A3LSPHA400Dual-Band Analog/PCS Phone & GPS Receiver
Samsung Electronics Co Ltd
Click to zoom
Application Details
- Equipment Class
- PCE - PCS Licensed Transmitter held to ear
- Date of Grant
- Jan 10, 2002
- Application Purpose
- Original Equipment
- Date of Application
- Oct 08, 2001
- Equipment Note
- Dual-Band Analog/PCS Phone & GPS Receiver
- Frequency Range
- 1851.25000000 - 1908.75000000
- Company
- Samsung Electronics Co Ltd
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Samsung Electronics - Proprietary and Confidential SPH User β s Manual Samsung Electronics SPH-A400 UserΓs Manual Samsung Electronics 2 Table of Contents 1.Getting Started with Sprint PCS Service ........................7 _ Getting started with Sprint PCS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..7 _ What you should have handy when you call . . . . . . . . . . . . . . . . . . . . . . . . . . .8 _ Setting up your Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 _ Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 _ Understanding this User Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 2.Understanding Roaming ................................................10 _ Understanding how Roaming works . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . .10 _ Setting your PhoneΓs Roam mode . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .11 _ Setting an Alert when roaming charges apply (Call Guard) Γ. . . . . . . . . . . . .11 _ Setting the Time and Date in Analog mode . . . . . . . . . . . . . . . ... . . . . . . . . . .12 3.Getting to know your Sprint PCS Phone β’....................13 _ Front view of Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 _ Highlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 _ Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 _ Viewing the display screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . .15 _ Turning your phone ON and OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 _ Using Key Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 _ Using the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 4.Making and Answering Calls .........................................19 _ Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 _ Answering calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 _ Missed call notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 _ Dialing options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 _ In-Call options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 _ Incoming call notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 _ End-of-Call options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 _ Saving a Phone number . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 _ Finding a Phone number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 _ Dialing and saving Phone numbers with Pauses .. . . . . . . . . . . . . . . . . . . . . .23 _ Four-Digit dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 _ Calling emergency numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 3 _ Dialing from the Internal Phone Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 _ Using One-Touch/Two-Touch/Three-Touch Speed Dialing . . . . . . . . . . . . .24 _ Displaying your Phone number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 5.Navigating through menus and entering text ...................26 _ Menu navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 _ Working within the menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 _ Viewing the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 _ Entering text, numbers or symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 _ Selecting a text input mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 _ Alphabetical text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 _ Numbers and symbol entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 _ T9Γ text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 6.Adjusting Volume.............................................................29 _ Changing Ringer Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 _ Silencing (or Muting) the Ringer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 _ Adjusting Volume during a conversation . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 _ Muting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 7.Using Sprint PCS Service Features ..................................31 _ Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 _ Responding to Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 _ Three-Way Calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 _ Forwarding your calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 8.Managing Messaging .....................................................33 _ Setting up Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 _ Message types . . . . . . . . . . . . .β¦
Text truncated - open the document above for the full version.
Attestation Statements
October 1, 2001 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.: A3LSPHA400 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, Parts list, Tune-up Procedure, Operational and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market.
Attestation Statements
April 2, 2001 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.862. Sincerely, Wallace Oh Engineering Manager Samsung Electronics America October 1, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC E911 REQUIREMENTS PER Β§22.921 Gentlemen: Samsung Electronics Co., Ltd. hereby certifies that the analog cellular telephone (FCC ID: A3LSPHA400), using the Automatic A/B Roaming β Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a β9-1-1β call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned. AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Portable Cellular Telephone (FCC ID:A3LSPHA400) is so designed that it complies with all the requirements for ESN protection specified in Sec.22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. October 1, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSPHA400 Users Manual RF Exposure Warning Statement Gentlemen: Samsung Electronics Co., Ltd., hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact me or PCTEST Lab at (410) 290-6652.
