A3LSMM625FGSM/WCDMA/LTE Phone + BT/BLE, DTS/UNII a/b/g/n/ac and NFC

Package contents • Device • USB cable • Ejection pin • USB power adaptor • Quick start guide The items supplied with the device and their images may vary by region. Device layout To turn on the device, press and hold the Side key for a few seconds. Multipurpose jack (USB Type-C) SIM card / Memory card tray Side key (Fingerprint recognition sensor) Volume key Front camera Rear camera The charger should remain close to the electric socket and easily accessible while charging. Installing a nano-SIM card Nano-SIM cards are sold separately. 231 <Underside> Nano-SIM card 2 Nano-SIM card 1 Correct disposal This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste. This product is RoHS compliant. This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste. Printed in Korea GH68-53099A Rev.1.0 English . 01/2021 QUICK START GUIDE SM-M 625F/DS Visit www.samsung.com t o view device information, the user manual, and more. You may incur additional charges for accessing the Internet. SM-E625F/DS During use, the actual SAR value for this device is usually well below the value stated above. This is because, for purposes of system efficiency and to minimise interference on the network, the operating power of your mobile device is automatically decreased when full power is not needed for the call. The lower the power output of the device, the lower its SAR value. Organisation such as the World Health Organisation and the US Food and Drug Administration have suggested that if people are concerned and want to reduce their exposure, they could use a hands-free accessory to keep the wireless device away from the head during use, or reduce the amount of time spent using the device. For more information, visit www.samsung.com/sar and search for your device with the model number. Supporting Indian official languages Your device supports Indian official languages and is capable of sending and reading message in the languages. Indian official languages are as follow. Language NameInput SupportMessage Readability Support EnglishOO HindiOO MarathiOO Assamese–O Bengali–O Gujarati–O Kannada–O Malayalam–O Nepali–O Oriya–O Punjabi–O Tamil–O Telugu–O Urdu–O Kashmiri–O Konkani–O Manipuri–O Sanskrit–O Sindhi–O Bodo–O Maithili –O Dogri–O Santhali–O Safety information Read all safety information before using the device to ensure safe and proper use. You can view more safety information in the safety information menu of the Settings app. Warning Follow the warnings below to prevent incidents, such as fires or explosions, injuries, or damage to the device • Do not expose the device to physical impact or damage. • Use only Samsung-approved batteries, chargers, and cables specifically designed for your device. • Prevent the multipurpose jack and battery terminals from coming into contact with foreign materials such as metal, liquids, or dust. • If an y part of the device, such as the glass or acrylic body, is broken, smokes, or emits a burning odor, stop using the device immediately. Use the device again only after it has been repaired at a Samsung Service Centre. • Do not tur n on or use the device when the battery compartment is exposed. • Do not disassemble or r euse the battery. • Do not allow children or animals to chew or suck the device. • The devic e can be used in locations with an ambient temperature of 0 °C to 35 °C. You can store the device at an ambient temperature of -20 °C to 50 °C. Using or storing the device outside of the recommended temperature ranges may damage the device or reduce the battery’s lifespan. • Do not use y our device in a hot environment or near fire. • Comply with all saf ety warnings and regulations regarding mobile device usage while operating a vehicle. THIS DEVICE MEETS INDIAN GOVERNMENT GUIDELINES FOR EXPOSURE TO RADIO WAVES Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) recommended by the Indian Government guidelines. The guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands. The highest SAR value under the Indian Government guidelines for this device model is: Maximum SAR for this model and conditions under which it was recorded Head SAR x.xxx W/kg Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. Copyright © 2021 Samsung Electronics Co., Ltd. • If your device is frozen and unresponsive, press and hold the Side key and the Volume Down key simultaneously for more than 7 seconds to restart it. • Depending on the region or model, some devices are required to receive approval from the Bureau of Indian Standards (BIS). If your device is approved by the BIS, you can view the BIS mark of the device. To view the BIS mark, launch the Settings app and tap About phone → Regulatory information. • It is r ecommended not to use fixed graphics on part or all of the touchscreen for extended periods. Doing so may result in afterimages (screen burn-in) or ghosting. To prevent possible hearing damage when using a headset, do not listen to sound at high volume for long periods. The use of WLAN band is restricted to indoor use only. This restriction will be applied in all countries below. ATBEBGCHCYCZDEDKEEESEL FIFRHRHUIEISITLILTLULV MTNLNOPLPTROSESISKTRUK •To transfer data of the previous dev…

