Y2 Package content • Device • USB cable • Ejection pin • USB power adaptor • Quick start guide Accessing more information To view the full user manual on your device, launch the Settings app and tap User manual. Visit www.samsung.com to view device information, the user manual, and more. To turn on the device, press and hold the Power key for a few seconds. Installing a nano-SIM card and a microSD card Insert the ejection pin into the hole next to the tray to loosen the tray. Gently press the card into the tray to secure it. Charging the battery Before using the device for the first time, you must charge the battery. Using the Home button When you turn on the screen, the Home button will appear at the bottom of the screen as a soft button. Correct disposal Safety information Read all safety information before using the device to ensure safe and proper use. Warning Follow the warning information provided below to prevent incidents such as fire or explosion • Do not expose the device to physical impact or damage. • Use manufacturer-approved batteries, chargers, accessories, and supplies. • Prevent the multipurpose jack and battery terminals from contacting conductive elements, such as metal or liquids. • If any part of the device, such as the glass or acrylic body, is broken, smokes, or emits a burning odor, stop using the device immediately. Use the device again only after it has been repaired at a Samsung Service Centre. • Do not turn on or use the device when the battery compartment is exposed. Follow the warnings below to prevent injury to people or damage to the device • Do not allow children or animals to chew or suck the device. • If the device has a camera flash or light, do not use it close to the eyes of people or animals. • The device can be used in locations with an ambient temperature of 0 °C to 35 °C. You can store the device at an ambient temperature of -20 °C to 50 °C. Using or storing the device outside of the recommended temperature ranges may damage the device or reduce the battery’s lifespan. • Do not use your device in a hot environment or near fire. • Comply with all safety warnings and regulations regarding mobile device usage while operating a vehicle. You can view more safety information, including device and battery disposal instructions, in the safety information menu of the Settings app. • It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods. Doing so may result in afterimages (screen burn-in) or ghosting. THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES Your mobile is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. The guidelines were developed by an independent scientific organisation (ICNIRP) and include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2.0 W/kg. The highest SAR values under the ICNIRP guidelines for this device model are: SAR values for European countries: The SAR values below are only for devices developed for use in European countries. Maximum SAR for this model and conditions under which it was recorded Head SAR TBD W/kg Body-worn SAR TBD W/kg Body-worn SAR testing has been carried out at a separation distance of 0.5 cm. To meet RF exposure guidelines during body-worn operation, the device should be positioned at least this distance away from the body. For SAR values for all other countries: For SAR values specific to your model, visit www.samsung.com/sar and search for your region and device with the model number. The use of WLAN band is restricted to indoor use only. This restriction will be applied in all countries below. The items supplied with the device may vary by region. • The user manual may not be available depending on the web browser or service provider. • You may incur additional charges for accessing the Internet. • Use only a nano-SIM card. • Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may be damaged. • If the card is not fixed firmly into the tray, the card may leave or fall out of the tray. Nano-SIM cards and microSD cards are sold separately. Use only USB Type-C cable supplied with the device. The device may be damaged if you use Micro USB cable. The charger should remain close to the electric socket and easily accessible while charging. This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. This product is RoHS compliant. This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste. To prevent possible hearing damage when using a headset, do not listen to sound at high volume for long periods. Specific Absorption Rate (SAR) certification information Draft • To transfer data of the previous device to a new device: Visit ww.samsung.com/smartswitch for more information. • If your device is frozen and unresponsive, press nd hold the Power key and the Volume Down key simultaneously for more than 7 seconds to restart it. Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. Copyright © 2019 Samsung Electronics Your device is a radio transmitter and receiver. It is designed and manufactured not to exceed the exposure limits for Radio Frequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These FCC RF exposure limits are derived from the recommendations of two expert organizations: the National Council on Radiation Protection and Measurement (NCRP) and the Institute of Electrical and Electronics Engineers (IEEE…

Text truncated - open the document above for the full version.

