www.samsung.com User Manual SM-T805Y 2 Table of Contents Read me first Getting started 7 Package contents 8 Device layout 10 Using the SIM or USIM card 13 Using a memor y card 15 Turning the device on and off 16 Locking and unlocking the screen Basics 17 Using the touch screen 20 Home screen layout 23 Notifications and quick setting panels 26 Opening apps 26 Installing or uninstalling apps 28 Ent ering text 30 Scr een capture 31 My Files 33 Po wer saving feature 35 Viewing help inf ormation Network connectivity 36 Mobile data 36 W i-Fi 38 Download booster 38 Tethering and Mobile hotspot 40 I nternet Motions & usability features 42 Motions and gestures 44 Multi window 49 Toolbox 49 Increasing touch screen sensitivity Personalising 50 Managing the Home and Apps screens 55 Setting wallpaper and ringtones 56 Changing the scr een lock method 57 Finger S canner 60 Pr ivate mode 61 Multiple users 63 Tr ansferring data from your previous device 64 Setting up accounts Table of Contents 3 Useful apps and features 103 Kids Mode 106 S Finder 107 S Planner 110 S Voice 112 Calculator 112 Clock 113 WatchON 116 W ebEx 125 Businessw eek+ 126 Dropbox 127 Evernote 128 F lipboard 129 Hancom Office Viewer 133 N YTimes 134 Google apps Connecting with other devices 136 Bluetooth 138 Wi-Fi Direct 140 Quick Connect 142 SideSync 3.0 148 Remot e PC 153 Scr een Mirroring 155 Mobile printing Phone 65 Making calls 67 Receiving calls 68 Options during calls Contacts 71 Adding contacts 72 Managing contacts Messages & email 75 Messages 78 Email Camera 80 Basic shooting 83 Shooting modes 87 Camera settings Gallery 89 Viewing photos or videos 91 Editing photos or videos 96 Galler y settings Multimedia 97 Music 100 V ideo Table of Contents 4 202 Assistant menu 204 Setting tap and hold delay options 204 In teraction control 205 Using single tap mode 205 Managing accessibility settings 206 Using other useful f eatures Troubleshooting Device & data manager 156 Upgrading the device 157 Transferring files between the device and a computer 158 Backing up and restoring data 159 Per forming a data reset Settings 160 About Settings 160 Connections 165 Device 171 General 178 A pplications Accessibility 186 About Accessibility 187 Using the Home button to open accessibility menus 187 Voice feedback (TalkBack) 198 Changing the font size 198 Magnifying the screen 198 Setting notification reminders 199 Reversing the display colours 199 Colour adjustment 200 Setting flash notifica tion 200 Tur ning off all sounds 200 Caption settings 201 Adjusting the sound balance 201 Mono audio 5 Read me first Please read this manual before using the device to ensure safe and proper use. • Descriptions are based on the device’s default settings. • Some content may differ from your device depending on the region, service provider, or device’s software. • Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in. • Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung. • Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly. • Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media. • You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature. • Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers. • Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty. Read me first 6 Instructional icons Warning: situations that could cause injury to yourself or others Caution: situations that could cause damage to your device or other equipment Note: notes, usage tips, or additional information 7 Getting started Package contents Check the product box for the following items: • Device • Quick start guide • The items supplied with the device and any available accessories may vary depending on the region or service provider. • The supplied items are designed only for this device and may not be compatible with other devices. • Appearances and specifications are subject to change without prior notice. • You can purchase additional accessories from your local Samsung retailer. Make sure they are compatible with the device before purchase. • Use only Samsung-approved accessories. Malfunctions caused by using unapproved accessories are not covered by the warranty service. • Availability of all accessories is subject to change depending entirely on manufacturing companies. For more information about available accessories, refer to the Samsung website. Getting started 8 Device layout Back button Recent apps button Home button Infrared LED Touch screen Front camera Speaker Light sensor Multipurpose jack Memory card slot SIM card slot Volume button Power button Headset jack Rear camera Flash GPS antenna Speaker Microphone Main antenna Push clip Push clip • Do not cover the antenna area with your hands or other objects. This may cause connectivity problems or drain the battery. • Do not u…

Text truncated - open the document above for the full version.

