A3LSMG986UPortable Handset

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: CXX - Communications Rcvr for use w/ licensed Tx and CBs
Date of Grant: Jan 23, 2020
Application Purpose: Original Equipment
Date of Application: Dec 30, 2019
Equipment Note: Portable Handset
Frequency Range: 859.00000000 - 894.00000000
Company: Samsung Electronics Co Ltd
Country: United States
