A3LSW207CD-R/RW Drive

ELECTFWWS Samsung Electronics Co., Ltd 416, Maetan-3Dong, Paldal-Gu, Suwon City, Kyungki-Do, Korea, 442-742 TEL : 82-3 l-200-4252 FAX : 82-3 l-200-7890 9 August 2000 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PC TEST Engineering Laboratory, Inc. on our behalf shall the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely MunEul Son Assistant Manager Samsung Electronics Co. LTD.

August 18, 2000 Federal Communications Commission Authorization & Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Samsung Electronics Co., Ltd. FCC ID: A3LSW207 Gentlemen: Submitted herewith, on behalf of Samsung Electronics Co. Ltd. and Tokin EMC Engineering Co., Ltd., is an application for Part 15 certification of the following CD-R/RW Drive : FCC ID: A3LSW207 MODEL: SW-207 Equip. Class: Class B Peripheral Device (JBP) EUT Type: CD-R/RW Drive Attached is the authorization letter, measurement report (measurement data), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematic diagram, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Samsung Electronics Co., Ltd.

FCC ID: A3LSW207 External Photo for SAMSUNG CD-R/RW ROM Drive FCC ID: A3LSW207 External Photo for SAMSUNG CD-R/RW ROM Drive

FCC ID LABEL FORMAT FCC ID LABEL LOCATION FCC ID Label

FCC ID: A3LSW207 Internal Photo for SAMSUNG CD-R/RW ROM Drive

FCC ID: A3LSW207 FCC ID: A3LSW207 FCC ID: A3LSW207 FCC ID: A3LSW207 FCC ID: A3LSW207 FCC ID: A3LSW207 FCC ID: A3LSW207

SAMSUNG FCC ID:A3LSW207 EMC TEST REPORT for SAMSUNG ELECTRONICS CO., LTD. 416, Maetan-3Dong, Paldal-Gu, Suwon City, Kyungki-Do, Korea Equipment Under Test: CD-R/RW DRIVE Model Name : SW-207 <Brand Name : RICOH, Model Name : MP7063A ⋅ RW7063A> FCC ID : A3LSW207 Category: FCC Part 15 Sub.part B Class B Digital Device Tokin Report No.: T3K005083 Date of Issue: June 8, 2000 -- ATTENTION -- The test results in this report relate only to the following EUTs, and this report shall not be reproduced except in full, without the written approval of the laboratory. This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC 15B Class B T3K005083 SAMSUNG FCC ID:A3LSW207 Contents Page 1 DESCRIPTION OF DEVICE ....................................................................... 1 2 TEST FACILITY............................................................................................... 2 3 SUMMARY OF RESULTS 3.1 Electromagnetic Emission ............................................................................. 2 3.2 Modification to The EUT............................................................................... 2 4 TESTED SYSTEM DETAILS 4.1 Peripherals and Others ................................................................................ 3 4.2 Type of Used Cables ................................................................................... 4 4-1 System Configuration Diagram...................................................................... 5 5 TECHNICAL COUNTERMEASURE.................................................................. 5 6 TEST RESULTS 6.1 RFI Voltage Measurement 6.1.1 Measurement Instrumentation Used........................................................ 6 6.1.2 Measurement Procedure......................................................................... 6 6.1.3 Measurement Uncertainty....................................................................... 6 6.1.4 Test Data............................................................................................... 7 ∼ 8 6.2 RFI Field Strength Measurement 6.2.1 Measurement Instrumentation Used........................................................ 9 6.2.2 Measurement Procedure......................................................................... 10 6.2.3 Measurement Uncertainty....................................................................... 10 6.2.4 Test Data............................................................................................... 11 ∼ 13 6.3 Minimum Margin........................................................................................... 14 6.4 Sample Calculation........................................................................................ 14 7 MEASUREMENT PHOTOS Photo 7.1 Setup with the Maximized RFI Voltage Emission Level........................ 15 Photo 7.2 Setup with the Maximized RFI Field Strength Emission Level.............. 16 ∼ 17 Page 1 of 17 FCC 15B Class B T3K005083 SAMSUNG FCC ID:A3LSW207 1 DESCRIPTION OF DEVICE A) Kind of Equipment : CD-R/RW DRIVE B) FCC ID : A3LSW207 C) Model Name : SW-207 <Brand Name : RICOH> < Model Name : MP7063A ⋅ RW7063A> D) Serial No. : None E) Type of Sample Tested : Pre-production F) High Frequency Used : 33.8688MHz ( DSP ) 18MHz ( MICOM ) 240 ∼ 300MHz ( Pick-up ) G) Rating Power Supply : DC5 ∼ 12V, 2.5/1.0A H) Tested Power Supply : 1phase AC120V, 60Hz (PC) I) Date of Manufacture : May 2000 J) Manufacturer : SAMSUNG ELECTRONICS CO., LTD. 416, Maetan-3Dong, Paldal-Gu, Suwon City, Kyungki-Do, Korea K) Description of Operating : Test Program (Read and Write) L) Date of Sample Received : May 9, 2000 M) Test Engineer : Masayuki Kuramochi Page 2 of 17 FCC 15B Class B T3K005083 SAMSUNG FCC ID:A3LSW207 2 TEST FACILITY The open field test site and conducted measurement facility are used for these testing, where are located following address. This site was fully described in a report dated Feb.12,1998, that was submitted to the FCC. And we had accepted in a letter dated Mar.30,1998 (31040/SIT). This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200221-0. Tokin EMC Engineering Co., Ltd. Tsukuba Testing Laboratory, Open Field Test Site No.3 and Shielded Room No.1 Address ; 28-1, Kitahara-aza, Hanashimashinden-ohaza, Tsukuba-city, Ibaragi 305-0875, Japan 3 SUMMARY OF RESULTS 3.1 Electromagnetic Emission RFI Voltage Measurement .............................PASS RFI Field Strength Measurement ...................PASS Although the measured emissions indicate that the EUT complies with the required limits, some measurements are close to these limits. When the uncertainty of measurement is considered, there is some possibility that the EUT may not be compliant. Test results are traceable to JQA, TELEC and NIST. 3.2 Modifications to The EUT : None Page 4 of 17 FCC 15B Class B T3K005083 SAMSUNG FCC ID:A3LSW207 4.2 Type of Used Cables : Description Length Type of shield Model name Manufacturer 1 AC power cable for CRT Display Monitor 2.5m Non-shielded None None 2 CRT Display Monitor cable 1.8m Shielded None Gateway 3 AC power cable for PC 2.2m Non-shielded None None 4 Earphone cable 1.3m Non-shielded None None 5 RS232C cable 1.5m Shielded None SPACE SHATTLE 6 Printer cable 1.5m Shielded None Canon 7 AC Adapter cable for Printer (DC side) 1.0m Non-shielded None Canon 8 AC Adapter cable for Printer(AC side) 1.5m Non-shielded None Canon 9 Line cable 1.0m × 2 Non-shielded None None 10 DC power cable for Modem 1.9m Non-shielded None ACEEX 11 AC cable for Speaker 1.25m Non-shielded None None 12 Speaker cable 1.0m Non-shielded None None 13 Speaker cable 1.2m Non-shielded None None 14 Microphone cable 2.3m Non-shielded None TELEX 15 USB Play Pad cable 2.5m Shielded None NEC 16 USB Camera cable 1.5m Shielded None LG 17 Mouse cable 1.9m Shielded None Microsoft 18 Keyboard cable 1.7m Shielded None Microsoft 19 Game Controller cable 1.8m Shielded None GRAVIS Page 5 of 17 FC…
