www.samsung.com User Manual SM-T116 SM-T116NU 2 About this manual This device provides high quality mobile communication and entertainment using Samsung’s high standards and technological expertise. This user manual is specially designed to detail the device’s functions and features. r
Please read this manual before using the device to ensure safe and proper use. r
Descriptions are based on the device’s default settings. r
Images and screenshots may differ in appearance from the actual product. r
Content may differ from the final product, or from software provided by service providers or carriers, and is subject to change without prior notice. For the latest version of the manual, refer to the Samsung website, www.samsung.com. r
Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Applications related to the content may not work properly depending on the device’s specifications and the environment that it is used in. r
Available features and additional services may vary by device, software, or service provider. r
Applications and their functions may vary by country, region, or hardware specifications. Samsung is not liable for performance issues caused by applications from any provider other than Samsung. r
Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or applications to work improperly. r
Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media. About this manual 3 r
Default applications that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an application provided with the device, contact a Samsung Service Centre. For user-installed applications, contact service providers. r
Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty. Instructional icons Warning: situations that could cause injury to yourself or others Caution: situations that could cause damage to your device or other equipment Note: notes, usage tips, or additional information Copyright Copyright © 2014 Samsung Electronics This guide is protected under international copyright laws. No part of this guide may be reproduced, distributed, translated, or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or storing in any information storage and retrieval system, without the prior written permission of Samsung Electronics. About this manual 4 Trademarks r
SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics. r
Bluetooth ® is a registered trademark of Bluetooth SIG, Inc. worldwide. r
Wi-Fi ® , Wi-Fi Protected Setup ™ , Wi-Fi Direct ™ , Wi-Fi CERTIFIED ™ , and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. r
All other trademarks and copyrights are the property of their respective owners. 5 Table of Contents Getting started 7 Device layout 8 Buttons 9 Package contents 10 Charging the battery 12 Inserting a memory card 14 Turning the device on and off 15 Holding the device 15 Locking and unlocking the device 15 Adjusting the volume 15 Switching to silent mode Basics 16 Indicator icons 17 Using the touch screen 20 Control motions 22 Using Multi Window 26 Notifications 27 Home screen 29 Applications screen 31 Using applications 31 Help 32 Entering text 34 Connecting to a Wi-Fi network 35 Setting up accounts 36 Transferring files 38 Securing the device 39 Upgrading the device Communication 40 Contacts 44 Email 46 Google Mail 48 Hangouts 48 Google+ 49 Photos Web & network 50 Internet 51 Chrome 52 Bluetooth Media 54 Music 56 Camera 61 Gallery 65 Video 66 YouTube Table of Contents 6 97 General 100 Google Settings Troubleshooting Application & media stores 67 Play Store 68 Samsung Apps 68 Play Music 69 Play Games 69 Play Newsstand Utilities 70 Memo 71 S Planner 73 Dropbox 74 Cloud 75 Drive 75 Hancom Viewer 78 Alarm 79 World Clock 79 Calculator 80 S Voice 81 Google 82 Voice Search 82 My Files Travel & local 85 Maps Settings 86 About Settings 86 Connections 89 Device 94 Controls 7 Getting started Device layout Recent apps button Home button Touch screen Back button Multipurpose jack V olume button Memory card slot Microphone Power button GPS antenna Rear camera Speaker Headset jack Earpiece Getting started 8 r
Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery. r
Do not use a screen protector. This causes sensor malfunctions. r
Do not allow water to contact the touch screen. The touch screen may malfunction in humid conditions or when exposed to water. Buttons ButtonFunction Power r
Press and hold to turn the device on or off. r
Press and hold for 8 seconds to reset the device if it has fatal errors or hang-ups, or freezes. r
Press to lock or unlock the device. The device goes into lock mode when the touch screen turns off. Recent apps r
Tap to open the list of recent applications. Home r
Press to return to the Home screen. r
Press and hold to launch Google search. Back r
Tap to return to the previous screen. Volume r
Press to adjust the device volume. Getting started 9 Package contents Check the product box for the following items: r
Device r
Quick start guide r
The items supplied with the device and any available accessories may vary depending on the region or service provider. r
The supplied items are designed only for this device and may not be co…

Text truncated - open the document above for the full version.