www.samsung.com USER MANUAL English. 11/2019. Rev.1.0 XYZ 2 Table of Contents Basics 4 Read me first 7 Device overheating situations and solutions 11 Device layout and functions 21 Battery 27 SIM or USIM card (nano-SIM card) 34 Memory card (microSD card) (Galaxy S) 37 Turning the device on and off 38 Initial setup 40 Samsung account 41 Transferring data from your previous devic e (Smart Switch) 44 Understanding the screen 57 Notification panel 59 Entering text Apps and features 62 Installing or uninstalling apps 64 Bixby 68 Bixby Vision 71 Bixby Home 74 Reminder 78 Phone 84 Contacts 88 Messages 91 Internet 93 Email 94 Camera 118 Gallery 124 AR EMOJI 131 Always On Display 134 Edge screen 138 Multi window 141 Samsung Pay 144 Samsung Health 150 Quick measure (Galaxy S5G) 151 Galaxy Wearable 151 Samsung Members 152 Samsung Notes 153 Calendar 154 Voice Recorder 157 My Files 157 Clock 159 Calculator 160 Game Launcher 162 Game Booster 163 Kids Home 165 SmartThings 169 Sharing content 170 Samsung DeX 177 Google apps Table of Contents 3 219 Accounts and backup 220 Samsung Cloud 221 Google 222 Advanced features 223 Bixby Routines 226 Motions and gestures 227 Dual Messenger 228 Digital wellbeing and parental controls 228 Digital Wellbeing 230 Device care 230 Optimising your device 231 Battery 232 Storage 232 Memory 233 Security 233 Apps 233 General management 234 Accessibility 235 Software update 235 About phone Appendix 236 Accessibility 253 Troubleshooting 260 Removing the battery Settings 179 Introduction 179 Connections 180 Wi-Fi 182 Bluetooth 183 NFC and payment 186 Data saver 186 Mobile data only apps 187 SIM card manager (dual SIM models) 187 Mobile Hotspot and Tethering 188 More connection settings 192 Sounds and vibration 192 Dolby Atmos (surround sound) 193 Separate app sound 193 Notifications 194 Display 195 Blue light filter 196 Dark mode 196 Changing the screen mode or adjusting the display colour 197 Screen resolution (Galaxy S5G, ) 198 Screensaver 198 Themes 199 Lock screen 200 Smart Lock 200 Biometrics and security 202 Face recognition 205 Fingerprint recognition 210 Samsung Pass 214 Secure Folder 4 Basics Read me first Please read this manual before using the device to ensure safe and proper use. • Descriptions are based on the device’s default settings. • Some content may differ from your device depending on the region, service provider, model specifications, or device’s software. • Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in. • Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung. • Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly. • Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media. • You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature. • Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers. Basics 5 • Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty. • Your device comes with a screen protector attached. If you replace it, it is recommended to use a Samsung product for better fingerprint recognition. (Galaxy S; Whether a screen protector is attached may vary by region.) • Depending on the region or service provider, a screen protector is attached for protection during production and distribution. Damage to the attached screen protector is not covered by the warranty. • You can see the touchscreen clearly even in strong outdoor sunlight by automatically adjusting the contrast range based on the surrounding environment. Due to the nature of the product, displaying fixed graphics for extended periods may result in afterimages (screen burn-in) or ghosting. – It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods and turn off the touchscreen when not using the device. – You can set the touchscreen to turn off automatically when you are not using it. Launch the Settings app, tap Display → Screen timeout, and then select the length of time you want the device to wait before turning off the touchscreen. – To set the touchscreen to automatically adjust its brightness based on the surrounding environment, launch the Settings app, tap Display, and then tap the Adaptive brightness switch to activate it. • Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC, you can view the FCC ID of the device. To view the FCC ID, launch the Settings app and tap About phone → Status. • Depending on the region, you can view the regulatory information on the device. To view the information, launch the Settings app and tap About phone → Regulatory information . Basics 6 Maintaining water and dust resistance Your device supports water- and dust-resistance. Follow these tips carefully to maintain the water- and dust-resistan…

Text truncated - open the document above for the full version.

Date: December 12, 2019 UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea To whom it may concern: I, the undersigned, hereby authorize UL Korea, Ltd. Suwon Laboratory, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Korea, Ltd. Suwon Laboratory on our behalf shall have the same effect as acts of our own. In authorizing UL Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. l) the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Ms. Jenni Chun General Manager Regu latory & Environmental Affairs Samsung Electronics CO. LTD TEL: +1-973-808-6375 E-mail: [email protected]

December 6, 2019 Federal Comm unications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMG985F To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0. 457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure PED Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s polic y, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Ms . J enni Chun General Manager Regulatory & Environmental Affairs Samsung Electronics CO. LTD TEL: +1-973-808-6375 E-mail: [email protected]

SAMSUNG CONFIDENTIAL Description of E-label and Location - FCC ID : A3LSMG985F - Model : SM-G985F/DS, SM-G985F Thi s model is applied E-label, please find description of E-label below. 1. FCC ID(E-label): Setting -> About Phone -> Status FCC certification FCC ID: A3LSMG985F <Device Display Sc reen> 2.Ins truction of E-label on the User manual (online manual) 3.FCC ID on the Quick Start Guide SAR information on this and other model phones can be viewed on-line at http://www.fcc.gov/oet/ea/fccid/. Please use the phone FCC ID number for search, A3LSMG985F. Once you have the FCC ID number for a particular phone, follow the instructions on the website and it should provide values for a typical or maximum SAR for a particular phone. Additional product specific SAR information can also be obtained at http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-cellular-telephones. Si ncerely, Engineer Seongkyu Choi Samsung Electronics Co., Ltd. TEL : +82-10-3299-4517 E- mail : [email protected]

