A3LSO32UOLCD Monitor

8 Block Diagrams 8-1 8 Block Diagram h This Document can not be used without Samsung's authorization.

FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Page : 1 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. EMC Test Report According to FCC Part 15 Subpart B Project No. LBE050810 Equipment under Test Address 416 Maetan3-Dong,Yeongtong-Gu,Suwon-Si,Gyeonggi-Do, Korea,443-742 Product Name LCD Monitor Model Name SO32UO Manufacturer SAMSUNG Brand Name SAMSUNG Variant Model See Page 3 FCC ID A3LSO32UO Date of Test April 11 , 2005 ~ April 21, 2005 Issued Date April 22, 2005 Name/Position Signature Tested by Tae Young, Jang Test Engineer Reviewed by No Cheon, Park Manager of EMC Lab. Authorized by Seung Kyu, Cha Chief of EMC Lab. 1. This test reports does not constitute an endorsement by NIST/NVLAP or U.S Government. 2. This test report is to certify that the tested device properly complies with the requirements of FCC Rules and Regulations Part 15 Subpart B Unintentional Radiators. All tests necessary to show compliance to the requirements were and these results met the specifications requirement. This laboratory is registered by the NIST/NVLAP, U.S.A. The test reported herein have been performed in accordance with its terms of registration. NVLAP LAB CODE 200623-0 Page : 2 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Table of Contents 1. General Information 1.1 Basic Information related Product 1.2 Detail Information related Product 1.3 Test Configuration 1.4 EUT Operating Conditions 1.5 Applied Standard 1.6 Test Facility 2. Summary of Test Results 3. Description of individual tests 3.1 Conducted Emission 3.2 Radiated Emission 4. Appendix A 4.1 Test Photography 4.2 EUT Photography Page : 3 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1. General Information 1.1 Basic Information related Product Applicant Samsung Electronics Co. Ltd Model name SO32UO Applicant Address 416 Maetan3- Dong, Yeongtong-Gu, Suwon-Si, Gyeonggi-Do, Korea, 443-742 Contact Person Chang Seub, Eum Kind of product LCD Monitor Valiant list Manufacturer Samsung Electronics Co. Ltd 1.2 Detail Information related Product Specification Image Viewable Image Size 32 Inch Maximum Resolution 1360 X 768@60Hz Horizontal Frequency 60KHz Vertical Frequency 75Hz 1.3 Operating Mode and Condition The system was configured for testing in typical fashion use. Cables were attached to each of the available I/O Ports. Where applicable, peripherals were attached to the I/O cables. The mode of operation utilized for testing was selected to best simulate typical EUT use. - PC Analog In 1.4 Equipment Modifications No equipment modifications were required. 1.5 Test Configuration Page : 4 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Used EUT and Peripherals Seq Device Model Name Serial # Maker FCC ID A LCD Monitor SO32UO - SAMSUNG A3LSO32UO B Personal Computer M6050 812092FRCO1963SAMSUNG DoC C Printer ML-1750 BABX822977N SAMSUNG A3LML-1750 D PS/2 Keyboard TKB-3000 C0412158564 SAMSUNG DoC E USB Mouse M-S48a 334648-007 SAMSUNG JNI201213 F Head Set Natural - - - Connect Cable Length [m] Shielded [Y/N] Remark 1 Power 1.8 No To the Mains 2 Power 1.8 No To the Mains 3 Power 1.8 No To the Mains 4 Monitor (PC Video Input) 1.7 Yes To the PC 5 Parallel (Printer) 1.8 Yes To the PC 6 PS/2 (Keyboard) 1.5 No To the PC 7 USB (Mouse) 1.5 No To the PC 8 Component In 1 1.5 No Termination 9 Component In 2 1.5 No Termination 10 Audio In 1 1.5 No Termination 11 Audio In 2 1.5 No Termination 12 S-video In 1.5 No Termination 13 AV In 1.5 No Termination 14 Audio Out 1.5 No Termination 15 PC audio in 1.5 No To the PC 16 Head Set 1.5 No To the EUT 17 DVI Audio In 1.5 No Termination 18 HDMI In 1.5 No Termination Port Description Page : 5 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Block Diagram Page : 6 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 1.6 Applied Standards List Applied Standards Test Procedure FCC Part15 Subpart B ANSI C63.4 : 2003 1.7 Test Facility General Information The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR 16-1, 16-2. This EMC Testing Lab. is accredited by Korea Laboratory Accreditation Scheme(KOLAS) which signed the International Laboratory Accreditation Cooperation (ILAC) Mutual Recognition Arrangement (MRA) for the above test item(s) and test method(s). This Lab. is operated as testing laboratory in accordance with the requirements of ISO/IEC 17025:1998. Accreditation and Listing Uncertainty Test Item Expanded Uncertainty Radiated Emission ±5.09 Conducted Emission ±1.64 (According to NAMAS Pub.NIS81) Page : 7 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 2. Summary of Test Results Result : PASS The equipment under test(EUT) has been found to comply with the applied standards. Test Name Applied Standard Result Electromagnetic Emission Test 3.1 Conducted Emission FCC Part15 Subpart B Complied 3.2 Radiated Emission FCC Part15 Subpart B Complied Page : 8 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 3. Description of Individual Tests…

Text truncated - open the document above for the full version.

Page : 13 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. 4. Appendix A 4.1 Test Photography Picture 1. Conducted Emission (Front view) Picture 2. Conducted Emission (Rear view) Page : 14 of 15 Samsung EMC Testing and Certification Laboratory Project NO. :LBE050810 This report shall not be reproduced except in full, without the written approval of SEC EMC Testing laboratory. Picture 3. Radiated Emission (Front view) Picture 4. Radiated Emission (Rear view)
