A3LSMG550FYMobile phone

User manual SM -G550FY Draft 6.1 2014-09-23 Only for Approval using this manual This user manual has been specially designed to guide you through the functions and features of your mobile phone. To get started quickly, refer to “intr oducing your mobile phone, Instructional icons Before you start, familiarise yourself with the icons you will see in this manual: Warning—situations that could cause injury to yourself or others Caution—situations that could cause damage to your phone or other equipment Note —notes, usage tips, or additional information  Refer to—pages with related information; for example:  p. 12 (represents “see page 12”) Õ Followed by—the order of options or menus you must select to perform a step; for example: In Menu mode, select Messages Õ Create new message (represents Messages, followed by Create new message) [ ] Square brackets—phone keys; for example: [ ](represents the Power/ Menu exit key) < > Angled brackets—softkeys that control different functions at each screen; for example: <OK> (represents the OK softkey) Copyright information Rights to all technologies and products that comprise this device are the property of their respective owners:  Bluetooth ® is a registered trademark of the Bluetooth SIG, Inc. worldwide  Java™ is a trademark of Sun Microsystems, Inc.  Windows Media Player ® is a registered trademark of Microsoft Corporation. contents safety and usage information Safety warnings Safety precautions Important usage information introducing your mobile phone Unpack .. Phone layout Keys Display Icons assembling and preparing your mobile phone Install the SIM card and battery Charge the battery using basic functions Turn your phone on and off Access menus Customise your phone Use basic call functions Send and view messages Add and find contacts troubleshooting safety and usage information Comply with the following precautions to avoid dangerous or illegal situations and ensure peak performance of your mobile phone. Safety warnings Keep your phone away from small children and pets Keep your phone and all accessories out of the reach of small children or animals. Small parts may cause choking or serious injury if swallowed. Protect your hearing Excessive exposure to sound at high volumes can cause hearing damage. Always turn the volume down before plugging the earphones into an audio source and use only the minimum volume setting necessary to hear your conversation or music. Install mobile phones and equipment with caution Ensure that any mobile phones or related equipment installed in your vehicle are securely mounted. Avoid placing your phone and accessories near or in an air bag deployment area. Improperly installed wireless equipment can cause serious injury when air bags inflate rapidly. Handle and dispose of batteries and chargers with care  Use only Samsung-approved batteries and chargers specifically designed for your phone. Incompatible batteries and chargers can cause serious injuries or damage to your phone.  Never dispose of batteries or phones in a fire. Follow all local regulations when disposing used batteries or phones.  Never place batteries or phones on or in heating devices, such as microwave ovens, stoves, or radiators. Batteries may explode when overheated.  Never crush or puncture the battery. Avoid exposing the battery to high external pressure, which can lead to an internal short circuit and overheating. Avoid interference with pacemakers Maintain a minimum of 15 cm (6 inches) between mobile phones and pacemakers to avoid potential interference, as recommended by manufacturers and the independent research group, Wireless Technology Research. If you have any reason to suspect that your phone is interfering with a pacemaker or other medical device, turn off the phone immediately and contact the manufacturer of the pacemaker or medical device for guidance. Turn off the phone in potentially explosive environments Do not use your phone at refuelling points (service stations) or near fuels or chemicals. Turn off your phone whenever directed by warning signs or instructions. Your phone could cause explosions or fire in and around fuel or chemical storage and transfer areas or blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories. Reduce the risk of repetitive motion injuries When sending text messages or playing games on your phone, hold the phone with a relaxed grip, press the keys lightly, use special features that reduce the number of keys you have to press (such as templates and predictive text), and take frequent breaks. Safety precautions Drive safely at all times Avoid using your phone while driving and obey all regulations that restrict the use of mobile phones while driving. Use hands-free accessories to increase your safety when possible. Follow all safety warnings and regulations Comply with any regulations that restrict the use of a mobile phone in a certain area. Use only Samsung-approved accessories Using incompatible accessories may damage your phone or cause injury. Turn off the phone near medical equipment Your phone can interfere with medical equipment in hospitals or health care facilities. Follow all regulations, posted warnings, and directions from medical personnel. Turn off the phone or disable the wireless functions when in an aircraft Your phone can cause interference with aircraft equipment. Follow all airline regulations and turn off your phone or switch to a mode that disables the wireless functions when directed by airline personnel. Protect batteries and chargers from damage Avoid exposing batteries to very cold or very hot temperatures (below 0° C/32° F or above 45° C/ 113° F). Extreme temperatures can reduce the charging capacity and life of your batteries. Prevent batteries from contacting metal objects, as this can create a connection between the + and - terminals of your batteries and lead to temporary o…

Text truncated - open the document above for the full version.

