SM-P905 You can access the full user manual for more information. To learn to access the user manual, see “Viewing the user manual” in this quick start guide. Quick Start Guide www.samsung.com 2014-01-13 Draft Version / 4 Instructional icons Warning: situations that could cause injury to yourself or others Caution: situations that could cause damage to your device or other equipment Note: notes, usage tips, or additional information 5 Copyright Copyright © 2013 Samsung Electronics This guide is protected under international copyright laws. No part of this guide may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Samsung Electronics. 6 Trademarks t
SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics. t
Bluetooth ® is a registered trademark of Bluetooth SIG, Inc. worldwide. t
Wi-Fi ® , Wi-Fi Protected Setup ™ , Wi-Fi Direct ™ , Wi-Fi CERTIFIED ™ , and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. Your device uses a non-harmonised frequency and is intended for use in all European countries. The WLAN can be operated in the EU without restriction indoors, but cannot be operated outdoors. t
All other trademarks and copyrights are the property of their respective owners. 7 Getting started Device layout Back button Menu button Home button IrLED To u c h s c re e n Front camera Speaker Light sensor Multipurpose jack Memory card slot SIM card slot Volume button Power button 8 Getting started Microphone Headset jack Rear camera Flash GPS antenna Speaker S Pen Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery. 9 Getting started Installing the SIM or USIM card Insert the SIM or USIM card provided by the mobile telephone service provider. t
Only microSIM cards work with the device. t
Some LTE services may not be available depending on the service provider. For details about service availability, contact your service provider. 1 Open the cover of the SIM card slot. 2 Insert the SIM or USIM card with the gold- coloured contacts facing downwards. 10 Getting started 3 Push the SIM or USIM card into the slot until it locks in place. 4 Close the cover of the SIM card slot. Charging the battery Before using the device for the first time or when the battery has been unused for extended periods, you must charge the battery. Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or cables can cause the battery to explode or damage the device. The USB 3.0 cable can be used to charge the device, but it may not be supplied with the device depending on the region or service provider. 11 Getting started Connect the USB cable to the USB power adaptor and then plug the end of the USB cable into the multipurpose jack. When using a USB 2.0 cable, plug the USB cable into the right side of the multipurpose jack as shown in the image below. 12 Getting started Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty. After fully charging, disconnect the device from the charger. First unplug the charger from the device, and then unplug it from the electric socket. To save energy, unplug the charger when not in use. The charger does not have a power switch, so you must unplug the charger from the electric socket when not in use to avoid wasting power. The charger should remain close to the electric socket and easily accessible while charging. 13 Getting started Checking the battery charge status When you charge the battery while the device is off, the following icons will show the current battery charge status: ChargingFully charged Turning the device on and off When turning on the device for the first time, follow the on-screen instructions to set up your device. 14 Getting started Press and hold the Power button for a few seconds to turn the device on and off. Viewing the user manual The user manual provides complete information about operating your device. You may incur additional charges for accessing the Internet or downloading media files. For details, contact your service provider. 15 Getting started From your device 1 Open the Internet application. 2 Ta p to open the bookmarks list. 3 Select the bookmark for the user manual. To access the user manual more easily, place a shortcut or widget for the user manual on the Home screen. The user manual may not be available depending on the web browser or service provider. From your computer Access www.samsung.com and then search for the user manual by the model name of your device. 16 Safety information This safety information contains content for mobile devices. Some content may be not applicable to your device. To prevent injury to yourself and others or damage to your device, read the safety information about your device before using the device. Warning Failure to comply with safety warnings and regulations can cause serious injury or death Do not use damaged power cords or plugs, or loose electrical sockets Unsecured connections can cause electric shock or fire. Do not touch the power cord with wet hands or disconnect the charger by pulling the cord Doing so may result in electrocution. Do not bend or damage the power cord Doing so may cause electric shock or fire. 17 Safety information Do not use your device while it is charging or touch your device with wet hands Doing so may cause electric shock. Do not short-circuit the charger or the device Doing so may cause electric shock or fire, or the battery may malfunction or explode. Do not use your device outdoor during a thunderstorm Doing so may result in electric shock or device malfunction. Use manufacturer-approved batteries, chargers, accessories, and supplies t
Using generic batteries or chargers may shorten the …
