A3LSMX510BT/BLE Tablet + DTS/UNII a/b/g/n/ac/ax and Digitizer

www.samsung.com USER MANUAL   U  = 9 8   U  = 9 >    U  > 9 8   U  > 9 >  English. 06/2023. Rev.1.0 2 Table of Contents Getting started 5 Device layout and functions 10 Charging the battery 13 Nano-SIM card and eSIM (Mobile network enabled models) 15 microSD c ard 18 Turning the device on and off 19 Initial setup 20 Samsung acc ount 21 Transferring data from your previous device (Smart Switch) 24 Understand ing the screen 33 Notification panel 35 Screen capture and screen record 36 Ent ering text Apps and features 39 Installing or uninstalling apps 40 S Pen 55 Phone 58 Contacts 60 Mess ages 61 Camer a 75 Gallery 79 AR Zone 85 Bix by 86 Bixb y Vision 87 Multi wind ow (Using multiple apps at once) 90 Samsung Internet 91 Samsung Health 92 Samsung Notes 97 Samsung Members 97 Samsung Kids 98 Samsung Global Goals 98 Samsung TV Pl us 98 Galaxy Shop 99 PENUP 99 C alendar 100 Reminder (Receiving notifications for to-do items) 101 Voice Recorder 102 My Files (Checking and managing the files) 102 Clock 102 Calculator 103 Game Launcher 104 Game Booster (Configuring your gaming environment) 105 SmartThings 105 Sharing cont ent 107 Music Share 108 Smart View (Mirroring on a TV screen) 109 Samsung Flow 110 Daily Board Table of Contents 3 139 Security and privacy 140 Fac e recognition 142 Fingerprint recognition 145 Samsung Pass 147 Sec ure Folder 150 Secure Wi-Fi 151 Location 152 Safety and emergency 153 Ac counts and backup 154 Users 156 Samsung Cloud 157 Google 157 Advanced features 158 Motions and gestures 159 Video call effects 160 Dual Mes senger 161 Digital W ellbeing and parental controls 161 Battery and device care 161 Optimising your device 162 Battery 162 Storage 162 Memory 163 Device protection 163 Auto optimisation 163 Sof tware update 163 Diagnostics 163 Maintenanc e mode 163 App s 164 General management 1 65 A ccessibility 166 Software update 166 About tabl et 113 Link to Windows (Using the device through a computer connection) 114 Samsung DeX 121 Google ap ps Settings 122 Introduction 122 Samsung account 122 C onnections 124 Wi-Fi 125 Bluetooth 127 Data saver (Mobile network enabled models) 127 All owed networks for apps (Mobile network enabled models) 128 Mobil e Hotspot (Mobile network enabled models) 128 More c onnection settings 130 Connect ed devices 131 Modes and R outines 131 Using modes 131 Using routines 1 32 Sound s and vibration 133 Sound quality and effects 133 Separate app sound 134 Notific ations 134 Displa y 136 Motion smoothnes s 136 Changing the scr een mode or adjusting the display colour 137 Wallp aper and style 137 Home scr een 138 Lock scr een 138 Smart L ock Table of Contents 4 Usage notices 167 Precautions for using the device 169 Notes on package contents and accessories 170 Maintaining water and dust resistance 171 Device overheating situations and solutions Appendix 175 Troubleshooting 180 Removing the battery 5 Getting started Device layout and functions ▶  U  = 9 8 E  U  = 9 >  D Side button Speaker Speaker Light sensor Keyboard dock port Touch screen Volume button Microphone   U  = 9 >  D    / ! M * & / ,     / ! 