September 21, 2015 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: A3LSMG550FY To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards CHANHO, YOUN General Manager Samsung Electronics CO. LTD TEL: +1-973-808-6362 E-mail: [email protected]

Date: July 23, 2014 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: comply with the relevant provisions of the certification program; a) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; b) make claims regarding certification only in respect of the scope for which certification has been granted; c) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; d) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; e) use certification only to indicate the products are certified as being in conformity with specified standards; f) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; g) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; h) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; i) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; j) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, CHANHO, YOUN General Manager Samsung Electronics CO. LTD TEL: +1-973-808-6362 E-mail: [email protected]

Label and Location Model: SM-G550FY FCC ID: A3LSMG550FY Label: Location: Top Back of device Bottom Phone: Label is placed inside of the battery compartment. Tablet : FCC ID is engraved on bottom of the device Label

FCC ID: A3LSMG550FY Issue Date: 09. 24, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 2 of 125 HCT-A-1509-F009-1 TEL: +82 31 645 6300 FAX: +82 31 645 6401 Version Rev. DATE DESCRIPTION HCT-A-1509-F009 09. 21, 2015 First Approval Report HCT-A-1509-F009-1 09. 24, 2015 Sec. 2.8 was revised. -Revised Sec. 2.8 (b) (Removed typo.) Revised the KDB version. (Revised 865664, 648474, 447498, 690783 and 941225 KDB version for whole report.) FCC ID: A3LSMG550FY Issue Date: 09. 24, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 3 of 125 HCT-A-1509-F009-1 TEL: +82 31 645 6300 FAX: +82 31 645 6401 Table of Contents 1. Attestation of Test Result of Device Under Test ............................................................................................ ４ 2. Device Under Test Description ..................................................................................................................... ５ 3. INTRODUCTION ...................................................................................................................................... １２ 4. DESCRIPTION OF TEST EQUIPMENT .................................................................................................. １３ 5. SAR MEASUREMENT PROCEDURE ..................................................................................................... １５ 6. DESCRIPTION OF TEST POSITION ....................................................................................................... １７ 7. ANSI/ IEEE C95.1 - 2005 RF EXPOSURE LIMITS .................................................................................. ２０ 8. FCC SAR GENERAL MEASUREMENT PROCEDURES ........................................................................ ２１ 9. Output Power Specifications .................................................................................................................... ２６ 10. SYSTEM VERIFICATION ....................................................................................................................... ３３ 11. SAR TEST DATA SUMMARY ................................................................................................................. ３５ 12. Simultaneous SAR Analysis ................................................................................................................... ４３ 13. SAR Measurement Variability and Uncertainty....................................................................................... ４５ 14. MEASUREMENT UNCERTAINTY ......................................................................................................... ４６ 15. SAR TEST EQUIPMENT ........................................................................................................................ ４７ 16. CONCLUSION ........................................................................................................................................ ４８ 17. REFERENCES ....................................................................................................................................... ４９ Attachment 1. – SAR Test Plots.................................................................................................................... ５１ Attachment 2. – Dipole Verification Plots ...................................................................................................... ６９ Attachment 3. – Probe Calibration Data ....................................................................................................... ７５ Attachment 4. – Dipole Calibration Data ...................................................................................................... ９９ Attachment 5. – SAR Tissue Characterization .......................................................................................... １２４ Attachment 6. – SAR SYSTEM VALIDATION ........................................................................................... １２５ FCC ID: A3LSMG550FY Issue Date: 09. 24, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 4 of 125 HCT-A-1509-F009-1 TEL: +82 31 645 6300 FAX: +82 31 645 6401 1. Attestation of Test Result of Device Under Test Attestation of SAR test result Applicant Name: SAMSUNG Electronics Co., Ltd. FCC ID: A3LSMG550FY Model: SM-G550FY EUT Type Mobile Phone Application Type: Certification The Highest Reported SAR (W/Kg) Band Tx. Frequency Equipment Class Reported 1g SAR (W/kg) (MHz) Head Body-Worn Hotspot GSM/GPRS 850 824.2 - 848.8 PCE 0.23 0.30 0.26 GSM/GPRS 1900 1 850.2 -1 909.8 PCE 0.23 0.46 0.68 UMTS 850 826.4 - 846.6 PCE 0.23 0.25 0.25 UMTS 1900 1 852.4 – 1 907.6 PCE 0.37 0.86 0.86 LTE 5 824.7 - 843 PCE 0.22 0.26 0.26 802.11b 2 412 - 2 462 DTS 1.03 0.23 0.23 Bluetooth 2 402 - 2 480 DSS/DTS - 0.13* - Simultaneous SAR per KDB 690783 D01v01r03 1.40 1.09 Date(s) of Tests: 09. 03, 2015 ~ 09. 17, 2015 Note : * BT Body-worn SAR value is estimated SAR value that should not be reported standalone SAR on grants of equipment approval. FCC ID: A3LSMG550FY Issue Date: 09. 24, 2015 Report No. HCT CO., LTD. 74, Seoicheon-ro 578 beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383. Rep. of KOREA 5 of 125 HCT-A-1509-F009-1 TEL: +82 31 645 6300 FAX: +82 31 645 6401 2. Device Under Test Description 2.1 DUT specification Device Wireless specification overview Band & Mode Operating Mode Tx Frequency GSM/GPRS 850 Voice / Data 824.2 – 848.8 MHz GSM/GPRS 1900 Voice / Data 1 850.0 – 1 909.8 MHz UMTS 850 Voice / Data 826.4 – 846.6 MHz UMTS 1900 Voice / Data 1 852.4 – 1 907.6 MHz LTE Band 5 (Cell) Data 824.7 – 848.3 MHz 2.4 GHz WLAN Data 2 412 – 2 462 MHz Bluetooth Data 2 402 – 2 480 MHz Device Description Device Dimension Overall (Length x Width) : 142 mm x 72 mm Overall Diagonal : 153 mm Display Diagonal : 128 mm Back Cover Normal Battery cover Battery Options Standard Hardware Ve…

