A3LSMM325FVMobile Phone

Quick Reference G uide (Terms and Conditions) SM-M325FV/DS Read this document before operating the mobile device, accessories, or software (defined collectively and individually as the “Product”) and keep it for future reference. This document contains important Terms and Conditions. Electronic acceptance, opening the packaging, use, or retention of the Product constitutes acceptance of these Terms and Conditions. Visit www.samsung.com/us to view device information, the user manual, and more. You may incur additional charges for accessing the Internet. DRAFT Device Layout To turn on the device, pr ess and hold the Side key for a few seconds. The charger should remain close to the electric socket and easily acc essible while charging. Installing a nano-SIM card Nano-SI M cards are sold separately. Contact us Questions? Visit us.community.samsung.com Get Support Call 1.800.SAMSUNG Service locations Find a service location near you at Samsung.com/us/support/service/locations Switching made simple Whether you are coming from an iOS or Android platform, you can easily transfer your data with Smart Switch. Back up your old phone Back up your old phone using your favorite back-up app. Samsung Smart Switch 1.From your new Galaxy device, tap Settings > Accounts and backup > Smart Switch. 2.Tap Receive data. 3.Select your old device type. 4.Tap Cable (Android) or Wireless (Android and iOS) and follow the prompts to connect your phones. Customize Tap Settings to personalize your phone. Flight mode This disables all wireless functions on your device. You can use only non- network services On the setting screen, tap Flight mode. N OTE: The use of mobile devices on an aircraft or a ship may be subject to federal and local guidelines and restrictions. Check with appropriate author and always follow crew instructions regarding when and how you may use your device. Important legal information Arbitration Agreement - This Product is subject to a binding arbitration agreement between you and SAMSUNG ELECTRONICS AMERICA, INC. (“Samsung”). You can opt out of the agreement within 30 calendar days of the first consumer purchase by emailing [email protected] or calling 1-800-SAMSUNG (726-7864) and providing the applicable information. The full Arbitration Agreement, Standard One-year Limited Warranty, End User License Agreement (EULA), and Health & Safety Information for your device are available online: Phone •English: www.samsung.com/us/Legal/Phone-HSGuide •Spanish: www.samsung.com/us/Legal/Phone-HSGuide-SP T his information can also be found on the device in the “About device” or “About phone” or “About tablet” section, for example: •Settings > About phone or About device or About tablet > Legal information > Samsung legal •Or,Search “Legal” I f your device required Federal Communications Commission (FCC) approval, you can view the FCC certification by opening Settings > About phone or About device or About tablet> Status. Health and Safety WARNING! To avoid electri c shock and damage to your device, do not charge device whil e i t is wet or in an area where it co uld get wet. Do not handle device, c harger or cords with wet hands whil e charging. Maint aining dust and water resistance The device is not impervious to dust and water damage in any situation. It is important that all c ompartments are closed tightly. Follow these tip s carefully to prevent damage to the device and maintain dust and water resistance performance: •Water resistant based on IP68 rating, which tests submers ion in fresh water deeper than 1.5 meters or keep it submerged for more than 30 minut es. If device is expos ed to fresh water, dry it thoroughly with a clean, soft cloth; if exposed to liquid other than fresh water, rinse with fresh water and dry as directed. •Any device which uses acces sible compar tments or por t s that can be opened should have th ese se aled or closed tightly to prevent liquid from entering th e syst em. •If th e device has been immersed i n water or th e microphone or speaker is wet, sound may not be heard clearly during a call. After wipi ng th e device with a dry cloth, dry it thoroughly before using it. •Do not exp ose th e device to water at high pressure. •If th e device is dropped or receives an impact, th e water and dust resistant features of th e device may be damaged. Note: Liquid other than fresh water may enter th e device fa ster. Failure to rinse th e device in fresh water and dry it as instructed may cause th e device to suffer from operability or cosmetic issues. Samsung Knox Samsung Knox is Samsung’s security platform. Additional licensing fees may be required for enterprise use. For more information about Knox, pl ease refer to: www.samsung.com/us/knox Specific Absorption Rate (SAR) certification information For information about SAR, visit : •https://www.fcc.gov/general/radio-frequency-safety-0 •www.fcc.gov/encyclopedia/ specific-absorption-rate-sar-cellular-telephones •www.samsung.com/sar B ody-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5cm separation between the device and the user's body. No te: Foldable devices can be stored in an environment with ambient temperatures of -10°C / 14.0°F to 50°C / 122°F safely; prolonged exposure to temperatures outside these recommended temperatures can pose a high risk of damage to the device. Samsung mobile products and recycling WARNING! Never dispose of batterie s in a fire because th ey may explode. Do not disassemble, crush, puncture, heat, burn or reuse. F or battery and cell phone recycling, go to call2re cy cle. org or call 1- 800-822-8837. F or more recycling information, go to our website: www.samsung.com/re cy cl ing or call 1-800-SAMSUNG. Your location Location-based information on that can be used to determine the approximate location of a mobile device. If you use applic ations that require location-based information (e.g.…

