A3LSPHI300Dual-Band Analog/PCS Phone (AMPS/CDMA)

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Aug 28, 2001
Application Purpose: Original Equipment
Date of Application: Jul 16, 2001
Equipment Note: Dual-Band Analog/PCS Phone (AMPS/CDMA)
Frequency Range: 1851.25000000 - 1908.75000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 1.8 cm. from the body. To maintain compliance with FCC RF exposure requirements, use only belt-clips, holsters or similar accessories that maintain a 1.8 cm. separation distance between the user’s body and the back of the phone, including the antenna, whether extended or retracted. The use of third-party belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. WARNING! Read this information before using your phone

Attestation Statements

March 9, 2001 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.853(a) Sincerely, Wallace Oh Engineering Manager Samsung Electronics America July 9, 2001 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.:A3LSPHI300 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the ge neral public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. July 9, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC E911 REQUIREMENTS PER §22.921 Gentlemen: Samsung Electronics Co., Ltd. hereby certifies that the analog cellular telephone (FCC ID: A3LSPHI300), using the Automatic A/B Roaming – Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a “9-1-1” call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned. AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Portable Cellular Telephone (FCC ID:A3LSPHI300) is so designed that it complies with all the requirements for ESN protection specified in Sec.22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. July 9, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSPHI300 Users Manual RF Exposure Warning Statement Gentlemen: Samsung Electronics Co., Ltd., hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact me or PCTEST Lab at (410) 290-6652.

Cover Letter(s)

July 12, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG Electronics Co., Ltd. FCC ID: A3LSPHI300 Part 24/22 Certification Gentlemen: Submitted herewith, on behalf of SAMSUNG Electronics Co., Ltd., is an application for Part 24/22 Certification of the following Dual-Band Analog/PCS Phone: FCC ID: A3LSPHI300 TRADE/MODEL(s): SAMSUNG SPH-I300 EUT TYPE: Dual-Band Analog/PCS Phone (AMPS/CDMA) Tx Freq. Range(s): 824.04 — 848.97 MHz (AMPS) 1851.25 — 1908.75 MHz (PCS CDMA) Max. RF Output Power: 0.414 W ERP AMPS (26.173 dBm) / 0.258 W EIRP PCS CDMA (24.121 dBm) Max. SAR Measurement: 1.3968 mW/g (1g) AMPS Brain SAR; 1.4553 mW/g (1g) PCS Brain SAR 1.1554 mW/g (1g) AMPS Body SAR; 0.6382 mW/g (1g) PCS Body SAR Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 compliance statement, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SAMSUNG Electronics Co., Ltd.

External Photos

ID Label/Location Info

© 2001PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) MODEL NO: SPH-i300 FCC ID: A3LSPHI300 MADE IN KOREA

Internal Photos

© 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA) © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Analog/PCS Phone (AMPS/CDMA)