Cover Letter(s)
November 7, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG Electronics Co., Ltd. FCC ID: A3LSPHA400 Part 24/22 Certification Gentlemen: Submitted herewith, on behalf of SAMSUNG Electronics Co., Ltd., is an application for Part 24/22 Certification of the following Dual-Band Analog/PCS Phone + GPS Receiver: FCC ID: A3LSPHA400 TRADE/MODEL(s): SAMSUNG SPH-A400 EUT TYPE: Dual-Band Analog/PCS Phone (AMPS/CDMA) + GPS Receiver Tx Freq. Range(s): 824.04 β 848.97 MHz (AMPS) 1851.25 β 1908.75 MHz (PCS CDMA) Max. RF Output Power: 0.337 W ERP AMPS (25.273 dBm) / 0.345 W EIRP PCS CDMA (25.381 dBm) Max. SAR Measurement: 1.34mW/g (1g) AMPS Brain SAR; 0.599 mW/g (1g) AMPS Body SAR 1.33W/g (1g) PCS CDMA Brain SAR; 0.727mW/g (1g) PCS CDMA Body SAR Attached is the applicantβs Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 compliance statement, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SAMSUNG Electronics Co., Ltd.
Cover Letter(s)
December 3, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSPHA400 731 Confirmation No.: EA102690 Correspondence Reference No.: 21386 Request for Tech. Info.: 11/30/01 Dear Martin: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated November 30, 2001. 1. We would like to confirm that all exhibits before 11/21/01 filing can be deleted. Furthermore, we would like to confirm that the test report that was submitted on 11/21/01 is the one to be used for evaluation. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.
Cover Letter(s)
December 3, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSPHA400 731 Confirmation No.: EA102690 Correspondence Reference No.: 21386 Request for Tech. Info.: 11/30/01 Dear Martin: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated November 30, 2001. 1. We would like to confirm that all exhibits before 11/21/01 filing can be deleted. Furthermore, we would like to confirm that the test report that was submitted on 11/21/01 is the one to be used for evaluation. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.
Cover Letter(s)
January 8, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSPHA400 731 Confirmation No.: EA102690 Correspondence Reference No.: 21432 Request for Tech. Info.: 1/8/02 Dear Martin: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated January 08, 2002. EMC NOTE: We would like to confirm that all exhibits before 11/21/01 filing can be deleted. Furthermore, we would like to confirm that the test report that was submitted on 11/21/01 is the one to be used for evaluation. 1. EXAMPLE: Channel 0991 AMPS mode 2 nd harmonic (1648.08MHz). The receive analyzer reading at 3 meters with the EUT on the turn table was β 85.8dBm. The gain of the substituted antenna is 6.1 dBd. The signal generator connected to the substituted antenna terminals is adjusted to produce a reading of 85.8 dBm on the receive analyzer. The cable loss of the cable between the signal generator and the terminals of the substituted antenna is 1.0dB at 1648.08MHz. So 5.1dB is added to the signal generator reading of β46.77 dBm yielding β41.67 dBm. The fundamental ERP was 25.273 dBm so this harmonic was 25.273 dBm so this harmonic was 25.273 dBm β (-44.17 dBm) = 66.9 dBc. 2. The SPHA400 has E911 Phase II GPS capability but has not yet enable this feature to the phone. Once this feature is incorporated into the phone, a Class I or Class II will be filed accordingly. 3. Please find the attached plot showing compliance with Section 22.917(f) SAR 1. Please note that the liquid depth of the tissue simulating materials of 15cm is noted of the summary pages of the SAR report. 2. In the case of brain SAR in the PCS band we used a recipe with a conductivity of 1.6 S/m instead of 1.4 S/m as specified in supplement C. Please note that the dielectric constant is with in the 5% specified. In this case the SAR value is directly proportional is with the conductivity. The overestimation of SAR should be approximately 14%. 3. Note that the ambient and liquid temperatures are on the attached SAR summary sheets. 4. A slim battery is not available at this time. When the slim battery becomes available, a Class I or Class II change testing will be performed. 5. Please find the calculated SAR values using the measured conductivity and permittivity. 6. We confirm that the phantom thickness is 2.0mm 7. Please find the attached revised page 10 of the SAR test report showing diagrams of the SAR test configurations in the tilt and touch positions (Under Grid Overlay per CRN 21432 Jan 8). We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.