Text truncated - open the document above for the full version.

www.samsung.com USER MANUAL English. 01/2021. Rev.1.0 SM-E625F/DS SM-M625F/DS 2 Table of Contents Basics 4 Read me first 6 D evice overheating situations and solutions 9 Device layout and functions 13 Charging the battery 15 SIM or USIM card (nano-SIM card) 17 M emory card (microSD card) 19 Turning the device on and off 20 Initial setup 21 S amsung account 22 T ransferring data from your previous device (Smart Switch) 24 Understanding the screen 32 Notification panel 34 Screen capture and screen record 35 Entering text Apps and features 38 Installing or uninstalling apps 39 Phone 42 Contacts 44 Messages 45 Internet 46 Camera 60 Gallery 64 AR Zone 69 Bixby 71 Bixby Vision 72 Bixby Routines 74 M ulti window 77 Samsung Pay 79 S amsung Health 80 Samsung Notes 81 S amsung Members 81 S amsung Kids 82 S amsung Global Goals 82 Samsung Shop 82 G alaxy Wearable 83 Calendar 83 Reminder 84 Radio 85 V oice Recorder 86 M y Files 86 Clock 86 Calculator 87 G ame Launcher 88 G ame Booster 89 SmartThings 89 Sharing content 91 M usic Share 92 Smar t View 93 Link to Windows 94 G oogle apps Table of Contents 3 122 Accounts and backup 122 Samsung Cloud 123 A dvanced features 124 Motions and gestures 125 Dual Messenger 126 Dig ital Wellbeing and parental controls 126 Ba ttery and device care 126 Optimising y our device 127 Battery 127 Storage 127 Memory 128 Device protection 128 Ultr a data saving 128 Apps 128 G eneral management 130 Accessibility 130 S oftware update 131 About phone Appendix 132 Troubleshooting Settings 95 Introduction 95 Samsung account 95 Connections 97 Wi-Fi 98 Bluetooth 99 NFC and c ontactless payments 101 Data saver 101 M obile data only apps 101 M obile Hotspot 102 More connection settings 103 Sounds and vibration 104 S ound quality and effects 104 S eparate app sound 105 Notifications 105 Display 106 Chang ing the screen mode or adjusting the display colour 107 Wallpaper 107 Themes 108 Home screen 108 L ock screen 109 Smar t Lock 109 Always On Display 110 Biometr ics and security 111 F ace recognition 113 F ingerprint recognition 115 S amsung Pass 117 Secure Folder 121 Privacy 121 Location 121 Google 4 Basics Read me first Please read this manual before using the device to ensure safe and proper use. • Descriptions are based on the device’s default settings. • Some content may differ from your device depending on the region, service provider, model specifications, or device’s software. • The device may require a connection to a Wi-Fi or mobile network when using some apps or features. • Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in. • Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung. • Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly. • Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media. • You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature. • Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers. • Modifying the device’s operating system or installing software from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty. Basics 5 • Depending on the region or service provider, a screen protector is attached for protection during production and distribution. Damage to the attached screen protector is not covered by the warranty. • You can see the touchscreen clearly even in strong outdoor sunlight by automatically adjusting the contrast range based on the surrounding environment. Due to the nature of the product, displaying fixed graphics for extended periods may result in afterimages (screen burn-in) or ghosting. – It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods and turn off the touchscreen when not using the device. – You can set the touchscreen to turn off automatically when you are not using it. Launch the Settings app, tap Display → Screen timeout, and then select the length of time you want the device to wait before turning off the touchscreen. – To set the touchscreen to automatically adjust its brightness based on the surrounding environment, launch the Settings app, tap Display, and then tap the Adaptive brightness switch to activate it. • Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC, you can view the FCC ID of the device. To view the FCC ID, launch the Settings app and tap About phone → Status information. If your device does not have an FCC ID, it means that the device has not been authorised for sale in the U.S. or its territories and may only be brought to the U.S. for the owner’s personal use. • The use of mobile devices on aeroplanes or ships may be subject to federal and local guidelines and restrictions. Check with the appropriate authorities and always follow crew instructions regarding when and how you may use your device. • Depending on the …

Text truncated - open the document above for the full version.

