A3LSTHN270Dual-Mode Cellular Phone (AMPS/TDMA)

Samsung Electronics Co Ltd

Click to zoom

Application Details

Equipment Class: TNE - Licensed Non-Broadcast Transmitter Held to Ear
Date of Grant: May 06, 2001
Application Purpose: Original Equipment
Date of Application: Mar 13, 2001
Equipment Note: Dual-Mode Cellular Phone (AMPS/TDMA)
Frequency Range: 824.04000000 - 848.97000000
Company: Samsung Electronics Co Ltd
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Printed in Korea Code No. : GH68-xxxxxA English. 10/2000. Rev. 1.0 ELECTRONICS World Wide Webhttp://www.samsungmobile.com TDMA MOBILE TELEPHONE STH-N270 Draft Version 1 ContentsImportant Safety Precautions . . . . . . . . . . . . . . . . . . . 5 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Phone Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Service Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Switching the Phone On/Off . . . . . . . . . . . . . . . . . . . . . . . 18 Locking Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 General Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Viewing Missed Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Quick-switching to Silent Mode . . . . . . . . . . . . . . . . . . . . . . 25 Recording a Voice Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Selecting Functions and Options . . . . . . . . . . . . . . . . 28 Example: Setting the Display Language . . . . . . . . . . . . . . 30 Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Storing a Phone Number with a Name . . . . . . . . . . . . . . 32 Speed Dialing by Memory Location . . . . . . . . . . . . . . . . . 34 Phonebook Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Searching for and Dialing a Number in the Phonebook . . . 37 Name Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of theUnited States with its action in Report and Order FCC 96-326 adopted anupdated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters.Those guidelines are consistent with the safety standard previously set byboth U.S. and international standards bodies. The design of this phonecomplies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas,modifications, or attachments could impair call quality, damage thephone, or result in violation of FCC regulations.Do not use the phone with a damaged antenna. If a damaged antennacomes into contact with the skin, a minor burn may result. Please contactyour local dealer for replacement antenna.Body-worn OperationThis device was tested for typical body-worn operations using the optional belt-clip/holster placed 0.7 inches (1.8cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.7 inches (1.8cm) must be maintained between the user’sbody and the phone, including the antenna, whether extended or retract-ed. The use of third-party belt-clips/ holsters with no metallic componentsthat provide the minimum separation distance of 0.7 inches (1.8cm) canbe used to satisfy FCC RF exposure requirements. The use of non-testedaccessories or other body-worn operations may not comply with FCC RFexposure requirements and should be avoided. Contact your local dealerfor optional accessory items.Vehicle Mounted External Antenna (optional, if available.)A minimum separation distance of 7.9 inches (20cm) must be maintainedBetween a person and the vehicle mounted external antenna to satisfyFCC RF exposure requirements.For more information about RF exposure, please visit the FCC website atwww .fcc.gov In-Call Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Putting a Call on Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Switching the Microphone Off (Mute) . . . . . . . . . . . . . . . 42 Muting/Sending Key Tones . . . . . . . . . . . . . . . . . . . . . . . 43 Searching for a Number in the Phonebook . . . . . . . . . . . . 43 Using the SMS Service . . . . . . . . . . . . . . . . . . . . . . . . . . 44 Answering a Second Call . . . . . . . . . . . . . . . . . . . . . . . . . 44 Making a Conference Call . . . . . . . . . . . . . . . . . . . . . . . . 45 Using the Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Accessing a Menu Function by scrolling . . . . . . . . . . . . . 46 Accessing a Menu Function by Using its Shortcut . . . . . . 47 List of Menu Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Call Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Missed Calls (Menu 1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Received Calls (Menu 1.2) . . . . . . . . . . . . . . . . . . . . . . . . 52 Dialed Calls (Menu 1.3) . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Call Time (Menu 1.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Voice Mail (Menu 2.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Read Messages (Menu 2.2) . . . . . . . . . . . . . . . . . . . . . . . 55 Write Messages (Menu 2.3) . . . . . . . . . . . . . . . . . . . . . . . 57 Preset Message List (Menu 2.4) . . . . . . . . . . . . . . . . . . . . 58 Setup (Menu 2.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 Ring Volume (Menu 3.1) . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