External Photos
Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA)
ID Label/Location Info
Β© 2001PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER Β§ Β§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) SAMSUNG ELECTRONICS CO., LTD. MODEL NO: SPH-A400 FCC ID: A3LSPHA400 MADE IN KOREA SAMSUNG ELECTRONICS CO., LTD
Internal Photos
Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) Β© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHA400 (Model: SPH-A400) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA)
Operational Description
Confidential SPH-A400 DualBandTri-Mode '2001.09. 3.AntennaRadiationPatten Mobile Antenna Performance Test -180-90090180 5 0 -5 -10 -15 -20 Unit : dBi Model : SPH-A400 Serial : USPCSAZFCEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1850 Date : 2001.09.21 Max(X/Y) : -166/-1.89 Min(X/Y) : 59/-5.86 Average : -3.35 Deviation : 3.97 Model : SPH-A400 Serial : USPCSAZFCEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1880 Date : 2001.09.21 Max(X/Y) : -168/-2.84 Min(X/Y) : 59/-6.3 Average : -4.21 Deviation : 3.46 Model : SPH-A400 Serial : USPCSAZFCEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1910 Date : 2001.09.21 Max(X/Y) : -152/-3.28 Min(X/Y) : 75/-7.03 Average : -4.74 Deviation : 3.75 Model : SPH-A400 Serial : USPCSAZFCEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1930 Date : 2001.09.21 Max(X/Y) : -150/-3.15 Min(X/Y) : 71/-7.59 Average : -4.83 Deviation : 4.44 Model : SPH-A400 Serial : USPCSAZFCEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1960 Date : 2001.09.21 Max(X/Y) : -44/-4.45 Min(X/Y) : 75/-9.65 Average : -6.42 Deviation : 5.2 Model : SPH-A400 Serial : USPCSAZFCEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1990 Date : 2001.09.21 Max(X/Y) : -48/-5.22 Min(X/Y) : 102/-11.57 Average : -7.86 Deviation : 6.35 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -5.35 -2.78 Value(dB) -5.78 -3.80 Value(dB) -6.82 -4.17 Value(dB) -7.19 -3.94 Value(dB) -9.30 -4.82 Value(dB) -11.09 -5.54 Mobile Antenna Performance Test -180-90090180 5 0 -5 -10 -15 -20 Unit : dBi Model : SPH-A400 Serial : USPCSAZFOEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1850 Date : 2001.09.21 Max(X/Y) : 176/-1.04 Min(X/Y) : -58/-8.63 Average : -4.82 Deviation : 7.59 Model : SPH-A400 Serial : USPCSAZFOEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1880 Date : 2001.09.21 Max(X/Y) : 179/-1.87 Min(X/Y) : -59/-8.96 Average : -5.3 Deviation : 7.09 Model : SPH-A400 Serial : USPCSAZFOEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1910 Date : 2001.09.21 Max(X/Y) : -178/-2.62 Min(X/Y) : -62/-8.37 Average : -5.53 Deviation : 5.75 Model : SPH-A400 Serial : USPCSAZFOEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1930 Date : 2001.09.21 Max(X/Y) : -174/-2.83 Min(X/Y) : -62/-7.5 Average : -5.36 Deviation : 4.67 Model : SPH-A400 Serial : USPCSAZFOEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1960 Date : 2001.09.21 Max(X/Y) : -162/-4.41 Min(X/Y) : -70/-7.62 Average : -6.48 Deviation : 3.21 Model : SPH-A400 Serial : USPCSAZFOEX Opt. : PATTERN Protocol : US PCS-V Freq. : 1990 Date : 2001.09.21 Max(X/Y) : -143/-5.99 Min(X/Y) : 119/-9.83 Average : -7.7 Deviation : 3.84 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -3.71 -6.98 Value(dB) -4.32 -7.84 Value(dB) -5.20 -7.15 Value(dB) -5.41 -6.69 Value(dB) -7.20 -7.03 Value(dB) -9.22 -7.49 