1 /  6   U  = 9 8 D* & / ,     / !1 /  6 Air vent hole Light sensor Front camera Microphone Speaker Speaker Main antenna S   U  = 9 >  T Headphone jack / Multipurpose jack (USB Type-C) Fingerprint recognition sensor Flash Rear camera   &+   + 1 " + +   S   U =9 >  T GPS antenna S Pen charger Getting started 6 ▶  U  > 9 8 E  U  > 9 >  D Side button Speaker Speaker Light sensor Microphone Keyboard dock port Touch screen Volume button   U  > 9 >  D    / !M * & / ,     / ! 1 /  6   U  > 9 8 D* & / ,     / !1 /  6 Front camera Air vent hole Microphone Speaker Speaker S Pen charger   &+   + 1 " + +   S   U  > 9 >  T  &$ % 1 0 " + 0 , / "  ! - % , + " ' (M  2 )1 &- 2 / -, 0 "  ' ( S     6 - " U  T &+ $ " / - / &+ 1  / " , $ + &1 &, + 0 " + 0 , / ) 0 %  "  /   * " /    &+   + 1 " + +   S   U  > 9 >  T    + 1 " + +  Getting started 8 • Use the device in a place without magnetic interference for the device to operate normally. • Your device and some accessories (sold separately) contain magnets. Keep it away from credit cards, implanted medical devices, and other devices that may be affected by magnets. In the case of medical devices, keep your device more than 15 cm apart. Stop using your device if you suspect any interference with your medical device and consult your physician or your medical device manufacturer. • Keep a safe distance between objects that are affected by magnets, and your device and some accessories (sold separately) that contain magnets. Objects such as credit cards, passbooks, access cards, boarding passes, or parking passes may be damaged or disabled by the magnets in the device. • When using the speakers, such as when playing media files or using speakerphone, do not place the device close to your ears. • Be careful not to expose the camera lens to a strong light source, such as direct sunlight. If the camera lens is exposed to a strong light source, such as direct sunlight, the camera image sensor may be damaged. A damaged image sensor is irreparable and will cause dots or spots in pictures. • If you use the device with its glass or acrylic body broken, there may be a risk of injury. Use the device only after it has been repaired at a Samsung Service Centre or an authorised service centre. • If dust or foreign materials enter the microphone, speaker, or receiver, or if these parts are covered, the device’s sound may become quiet or certain features may not work. If you attempt to remove the dust or foreign materials with a sharp object, the device may be damaged and its appearance may be affected. • Connectivity problems and battery drain may occur in the following situations: ‒ If you attach metallic stickers on the antenna area of the device ‒ If you attach a device cover made with…

