A3LSR8PWUWReceiver

The FCC logo is for Receiver( AA-SR8PWUW)

Samsung Electronics Co., Ltd. 129, Samsung-ro, Yeongtong-gu Suwon-si, Gyeonggi-do, 443-742 Korea Date: July 8, 2013 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA LETTER OF ATTESTATION FCC ID : A3LSR8PWUW/ IC ID : 649E-SR8PWUW Duty of nRF24LU1 chipset is restricted to use by software. (DUTY 1.3%(ON TIME : 0.2ms , ON+OFF TIME : 15ms)) Therefore the restricted functions can never be enabled in this device. This device supports only 1Mbps(GFSK) Mode of nRF24LU1+ chipset is restricted to use by software. Therefore the restricted functions can never be enabled in this device. The frequency range supported by the chipset is 2400 to 2525MHz , This Receiver can only operate from 2412-2472MHz, other channels are disabled by software. Sincerely, Name : John SC Lee Position: Manager Samsung Electronics Co., Ltd e-mail address: [email protected] Tel: +82-31-277-4784 Fax: +82-31-277-9247

Samsung Electronics Co., Ltd. 19 Chapin Rd., Building D Pine Brook, United States, NJ 07058 Date: June 12, 2013 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner;

Samsung Electronics Co., Ltd. 19 Chapin Rd., Building D Pine Brook, United States, NJ 07058 Date: June 12, 2013 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA LETTER OF AUTHORIZATION We, the undersigned, hereby authorize Harvey Sung of Digital EMC Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: A3LSR8PWUW including signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of Digital EMC Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Samsung Electronics Co., Ltd. Sincerely, Name : John SC Lee Position: Director Samsung Electronics Co., Ltd e-mail address: [email protected] Tel: +82-31-277-4784 Fax: +82-31-277-9247

Samsung Electronics Co., Ltd. 19 Chapin Rd., Building D Pine Brook, United States, NJ 07058 Date: June 12, 2013 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: A3LSR8PWUW To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Samsung Electronics Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Descripion PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics 4 Part Lists and Tune-Up Procedure SHORT-TERM 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Name : John SC Lee Position: Director Samsung Electronics Co., Ltd e-mail address: [email protected] Tel: +82-31-277-4784 Fax: +82-31-277-9247

SAMSUNG Electronics America INC. Federal Communications Commission Date: May 19, 2011 Authorization and Evaluation Division 7435 Oakland Mills Road AGENT AUTHORIZATION LETTER To whom it may concern, We, the undersigned, Samsung Electronics Co., Ltd. hereby authorize the following to act on our behalf, as our agent, in all matters relating to all processes required according to FCC Part 15B and 15C for Samsung Electronics Co., Ltd. products (Grantee Code : A3L): John SC Lee If you have any questions regarding the authorization, please do not hesitate to contact us. Sincerely Yours, ____________________________________________ Sang Kyung, Ra/General Manager American QA Lab SAMSUNG Electronics America INC. E-mail : [email protected] Telephone : 310-900-5250

FCCID: A3LSR8PWUW IC: 649E-SR8PWUW Copyright Ⓒ 2013, Digital EMC Co., Ltd. View 1 FCCID: A3LSR8PWUW IC: 649E-SR8PWUW Copyright Ⓒ 2013, Digital EMC Co., Ltd. View 2 FCCID: A3LSR8PWUW IC: 649E-SR8PWUW Copyright Ⓒ 2013, Digital EMC Co., Ltd. View 3

FCCID: A3LSR8PWUW IC: 649E-SR8PWUW Copyright Ⓒ 2013, DIGITAL EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will ap p ear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual.

FCCID: A3LSR8PWUW IC: 649E-SR8PWUW Copyright Ⓒ 2013, Digital EMC Co., Ltd. Page1 / 2 View 1 FCCID: A3LSR8PWUW IC: 649E-SR8PWUW Copyright Ⓒ 2013, Digital EMC Co., Ltd. Page2 / 2 View 2