Mobile Antenna Performance Test -180-90090180 5 0 -5 -10 -15 -20 Unit : dBi Model : SPH-A400 Serial : USPCSAZFCRE Opt. : PATTERN Protocol : US PCS-V Freq. : 1850 Date : 2001.09.21 Max(X/Y) : -76/-6.09 Min(X/Y) : 56/-23.74 Average : -12.76 Deviation : 17.65 Model : SPH-A400 Serial : USPCSAZFCRE Opt. : PATTERN Protocol : US PCS-V Freq. : 1880 Date : 2001.09.21 Max(X/Y) : -83/-5.71 Min(X/Y) : 136/-24.61 Average : -12.56 Deviation : 18.9 Model : SPH-A400 Serial : USPCSAZFCRE Opt. : PATTERN Protocol : US PCS-V Freq. : 1910 Date : 2001.09.21 Max(X/Y) : -87/-6.05 Min(X/Y) : 143/-26.11 Average : -12.74 Deviation : 20.06 Model : SPH-A400 Serial : USPCSAZFCRE Opt. : PATTERN Protocol : US PCS-V Freq. : 1930 Date : 2001.09.21 Max(X/Y) : -72/-5.76 Min(X/Y) : 152/-24.27 Average : -11.95 Deviation : 18.51 Model : SPH-A400 Serial : USPCSAZFCRE Opt. : PATTERN Protocol : US PCS-V Freq. : 1960 Date : 2001.09.21 Max(X/Y) : -76/-6.16 Min(X/Y) : 152/-20.92 Average : -11.89 Deviation : 14.76 Model : SPH-A400 Serial : USPCSAZFCRE Opt. : PATTERN Protocol : US PCS-V Freq. : 1990 Date : 2001.09.21 Max(X/Y) : -68/-8.19 Min(X/Y) : 146/-25.07 Average : -14.34 Deviation : 16.88 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -19.39 -6.29 Value(dB) -17.19 -5.75 Value(dB) -15.48 -6.19 Value(dB) -13.75 -6.19 Value(dB) -13.93 -6.34 Value(dB) -16.77 -8.58 Mobile Antenna Performance Test -180-90090180 5 0 -5 -10 -15 -20 Unit : dBi Model : SPH-A400 Serial : USPCSAZFORE Opt. : PATTERN Protocol : US PCS-V Freq. : 1850 Date : 2001.09.21 Max(X/Y) : -29/-5.67 Min(X/Y) : 110/-15.26 Average : -9.46 Deviation : 9.59 Model : SPH-A400 Serial : USPCSAZFORE Opt. : PATTERN Protocol : US PCS-V Freq. : 1880 Date : 2001.09.21 Max(X/Y) : -24/-5.4 Min(X/Y) : 114/-17.88 Average : -9.79 Deviation : 12.48 Model : SPH-A400 Serial : USPCSAZFORE Opt. : PATTERN Protocol : US PCS-V Freq. : 1910 Date : 2001.09.21 Max(X/Y) : -25/-5.89 Min(X/Y) : 118/-23.07 Average : -11.39 Deviation : 17.18 Model : SPH-A400 Serial : USPCSAZFORE Opt. : PATTERN Protocol : US PCS-V Freq. : 1930 Date : 2001.09.21 Max(X/Y) : -32/-5.55 Min(X/Y) : 118/-28.58 Average : -12.29 Deviation : 23.03 Model : SPH-A400 Serial : USPCSAZFORE Opt. : PATTERN Protocol : US PCS-V Freq. : 1960 Date : 2001.09.21 Max(X/Y) : -28/-6.1 Min(X/Y) : 122/-51.92 Average : -13.95 Deviation : 45.82 Model : SPH-A400 Serial : USPCSAZFORE Opt. : PATTERN Protocol : US PCS-V Freq. : 1990 Date : 2001.09.21 Max(X/Y) : -24/-7.73 Min(X/Y) : 118/-34.79 Average : -15.24 Deviation : 27.06 Mark 1 Mark 2 Degree 90.00 -90.00 Value(dB) -13.73 -7.76 Value(dB) -15.50 -7.28 Value(dB) -18.84 -8.04 Value(dB) -19.20 -8.16 Value(dB) -19.60 -9.07 Value(dB) -21.40 -11.16 Mobile Antenna Performance Test -180-90090180 5 0 -5 -10 -15 -20 Unit : dBi Model : SPH-A400 Serial : USPCSE1FCEX Opt. : PATTERN Protocol : US PCS-H Freq. : 1850 Date : 2001.09.21 Max(X/Y) : 75/-1.88 Min(X/Y) : -140/-21.09 Average : -8.35 Deviation : 19.21 Model : SPH-A400 Serial : USPCSE1FCEX Opt. : PATTERN Protocol : US PCS-H Freq. : 1880 Date : 2001.09.21 Max(X/Y) : 71/-3.25 Min(X/Y) : -133/-23.86 Average : -9.93 Deviation : 20.61 Model : SPH-A400 Serial : USPCSE1FCEX Opt. : PATTERN Protocol : US PCS-H Freq. : 1910 Date : 2001.09.21 Max(X/Y) : 71/-3.18 Min(X/Y) : -129/-32.38 Average : -9.86 Deviation : 29.2 Moβ¦
Text truncated - open the document above for the full version.