Useful apps and features 108 Creating events or tasks 1 Tap S Planner on the Apps screen. 2 Tap . Alternatively, select a date with no events or tasks in it and tap the date again. If the date already has saved events or tasks in it, tap the date and tap . 3 Select either event or task and enter details. • Event: Set a start and end date for an event. You can set an optional repeat setting. • Task: Add a task to do on a specific date. You can set an optional priority setting. Attach a map showing the location of the event. Add more details. Set a start and end date for the event. Enter a title. Select a calendar to use or sync with. Select an item. 4 Tap Done to save the event or task. Useful apps and features 109 Syncing events and tasks with your accounts Tap S Planner on the Apps screen. To sync events and tasks with your accounts, tap → Sync. To add accounts to sync with, tap → Calendars → Add account. Then, select an account to sync with and sign in. When an account is added, a green circle is displayed next to the account name. To change an account’s syncing option, open the Apps screen, tap Settings → General → Accounts, and then select an account service. Deleting events or tasks Tap S Planner on the Apps screen. To delete events or tasks, tap → Delete, select the events or tasks, and then tap Done → OK. To delete an event or task while viewing it, tap → Delete → OK. To mark tasks as completed, tap a date that has tasks in it and tick completed tasks. Sharing events or tasks Tap S Planner on the Apps screen. To share an event or task while viewing it, tap → Share via, and then select a sharing method. Useful apps and features 110 S Voice About S Voice Use this app to command the device by voice to perform various features. Tap S Voice on the Apps screen. Alternatively, press the Home button twice. To deactivate the access by pressing the Home button, tap → Settings → Wake-up, and then deselect Open via the home key. This app may not be available depending on the region or service provider. Setting the language Tap → Settings → General → Language, and then select a language. The selected language is applied to S Voice only, not to the language displayed on the device. Using S Voice When you launch S Voice, the device starts voice recognition and the microphone icon turns red. Say a voice command. If you say a command and the device recognises it, the microphone icon at the bottom of the screen flashes green. Then, the device performs the command. Useful apps and features 111 Tips for better voice recognition: • Speak clearly. • Speak in quiet places. • Do not use offensive or slang words. • Avoid speaking in dialectal accents. The device may not recognise your commands or may perform unwanted commands depending on your surroundings or how you speak. Waking up S Voice in standby mode If S Voice is not used for a certain period, it automatically switches to standby mode. Tap the microphone icon or say “Hi Galaxy” to the device to resume voice recognition. Changing the wake-up command You can change the wake-up command from “Hi Galaxy”. The wake-up command is used to launch S Voice when the device is in standby mode. Tap → Settings → Wake-up → Voice wake-up → Set wake-up command. Disabling voice feedback Tap → Disable voice prompt. The device stops providing voice feedback when you say commands. Correcting unwanted voice commands You can edit the voice commands if the device does not recognise them correctly. To correct a voice command, tap the last speech bubble that contains your spoken text and edit the text with the keyboard. Useful apps and features 112 Calculator Use this app for simple or complex calculations. Tap Calculator on the Apps screen. You can see the calculation history on the left side of the screen. To clear the history, tap . Clock Alarm On the Apps screen, tap Clock → Alarm. Setting alarms Tap in the alarms list, set an alarm time, select the days on which the alarm will repeat, set other various alarm options, and then tap Save. To activate or deactivate alarms, tap next to the alarm in the alarms list. • Snooze: Set an interval and the number of times for the alarm to repeat after the preset time. • Smart alarm: Set a time and tone for the smart alarm. A smart alarm starts at a low volume a few minutes before a preset alarm is scheduled to sound. The volume of the smart alarm increases gradually until you turn it off or the preset alarm sounds. Stopping alarms Drag outside the large circle to stop an alarm. If you have previously enabled the snooze option, drag outside the large circle to repeat the alarm after a specified length of time. Deleting alarms Tap → Delete, select alarms, and then tap Done. Useful apps and features 113 World clock On the Apps screen, tap Clock → World clock. Creating clocks Tap and enter a city name or select a city from the cities list. To apply summer time, tap and hold a clock, and then tap . Deleting clocks Tap → Delete, select clocks, and then tap Done. WatchON About WatchON Use this app to connect to a TV and use the device as a remote control. You can search for and select TV programmes and control channels with your device. Tap WatchON on the Apps screen. Useful apps and features 114 Connecting to a TV 1 Tap WatchON on the Apps screen. 2 Select a region and the broadcast service, and then follow the on-screen instructions. The available TV programmes appear. Using the device as a remote control You can turn the TV on or off, browse channels, or adjust the volume level on the TV using the device as a remote control. 1 Tap WatchON on the Apps screen. 2 Tap → Setup. 3 Select the TV brand. 4 Ensure that the device’s infrared port is facing the TV and tap Turn on your TV. Then, tap OK if the device turns on the TV. If the device does not turn on the TV, tap Retry, and then repeat this until the TV recognises the signal. 5 Select a channel source. Useful apps and features 115 6 When the setup is completed, tap . Additional function…

Text truncated - open the document above for the full version.

