A3LSW232CD-Rewritable

User's Guide CD-R/RW DRIVESW-232 FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.These limits are designed to provide reasonable protection against harmfulinterference in a residential installation.This equipment generates, uses, and can radiate radio frequency energy and,if not installed and used in accordance with the instructions, may causeharmful interference to radio communications. However, there is no guaranteethat interference will not occur in a particular installation. If this equipmentdoes cause harmful interference to radio or television reception, which can be deter-mined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Re-orient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. SW-232_eng-00 1/3/02 5:39 PM Page 1 Contents 3 Safety Precautions 2 The following diagrams illustrate the precautions to be taken when usingyour CD-R/RW drive. You must not use the drive in any manner other than that specified in this guide. ✱ Changes or modifications not expressly approved by the party responsible for compliancecould void the user’s authority to operate the equipment Avoid exposing your eyes or skin to direct or scattered radiation. CAUTION Do not attempt to repair the CD-R/RW drive yourself. Contactyour dealer or local SAMSUNG representative for all repairs.If you make any adjustments or perform any operations otherthan those specified in this guide, you run the risk of exposure tohazardous radiation. WARRANTY Please refer to the Samsung limited warranty statements . Precautions 1. To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. 2. Always check each disc for cracks before using it. If there are cracks on the surfaces, especially around the border of thecenter hole, we recommend that you make a copy of the discimmediately and then stop using it. If you continue using thedisc, it will probably develop more cracks and eventually causeirreparable damage. 3. Do not use poor quality discs:  From unknown sources  Without any copyright  Scratched or damaged in any way * All product names mentioned in this document are trademarks or registered trademarks of their respective owners. Safety Precautions 2 Your CD-R/RW Drive 4 Upgrading the Firmware Flash Memory 5 System Requirements 5 Installing the CD-R/RW Drive 5 Connecting the Cables 6 Installing the CD Record Utility 8 Installing the Device Driver 8 Setting Up the Device Driver 9 Using the CD-R/RW Drive 10 Storing and Cleaning Your Discs 10 Solving Recording Problems 11 Recommended Disc Types 13 Caution with errors 14 Term Description 15 Solving Technical Problems 16 Technical Specifications 18 SW-232_eng-00 1/3/02 5:39 PM Page 2 Upgrading the Firmware Flash Memory 5 The product firmware can be upgraded by downloading the updated file from thefollowing Web site: http://www.samsungodd.com Before you install the CD-R/RW drive, we strongly recommend that youcheck that your setup meets the system requirements listed below.System Requirements Item Description Computer Intel Pentium II ( or higher), 32 MB of RAM (or higher) with an E-IDE interface Disk space 700 MB minimum Windows version Windows 95 / 98 OSR2 / 2000 / ME or XP / Windows NT 4.0 (or higher) Your CD-R/RW Drive 4 1 2 3 4 5 6 1 23 4 5 1. Connector for stereo headphones with a 3.6 mm stereo mini-jack2. Headphone volume control3. Emergency eject hole (if the compartment does not open when you press the Eject button, power off the computer, insert a pin orunfolded paper clip in the hole and push firmly) 4. Indicator light (when it is green, a disc is being read or recorded)5. Disc compartment (the compartment opens and closes automatically when you press the Eject button) 6. Eject button1. Two-pin digital audio output terminal for use with a sound or MPEG card supporting digital audio features 2. Four-pin sound output terminal for use with a sound card (refer to the sound card documentation for further details) 3. Master/slave select terminal4. 40pin host E-IDE interface connector5. 4pin power terminal General DMA Installation Guide Windows 95/98/Me Important!Please read the entire DMA installation guide before installing your CD-R/RW drive.About DMA InstallationFor stable writing performance at high speeds, Installation of DMA transfer mode forE-IDE/ATAPI interface is strongly recommended. We recommend DMA mode for fast writing.DMA SettingBefore you install your CD-R/RW drive, we recommend to set DMA to enabled onyour PC system. See the following procedure to set DMA transfer mode in windowsoprerating system. (Windows 95 OSR2/98/ME) Click on START  Click on Settings  Select Control Panel  Select the System Icon  Select the Device Manager panel in System Properties  Expand the CD-ROM icon  Select your CD-R/RW drive  Click on the Properties button  Click on the Settings tab  Check the DMA checkbox to enables DMA.  Click OK  Restart your PC www.samsungelectronics.com Windows 2000/XPSelect the DMA mode by selecting [Start > Setting > Control Panel > System >Device Manager > IDEATA/ATAPI Controller > Default/Assistant IDE ChannelAdvanced Information] SW-232_eng-00 1/3/02 5:39 PM Page 4 7 Connecting the Cables 6 1. Power cable 3. E-IDE cable 2. Master/slave select terminal 4. Audio cable 1 Connecting the power cableThe 4-pin power cable from the internal power unit of your computer must beconnected to the power terminal on the rear of the CD-R/RW drive. 3 Connecting the E-IDE cableTwo configurations are possible. The CD-R/RW drive is the only E-IDE device in addition to the hard disk. 4 Connecting the audio cable from a sou…

Text truncated - open the document above for the full version.