Parts List/Tune Up Info

SPH-I300(Dual-Band) CONFIDENTIAL Feb ruary 15, 2001 5. Test Commands &Test Procedure List SPH-I300(Dual-Band) CONFIDENTIAL Feb ruary 15, 2001 Test CommandTable To change the phone fromnormal mode to test mode, you should enter the following keys : Press [6 5 4 8 # 0 * 4 5 6 8 0] Command NoCommandSWNameDescription 001 002 003 004 005 006 007 008 009 010 011 012 013 014 015 016 017 018 020 021 022 023 024 025 026 027 028 029 030 031 032 033 034 035 036 037 038 039 040 041 042 043 044 045 T_SUSPEND_I T_RESTART_I T_SAVE_VAL_I T_GET _MODE_I T_SET_MODE_I T_WRITE_NV_I T_CARRI ERON_I T_CARRI EROF F_I T_L OADSYN_I T_P WRLEVEL_I T_RXMUT E_I T_RXUNMUTE_I T_T XMUTE_I T_T XUNM UTE_I T_VOC_ESEC_I T_STON_I T_STOFF_I T_L CD_CONTRAST_I T_T EST_SYS_I T_SNDPI NFO_I T_SNDNAM_I T_SNDVERSION_I T_SNDESN_I T_BACKLIGHT_ON_I T_BACKLIGHT_OFF _I T_L AMP _ON_I T_L AMP _OFF_I T_REBUI LD_I T_P LINE_I T_AUTOANSWER_I T_SATON_I T_SATOFF _I T_CDATA_I T_VOL UME_UP_I T_VOL UME_DOWN_I T_F M_TEST_I T_P CS_CH_FL ATNESS_BP _ON_I T_T XRAS_ADJ_BP_ON_I T_RXRAS_FL AT_AUTO_I T_RXRAS_FL ATNESS_I T_DTMFON_I T_DTMFOFF _I T_COM PANDORON_I T_COM PANDOROF_ nter to test menu escape fromtest menu Save values i n e2promonly in auto t est Get mode CDMA/F MAUTOTEST Set mode CDMA/FMAUT OTEST Wri te the EEPROMitem turn on t he carrier turn off the carri er load the synthesizer for l ocking change RF power l evel mute rx audi o unmute rx audi o mute tx aud io unmute tx audio Echo Cancell er turn on ST turn off ST LCDContrast DBDMRoamad d Test System Send Product information 8 character Send NAMInformation Send Software Version Send ESN Backlight on Backlight off LAMP on LAMP off Rebuildi ng EEPROM Product li le information Auto Answer turn on SAT turn off SAT continuously send TXControl data Electric Vol ume Up Electric Vol ume Down fmtest command PCS chnnel flatness BP ON RXRAS TABLEADJUST adj TXRAS from8924C adj TXFLATNESS from8924C turn on DTMF turn off DTMF turn on compandor turn off compandor SPH-I300(Dual-Band) CONFIDENTIAL Feb ruary 15, 2001 CommandNoCommandSWNameDescription 046 047 048 049 050 051 052 053 054 055 056 057 058 059 060 061 062 063 064 065 066 067 068 069 070 071 072 073 074 075 076 077 078 079 080 081 082 083 084 085 086 087 088 089 090 091 092 093 094 T_FM_VCLINE_I T_FM_AUD_GAIN_I T_VIBRATOR_ON_I T_VIBRATOR_OFF_I T_BATT_TYPE_I T_CDMA_TEST_I T_HW_VERSION_I T_SET_PDM1_I T_SET_PDM2_I T_EXT_AUDIO_I T_ALLPATH_I T_MIC_ON_I T_MIC_OFF_I T_SIO_MODE_I T_FM_TX_GAIN_I T_FM_RX_GAIN_I T_DTMF_VOL_TX_I T_TX_LIMITER_I T_FM_SAT_LEVEL_I T_FM_FREQ_SGAIN_I T_FM_ST_GAIN_I T_READ_BATT_I T_VBATT1_I T_VBATT2_I T_WRITE_BATT_I T_CDMA_TXADJ_I T_FM_TXADJ_I T_SET_PA_R_I T_TXRAS_ADJ_I T_READ_RSSI_I T_WRITE_RSSI_I T_READ_TEMP_I T_RXRAS_AUTO_I T_BUZZER_ON_I T_BUZZER_OFF_I T_VOC_PCMLPON_I T_VOC_PCMLPOFF_I T_BYPASS_ON_I T_BYPASS_OFF_I T_SPEAKER_ON_I T_SPEAKER_OFF_I T_FM_LOOP_TEST_I T_TRK_ADJ_I T_CDTRK_ADJ_I T_HW_CHANFLAT_I T_SW_CHANFLAT_I T_FM_TX_PWR_I T_CH_FLATNESS_I T_RXRAS_ADJ_I Enetr FMvoice state