 June17  4             !" # $  $ %   &" SMT805Y  ' ()  &%  "  *    )+ ,  $  - -. $)  / 0 11-2-.324#  5)     4)) )$  4 5 )   $    $ +    $ %-     ! ! !!! "! # $!%& #'$  6 ,        %  # +  +   + +% $     +  $)# +  -')+     $ ,    5)) $    + % 4 5,  +   $, 5 ) -  &    ,      2+    * 7 68 $ )  /+ %2    +%4))  55     1-9 ) +     1-24)   5)    , $      $  )   5 $ 4% ) : ,-(#  5)   5 ) 8  $ %#  )$  4 5)    ( ')  *+!# ,!!# $ # &-!$  &    5)    + 2 &$     +    5$ ,4+  5  $       ) $   4,$ + ,4 )5  $ # +   ) :  -  ;5        5<% 50*32=>  5    5?  -@' '?@".8998 6A".8998 ?8 "B  5-

129, Samsung-Ro, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, KOREA Date : October 22 nd , 2013 UL Verification Services Inc. Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our agent, we still recognize that we are responsible to: comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; 129, Samsung-Ro, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, KOREA f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang Kyung (Peter), RA Head of QA Lab (General Manager) Samsung Electronics America, Inc 19 Chapin Rd, Bldg D Pine Brook, NJ 07058

Label and Location Samsung EUT Model: SM-T805Y FCC ID: A3LSMT805Y Label: Location: Top Back of EUT Bottom Tablet : FCC ID is printed on bottom of the device

FCC CFR47 PART 15 SUBPART C ANT+ CERTIFICATION TEST REPORT FOR GSM/WCDMA/LTE Tablet with Bluetooth, DTS/UNII a/b/g/n/ac, and ANT + MODEL NUMBER: SM-T805Y FCC ID: A3LSMT805Y REPORT NUMBER: 14U17785-5 ISSUE DATE: May 30, 2014 Prepared for SAMSUNG ELECTRONICS CO., LTD. 416, MAETAN 3-DONG, YEONGTONG-GU SUWON-CITY GYEONGGI-DO, 443-742, SOUTH KOREA Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 14U17785-5 DATE: May 30, 2014 FCC ID: A3LSMT805Y Page 2 of 42 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 5/30/14 Initial Issue P. Kim REPORT NO: 14U17785-5 DATE: May 30, 2014 FCC ID: A3LSMT805Y Page 3 of 42 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY .......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. SAMPLE CALCULATION ............................................................................................................ 5 4.3. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5. EQUIPMENT UNDER TEST ............................................................................................................ 6 5.1. DESCRIPTION OF EUT .............................................................................................................. 6 5.2. MAXIMUM OUTPUT FUNDAMENTAL FIELD STRENGTH .................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................................. 6 5.4. WORST-CASE CONFIGURATION AND MODE ......................................................................... 6 5.5. DESCRIPTION OF TEST SETUP ................................................................................................ 7 6. TEST AND MEASUREMENT EQUIPMENT ................................................................................ 9 7. LIMITS AND RESULTS ................................................................................................................. 10 7.1. 99% BANDWIDTH ..................................................................................................................... 10 7.2. TRANSMITTER RADIATED EMISSIONS .................................................................................. 13 7.2.1. DUTY CYCLE (From Original) ......................................................................................... 15 7.2.2. FUNDAMENTAL FREQUENCY RADIATED EMISSION ............................................ 16 7.2.3. TRANSMITTER RESTRICTED BAND EDGES ............................................................. 17 7.2.4. HARMONICS AND SPURIOUS EMISSIONS ABOVE 1GHz ....................................... 21 7.2.5. SPURIOUS BELOW 1 GHz ............................................................................................... 22 8. AC POWER LINE CONDUCTED EMISSIONS .......................................................................... 25 9. SETUP PHOTOS .............................................................................................................................. 30 REPORT NO: 14U17785-5 DATE: May 30, 2014 FCC ID: A3LSMT805Y Page 4 of 42 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. 416, MAETAN 3-DONG, YEONGTONG-GU SUWON-CITY, GYEONGGI-DO, 443-742, SOUTH KOREA EUT DESCRIPTION: GSM/WCDMA/LTE Tablet with Bluetooth, DTS/UNII a/b/g/n/ac, & ANT+ MODEL: SM-T805Y SERIAL NUMBER: R32F203DVSN (Radiated); R32F108JLEK (Conducted); DATE TESTED: February 7 - April 28, 2014 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 Part 15 Subpart C Pass UL Verification Services Inc. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by UL Verification Services Inc. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by UL Verification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL Verification Services Inc. will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorse…