Text truncated - open the document above for the full version.

Apps and features 76 Viewing images Open the Gallery app and select an image. To view other files, swipe to the left or right on the screen. More options Delete the image. Share the image with others. Modify the image. Image and video thumbnail Bixby Vision View the content on a large screen using the Smart View feature. Add the image to favourites. Cropping enlarged images 1 Open the Gallery app and select an image. 2 Spread two fingers apart on the area you want to save and tap . The cropped area will be saved as a file. Saved image thumbnail Apps and features 77 Viewing videos Open the Gallery app and select a video to play. To view other files, swipe to the left or right on the screen. To use more options during playback, tap → Open in Video player. Lock the playback screen. Skip to the previous video. Tap and hold to rewind. Switch to the pop-up video player. Capture the current screen. Display your videos. Configure the caption settings. Rewind or fast-forward by dragging the bar. Create a GIF. More options Rotate the screen. Skip to the next video. Touch and hold to fast-forward. Pause and resume playback. Change the screen ratio. View the content on a large screen using the Smart View feature. Drag up or down on the left side of the playback screen to adjust the brightness, or drag up or down on the right side of the playback screen to adjust the volume. To rewind or fast-forward, swipe to the left or right on the playback screen. Viewing brighter and clearer videos Enhance the image quality of your videos to enjoy brighter and more vivid colours. Open Settings and tap Advanced features → Video brightness → Bright. • This feature is only available in some apps. • Using this feature will increase battery consumption. Apps and features 78 Albums Create albums and sort your images and videos. 1 Open the Gallery app and tap → Albums → → Album to create an album. 2 Select the images or videos you want to copy or move them to an album. Stories When you capture or save images and videos, the device will read their date and location tags, sort the images and videos, and then create stories. Open the Gallery app, tap → Stories, and then select a story. If you tap , you can use various options, such as managing story content or changing the story title. If you tap → Create story on the stories list, you can create stories manually. Syncing images and videos Open the Gallery app, tap , and then follow the on-screen instructions to complete the sync. The Gallery app and the cloud will be synced. When your Gallery app is synced with the cloud, pictures and videos you take will also be saved in the cloud. You can access images and videos saved in the cloud in your Gallery app and from other devices. When you connect your Samsung account and Microsoft account, you can set the cloud storage as Microsoft OneDrive. Deleting images or videos Open the Gallery app, touch and hold an image, a video, or a story to delete, and then tap Delete. Using the recycle bin feature You can keep the deleted images and videos in the recycle bin. The files will be deleted after a certain period. Open the Gallery app, tap → , and then tap the Recycle bin switch to turn it on. To access files in the recycle bin, open the Gallery app and tap → Recycle bin. Apps and features 79 AR Zone Introduction AR Zone provides you AR related features. Choose a feature and capture fun pictures or videos. Launching AR Zone Use the following methods to launch AR Zone: • Open the AR Zone app. • Open the Camera app and tap MORE → AR ZONE. Some features may not be available depending on the carrier or model. AR Emoji Studio Create emojis any way you want and have fun using them in various features. Creating an AR Emoji 1 Open the AR Zone app and tap AR Emoji Studio. 2 You can pick a pre-made emoji. Swipe to the left or right, select an emoji, and then tap . If you want to make your own emoji, take a selfie or select an image. Apps and features 80 3 Follow the on-screen instructions to create an emoji. Edit the emoji. My emojis list More options Selecting an AR emoji to use Open the AR Zone app, tap AR Emoji Studio → , and then select an emoji you want. Deleting AR emojis Open the AR Zone app, tap AR Emoji Studio → → , tick emojis to delete, and then tap Delete. Creating an AR emoji short video and decorating your device with it You can create a short video with an emoji and use it as a wallpaper or call background image. 1 Open the AR Zone app and tap AR Emoji Studio. 2 Select Create video, Call screen, or Lock screen. 3 Select a template you want. To change the background image, tap → . 4 Tap Save to save the video. You can check the saved videos in Gallery. 5 To use the video directly, select an option at the bottom of the screen. Apps and features 81 Creating your contact profile with an AR emoji Use an emoji as your profile picture for your Samsung account and in the Contacts app. You can choose from various poses or create your own expressions. 1 Open the AR Zone app and tap AR Emoji Studio. 2 Tap Profile and select an emoji. 3 Tap to capture your expression or select a pose you want. 4 Tap Done → Save. Take a picture. Emoji Pose Apps and features 82 AR Emoji Camera Create fun pictures or videos with emojis using various shooting modes. 1 Open the AR Zone app and tap AR Emoji Camera. 2 Select the emoji and the mode you want to use. The available modes may vary depending on the emoji you select. • SCENE: The emoji mimics your expressions. You can also change the background image. • MASK: The emoji’s face appears over your face so it looks like you are wearing a mask. • MIRROR: The emoji mimics your body movements. • PLAY: The emoji moves on a real background. 3 Tap the emoji icon to take a picture, or touch and hold the icon to record a video. You can check and share the pictures and videos that you have captured in Gallery. AR Emoji Stickers When you create AR emojis, stickers with emoji expressions and actions will be created auto…

Text truncated - open the document above for the full version.

CFR 47 §2.911 (d)(5) Attestation Date: 05-02-2023 FCC ID: A3LSMX510 FRN : 0027908797 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA 1.Samsung Electronics Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Samsung Electronics Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Name: Ms. Jenni Chun Job Title: General Manager Regulatory & Environmental Affairs Company Name: Samsung Electronics Co., Ltd.