FMaudio gain activate a vibrator inactivate a vibrator Battery Type cdma test command HWversion SET PDM1 SET PDM2 External Audio Path On/Of tune on the all audio path mute MIC Path Unmute MIC Path SIOMode FMTx Audio Gain Control FMRx Audio Gain Control FMTx DTMF Gain Control FMTx Limiter Gain Control FMTx SAT level Control FMTx Master Gain Control FMTx ST Gain Control Saved Lowbattery value read set the lowbattey position in the standby set the lowbattey position in the talking write a BATT sets tx_agc_adj for cdma mode sets tx_agc_adj for fmmode sets PA R1,R0 range bits TX RAS TABLE ADJUST (16 POINT) read a RSSI write a RSSI read a TEMP adj RXRAS from8924C Buzzer on Buzzer off turn on to play a PCMLOOP BACK turn off to play a PCMLOOP BACK turn on the bypass mode turn off the bypass mode turn onthe speaker path turn off the speaker path FMloop back TRK LOCAL ADJUST CDMA TRKLOCAL ADJUST HWChanflat SWChanflat setting the volume for Power Level 2-7 Tx Pwr : 23dBm RX RAS adj = RXRAS offset array SPH-I300(Dual-Band) CONFIDENTIAL Feb ruary 15, 2001 Command NoCommand SWNameDe scription 095 096 097 098 099 100 101 102 103 104 105 106 107 T_DATASVC_ON_I T_DATASVC_OFF_I T_PCS_CH_FLATNESS_I T_PCS_CH_MAX_MIN_I T_SND_GAIN_I T_MIC_GAIN_I T_CDMA_EAR_GAIN_I T_VOC_CDMA_UNITY_GAIN_I T_BELL_TEST_I T_PDA_DIAG_I T_REDIRECTION_TEST_I T_DEL_ALL_VMEMO_DIAL_I T_MAX_I DATASVC ON DATASVC OFF PCS channel flatness Edge Channel Max/Min Power Code SNDGain MIC Gain CODEC Default Gain VOCODER CDMA Gain SOUNDTEST PDA DIAG REDIRECTIONTEST DEL_ALL VMEMODIAL Compensated value for Most PWR = NULL! SPH-I300(Dual-Band) CONFIDENTIAL Feb ruary 15, 2001 List of Equipment - DCPower Supply - Test Jig - Test Cable - CDMAMobile Station Test Set HP8924C, HP83236A, CMD-80, etc - SpectrumAnalyzer(include CDMATest Mode) HP8596E Configurationof Test CAUTION: The test jig and data cable has a voltage drop of 0.15Vat FMMax power output, you'd better set the DCpower supply is 3.9Vfor normal test condition. (Nominal voltage of battery is 3.9Vat cellular phone) SPH-I300(Dual-Band) CONFIDENTIAL Feb ruary 15, 2001 TEST CABLE DESCRIPTION FOR SPH-I300 1. TESTCABLE 2. TESTCABLECONNECTIONS 1MHC172 2 RF CABLE (1.4dB Loss for AMPS, 2.1dBLoss for PCS) 3BNCCONNECTOR(RF) 4PLUG CONNECT TO SPH-I30 0 5DATACABLE 6Dsub 25PINCONNECTOR(DATA) SPH-I300(Dual-Band) CONFIDENTIAL Feb ruary 15, 2001 3. Dsub 25 PINCONNECTORPINDESCRIPTION(TESTCABLE1, BACKSIDE) DATA DESCRIPTION Dsub CONN. PINNO. DATA DESCRIPTION Dsub CONN. PINNO. V_F12,21DP_RX_DATA8 DGND2,4,6,13,19HP_PWR9 BATT15,16,22RI10 C_F3,20CD11 TX_AUDIO5RTS14 DP_TX_DATA7CTS17 RX_AUDIO1DTR18 4. CONVERSIONTABLEOFFREQUENCYvs CHANNEL TYPECHANNELCONVERSIONEQUATIONREMARK TX FREQUENCY 1 N 799 990 N 1023 F=0.03 N+ 825.00 F=0.03 (N-1023) + 825.00 N; CHNUMBER F; FREQUENCY (AMP) RX FREQUENCY 1 N 799 990 N 1023 F=0.03 N+ 870.00 F=0.03 (N-1023) + 870.00 TX FREQUENCY 0 N 1199F=0.05 N+ 1850.00 N; CHNUMBER F; FREQUENCY (PCS) RX FREQUENCY 0 N 1199F=0.05 N+ 1930.00 SPH-I300(Dual-Band) CONFIDENTIAL Feb ruar…