Text truncated - open the document above for the full version.

Samsung Electronics America, Inc 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: May 24, 2021 FCC ID: A3LSMM325FV To whom it may concern: We, the undersigned, hereby authorize HCT Co., LTD to act on our behalf in all ma tters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by HCT Co., LTD on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to any application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. Sincerely, ---------------------------------------------------- Jenni Chun / General Manager Samsung Electronics America, Inc. Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1-973-808-6375

DATE : May 24, 2021 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMM325FV To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards ---------------------------------------------------- Jenni Chun / General Manager Samsung Electronics America, Inc. Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1-973-808-6375

FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 1 / 7 HCT CO.,LTD. - EXTERNAL PHOTOGRAPHS FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 2 / 7 HCT CO.,LTD. 1. External Photo (Front view) FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 3 / 7 HCT CO.,LTD. 2. External Photo (Rear view) FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 4 / 7 HCT CO.,LTD. 3. External Photo (Left side view) FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 5 / 7 HCT CO.,LTD. 4. External Photo (Right side view) FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 6 / 7 HCT CO.,LTD. 5. External Photo (Top view) FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 7 / 7 HCT CO.,LTD. 6. External Photo (Bottom view)

Description of E-label on the A3LSMM325FV May. 21, 2021 FCC ID : A3LSMM325FV This model is applied E-label, please find description of E-label below. 1. FCC ID(E-label) : Settings > About Phone > Status <Device Display Screen> 2. Instruction of E-label on the User manual (online manual) Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission(FCC). If your device is approved by the FCC, you can view the FCC ID or the device. To view the FCC ID, tap Settings > About phone > Status 3. FCC ID on the Quick Start Guide The FCC has granted an Equipment Authorization for this model device based on the compliance of all reported SAR levels with the FCC RF exposure guidelines. This device has a FCC ID number A3LSMA325F and the specific SAR levels for this device can be found at the following FCC website: www.fcc.gov/oet/eat/. The SAR information for this device can be also be found on Samsung's website: www.samsung.com/sar. FCC Certification FCC ID : A3LSMM325FV

Samsung Electronics Co., LTD. 12 9, Sa msu ng -ro , Yeongton g-gu Suwon-City, Gyeong gi-d o, 16677, Ko rea Date: May 24, 2021 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Label Statement FCC ID: A3LSMM325FV To Whom it Ma y Concern We hereby provide the following attestations according to CFR 2.935 and FCC KDB 784748 D02: At the time of purchase, the FCC ID is readily and physically visible to the purchaser on the exterior package per CFR 2.935(f). The FCC ID will be readily legible without the aid of magnification according to CFR 2.935(d). The literature in the package describes how to access the electr onic display to find the FCC ID per CFR 2. 935(b) and FCC KDB 784748. Per CFR 2.935(c), the user will be able to access this information within a maximum of 3 steps. The user will be able to access this information without a SIM card, special accessories or supplemental plug- ins. Per CFR 2.935(e), We, Samsung have programmed the e- label and it is not able to be modified by any third party. Per CFR 2.935(f), the FCC ID will be able to survive normal shipping and handling so it is visible for in spection at the time of import. Shou ld you have any questions or comments concern ing the abov e, please contact the undersign ed. Sincerely, ---------------------------------------------------- Jenni Chun / General Manager Samsung Electronics America, Inc. Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1-973-808-6375

FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 1 / 17 HCT CO.,LTD. - INTERNAL PHOTOGRAPHS FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 2 / 17 HCT CO.,LTD. ■ Main / Bluetooth & WLAN Antenna Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 3 / 17 HCT CO.,LTD. 1. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 4 / 17 HCT CO.,LTD. 2. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 5 / 17 HCT CO.,LTD. 3. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 6 / 17 HCT CO.,LTD. 4. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 7 / 17 HCT CO.,LTD. 5. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 8 / 17 HCT CO.,LTD. 6. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 9 / 17 HCT CO.,LTD. 7. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 10 / 17 HCT CO.,LTD. 8. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 11 / 17 HCT CO.,LTD. 9. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 12 / 17 HCT CO.,LTD. 10. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 13 / 17 HCT CO.,LTD. 11. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 14 / 17 HCT CO.,LTD. 12. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 15 / 17 HCT CO.,LTD. 13. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 16 / 17 HCT CO.,LTD. 14. Internal Photo FCC ID: A3LSMM325FV Report No. HCT-SR-2105-FC012 F-TP22-03 (Rev.00) 17 / 17 HCT CO.,LTD. 15. Internal Photo

FCC ID: A3LSMM325FV Report No.: HCT-EM-2105-FC007 F-TP22-03 (Rev.00) 2 / 20 HCT CO.,LTD. REVISION HISTORY The revision history for this document is shown in table. Report No. Issue Date Information About Changes 0 May 27, 2021 Initial Release The above Test Report is not related to the accredited test result by (KS Q) ISO/IEC 17025 and KOLAS (Korea Laboratory Accreditation Scheme) / A2LA (American Association for Laboratory Accreditation), which signed the ILAC-MRA. * The report shall not be reproduced except in full(only partly) without approval of the laboratory. FCC ID: A3LSMM325FV Report No.: HCT-EM-2105-FC007 F-TP22-03 (Rev.00) 3 / 20 HCT CO.,LTD. TABLE OF CONTENTS PAGE 1. GENERAL INFORMATION .............................................................................................................. 4 1.1 Description of EUT .................................................................................................................... 4 1.2 Tested System Details ................................................................................................................ 4 1.3 Cable Description ....................................................................................................................... 5 1.4 Noise Suppression Parts on Cable. (I/O Cable) ......................................................................... 5 1.5 Test Facility ................................................................................................................................ 6 1.6 Calibration of Measuring Instrument ......................................................................................... 6 1.7 Measurement Uncertainty .......................................................................................................... 6 2. LIST OF TEST EQUIPMENT ............................................................................................................ 7 3. DESCRIPTION OF TEST ................................................................................................................... 8 3.1 Measurement of Conducted Emission........................................................................................ 8 3.2 Measurement of Radiated Emission ........................................................................................... 9 4. PRELIMINARY TEST ....................................................................................................................... 11 4.1 Conducted Emission.................................................................................................................. 