RF Exposure Info
SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.938 mW/g, SAR (10g): 0.653 mW/g SAMSUNG Dual-Band Phone Model:SPH-A400 FM Mode, Ch.0991 [824.04MHz]; Extended Battery Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/06/2001 SAR Tot [mW/g] 9.10E-2 2.73E-1 4.55E-1 6.37E-1 8.19E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.07 mW/g, SAR (10g): 0.747 mW/g SAMSUNG Dual Band Phone Model:SPH-A400 FM Mode, Ch.0991 [824.04MHz]; Extended Battery Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/06/2001 SAR Tot [mW/g] 1.03E-1 3.10E-1 5.17E-1 7.24E-1 9.31E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 1.19 mW/g, SAR (10g): 0.832 mW/g SAMSUNG Dual Band Phone Model:SPH-A400 FM Mode, Ch.0383 [836.49MHz]; Extended Battery Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/06/2001 SAR Tot [mW/g] 1.15E-1 3.46E-1 5.76E-1 8.06E-1 1.04E+0 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.996 mW/g, SAR (10g): 0.690 mW/g SAMSUNG Dual Band Phone Model:SPH-A400 FM Mode, Ch.0383 [836.49MHz]; Extended Battery Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/06/2001 SAR Tot [mW/g] 9.68E-2 2.90E-1 4.84E-1 6.78E-1 8.71E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 1.34 mW/g, SAR (10g): 0.931 mW/g SAMSUNG Dual Band Phone Model:SPH-A400 FM Mode, Ch.0799 [848.97MHz]; Extended Battery Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/06/2001 SAR Tot [mW/g] 1.30E-1 3.90E-1 6.50E-1 9.10E-1 1.17E+0 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.971 mW/g, SAR (10g): 0.673 mW/g SAMSUNG Dual Band Phone Model:SPH-A400 FM Mode, Ch.0799 [848.97MHz]; Extended Battery Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/06/2001 SAR Tot [mW/g] 9.56E-2 2.87E-1 4.78E-1 6.69E-1 8.60E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 1.20 mW/g, SAR (10g): 0.832 mW/g SAMSUNG Dual Band Phone Model:SPH-A400 FM Mode, Ch.0799 [848.97MHz]; Standard Battery Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/06/2001 SAR Tot [mW/g] 1.18E-1 3.53E-1 5.88E-1 8.23E-1 1.06E+0 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.891 mW/g, SAR (10g): 0.618 mW/g SAMSUNG Dual Band Phone Model:SPH-A400 FM Mode, Ch.0799 [848.97MHz]; Standard Battery Conducted Power = 26.5dBm; Left Head Phantom, Cheek/Touch position Test Date -- 11/06/2001 SAR Tot [mW/g] 8.71E-2 2.61E-1 4.36E-1 6.10E-1 7.84E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- In; Crest Factor 1.0 SAR (1g): 0.519 mW/g, SAR (10g): 0.360 mW/g SAMSUNG DualBand Phone Model:SPH-A400 FM Mode, Ch.0991 [824.04MHz]; Extended Battery Conducted Power = 26.5dBm; Left Head Phantom, Ear/15degree Tilt position Test Date -- 11/06/2001 SAR Tot [mW/g] 5.23E-2 1.56E-1 2.60E-1 3.64E-1 4.68E-1 PCTEST Engineering Laboratory, Inc. SAMSUNG FCC ID:A3LSPHA400 -- FM Head SAR Generic Twin Phantom; Left Hand Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Brain: Ο = 0.90 mho/m Ξ΅ r = 41.5 Ο = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.889 mW/g, SAR (10g): 0.623 mW/g SAMSUNG DualBand Phone Model:SPH-A400 FM Modeβ¦
Text truncated - open the document above for the full version.
Contact Information
Applicant
Jenni Chun(General Manager)
Technical Contact
PCTEST Engineering Laboratory Inc.Randy Ortanez
[email protected]410-290-6652
6660-B Dobbin Road Β· Columbia, Maryland Β· United States
Non-Technical Contact
PCTEST Engineering Laboratory Inc.Randy Ortanez
[email protected]410-290-6652
Test Firm
PCTEST Engineering Laboratory, Inc.Randy Ortanez
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 3 | 24E | 1.85 GHz - 1.91 GHz | 345.00 mW | 1M25F9W | 0.000014 % |