Text truncated - open the document above for the full version.

RF Exposure Info

© 2001 PCTEST Engineering Lab., Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: June 20-26, 2001 416 Maetan-3 Dong, Paldal-Ku Test Report S/N: SAR.210611364.A3L Suwon City Kyungki-Do 441-742, KOREA Test Site: PCTEST Lab, Columbia, MD USA Attn: Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) FCC ID A3LSPHI300 APPLICANT SAMSUNG Electronics Co., Ltd. EUT Type: Dual-Band Analog/PCS Phone (AMPS/CDMA) Tx Frequency: 824.04 — 848.97 MHz (AMPS) 1851.25 — 1908.75 MHz (PCS CDMA) Rx Frequency: 869.04 — 893.97 MHz (AMPS) 1931.25 — 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.414W ERP AMPS (26.173 dBm) 0.258W EIRP PCS CDMA (24.121 dBm) Trade Name/Model(s): SAMSUNG SPH-I300 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) Application Type: Certification FCC Rule Part(s): §2.1093; ET Docket 96.326 Maximum SAR: 1.3968 W/kg AMPS Brain SAR; 1.1554 W/kg AMPS Body SAR 1.4553 W/kg PCS Brain SAR; 0.6382 W/kg PCS Body SAR This wireless portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and has been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report) I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210611364.A3L Test Report S/N: SAR.210611364.A3L SAR Measurement Report Test Dates: JUNE 20-26, 2001 FCC Part 22/24 Certification Table of Contents 1.1 SCOPE ........................................................................................................... 1 2.1 INTRODUCTION ............................................................................................ 2 3.1 SAR MEASUREMENT SET-UP ..................................................................... 3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM........................................................ 4 5.1 E-field PROBE CALIBRATION PROCESS ................................................... 5 6.1 PHANTOM AND EQUIVALENT TISSUES..................................................... 7 7.1 SYSTEM SPECIFICATIONS .......................................................................... 8 8.1 MEASUREMENT PROCESS ......................................................................... 9 9.1 TEST POSITION OF THE PHONE............................................................... 10 10.1 BODY-WORN TEST SETUP...................................................................... 11 11.1 ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS ..................................... 12 12.1 MEASUREMENT UNCERTAINTIES.......................................................... 13 13.1 SAR TEST DATA SUMMARY....................................................................14 14.1 SAR TEST EQUIPMENT............................................................................ 18 15.1 CONCLUSION............................................................................................ 19 Test Report S/N: SAR.210611364.A3L SAR Measurement Report Test Dates: June 20-26, 2001 FCC Part 22/24 Certification SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) © 2001 PCTEST Lab Dual-Band Analog/PCS Phone (AMPS/CDMA) 1 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant Name: SAMSUNG ELECTRONICS CO., LTD. Address: 416 Maetan-3 Dong, Paldal-Ku Suwon City, Kyungki-Do, 441-742, KOREA Attention: Mr. Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) • EUT Type: Dual-Band Analog/PCS Phone (AMPS/CDMA) • Trade Name: SAMSUNG • Model(s): SPH-I300 • FCC IDENTIFIER: A3LSPHI300 • Tx Frequency: 824.04 — 848.97 MHz (AMPS) 1851.25 — 1908.75 MHz (PCS CDMA) • Rx Frequency: 869.04 — 893.97 MHz (AMPS) 1931.25 — 1988.75 MHz (PCS CDMA) • Application Type: Certification • FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) • FCC Rule Part(s): § 2.1093, Docket 96-326 • Modulation(s): AMPS/CDMA • Max RF. Output Power: 0.414W ERP AMPS (26.173 dBm) 0.258W EIRP PCS CDMA (24.121 dBm) • Date(s) of Tests: June 20-26, 2001 • Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.210611364.A3L 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.210611364.A3L SAR Measurement Report Test Dates: June 20-26, 2001 FCC Part 22/24 Certification SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) © 2001 PCTEST Lab Dual-Band Analog/PCS Phone (AMPS/CDMA) 2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National …

Text truncated - open the document above for the full version.