11 4.2 Rediated Emission ..................................................................................................................... 11 5. CONDUCTED AND RADIATED EMISSION TEST SUMMARY ................................................. 12 5.1 Conducted Emission................................................................................................................. 12 5.2 Radiated Emission .................................................................................................................... 13 6. CONCLUSION ................................................................................................................................. 19 7. APPENDIX A. TEST SETUP PHOTO ............................................................................................. 20 FCC ID: A3LSMM325FV Report No.: HCT-EM-2105-FC007 F-TP22-03 (Rev.00) 4 / 20 HCT CO.,LTD. 1. GENERAL INFORMATION 1.1 Description of EUT FCC ID A3LSMM325FV Model Name SM-M325FV/DS Product Name Mobile phone Frequency Band GSM 850/1900, WCDMA B2/4/5, LTE B2/4/5/12/17/26/41/66 BT BDR/EDR/LE(5.0), WLAN a/b/g/n/ac (SISO), NFC Power Voltage Travel adaptor Input: 100 ~ 240 V, 50 ~ 60 ㎐, 0.5 A, Output: 9.0 V, 1.67 A or 5.0 V, 2.0 A Battery Li-ion Battery Low: 3.65 V, Normal: 3.86 V, High: 4.43 V 1.2 Tested System Details All equipment descriptions used in the tested system (including inserted cards) are: Device Type Model Name Serial Number Manufacturer EUT SM-M325FV/DS - SAMSUNG TA EP-TA200 - SOLUM Data Cable EP-DR140AWE - RF-TECH Earphone EHS61ASFWE - CRESYN Micro SD Card - - SAMSUNG FCC ID: A3LSMM325FV Report No.: HCT-EM-2105-FC007 F-TP22-03 (Rev.00) 5 / 20 HCT CO.,LTD. 1.3 Cable Description Product Name Port Power Cord Shielded (Y/N) I/O Cable Shielded (Y/N) Length (m) EUT USB Type C (Data Cable) Y Y (P,D) 0.8 Earphone N/A N (D) 1.6 “(D)” Data Cable and “(P)” Power Cable. 1.4 Noise Suppression Parts on Cable. (I/O Cable) Product Name Port Ferrite Bead (Y/N) Location Metal Hood (Y/N) Location EUT USB Type C (Data Cable) N N/A Y Both End Earphone N N/A Y EUT End FCC ID: A3LSMM325FV Report No.: HCT-EM-2105-FC007 F-TP22-03 (Rev.00) 6 / 20 HCT CO.,LTD. 1.5 Test Facility Test site is located at 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea. Those measurement facilities are constructed in conformance with the requirements of ANSI C63.4-2014. The Normalized site attenuations (30 ㎒ to 1 ㎓) and Site validation (1 ㎓ to 18 ㎓) were performed in accordance with the standard in ANSI C63.4-2014. Our laboratories are accredited and designated in accordance with the provisions of Radio Waves ACT and International Standard ISO/IEC 17025:2017. (National Radio Research Agency, Designation No. KR0032) 1.6 Calibration of Measuring Instrument The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturers recommendations for utilizing calibration equipment, which is traceable to recognized national standards. Espectially, all antenna for measurement is calibrated in accordance with the requirements of C63.5:2017 1.7 Measurement Uncertainty The measurement uncertainties shown below were calculated in accordance with the requirements of ANSI C63.4-2014. All measurement uncertainty values are shown with a coverage factor of k = 2 to indicate a 95 % level of confidence.…

Text truncated - open the document above for the full version.

74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 FCC ID: A3LSMM325FV File No. HCT-EM-2105-FC007-P Page 1 of 5 APPENDIX A. Test Setup Photo 1. Revision History Rev. No. Issue Date Description 0 May 27, 2021 First approval report 2. Test Setup Photo No. No. File No. 0 HCT-EM-2105-FC007-P FCC ID: A3LSMM325FV File No. HCT-EM-2105-FC007-P Page 2 of 5 A.1. Conducted Emission Not Applicable FCC ID: A3LSMM325FV File No. HCT-EM-2105-FC007-P Page 3 of 5 A.2 Radiated Emission below 1 GHz FCC ID: A3LSMM325FV File No. HCT-EM-2105-FC007-P Page 4 of 5 A.3 Radiated Emission above 1 GHz 1 GHz to 18 GHz FCC ID: A3LSMM325FV File No. HCT-EM-2105-FC007-P Page 5 of 5 18 GHz to 30 GHz End of report