January 6, 2021 Federal Comm unications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMM625F To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0. 457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Antenna Specification Parts List Tune-Up Procedure PED Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with t he marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Date: November 19, 2020 UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea To whom it may concern: I, the undersigned, hereby authorize UL Korea, Ltd. Suwon Laboratory, to ac t on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Korea, Ltd. Suwon Laboratory on our behalf shall have the same effect as acts of our own. In authorizing UL Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. l) the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Description of E-label and Location - FCC ID : A3LSMM625F - Model : SM-M625F/DS, SM-E625F/DS This mod el is applied E-label, please find description of E-label below. 1.FCC ID(E-label ): Setting -> About Phone -> Status FCC certification FCC ID: A3LSM M625F <Device Di splay Screen> 2.Instruction of E-label on the User manual (online manual) Sincerely, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E- mail: [email protected]

Testing Laboratory TL-637 CERTIFICATION TEST REPORT Report Number. : 4789739083-E1V3 Applicant : SAMSUNG ELECTRONICS CO., LTD. 129 SAMSUNG-RO, YEONGTONG-GU, SUWON-SI, GYEONGGI-DO, 16677, KOREA Model : SM-M625F/DS, SM-E625F/DS FCC ID : A3LSMM625F EUT Description : GSM/WCDMA/LTE Phone + BT/BLE, DTS/UNII a/b/g/n/ac and NFC Test Standard(s) : FCC 47 CFR PART 15 SUBPART B Date Of Issue: January 14, 2021 Prepared by: UL Korea, Ltd. 26th floor, 152, Teheran-ro, Gangnam-gu Seoul, 06236, Korea Suwon Test Site: UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 REPORT NO: 4789739083-E1V3 DATE: JAN 14, 2021 FCC ID: A3LSMM625F Page 2 of 35 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. Revision History Rev. Issue Date Revisions Revised By V1 01/06/21 Initial issue Hyunsik Yun V2 01/11/21 Updated to address TCB’s question Hyunsik Yun V3 01/14/21 Updated to address TCB’s question Hyunsik Yun REPORT NO: 4789739083-E1V3 DATE: JAN 14, 2021 FCC ID: A3LSMM625F Page 3 of 35 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. FACILITIES AND ACCREDITATION ................................................................................. 5 4. CALIBRATION AND UNCERTAINTY ................................................................................ 6 4.1. MEASURING INSTRUMENT CALIBRATION ................................................................ 6 4.2. SAMPLE CALCULATION .............................................................................................. 6 4.3. MEASUREMENT UNCERTAINTY ................................................................................ 6 4.4. DECISION RULE .......................................................................................................... 6 5. EQUIPMENT UNDER TEST ............................................................................................... 7 5.1. DESCRIPTION OF EUT ................................................................................................ 7 5.2. TEST MODE ................................................................................................................. 7 5.3. WORST-CASE ORIENTATION AND MODE ................................................................. 8 5.4. DESCRIPTION OF TEST SETUP ................................................................................. 9 6. TEST AND MEASUREMENT EQUIPMENT ......................................................................10 7. APPLICABLE LIMIYS AND TEST RESULTS ...................................................................11 7.1. Above 1 GHz in the GSM850 .......................................................................................12 7.2. Above 1 GHz in the WCDMA Band 5 ...........................................................................15 7.3. Above 1 GHz in the LTE Band 12 ................................................................................16 7.4. Above 1 GHz in the LTE Band 26 ................................................................................19 7.5. Below 1 GHz in the GSM850 ........................................................................................22 7.6. Below 1 GHz in the WCDMA Band 5 ............................................................................28 7.7. Below 1 GHz in the LTE Band 12 .................................................................................29 7.8. Below 1 GHz in the LTE Band 26 .................................................................................33 REPORT NO: 4789739083-E1V3 DATE: JAN 14, 2021 FCC ID: A3LSMM625F Page 4 of 35 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. EUT DESCRIPTION: GSM/WCDMA/LTE Phone + BT/BLE, DTS/UNII a/b/g/n/ac and NFC MODEL NUMBER: SM-M625F/DS, SM-E625F/DS SERIAL NUMBER: R38NB04CLGT (RADIATED) DATE TESTED: DEC 16, 2020 – DEC 21, 2020; APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15B Pass UL Korea, Ltd. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL Korea, Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by UL Korea, Ltd. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL Korea, Ltd. will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endor…