47 CFR §2.911 (d)(7) Agent Designation Attestation Date: 05-02-2023 FRN : FRN : 0027908797 FCC ID: A3LSMX510 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Samsung Electronics Co., Ltd. (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The appl icant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: Contact Person : Ms. Jenni Chun Company Name : Samsung Electronics Co., Ltd. Company Address : 19 Chapin Rd., Building D, Pine Brook, NJ 07058 Email : [email protected] FRN : 0027908797 Sincerely yours, Name: Ms. Jenni Chun Job Title: Head of Regulatory & Environmental Affairs Company Name: Samsung Electronics Co., Ltd.

April 14, 2023 Federal Comm unications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: FCC ID: Request for Confidentiality A3LSMX510 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0. 457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics Block Diagram Operational Description Parts List Tune-Up Procedure Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachm ents until 180 days External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Best Regards Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

Date: April 14, 2023 UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea To whom it may concern: I, the undersigned, hereby authorize UL Korea, Ltd. Suwon Laboratory, to act on our behalf in all manners relating to application for equipment authorization, including signing of all doc uments relating to these matters. Any and all acts carried out by UL Korea, Ltd. Suwon Laboratory on our behalf shall have the same effect as acts of our own. In authorizing UL Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. l) the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Ms. Jenni Chun General Manager Samsung Electronics America, Inc. TEL: +1-973-808-6375 E-mail: [email protected]

External Photo Applicant : SAMSUNG ELECTRONICS CO., LTD. 129 SAMSUNG-RO, YEONGTONG-GU, SUWON-SI, GYEONGGI-DO, 16677, KOREA Model : SM-X510 FCC ID : A3LSMX510 ISED ID : 649E-SMX510 Date Of Issue: 2023-07-19 Prepared by: UL Korea, Ltd. 26th floor, 152, Teheran-ro, Gangnam-gu Seoul, 06236, Korea Suwon Test Site: UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 Testing Laboratory TL-637 SM-X510 DATE: 2023-07-19 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. External Photo SM-X510 DATE: 2023-07-19 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. SM-X510 DATE: 2023-07-19 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. The End SM-X510 DATE: 2023-07-19 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd.

SAMSUNG ELECTRONICS CO., LTD 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Korea April 21, 2023 Federal Communications Comm ission 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT : Label Statement FCC ID : A3LSMX510 To whom it may concern We hereby p rovide the following attestations according to CFR 2.935 and FCC KDB 784748 D02: At the time of purchase, the FCC ID is readily and physically visible to the purchaser on the exterior package per CFR 2.935(f). The FCC ID will be readily legible without the aid of magnification according to CFR 2.935(d). The literature in the package describes how to access the electronic display to find the FCC ID per CRF 2.935(b) and FCC KDB 784748. Per CFR 2.935(c), the user will be able to access this information within a maximum of 3 steps. The user will be able to access this information without a SIM card, special accessories or supplemental plug-ins. Per CFR 2.935(e), We, Samsung have programmed the e-label and it is not able to be modified by any third party. Per CFR 2 .935(f), the FCC ID will be able to survive normal shipping and handling so it is visible for inspection at the time of import. Should you hav e any questions or comments concerning the above, please contact the undersigned. Sincerel y Yours, Jenni Chun / General Manager Samsung Electronics America. Inc Address: 19 Chapin Rd., Building D Pine Brook, NJ 07058 Tel: 1-973-808-6375

FCC certification FCC ID: A3LSMX510 Description of E-label on the A3LSMX510 Date: July 18 th , 2023 FCC ID: A3LSMX510 This model is applied E-label, please find description of E-label below. 1. FCC ID (E-label): Settings > About tablet > Status <Device Display Screen> 2. FCC ID on the Quick Start Guide The FCC has granted an Equipment Authorization for this model device based on the compliance of all reported SAR levels with the FCC RF exposure guide lines. This device has a FCC ID number A3LSMX510 [Model Number: SM-X510] and the specific SAR levels for this device can be found at the following. FCC website: www.fcc.gov/oet/ea/ The SAR information for this device can be found on Samsung’s website: www.samsung.com/sar 3. Insturction of E-label on the User manual (online manual)