RF Exposure Info

Peak SAR Location © 2001 PCTEST Lab SAMSUNG FCC ID: A3LSPHI300 (Model: SPH-I300) NVLAP Lab Code: 100431-0 Dual-Band Cellular/PCS Phone (AMPS/CDMA) 800 MHz Head SAR File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01062012_ZOOM.VLT Start : 20-Jun-101 03:38:02 pm End : 20-Jun-101 03:47:20 pm Radio Type : SAMSUNG Model Number : SPH-I300 Serial Number : 1 Frequency : 824.04 MHz Peak Trans. Pwr : 0.450 W Start Trans. Pwr: 0.450 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL-BAND PHONE CH 991 Conducted 26.5 dBm SAMSUNG DUAL-BAND PHONE - HEAD SAR Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = 0.000, Y = -2.000, Z = 0.000 (cm) Value = 20.996 Measured Values (volts) = 2.062E-002 1.644E-002 1.328E-002 1.101E-002 9.088E-003 7.057E-003 5.845E-003 4.678E-003 3.901E-003 3.453E-003 3.200E-003 3.066E-003 2.999E-003 2.873E-003 2.583E-003 2.129E-003 1.647E-003 1.160E-003 6.708E-004 4.305E-004 3.442E-004 Calc. Voltage @ Surface (Vs) = 0.0257 Voltage @ 1.00 cm (Vt) = 0.0110 Ave. Voltage (Vs+Vt)/2 = 0.0184 Ave. SAR over 1 g (mW/g) = 1.3393 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 mW/g -1012345 Z centimeters SAR Scan File : 01062012_ZOOM Start : 20-Jun-101 03:38:02 pm End : 20-Jun-101 03:47:20 pm SAMSUNG/SPH-I300/1;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01062012_ZOOM Start : 20-Jun-101 03:38:02 pm End : 20-Jun-101 03:47:20 pm SAMSUNG/SPH-I300/1;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.532 1.457 1.381 1.306 1.231 1.156 1.081 1.005 0.930 0.855 File : 01062012_ZOOM Start : 20-Jun-101 03:38:02 pm End : 20-Jun-101 03:47:20 pm SAMSUNG/SPH-I300/1;824.04MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.532 1.457 1.381 1.306 1.231 1.156 1.081 1.005 0.930 0.855 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01062017_ZOOM.VLT Start : 20-Jun-101 04:38:38 pm End : 20-Jun-101 04:47:58 pm Radio Type : SAMSUNG Model Number : SPH-I300 Serial Number : 1 Frequency : 824.04 MHz Peak Trans. Pwr : 0.450 W Start Trans. Pwr: 0.450 W Antenna Type : Helical Antenna Posn. : Out Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL-BAND PHONE CH 991 Conducted 26.5 dBm SAMSUNG DUAL-BAND PHONE - HEAD SAR Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = -0.250, Y = -1.500, Z = 0.000 (cm) Value = 18.382 Measured Values (volts) = 1.803E-002 1.440E-002 1.167E-002 9.882E-003 8.061E-003 6.648E-003 5.415E-003 4.544E-003 3.824E-003 3.388E-003 3.364E-003 3.402E-003 3.338E-003 3.291E-003 2.951E-003 2.800E-003 2.200E-003 1.709E-003 1.308E-003 1.263E-003 9.446E-004 Calc. Voltage @ Surface (Vs) = 0.0224 Voltage @ 1.00 cm (Vt) = 0.0099 Ave. Voltage (Vs+Vt)/2 = 0.0161 Ave. SAR over 1 g (mW/g) = 1.1781 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 mW/g -1012345 Z centimeters SAR Scan File : 01062017_ZOOM Start : 20-Jun-101 04:38:38 pm End : 20-Jun-101 04:47:58 pm SAMSUNG/SPH-I300/1;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01062017_ZOOM Start : 20-Jun-101 04:38:38 pm End : 20-Jun-101 04:47:58 pm SAMSUNG/SPH-I300/1;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.341 1.284 1.227 1.170 1.113 1.056 0.999 0.942 0.885 0.828 File : 01062017_ZOOM Start : 20-Jun-101 04:38:38 pm End : 20-Jun-101 04:47:58 pm SAMSUNG/SPH-I300/1;824.04MHz;W;Helical/Out; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.341 1.284 1.227 1.170 1.113 1.056 0.999 0.942 0.885 0.828 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01062013_ZOOM.VLT Start : 20-Jun-101 03:58:49 pm End : 20-Jun-101 04:08:08 pm Radio Type : SAMSUNG Model Number : SPH-I300 Serial Number : 1 Frequency : 836.49 MHz Peak Trans. Pwr : 0.450 W Start Trans. Pwr: 0.450 W Antenna Type : Helical Antenna Posn. : In Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL-BAND PHONE CH 383 Conducted 26.5 dBm SAMSUNG DUAL-BAND PHONE - HEAD SAR Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = 0.000, Y = -2.000, Z = 0.000 (cm) Value = 21.654 Measured Values (volts) = 2.153E-002 1.675E-002 1.368E-002 1.128E-002 9.311E-003 7.479E-003 5.997E-003 4.828E-003 4.072E-003 3.556E-003 3.409E-003 3.214E-003 3.109E-003 2.984E-003 2.639E-003 2.240E-003 1.756E-003 1.186E-003 7.464E-004 4.362E-004 3.494E-004 Calc. Voltage @ Surface (Vs) = 0.0270 Voltage @ 1.00 cm (Vt) = 0.0113 Ave. Voltage (Vs+Vt)/2 = 0.0191 Ave. SAR over 1 g (mW/g) = 1.3968 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 mW/g -1012345 Z centimeters SAR Scan File : 01062013_ZOOM Start : 20-Jun-101 03:58:49 pm End : 20-Jun-101 04:08:08 pm SAMSUNG/SPH-I300/1;836.49MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01062013_ZOOM Start : 20-Jun-101 03:58:49 pm End : 20-Jun-101 04:08:08 pm SAMSUNG/SPH-I300/1;836.49MHz;W;Helical/In; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.580 1.502 1.423 1.345 1.267 1.188 1.110 1.032 0.954 0.875 File : 01062013_ZOOM Start : 20-Jun-101 03:58:49 pm End : 20-Jun-101 04:08:08 pm SAMSUNG/SPH-I300/1;836.49MHz;W;Helical/In; …