Text truncated - open the document above for the full version.

EMC TEST REPORT Project No. LBE20201187 Issue No. I 1 Name of organization Samsung Electronics Co., Ltd. Applicant Address (Maetan-dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Republic of Korea Date of receipt December 16, 2020 因All other Receivers subject to part1 5 Type of device 因Class B Personal Computers and peripherals 因Other Class B digital devices and peripherals 因FM Broadcast Receiver Eutqhuoipriment a zation 因Certification 口Supplier's Declaration of Conformity FCC ID A3LSMM625F Kind of product Mobile Phone EUT Model No. SM-M625F/DS Variant Model No. Refer to clause 4.6 SAMSUNG ELECTRONICS VIETNAM CO.,LTD. Yenphong 1 - I.P Yentrung Commune, Yenphong Dist., Bae Ninh Province, Vietnam Manufacturer SAMSUNG INDIA ELECTRONICS PVT LTD B-1 Sector-81, Phase -II NOIDA U.P. INDIA SAMSUNG ELECTRONICS CO.,LTD. 302, 3 Gongdan 3-ro, Gumi-si, Gyengsangbuk-do, 39388, Republic of Korea Applied Standards 47 CFR Part 15, Subpart B, Class B / ANSI C63.4-2014 Test Period December 16, 2020 ~ December 22, 2020 Issue date December 23, 2020 Test result : Complied The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Tested by Sung-Wook Choi Reviewed by Sun-Ho Kim ’ LJ` 乙〈己入 /4 一 三墨 /「f / The test results in this report only apply to the tested sample. This report must not be reproduced, except in full, without written permission from Global CS center. Samsung Electronics Co., Ltd., Global CS Center (Maetan dong) 129, Samsung-ro, Yeongtong-Gu, Suwon-Si,Gyeonggi-Do 16677, Korea Project No. : LBE20201187 Mobile Phone : SM-M625F/DS - 2/28- This report must not be reproduced, except in full, without written permission from Global CS Center. Form No.: SRA-TRF-46/11 Table of contents 1. Report Information 1.1 Revision history ----------------------------------------------------------------------------------------------------------------- 3 2. Summary of test results 2.1 Emission ------------------------------------------------------------------------------------------------------------------------------- 3 3. General Information 3.1 Test facility --------------------------------------------------------------------------------------------------------------------------- 3 4. Test Configuration 4.1 Test Peripherals ----------------------------------------------------------------------------------------------------------------- 4 4.2 EUT operating mode ------------------------------------------------------------------------------------------------------- 5 4.3 Details of Sampling ---------------------------------------------------------------------------------------------------------- 5 4.4 Used cable description --------------------------------------------------------------------------------------------------- 6 4.5 Test arrangement -------------------------------------------------------------------------------------------------------------- 7 4.6 EUT Description ---------------------------------------------------------------------------------------------------------------- 9 4.7 EUT Frequencies ------------------------------------------------------------------------------------------------------------ 9 4.8 Test configuration and condition --------------------------------------------------------------------------------- 10 4.9 Measurement uncertainty ---------------------------------------------------------------------------------------------- 10 5. Result of individual tests 5.1 Conducted disturbance --------------------------------------------------------------------------------------------------- 11 5.2 Radiated disturbance ------------------------------------------------------------------------------------------------------ 17 Project No. : LBE20201187 Mobile Phone : SM-M625F/DS - 3/28- This report must not be reproduced, except in full, without written permission from Global CS Center. Form No.: SRA-TRF-46/11 1. Report Information 1.1 Revision history No. Date of Issue Revised detailed information Issue 0 December 22, 2020 There are no revisions and this version is basic test report. Issue 1 December 23, 2020 The SM-M625F variant model was deleted as per customer’s request. ※ Remark Compliance with Part 15B requirements for the receiver part of the licensed transmitter (equipment code CXX) is covered by other test report. 2. Summary of test results 2.1 Emission The EUT has been tested according to the following specifications: Applied Test type Applied standard Result Conducted Disturbance (Mains port) 47 CFR Part 15 Subpart B / ANSI C63.4-2014 (Class B) Complied Radiated Disturbance Complied 3. General Information 3.1 Test facility The Global CS Center is located on Samsung Electronics Co., Ltd. at (Maetan-dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Republic of Korea. All testing are performed in Semi-anechoic chambers conforming to the site attenuation characteristics defined by ANSI C63.4, CISPR 32, CISPR 16-1-4 and Shielded rooms. And all antennas are properly calibrated using ANSI C63.5:2017. The Global CS Center is an ISO/IEC 17025 accredited testing laboratory by the National Radio Research Agency with designation No. KR0004. for EMC testing. Project No. : LBE20201187 Mobile Phone : SM-M625F/DS - 4/28- This report must not be reproduced, except in full, without written permission from Global CS Center. Form No.: SRA-TRF-46/11 4. Test Setup configuration 4.1 Test Peripherals The cables used for these peripherals are either permanently attached by the peripheral manufacturer or coupled with an assigned cable as defined below. The following is a listing of the EUT and peripherals utilized during the performance of EMC test: Mark Description Model No. Serial No. Manufacturer / Trademark FCC ID A Mobile Phone SM-M625F/DS - SAMSUNG A3LSMM625F B Battery EB-BM415ABY - SDI - C Headset EHS61ASFBE - POSTER - D Data Cable EP-DA705BWE - RFTECH - E Micro SD Card 64GB - SAMSUNG DoC F Laptop Com…