Text truncated - open the document above for the full version.

Report No.: HCT-R-1509-F037-1 Model: SM-G550FY Page 2 of 54 F-01P-02-014 (Rev.00) FCC ID: A3LSMG550FY HCT CO.,LTD. Version TEST REPORT NO. DATE DESCRIPTION HCT-R-1509-F037 September 22, 2015 - First Approval Report HCT-R-1509-F037-1 September 24, 2015 - Revised radiated spurious emissions test results table and plots. - Revised the list of test requirement. Report No.: HCT-R-1509-F037-1 Model: SM-G550FY Page 3 of 54 F-01P-02-014 (Rev.00) FCC ID: A3LSMG550FY HCT CO.,LTD. Table of Contents 1. GENERAL INFORMATION ........................................................................................................................... 4 2. EUT DESCRIPTION ...................................................................................................................................... 4 3. TEST METHODOLOGY ................................................................................................................................ 5 3.1 EUT CONFIGURATION ....................................................................................................................... 5 3.2 EUT EXERCISE ................................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES ....................................................................................................... 5 3.4 DESCRIPTION OF TEST MODES ...................................................................................................... 5 4. INSTRUMENT CALIBRATION...................................................................................................................... 6 5. FACILITIES AND ACCREDITATIONS .......................................................................................................... 6 5.1 FACILITIES .......................................................................................................................................... 6 5.2 EQUIPMENT ........................................................................................................................................ 6 6. ANTENNA REQUIREMENTS ....................................................................................................................... 6 7. SUMMARY TEST OF RESULTS .................................................................................................................. 7 8. TEST RESULT .............................................................................................................................................. 8 8.1 DUTY CYCLE ....................................................................................................................................... 8 8.2 6dB BANDWIDTH MEASUREMENT ................................................................................................ 10 8.3 OUTPUT POWER MEASUREMENT ................................................................................................. 13 8.4 POWER SPECTRAL DENSITY ......................................................................................................... 20 8.5 OUT OF BAND EMISSIONS AT THE BAND EDGE/ CONDUCTED SPURIOUS EMISSIONS ...... 24 8.6 RADIATED MEASUREMENT. ........................................................................................................... 35 8.6.1 RADIATED SPURIOUS EMISSIONS. ..................................................................................... 35 8.6.2 RADIATED RESTRICTED BAND EDGES ............................................................................. 45 8.7 POWERLINE CONDUCTED EMISSIONS ........................................................................................ 48 9. LIST OF TEST EQUIPMENT ...................................................................................................................... 53 9.1 LIST OF TEST EQUIPMENT(Conducted Test) ............................................................................... 53 9.2 LIST OF TEST EQUIPMENT(Radiated Test) ................................................................................... 54 Report No.: HCT-R-1509-F037-1 Model: SM-G550FY Page 4 of 54 F-01P-02-014 (Rev.00) FCC ID: A3LSMG550FY HCT CO.,LTD. 1. GENERAL INFORMATION Applicant: SAMSUNG Electronics Co.,Ltd. Address: 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Rep. of Korea FCC ID: A3LSMG550FY EUT Type: Mobile Phone Model name(s): SM-G550FY Date(s) of Tests: August 31, 2015 ~ September 24, 2015 Place of Tests: HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION FCC Model Name SM-G550FY EUT Type Mobile Phone Power Supply DC 3.8 V Battery Infomation Model: EB-BG530CBN Type: Li-ion Battery(Standard) Frequency Range TX: 2402 MHz ~ 2480 MHz RX: 2402 MHz ~ 2480 MHz Max. RF Output Power Peak 7.128 dBm (5.162 mW) Average 6.637 dBm (4.610 mW) BT Operating Mode BT _Low Energy Mode Modulation Type GFSK Number of Channels 40 Channels Antenna Specification Manufacturer: EMW Antenna type: INTERNAL ANTENNA Peak Gain : -0.45 dBi Report No.: HCT-R-1509-F037-1 Model: SM-G550FY Page 5 of 54 F-01P-02-014 (Rev.00) FCC ID: A3LSMG550FY HCT CO.,LTD. 3. TEST METHODOLOGY FCC KDB 558074 D01 DTS Meas Guidance v03r03 dated June 09, 2015 entitled “Guidance for Performing Compliance Measurements on Digital Transmission Systems(DTS) and the measurement procedure described in the American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices (ANSI C63.10-2013) Operating Under §15.247” were used in the measurement. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the Tx frequency that was for the purpose of the measurements. Acco…

Text truncated - open the document above for the full version.