Internal Photo Applicant : SAMSUNG ELECTRONICS CO., LTD. 129 SAMSUNG-RO, YEONGTONG-GU, SUWON-SI, GYEONGGI-DO, 16677, KOREA Model : SM-X510 FCC ID : A3LSMX510 ISED ID : 649E-SMX510 Date Of Issue: 2023-07-28 Prepared by: UL Korea, Ltd. 26th floor, 152, Teheran-ro, Gangnam-gu Seoul, 06236, Korea Suwon Test Site: UL Korea, Ltd. Suwon Laboratory 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 Testing Laboratory TL-637 SM-X510 DATE: 2023-07-28 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. Internal Photo SM-X510 DATE: 2023-07-28 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. SM-X510 DATE: 2023-07-28 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. SM-X510 DATE: 2023-07-28 UL Korea, Ltd. Suwon Laboratory FORM ID: FCC_15B(04) 218 Maeyeong-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16675, Korea TEL: (031) 337-9902 FAX: (031) 213-5433 UL Korea, Ltd. Confidential This report shall not be reproduced except in full, without the written approval of UL Korea, Ltd. The End

Plot No. 1 UL Korea, Ltd. Suwon Laboratory SAR#7 Date/Time:2023-07-13 Measurement Report for SM-X510, EDGE LEFT, WLAN 2.4GHz, IEEE 802.11b WiFi 2.4 GHz (DSSS, 1 Mbps, 99pc duty cycle), Channel 1 (2412.0 MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL EDGE LEFT, 0.00 WLAN 2.4GHz WLAN, 10415- AAA 2412.0, 1 8.42 1.80 38.3 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2039 HBBL-600-10000, 2023-Jul-13 EX3DV4 - SN7646, 2023-03-23 DAE4 Sn1447, 2023-03-22 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 60.0 x 180.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 10.0 3.8 x 3.8 x 1.4 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.507 0.516 psSAR10g [W/Kg] 0.199 0.187 Power Drift [dB] -0.07 M2/M1 [%] 65.9 Dist 3dB Peak [mm] 5.4 Plot No. 2 UL Korea, Ltd. Suwon Laboratory SAR#7 Date/Time:2023-07-13 Measurement Report for SM-X510, BACK, WLAN 2.4GHz, IEEE 802.11b WiFi 2.4 GHz (DSSS, 1 Mbps, 99pc duty cycle), Channel 1 (2412.0 MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL BACK, 0.00 WLAN 2.4GHz WLAN, 10415- AAA 2412.0, 1 8.42 1.80 38.3 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2039 HBBL-600-10000, 2023-Jul-13 EX3DV4 - SN7646, 2023-03-23 DAE4 Sn1447, 2023-03-22 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 220.0 x 140.0 30.0 x 30.0 x 30.0 Grid Steps [mm] 10.0 x 10.0 4.2 x 4.2 x 1.4 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.684 0.671 psSAR10g [W/Kg] 0.282 0.256 Power Drift [dB] -0.05 M2/M1 [%] 69.5 Dist 3dB Peak [mm] 5.1 Plot No. 3 UL Korea, Ltd. Suwon Laboratory SAR#6 Date/Time:2023-07-12 Measurement Report for SM-X510, EDGE RIGHT, WLAN 5GHz, IEEE 802.11ac WiFi (80MHz, MCS0, 90pc duty cycle), Channel 58 (5290.0 MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL EDGE RIGHT, 0.00 WLAN 5GHz WLAN, 10626- AAC 5290.0, 58 5.4 4.55 35.8 