Text truncated - open the document above for the full version.

1. Appendix: UNLICENSED BAND SETUP PHOTOS(Conducted Test) 1) CONDUCTED RF MEASUREMENT SETUP (DTS, UNII, BLE) CONDUCTED TEST PHOTO 2) CONDUCTED RF MEASUREMENT SETUP (Bluetooth) BLUETOOTH TEST PHOTO 3) CONDUCTED RF MEASUREMENT SETUP (DFS) DFS TEST PHOTO 4) CONDUCTED RF MEASUREMENT SETUP (NFC Stability) NFC STABILITY TEST PHOTO 2. Appendix: UNLICENSED BAND SETUP PHOTOS(Radiated Test) 1) RADIATED RF MEASUREMENT SETUP (BELOW 1 GHz) BELOW 1 GHz FRONT TEST PHOTO BELOW 1 GHz REAR TEST PHOTO 2) RADIATED RF MEASUREMENT SETUP (ABOVE 1 GHz) ABOVE 1 GHz FRONT TEST PHOTO ABOVE 1 GHz REAR TEST PHOTO 3) RADIATED RF MEASUREMENT SETUP (NFC) FACE ON TEST PHOTO FACE OFF TEST PHOTO 4) RADIATED RF MEASUREMENT SET-UP (Axis) X AXIS PHOTO Y AXIS PHOTO Z AXIS PHOTO 5) AC LINE CONDUCTED MEASUREMENT SETUP AC LINE CONDUCTED FRONT TEST PHOTO AC LINE CONDUCTED REAR TEST PHOTO END OF TEST PHOTO

Project No. : LBE20201187 Mobile Phone: SM-M625F/DS - 1/9- This report must not be reproduced, except in full, without written permission from Global…