Samsung Electronics America, Inc 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: Jan. 5, 2015 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no p arty to any application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S. C. 862. FCC ID: A3LSMT116 Sincerely, CHANHO, YOUN General Manager American QA Lab SAMSUNG Electronics America INC.

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro,Yeongtong-gu Suwon-si,Gyeonggi-do, 443-742 Korea January 5, 2015 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMT116 Gentlemen: The device is compliant in accordance to the FCC rules about identification of equipment, stated in 47 CFR Part 2.925(d). The label statement is as follows: The FCC ID label is located on the rear of the device with the battery installed. At this time the FCC ID is readily visible to the user. The label is permanently engraved by laser and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely Yours, Seoung Ho Park Senior Manager SAMSUNG ELECTRONICS CO.,LTD Telecommunication Network Business Mobile Communication Division Regulatory Compliance Group.

SAMSUNG ELECTRONICS AMERICA, INC. American QA Lab 19 Chapin Rd, Building D. Pine Brook, NJ 07058 Date: Jan. 5, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: A3LSMT116 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SAMSUNG ELECTRONICS CO.,LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SAMSUNG ELECTRONICS CO.,LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST ExhibitDescription 1 Block Diagram 2 Operational Description PERMANENT 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, CHANHO, YOUN General Manager American QA Lab SAMSUNG Electronics America INC.

Label and Location Model: FCC ID: SM-T116, SM-T116NU A3LSMT116 Label: Location: Top Back of device Bottom FCC ID is placed on rear of device Label