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2023-Jul-12 EX3DV4 - SN7314, 2023-05-26 DAE4 Sn1671, 2023-05-25 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 60.0 x 180.0 22.0 x 22.0 x 22.0 Grid Steps [mm] 10.0 x 10.0 2.9 x 2.9 x 1.2 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.253 0.283 psSAR10g [W/Kg] 0.062 0.059 Power Drift [dB] -0.07 M2/M1 [%] 63.9 Dist 3dB Peak [mm] 4.3 Plot No. 4 UL Korea, Ltd. Suwon Laboratory SAR#6 Date/Time:2023-07-12 Measurement Report for SM-X510, EDGE RIGHT, WLAN 5GHz, IEEE 802.11ac WiFi (80MHz, MCS0, 90pc duty cycle), Channel 58 (5290.0 MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL EDGE RIGHT, 0.00 WLAN 5GHz WLAN, 10626- AAC 5290.0, 58 5.4 4.55 35.8 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2023-Jul-12 EX3DV4 - SN7314, 2023-05-26 DAE4 Sn1671, 2023-05-25 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 60.0 x 180.0 22.0 x 22.0 x 22.0 Grid Steps [mm] 10.0 x 10.0 2.9 x 2.9 x 1.2 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.329 0.364 psSAR10g [W/Kg] 0.083 0.079 Power Drift [dB] 0.04 M2/M1 [%] 64.3 Dist 3dB Peak [mm] 4.3 Plot No. 5 UL Korea, Ltd. Suwon Laboratory SAR#7 Date/Time:2023-07-17 Measurement Report for SM-X510, BACK, U-NII-2C Standalone, IEEE 802.11a/h WiFi 5 GHz (OFDM, 6 Mbps, 90pc duty cycle), Channel 140 (5700.0 MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL BACK, 0.00 U-NII-2C Standalone WLAN, 10583- AAC 5700.0, 140 5.25 5.18 35.4 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2039 HBBL-600-10000, 2023-Jul-17 EX3DV4 - SN7646, 2023-03-23 DAE4 Sn911, 2023-03-21 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 220.0 x 140.0 22.0 x 22.0 x 22.0 Grid Steps [mm] 10.0 x 10.0 2.2 x 2.2 x 1.2 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.631 0.846 psSAR10g [W/Kg] 0.158 0.174 Power Drift [dB] -0.19 M2/M1 [%] 60.4 Dist 3dB Peak [mm] 3.7 Plot No. 6 UL Korea, Ltd. Suwon Laboratory SAR#6 Date/Time:2023-07-18 Measurement Report for SM-X510, EDGE RIGHT, WLAN 5GHz, IEEE 802.11a/h WiFi 5 GHz (OFDM, 6 Mbps, 90pc duty cycle), Channel 140 (5700.0 MHz) Exposure Conditions Phantom Section, TSL Position, Test Distance [mm] Band Group, UID Frequency [MHz], Channel Number Conversion Factor TSL Conductivity [S/m] TSL Permittivity Flat, HSL EDGE RIGHT, 0.00 WLAN 5GHz WLAN, 10583- AAC 5700.0, 140 4.93 5.17 35.7 Hardware Setup Phantom TSL, Measured Date Probe, Calibration Date DAE, Calibration Date Twin-SAM V8.0 (30deg probe tilt) - 2043 HBBL-600-10000, 2023-Jul-18 EX3DV4 - SN7330, 2023-01-24 DAE4 Sn1671, 2023-05-25 Scans Setup Area Scan Zoom Scan Grid Extents [mm] 60.0 x 180.0 22.0 x 22.0 x 22.0 Grid Steps [mm] 10.0 x 10.0 2.9 x 2.9 x 1.2 Sensor Surface [mm] 3.0 1.4 Measurement Results Area Scan Zoom Scan psSAR1g [W/Kg] 0.656 0.767 psSAR10g [W/Kg] 0.172 0.176 Power Drift [dB] -0.10 M2/M1 [%] 61.4 Dist 3dB Peak [mm] 4.5 …