Text truncated - open the document above for the full version.

RF Exposure Info

Test Report

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Parts 24/22 Certification SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: June 20-26, 2001 416 Maetan-3 Dong, Paldal-ku Test Report S/N: 24/22. 210611365.A3L Suwon City Kyungki-Do 441-742, KOREA Test Site: PCTEST Lab, Columbia MD Attn: Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) FCC ID A3LSPHI300 APPLICANT SAMSUNG ELECTRONICS CO., LTD. Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §24(E), §22(H), §2 EUT Type: Dual-Band Analog/PCS Phone (AMPS/CDMA) Trade Name/Model: SAMSUNG SPH-I300 Tx Frequency Range: 1851.25MHz — 1908.75MHz (PCS CDMA) / 824.04MHz — 848.97MHz (AMPS) Rx Frequency Range: 1931.25MHz — 1988.75MHz (PCS CDMA) / 869.04MHz — 893.97MHz (AMPS) Max. RF Output Power: 0.414 W ERP AMPS (26.173 dBm) / 0.258 W EIRP PCS CDMA (24.121 dBm) Max. SAR Measurement: 1.3968 mW/g (1g) AMPS Brain SAR; 1.4553 mW/g (1g) PCS Brain SAR 1.1554 mW/g (1g) AMPS Body SAR; 0.6382 mW/g (1g) PCS Body SAR Emission Designator(s): 40K0F8W, 40K0F1D, 1M25F9W This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordan…

Text truncated - open the document above for the full version.
