maximum value of SAR (measured) = 3.19 W/kg 0 dB = 3.19 W/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2013.08.19 System Check_Head_1900MHz_130819 DUT: D1900V2 - SN: 5d118 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_130819 Medium parameters used: f = 1900 MHz; σ = 1.417 mho/m; ε r = 40.994; ρ = 1000 kg/m 3 Ambient Temperature： 23.6 °C; Liquid Temperature：22.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3819; ConvF(7.84, 7.84, 7.84); Calibrated: 26.11.2012; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1303; Calibrated: 22.11.2012 - Phantom: SAM2; Type: QD000P40CD; Serial: TP:1671 - Measurement SW: DASY52, Version 52.8 (2); SEMCAD X Version 14.6.6 (6824) Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 14.6 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 103.3 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 18.657 mW/g SAR(1 g) = 10.1 mW/g; SAR(10 g) = 5.2 mW/g Maximum value of SAR (measured) = 14.3 W/kg 0 dB = 14.3 W/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2013.08.26 System Check_Head_2450MHz_130826 DUT: D2450V2 - SN: 840 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: HSL_2450_130826 Medium parameters used: f = 2450 MHz; σ = 1.878 mho/m; ε r = 40.464; ρ = 1000 kg/m 3 Ambient Temperature： 23.5 °C; Liquid Temperature：22.7 °C DASY5 Configuration: - Probe: EX3DV4 - SN3819; ConvF(6.99, 6.99, 6.99); Calibrated: 26.11.2012; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1303; Calibrated: 22.11.2012 - Phantom: SAM2; Type: QD000P40CD; Serial: TP:1671 - Measurement SW: DASY52, Version 52.8 (2); SEMCAD X Version 14.6.6 (6824) Pin=250mW/Area Scan (81x81x1): Interpolated grid: dx=12mm, dy=12mm Maximum value of SAR (interpolated) = 22.0 W/kg Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 93.205 V/m; Power Drift = -0.05 dB Peak SAR (extrapolated) = 30.195 mW/g SAR(1 g) = 14.2 mW/g; SAR(10 g) = 6.41 mW/g Maximum value of SAR (measured) = 22.1 W/kg 0 dB = 22.1 W/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2013.08.20 System Check_Body_835MHz_130820 DUT: D835V2 - SN: 4d091 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_835_130820 Medium parameters used: f = 835 MHz; σ = 0.977 mho/m; ε r = 54.379; ρ = 1000 kg/m 3 Ambient Temperature： 23.5 °C; Liquid Temperature：22.9 °C DASY5 Configuration: - P…