Attestation Statements

© 2001 PCTEST Lab ATTACHMENT B – ATTESTATION STATEMENT(S) March 9, 2001 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act as agent on behalf of all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988,21 U.S.C.853(a) Sincerely, Wallace Oh Engineering Manager Samsung Electronics America March 13, 2001 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Samsung Electronics Co., Ltd. FCC ID.:A3LSTHN270 Request for Confidentiality To Whom It May Concern: In accordance with 0.459 of CFR 47, Samsung Electronics Co., Ltd. requests confidentiality for the Block Diagram, Schematics, and Circuit Description of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product which Samsung Electronics Co., Ltd. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Samsung feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. March 13, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC E911 REQUIREMENTS PER §22.921 Gentlemen: Samsung Electronics Co., Ltd. hereby certifies that the analog cellular telephone (FCC ID: A3LSTHN270), using the Automatic A/B Roaming – Intelligent Retry method, meets the E911 requirements specified in Section 22.921 of the FCC Rules. This procedure recognizes when a “9-1-1” call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to be handled by other analog carriers. Should you have any questions or comments concerning the above, please contact the undersigned. AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the Portable Cellular Telephone (FCC ID:A3LSTHN270) is so designed that it complies with all the requirements for ESN protection specified in Sec.22.919 of the FCC Rules. a) The transmitter in service has a unique ESN. b) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. c) The ESN is factory set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. March 13, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSTHN270 Users Manual RF Exposure Warning Statement Gentlemen: Samsung Electronics Co., Ltd., hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, please do not hesitate to contact me or PCTEST Lab at (410) 290-6652.

Cover Letter(s)

March 13, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SAMSUNG ELECTRONICS CO., LTD. FCC ID: A3LSTHN270 Part 22 Certification Gentlemen: Attached herewith, on behalf of SAMSUNG ELECTRONICS CO., LTD. is an application for Part 22 Certification of the following Dual-Mode Cellular Phone (AMPS/TDMA): FCC ID: A3LSTHN270 TRADE / MODEL(s): SAMSUNG STH-N270, STH-N271, STH-N275 EUT TYPE: Non-Broadcast Transmitter held to ear (TNE) Tx Freq. Range: 824.04 – 848.97 MHz (AMPS) 824.04 – 848.97 MHz (TDMA) Rx Freq. Range: 869.04 – 893.97 MHz (AMPS) 869.04 – 893.97 MHz (TDMA) Max. RF Output Power: 0.406 W ERP AMPS (26.083 dBm) 0.434 W ERP TDMA (26.373 dBm) Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 Compliance Statement, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description, parts list & tune-up procedure, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Wallace Oh Engineering Manager SAMSUNG American QA Lab

Cover Letter(s)

May 4, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSTHN270 731 Confirmation No.: EA100330 Correspondence Reference No.: 19077 Request for Tech. Info.: 5/4/01 Dear Steve: Transmitted herewith, on behalf of Samsung Electronics Co., Ltd. is an amendment provided in response to the request for technical information dated May 4, 2001. 1. Corrected Maximum RF Output Power: 0.434 W ERP TDMA (26.37 dBm) We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Samsung Electronics Co., Ltd.

Cover Letter(s)

External Photos

© 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA)

ID Label/Location Info

© 2001 PCTEST Lab ATTACHMENT E – FCC ID LABEL / LOCATION © 2001 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) SAMSUNG ELECTRONICS CO., LTD. MODEL NO: STH-N270 FCC ID: A3LSTHN270 MADE IN KOREA SAMSUNG ELECTRONICS CO., LTD