Report No.: HCT-R-1509-F036-1 Model: SM-G550FY Page 2 of 61 F-01P-02-014 (Rev.00) FCC ID: A3LSMG550FY HCT CO.,LTD. Version TEST REPORT NO. DATE DESCRIPTION HCT-R-1509-F036 September 22, 2015 - First Approval Report HCT-R-1509-F036-1 September 24, 2015 - Revised channel number on page 54. - Revised the list of test requirement. Report No.: HCT-R-1509-F036-1 Model: SM-G550FY Page 3 of 61 F-01P-02-014 (Rev.00) FCC ID: A3LSMG550FY HCT CO.,LTD. Table of Contents 1. GENERAL INFORMATION ........................................................................................................................... 4 2. EUT DESCRIPTION ...................................................................................................................................... 4 3. TEST METHODOLOGY ................................................................................................................................ 5 3.1 EUT CONFIGURATION ....................................................................................................................... 5 3.2 EUT EXERCISE ................................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES ....................................................................................................... 5 3.4 DESCRIPTION OF TEST MODES ...................................................................................................... 5 4. INSTRUMENT CALIBRATION...................................................................................................................... 6 5. FACILITIES AND ACCREDITATIONS .......................................................................................................... 6 5.1 FACILITIES .......................................................................................................................................... 6 5.2 EQUIPMENT ........................................................................................................................................ 6 6. ANTENNA REQUIREMENTS ....................................................................................................................... 7 7. SUMMARY TEST OF RESULTS .................................................................................................................. 8 8. TEST RESULT .............................................................................................................................................. 9 8.1 DUTY CYCLE ....................................................................................................................................... 9 8.2 6dB BANDWIDTH (802.11b/g/n) ....................................................................................................... 11 8.3 OUTPUT POWER (802.11b/g/n) ....................................................................................................... 15 8.4 POWER SPECTRAL DENSITY (802.11b/g/n) .................................................................................. 22 8.5 OUT OF BAND EMISSIONS AT THE BAND EDGE/ CONDUCTED SPURIOUS EMISSIONS ...... 26 8.6 RADIATED MEASUREMENT. ........................................................................................................... 39 8.6.1 RADIATED SPURIOUS EMISSIONS. ..................................................................................... 39 8.6.2 RADIATED RESTRICTED BAND EDGES ............................................................................. 52 8.7 POWERLINE CONDUCTED EMISSIONS ........................................................................................ 55 9. LIST OF TEST EQUIPMENT ...................................................................................................................... 60 9.1 LIST OF TEST EQUIPMENT(Conducted Test) ............................................................................... 60 9.2 LIST OF TEST EQUIPMENT(Radiated Test) ................................................................................... 61 Report No.: HCT-R-1509-F036-1 Model: SM-G550FY Page 4 of 61 F-01P-02-014 (Rev.00) FCC ID: A3LSMG550FY HCT CO.,LTD. 1. GENERAL INFORMATION Applicant: SAMSUNG Electronics Co.,Ltd. Address: 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Rep. of Korea FCC ID: A3LSMG550FY EUT Type: Mobile Phone Model name(s): SM-G550FY Date(s) of Tests: August 31, 2015 ~ September 21, 2015 Place of Tests: HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION FCC Model Name SM-G550FY EUT Type Mobile Phone Power Supply DC 3.8 V Battery Infomation Model: EB-BG530CBN Type: Li-ion Battery(Standard) Frequency Range TX: 2412 MHz ~ 2462 MHz RX: 2412 MHz ~ 2462 MHz Max. RF Output Power Peak Wi-Fi 802.11b(19.62 dBm) / Wi-Fi 802.11g (24.17 dBm) / Wi-Fi 802.11n_20MHz BW (23.72dBm)/ Average Wi-Fi 802.11b(16.93 dBm) / Wi-Fi 802.11g (13.88 dBm) / Wi-Fi 802.11n_20MHz BW (12.89 dBm)/ Modulation Type DSSS/CCK(802.11b), OFDM(802.11g, 802.11n) Antenna Specification Manufacturer: EMW Antenna type: INTERNAL ANTENNA Peak Gain :- 0.45 dBi Report No.: HCT-R-1509-F036-1 Model: SM-G550FY Page 5 of 61 F-01P-02-014 (Rev.00) FCC ID: A3LSMG550FY HCT CO.,LTD. 3. TEST METHODOLOGY FCC KDB 558074 D01 DTS Meas Guidance v03r03 dated June 09, 2015 entitled “Guidance for Performing Compliance Measurements on Digital Transmission Systems(DTS) and the measurement procedure described in the American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices (ANSI C63.10-2013) Operating Under §15.247” were used in the measurement. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the enginee…

Text truncated - open the document above for the full version.

FCC ID: A3LSMG550FY HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 16 TEST SETUP PHOTOGRAPHS FCC ID: A3LSMG550FY HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 16 ■ Conducted BT Test Setup Photo FCC ID: A3LSMG550FY HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 16 ■ Conducted WLAN Test Setup Photo FCC ID: A3LSMG550FY HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 16 ■ BT/WLAN Test Setup Photo FCC ID: A3LSMG550FY HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 16 ■ BT/WLAN Test Setup Photo FCC ID: A3LSMG550FY HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 16 ■ BT/WLAN Test Setup Photo FCC ID: A3LSMG550FY HCT CO., LTD 74, Seoicheon-ro…

Text truncated - open the document above for the full version.