Me Project No. LB E20 145966 Issue No. o Name of organization Samsung Electronics Co., Ltd. (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Applicant Address Suwon-si, Gyeonggi-do, 443-742, Republ ic of Korea Date of application December 10, 2014 [gJ Class B personal computers and peripherals Type of device D All other devices Eq uipment D Declaration of Conformity ~ Certification D Verification authorization FCCID A3LSMT116 Kind of product Portable Device EUT Model No. SM-T1 16 Variant Model No. Refer to clause 4.6 SAMSUNG ELECTRONICS CO., LTD. 94-1, Imsu-dong, Gumi-si, Gyengsangbuk·do, 730-722, Republic of Korea Manufacturer SAMSUNG ELECTRONICS VIETNAM Thai Nguyen CO., LTD. KCN Yen Sinh I, Pho Yen, Thai Nguyen, Vietnam Applied Standards 47 CFR Part 15, Subpart B, Class B / A NSI C63.4-2009 Test Period December 12, 2014 - December 1 7,2014 Issue date December 23, 2014 Test result: Compli ed The equipment under test has found to be compliant with the applied standards. (Refer to the attached test result for more detail.) Reviewed by : Min-Gon Kim ~\fz The test results in this report only apply to the t ested sample. This report must not be reproduced, except in full, without written permission from CS &Environment center. CS & Environment Center of Samsung Electronics Co., Ltd. (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-so, 443-742, Republic of Korea Project No. : LBE20145966 Portable Device : SM-T116 - 2/13- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/2 Table of contents 1. Report Information 1.1 Revision history ------------------------------------------------------------------------------------------------------------------ 3 2. Summary of test results 2.1 Emission ------------------------------------------------------------------------------------------------------------------------------- 3 3. General Information 3.1 Test facility ---------------------------------------------------------------------------------------------------------------------------- 3 4. Test Configuration 4.1 Test Peripherals ----------------------------------------------------------------------------------------------------------------- 4 4.2 EUT operating mode -------------------------------------------------------------------------------------------------------- 4 4.3 Details of Sampling ----------------------------------------------------------------------------------------------------------- 4 4.4 Used cable description ---------------------------------------------------------------------------------------------------- 5 4.5 Test arrangement -------------------------------------------------------------------------------------------------------------- 5 4.6 EUT Description ----------------------------------------------------------------------------------------------------------------- 6 4.7 Clock Frequencies ------------------------------------------------------------------------------------------------------------ 6 4.8 Test configuration and condition ---------------------------------------------------------------------------------- 6 4.9 Measurement uncertainty ---------------------------------------------------------------------------------------------- 7 5. Result of individual tests 5.1 Conducted disturbance --------------------------------------------------------------------------------------------------- 8 5.2 Radiated disturbance ------------------------------------------------------------------------------------------------------- 10 Project No. : LBE20145966 Portable Device : SM-T116 - 3/13- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/2 1. Report Information 1.1 Revision history No. Revised detailed information Issue 0 There are no revisions and this version is basic test report. 2. Summary of test results 1.1 Emission The EUT has been tested according to the following specifications: Applied Test type Applied standard Result Conducted Disturbance (Mains port) 47 CFR Part 15, Subpart B / ANSI C63.4-2009 ( Class B) Complied Radiated Disturbance Complied 3. General Information 3.1 Test facility The CS & Environment center is located on Samsung Electronics Co., Ltd. at (Maetan dong) 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Republic of Korea. All testing are performed in Semi-anechoic chambers conforming to the site attenuation characteristics defined by ANSI C63.4, CISPR 22, 16-1 and 16-2. and Shielded rooms. The CS & Environment center is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:2005. Project No. : LBE20145966 Portable Device : SM-T116 - 4/13- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/2 4. Test Setup configuration 4.1 Test Peripherals The cables used for these peripherals are either permanently attached by the peripheral manufacturer or coupled with an assigned cable as defined below. The following is a listing of the EUT and peripherals utilized during the performance of EMC test: Mark Description Model No. Serial No. Manufacturer / Trademark FCC ID / DoC A Portable Device SM-T116 - SAMSUNG A3LSMT116 B Battery EB-BT116ABE - SAMSUNG - C Headset EHS64AVFWE - SAMSUNG - D Data Cable ECB-DU68WE - SAMSUNG - E Micro SD Card32GB - SANDISK - F Desk-Top Computer HP Compaq dx2200 Microtower CNG7060LW0 HP DoC G LCD Monitor U2713HMt CN-0GK0KD-74445-332-106L Dell DoC H Mouse M-SBF96 LZ949BG0D9Y Logitech DoC I Keyboard SKG-2000PB CNBA5902830AGP53Z5A3485 SAMSUNG DoC J Router T3004 T300475G00563 EFM Networks DoC K Power Supply FS0D0900800KFW121030770D13041902138 FAIRONE DoC This tablet device does not contain the minimum number of ports required for personal computer testing per ANSI C63.4, but the EUT is attached to a computer through its only available port, which represents worst cas…

Text truncated - open the document above for the full version.

Project No. : LBE20145966 Portable Device : SM-T116 - 1/4- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/1 APPENDIX – Test Setup and EUT photography – Project No. : LBE20145966 Portable Device : SM-T116 - 2/4- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/1 1. Photograph of Test Setup [ Conducted Disturbance – Front ] [ Conducted Disturbance – Rear ] Project No. : LBE20145966 Portable Device : SM-T116 - 3/4- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/1 [ Radiated Disturbance for Below 1 GHz – Front ] [ Radiated Disturbance for Below 1 GHz – Rear ] Project No. : LBE20145966 Portable Device : SM-T116 - 4/4- This report must not be reproduced, except in full, without written permission from CS & Environment center. Form No.: SRA-TRF-46/1 [ Radiated Disturbance for Above 1 GHz – Front ] [ Radiated Disturbance for Above 1 GHz – Rear ]