Internal Photos

RF Exposure Info

© 2001 PCTEST Lab ATTACHMENT N – SAR MEASUREMENT REPORT © 2001 PCTEST Engineering Lab., Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: Feb. 28 & Mar. 1-2, 2001 416 Maetan-3 Dong, Paldal-Ku Test Report S/N: SAR.210228041.A3L Suwon City Kyungki-Do 441-742, KOREA Test Site: PCTEST Lab, Columbia, MD USA Attn: Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) FCC ID A3LSTHN270 APPLICANT SAMSUNG Electronics Co., Ltd. EUT Type: Dual-Mode Cellular Phone (AMPS/TDMA) Tx Frequency: 824.04 – 848.97 MHz (AMPS) / 824.04 – 848.97 MHz (TDMA) Rx Frequency: 869.04 – 893.97 MHz (AMPS) / 869.04 – 893.97 MHz (TDMA) Max. RF Output Power: 0.467 W ERP AMPS (26.62 dBm) / 0.6 W ERP TDMA (27.67 dBm) Trade Name/Model(s): SAMSUNG STH-N270, STH-N271, STH-N275 FCC Classification: Non-Broadcast Transmitter Held to Ear (TNE) Application Type: Certification FCC Rule Part(s): §2.1093; ET Docket 96.326 Maximum SAR: 1.4842 W/kg AMPS Brain SAR; 1.2404 W/kg AMPS Body SAR 0.5982 W/kg TDMA Brain SAR; 0.4866 W/kg TDMA Body SAR This wireless portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report) I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210228041.A3L Test Report S/N: SAR.210228041.A3L SAR Measurement Report Test Dates: FEB. 28 & MAR. 1-2, 2001 FCC Part 22 Certification FCC ID: A3LSTHN270 (Model(s): STH-N270, STH-N271, STH-N275) © 2001 PCTEST Lab SAMSUNG Dual-Mode Cellular Phone i Table of Contents 1.1 SCOPE........................................................................................................................1 2.1 INTRODUCTION.......................................................................................................1 2.2 SAR Definition......................................................................................................2 3.1 SAR MEASUREMENT SET-UP............................................................................3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM..............................................................4 5.1 E-field PROBE CALIBRATION PROCESS.........................................................5 6.1 PHANTOM AND EQUIVALENT TISSUES..........................................................7 7.1 SYSTEM SPECIFICATIONS..................................................................................8 8.1 MEASUREMENT PROCESS.................................................................................9 9.1 TEST POSITION OF THE PHONE......................................................................10 10.1 BODY-WORN TEST SETUP..............................................................................11 11.1 ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS........................................12 12.1 MEASUREMENT UNCERTAINTIES.................................................................13 13.1 SAR TEST DATA SUMMARY............................................................................14 14.1 SAR TEST EQUIPMENT.....................................................................................17 15.1 CONCLUSION.......................................................................................................18 Test Report S/N: SAR.210228041.A3L SAR Measurement Report Test Dates: Feb. 28 & Mar. 1-2, 2001 FCC Part 22 Certification FCC ID: A3LSTHN270 (Model(s): STH-N270, STH-N271, STH-N275) © 2001 PCTEST Lab SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) 1 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant Name: SAMSUNG ELECTRONICS CO., LTD. Address: 416 Maetan-3 Dong, Paldal-Ku Suwon City, Kyungki-Do, 441-742, KOREA Attention: Mr. Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) • EUT Type: Dual-Mode Cellular Phone (AMPS/TDMA) • Trade Name: SAMSUNG • Model(s): STH-N270, STH-N271, STH-N275 • FCC IDENTIFIER: A3LSTHN270 • Tx Frequency: 824.04 – 848.97 MHz (AMPS) 824.04 – 848.97 MHz (TDMA) • Rx Frequency: 869.04 – 893.97 MHz (AMPS) 869.04 – 893.97 MHz (TDMA) • Application Type: Certification • FCC Classification: Non-broadcast Transmitter Held to Ear (TNE) • FCC Rule Part(s): § 2.1093, Docket 96-326 • Modulation(s): AMPS/TDMA • Max RF. Output Power: 0.467W ERP AMPS (26.62 dBm) 0.6W ERP TDMA (27.67 dBm) • Date(s) of Tests: Feb. 28 & Mar. 1-2, 2001 • Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.210228041.A3L 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.210228041.A3L SAR Measurement Report Test Dates: Feb.…

Text truncated - open the document above for the full version.