SAMSUNG CONFIDENTIAL Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 16677, Korea F ederal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 E- l abel Attestation Letter - FCC ID : A3LSMG985F - Model : SM-G985F/DS, SM-G985F T o Whom It May Concern W e hereby provide the following attestations according to CFR 2.935 and FCC KDB 784748 D02: At the time of purchase, the FCC ID is readily and physically visible to the purchaser on the exterior package per CFR 2.935(f). The FCC ID will be readily legible without the aid of magnification according to CFR 2.935(d). The literature in the package describes how to access the electronic display to find FCC ID per CFR 2.935(b) and FCC KDB 784748. Per CFR 2.935(c), the user will be able to access this information within a maximum of 3 steps. The user will be able to access this information without a SIM card, special accessories or supplemental plug-ins. Per CFR 2.935(e), We, Samsung Electronics Co., Ltd., have programmed the e-label and it is not able to be modified by any third party. P er CFR 2.935(f), the FCC ID will be able to survive normal shipping and handling so it is visible for inspection at the time of import. S hould you have any questions or comments concerning the above, please contact the undersigned. S incerely, Ms . Jenni Chun General Manager Regulatory & Environmental Affairs Samsung Electronics Co., Ltd. TEL : +1-973-808-6375 E- mail : [email protected]

Sub Ant. #1 Rx Sub Ant. #2 Rx Sub Ant. #3 Rx Sub Ant. #4 Rx Sub Ant. #7 WIFI Tx/Rx Sub Ant. #5 Rx Sub Ant. #6 Rx Main Ant. #1 Tx/Rx Main Ant. #2 Tx/Rx Main Ant. #3 Rx Main Ant. #4 Rx

Testing Laboratory TL-637 CERTIFICATION TEST REPORT Report Number. : 4789247757-E9V2 Applicant : SAMSUNG ELECTRONICS CO., LTD. 129 SAMSUNG-RO, YEONGTONG-GU, SUWON-SI, GYEONGGI-DO, 16677, KOREA Model : SM-G985F/DS, SM-G985F FCC ID : A3LSMG985F EUT Description : GSM/WCDMA/LTE Phone + BT/BLE, DTS/UNII a/b/g/n/ac/ax, ANT+, NFC and WPT Test Standard(s) : FCC 47 CFR PART 15 SUBPART C Date Of Issue: December 17, 2019 Prepared by: UL Korea, Ltd. 26th floor, 152, Teheran-ro, Gangnam-gu Seoul, 06236, Korea Suwon Test Site: UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 REPORT NO: 4789247757-E9V2 DATE: DEC 17, 2019 FCC ID: A3LSMG985F Page 2 of 40 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15C(03) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. Revision History Rev. Issue Date Revisions Revised By V1 12/12/19 Initial issue Sangyun Kim V2 12/17/19 Updated to address TCB’s question Sangyun Kim REPORT NO: 4789247757-E9V2 DATE: DEC 17, 2019 FCC ID: A3LSMG985F Page 3 of 40 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15C(03) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 1.1. INTRODUCTION OF TEST DATA REUSE ................................................................... 5 1.2. DIFFERENCE ............................................................................................................... 5 1.3. SPOT CHECK VERIFICATION DATA ........................................................................... 5 1.4. REFERENCE DETAIL ................................................................................................... 6 2. TEST METHODOLOGY ..................................................................................................... 7 3. FACILITIES AND ACCREDITATION ................................................................................. 7 4. CALIBRATION AND UNCERTAINTY ................................................................................ 8 4.1. MEASURING INSTRUMENT CALIBRATION ................................................................ 8 4.2. SAMPLE CALCULATION .............................................................................................. 8 4.3. MEASUREMENT UNCERTAINTY ................................................................................ 8 4.4. DECISION RULE .......................................................................................................... 8 5. EQUIPMENT UNDER TEST ............................................................................................... 9 5.1. DESCRIPTION OF EUT ................................................................................................ 9 5.2. MAXIMUM E-FIELD STRENGTH .................................................................................. 9 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................... 9 5.4. WORST-CASE CONFIGURATION AND MODE ........................................................... 9 5.5. DESCRIPTION OF TEST SETUP ................................................................................10 6. TEST AND MEASUREMENT EQUIPMENT ......................................................................12 7. LIMITS AND RESULTS .....................................................................................................13 7.1. 99% BANDWIDTH .......................................................................................................13 7.2. TRANSMITTER RADIATED EMISSIONS ....................................................................15 7.2.1. DUTY CYCLE ........................................................................................................17 7.2.1. FUNDAMENTAL FIELD STRENGTH LEVEL ........................................................18 7.2.2. TRANSMITTER BAND EDGES .............................................................................24 7.2.3. HARMONICS AND SPURIOUS EMISSIONS ........................................................28 7.2.4. SPURIOUS BELOW 1 GHz ...................................................................................34 8. AC POWER LINE CONDUCTED EMISSIONS ..................................................................36 REPORT NO: 4789247757-E9V2 DATE: DEC 17, 2019 FCC ID: A3LSMG985F Page 4 of 40 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15C(03) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. EUT DESCRIPTION: GSM/WCDMA/LTE Phone + BT/BLE, DTS/UNII a/b/g/n/ac/ax, ANT+, NFC and WPT MODEL NUMBER: SM-G985F/DS, SM-G985F SERIAL NUMBER: R3CM90FSA4H (CONDUCTED, Original); R3CM90FS8HH (RADIATED, Original); R38MA0KHL8H (Spot check); DATE TESTED: OCT 20, 2019 – OCT 25, 2019 (Original); NOV 15, 2019 (Spot check); APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart C Pass UL Korea, Ltd. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL Korea, Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment teste…