DEMC1305-01501 & DEMC1305-01503 FCC ID: A3LSR8PWUW Report No.: DRTFCC1306-0606 IC: 649E-SR8PWUW TRF-RF-215(00)110331 Page 2 / 18 Copyright ○ C 2013, Digital EMC Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1306-0606 Jun. 18, 2013 Initial issue DEMC1305-01501 & DEMC1305-01503 FCC ID: A3LSR8PWUW Report No.: DRTFCC1306-0606 IC: 649E-SR8PWUW TRF-RF-215(00)110331 Page 3 / 18 Copyright ○ C 2013, Digital EMC Co., Ltd. CONTENTS 1. Equipment information .............................................................. 4 1.1 Equipment description ............................................................. 4 1.2 Ancillary equipment ................................................................. 4 2. Information about test items ..................................................... 5 2.1 Test mode ................................................................................ 5 2.2 Auxiliary equipment ................................................................. 5 2.3 Tested frequency ..................................................................... 5 2.4 Tested environment ................................................................. 5 2.5 EMI Suppression Device(s)/Modifications ............................... 5 3. Test Report ................................................................................. 6 3.1 Summary of tests .................................................................... 6 3.2 Transmitter requirements ........................................................ 7 3.2.1 AC Conducted Emissions .................................................... 7 3.2.2 Radiated Emission ............................................................ 10 3.2.3 Antenna Requirements ..................................................... 13 3.2.4 Occupied Bandwidth (99%)............................................... 14 APPENDIX I................................................................................... 17 DEMC1305-01501 & DEMC1305-01503 FCC ID: A3LSR8PWUW Report No.: DRTFCC1306-0606 IC: 649E-SR8PWUW TRF-RF-215(00)110331 Page 4 / 18 Copyright ○ C 2013, Digital EMC Co., Ltd. 1. Equipment information 1.1 Equipment description FCC Equipment Class Part 15 Low Power Communication Device Transmitter FCC ID A3LSR8PWUW IC ID 649E-SR8PWUW Equipment type Receiver Equipment model name AA-SR8PWUW Equipment add model name N/A Equipment serial no. Identical prototype Frequency band 2412 ~ 2472MHz Channel information 5 channels(2412MHz, 2427MHz, 2452MHz, 2467MHz, 2472MHz) Power DC 5.0 V Antenna type Internal Type: Internal antenna (Max. peak gain: -1.9 dBi) 1.2 Ancillary equipment Equipment Model No. Serial No. Manufacturer Note - - - - - - - - - - DEMC1305-01501 & DEMC1305-01503 FCC ID: A3LSR8PWUW Report No.: DRTFCC1306-0606 IC: 649E-SR8PWUW TRF-RF-215(00)110331 Page 5 / 18 Copyright ○ C 2013, Digital EMC Co., Ltd. 2. Information about test items 2.1 Test mode This device was tested in maximum duty mode at maximum power. Test Case 1 GFSK Test Case 2 - Test Case 3 - 2.2 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note - - - - - - - - - - 2.3 Tested frequency TX Frequency (MHz) RX Frequency (MHz) Lowest Channel 2412 2412 Middle Channel 2452 2452 Highest Channel 2472 2472 2.4 Tested environment Temperature : 22 ~ 23 o C Relative humidity content : 43 ~ 45 % R.H. Details of power supply :DC 5.0 V 2.5 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None DEMC1305-01501 & DEMC1305-01503 FCC ID: A3LSR8PWUW Report No.: DRTFCC1306-0606 IC: 649E-SR8PWUW TRF-RF-215(00)110331 Page 6 / 18 Copyright ○ C 2013, Digital EMC Co., Ltd. 3. Test Report 3.1 Summary of tests FCC Part RSS-210 & GEN Parameter Limit (Using in 2400 ~ 2483.5MHz) Test Condition Status Note 1 15.249 (a) RSS-210 [A2.9] Field Strength Limits Refer to the FCC 15.249(a) Radiated C 15.205, 209 RSS-210 [A2.9] General Field Strength Limits (Restricted Bands and Radiated Emission Limits) < FCC 15.209 limits Radiated C 15.207 RSS-Gen [7.2.4] AC Conducted Emissions < FCC 15.207 limits Line Conducted C RSS Gen [4.6.1] Occupied Bandwidth (99%) RSS-Gen(4.6.1) Conducted C Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: The sample was tested according to the following specification: ANSI C-63.10-2009, RSS-Gen Issue 3: 2010 Note3: The JBP portion of this device was performed according to DoC procedure. DEMC1305-01501 & DEMC1305-01503 FCC ID: A3LSR8PWUW Report No.: DRTFCC1306-0606 IC: 649E-SR8PWUW TRF-RF-215(00)110331 Page 7 / 18 Copyright ○ C 2013, Digital EMC Co., Ltd. 3.2 Transmitter requirements 3.2.1 AC Conducted Emissions Test Requirements and limit, §15.207& RSS-Gen [7.2.4] For an intentional radiator which is designed to be connected to the public utility (AC) power line, the radio frequency voltage that is conducted back onto the AC power line on any frequency or frequencies within the band 150 kHz to 30 MHz shall not exceed 250 microvolts (The limit decreases linearly with the logarithm of the frequency in the range 0.15 MHz to 0.50 MHz). The limits at specific frequency range is listed as follows: Frequency Range (MHz) Conducted Limit (dBuV) Quasi-Peak Average 0.15 ~ 0.5 66 to 56 * 56 to 46 * 0.5 ~ 5 56 46 5 ~ 30 60 50 * Decreases with the logarithm of the frequency Compliance with this provision shall be based on the measurement of the radio frequency voltage between each power line (LINE and NEUTRAL) and ground at the power terminals. Test Configuration See test photographs for the actual connections. Test Procedure 1. The EUT is placed on a wooden table 80 cm above the reference groundplane. 2. The EUT is connected via LISN to the test power supply. 3. The measurement results are obtained as described below: 4. Detectors – Quasi Peak and Average Detector. Test Result: Comply DEMC1305-01501 & DEMC1305-01503 FCC ID: A3LSR8PWUW Report No.: DRTFCC1306-0606 IC: 649E-SR8PWUW TRF-RF-215(00)110331 Page 8 / 18 Copyright …