RF Exposure Info

© 2001 PCTEST Lab ATTACHMENT O – SAR TEST DATA Peak SAR Location © 2001 PCTEST Lab FCC ID: A3LSTHN270 (Models: STH-N270, STH-N271, STH-N275) NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) Head SAR File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01030110_ZOOM.VLT Start : 1-Mar-101 02:29:09 pm End : 1-Mar-101 02:38:41 pm Radio Type : SAMSUNG Model Number : STH-N270 Serial Number : 6D Frequency : 824.04 MHz Peak Trans. Pwr : 0.400 W Start Trans. Pwr: 0.400 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL-MODE PHONE - AMPS MODE CHAN 0991 Conducted 26.0 dBm SAMSUNG DUAL-MODE PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = 2.500, Y = -5.000, Z = 0.000 (cm) Value = 17.261 Measured Values (volts) = 1.742E-002 1.384E-002 1.209E-002 1.079E-002 9.915E-003 9.041E-003 8.205E-003 7.088E-003 6.033E-003 4.799E-003 3.631E-003 2.694E-003 1.955E-003 1.606E-003 1.500E-003 1.730E-003 2.137E-003 2.514E-003 2.747E-003 2.622E-003 1.928E-003 Calc. Voltage @ Surface (Vs) = 0.0209 Voltage @ 1.00 cm (Vt) = 0.0108 Ave. Voltage (Vs+Vt)/2 = 0.0159 Ave. SAR over 1 g (mW/g) = 1.1574 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 mW/g -1012345 Z centimeters SAR Scan File : 01030110_ZOOM Start : 1-Mar-101 02:29:09 pm End : 1-Mar-101 02:38:41 pm SAMSUNG/STH-N270/6D;824.04MHz;W;Helical/Internal; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01030110_ZOOM Start : 1-Mar-101 02:29:09 pm End : 1-Mar-101 02:38:41 pm SAMSUNG/STH-N270/6D;824.04MHz;W;Helical/Internal; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.259 1.185 1.110 1.035 0.961 0.886 0.811 0.737 0.662 0.587 File : 01030110_ZOOM Start : 1-Mar-101 02:29:09 pm End : 1-Mar-101 02:38:41 pm SAMSUNG/STH-N270/6D;824.04MHz;W;Helical/Internal; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.259 1.185 1.110 1.035 0.961 0.886 0.811 0.737 0.662 0.587 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01022803_ZOOM.VLT Start : 28-Feb-101 10:31:39 am End : 28-Feb-101 10:41:11 am Radio Type : SAMSUNG Model Number : STH-N270 Serial Number : 6D Frequency : 836.49 MHz Peak Trans. Pwr : 0.400 W Start Trans. Pwr: 0.400 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL-MODE PHONE - AMPS MODE CHAN 0383 Conducted 26.0 dBm SAMSUNG DUAL-MODE PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = 2.250, Y = -5.000, Z = 0.000 (cm) Value = 11.503 Measured Values (volts) = 1.104E-002 8.591E-003 7.377E-003 6.554E-003 5.945E-003 5.407E-003 4.927E-003 4.397E-003 3.875E-003 3.193E-003 2.497E-003 1.890E-003 1.383E-003 1.055E-003 9.145E-004 9.462E-004 1.103E-003 1.337E-003 1.504E-003 1.552E-003 1.349E-003 Calc. Voltage @ Surface (Vs) = 0.0135 Voltage @ 1.00 cm (Vt) = 0.0066 Ave. Voltage (Vs+Vt)/2 = 0.0100 Ave. SAR over 1 g (mW/g) = 0.7321 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 mW/g -1012345 Z centimeters SAR Scan File : 01022803_ZOOM Start : 28-Feb-101 10:31:39 am End : 28-Feb-101 10:41:11 am SAMSUNG/STH-N270/6D;836.49MHz;W;Helical/Internal; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01022803_ZOOM Start : 28-Feb-101 10:31:39 am End : 28-Feb-101 10:41:11 am SAMSUNG/STH-N270/6D;836.49MHz;W;Helical/Internal; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 0.839 0.794 0.748 0.702 0.656 0.611 0.565 0.519 0.474 0.428 File : 01022803_ZOOM Start : 28-Feb-101 10:31:39 am End : 28-Feb-101 10:41:11 am SAMSUNG/STH-N270/6D;836.49MHz;W;Helical/Internal; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 0.839 0.794 0.748 0.702 0.656 0.611 0.565 0.519 0.474 0.428 File : c:/idx3/SYSTEM/SARMEAS3/data/Normal/01030111_ZOOM.VLT Start : 1-Mar-101 02:53:52 pm End : 1-Mar-101 03:03:26 pm Radio Type : SAMSUNG Model Number : STH-N270 Serial Number : 6D Frequency : 848.97 MHz Peak Trans. Pwr : 0.400 W Start Trans. Pwr: 0.400 W Antenna Type : Helical Antenna Posn. : Internal Phantom Type : Head Phantom Posn. : Left Ear Scan Type : ZOOM/SAR Probe Name : PCTEST Field Type : E Field Orientation : 0 Degrees Mixture Type = Brain Mixture Dielectric Constant = 41.500 Mixture Conductivity = 0.900 Comment : SAMSUNG DUAL-MODE PHONE - AMPS MODE CHAN 0799 Conducted 26.0 dBm SAMSUNG DUAL-MODE PHONE Robot : PCTEST Probe Offset = 0.25 cm Sensor Factor = 0.0108 Conversion Factor = 0.788 PCTEST Amplifier Channel Settings : 0.166 0.135 0.132 Max Location : X = 2.500, Y = -5.000, Z = 0.000 (cm) Value = 22.750 Measured Values (volts) = 2.238E-002 1.761E-002 1.539E-002 1.365E-002 1.268E-002 1.148E-002 1.037E-002 9.169E-003 7.881E-003 6.346E-003 4.836E-003 3.640E-003 2.631E-003 2.086E-003 1.920E-003 2.147E-003 2.664E-003 3.187E-003 3.497E-003 3.380E-003 2.513E-003 Calc. Voltage @ Surface (Vs) = 0.0270 Voltage @ 1.00 cm (Vt) = 0.0137 Ave. Voltage (Vs+Vt)/2 = 0.0203 Ave. SAR over 1 g (mW/g) = 1.4842 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 mW/g -1012345 Z centimeters SAR Scan File : 01030111_ZOOM Start : 1-Mar-101 02:53:52 pm End : 1-Mar-101 03:03:26 pm SAMSUNG/STH-N270/6D;848.97MHz;W;Helical/Internal; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 File : 01030111_ZOOM Start : 1-Mar-101 02:53:52 pm End : 1-Mar-101 03:03:26 pm SAMSUNG/STH-N270/6D;848.97MHz;W;Helical/Internal; Head/Left Ear;ZOOM/SAR;PCTEST/E Field/0 DegreesBrain/41.500/0.900 1.660 1.563 1.466 1.369 1.272 1.175 1.079 0.982 0.885 0.788 Fi…

Text truncated - open the document above for the full version.

RF Exposure Info

© 2001 PCTEST Lab ATTACHMENT P – SAR TEST SETUP PHOTOGRAPHS © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) © 2001 PCTEST Lab FCC ID: A3LSTHN270 NVLAP Lab Code: 100431-0 SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA)

RF Exposure Info

© 2001 PCTEST Engineering Lab., Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SAMSUNG ELECTRONICS CO., LTD. Dates of Tests: Feb. 28 & Mar. 1-2, 2001 416 Maetan-3 Dong, Paldal-Ku Test Report S/N: SAR.210228041.A3L Suwon City Kyungki-Do 441-742, KOREA Test Site: PCTEST Lab, Columbia, MD USA Attn: Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) FCC ID A3LSTHN270 APPLICANT SAMSUNG Electronics Co., Ltd. EUT Type: Dual-Mode Cellular Phone (AMPS/TDMA) Tx Frequency: 824.04 – 848.97 MHz (AMPS) / 824.04 – 848.97 MHz (TDMA) Rx Frequency: 869.04 – 893.97 MHz (AMPS) / 869.04 – 893.97 MHz (TDMA) Max. RF Output Power: 0.406 W ERP AMPS (26.08 dBm) / 0.434 W ERP TDMA (26.37 dBm) Trade Name/Model(s): SAMSUNG STH-N270, STH-N271, STH-N275 FCC Classification: Non-Broadcast Transmitter Held to Ear (TNE) Application Type: Certification FCC Rule Part(s): §2.1093; ET Docket 96.326 Maximum SAR: 1.4842 W/kg AMPS Brain SAR; 1.2404 W/kg AMPS Body SAR 0.5982 W/kg TDMA Brain SAR; 0.4866 W/kg TDMA Body SAR This wireless portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report) I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 210228041.A3L Test Report S/N: SAR.210228041.A3L SAR Measurement Report Test Dates: Feb. 28 & Mar. 1-2, 2001 FCC Part 22 Certification FCC ID: A3LSTHN270 (Model(s): STH-N270, STH-N271, STH-N275) © 2001 PCTEST Lab SAMSUNG Dual-Mode Cellular Phone (AMPS/TDMA) 1 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Applicant Name: SAMSUNG ELECTRONICS CO., LTD. Address: 416 Maetan-3 Dong, Paldal-Ku Suwon City, Kyungki-Do, 441-742, KOREA Attention: Mr. Wallace Oh, Engineering Manager Samsung Electronics America (QA Lab) • EUT Type: Dual-Mode Cellular Phone (AMPS/TDMA) • Trade…