Deck Mecha D6C 삼성전자 P/U CD-DSP & ENDEC RL5E935 Ricoh AFEP RL3E804 Ricoh DAC BU2505 FV Rohm DRAM 2MB or 8MB FSPD PD I-V Actuator HOE LD LD Driver EL62XX Elantec Motor/Act. Driver BD7902C FS Rohm AD Sled Motor Loading Motor CPU H8S/2312 Hitachi Flash ROM 8bit512K Hynix & ST Spindle Motor ATAPI IF SCI Audio Out VA-VFH 33.86MHz 18 MHz ABSDVA Block Diagram

ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. EMI TEST REPORT Test report no. : ERI-FCC-0089 Type of equipment : CD-ReWritable Basic Model no. : SW-232 Variant Model no. : MP7320A ( OEM : RICOH ) RW7320A ( OEM : - ) FCC ID : A3LSW232 Applicant. : SAMSUNG ELECTRONICS Co., Ltd. Test standards : FCC Part15 Subpart B (Class B) Test result : Complied This equipment has been tested for FCC Part 15 standard. The results in this report apply only to the sample tested. This test report shall not be reproduced except in full, Without the written approval of ERI Laboratory. Date of test: 2002. 1. 2 Issued date: 2002. 1. 5 Tested by : approved by: YOUNG-SIK, KIM MIN-SEOK, CHUNG This laboratory is registered by KOLAS, KOREA. This test report have been performed in accordance with Its terms of registration. ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. Contents 1. client information 2. Laboratory information 3. TEST SYSTEM CONFIGURATION 3.1 Operation Environment 3.2 Measurement Uncertainty 3.3 sample calculation 4. Description of e.u.t. 4.1 Product Description 4.2 Peripherals 4.3 used cables 4.4 e.u.t. test configuration 4.5 operating conditions 5. Test Results 5.1 Conducted Emission 5.1.1 Measurement procedure 5.1.2 Used equipments 5.1.3 measurement uncertainty 5.1.4 Test data 5.1.5 Result 5.2 Radiated Emission 5.2.1 Measurement procedure 5.2.2 Used equipments 5.2.3 measurement uncertainty 5.2.4 Test data 5.2.5 Result ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. 6. Photographs Conducted Emission test Radiated Emission Test 1. Client information Applicant : SAMSUNG ELECTRONICS Co., Ltd. Address : 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 Telephone Number : 82-31-200-4252 Facsimile Number : 82-31-200-7890 Manufacturer : SAMSUNG ELECTRONICS Co., Ltd. Address : 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 Telephone Number : 82-31-200-4252 Facsimile Number : 82-31-200-7890 ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. 2. Laboratory information Address The open area test site and EMC facilities are used for these testing. This facility was accredited by KOLAS, EK of Korea, MIC, FCC. EMC RESEARCH INSTITUTE . 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA Telephone Number : 82- 31- 336- 1186 Facsimile Number : 82- 31- 336 -1184 KOLAS No. : 111 EK : J MIC : KR0030 FCC Filing No. : 96753 ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. MAP IC(), TG , 17 (42 ) FA TG TG 3km (ERI) ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. 3. TEST SYSTEM CONFIGURATION 3.1 Operation Environment Temperature Humidity pressure 3m OATS (Radiated Emission) : 2C 25 % 1003hPa Shielded room (Conducted Emission) : 23C 45 % 1003hPa 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, specially in field of EMC. The factors contributing to uncertainties are test receiver, Cable loss, antenna factor calibration, Antenna directivity, antenna factor variation with height, antenna phase center variation, antenna Frequency interpolation, measurement distance variation, site imperfection, mismatching, and system repeatability. Based on NIS 80,81, The measurement uncertainty level with a 95% confidence level were applied. 3.3 sample calculation radiated emission The field strength is calculated adding the antenna Factor, cable loss and, Antenna pad adding, subtracting the amplifier gain from the measured reading. The sample calculation is as follows : ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. FS = MR + AF + CL + AT -AG MR = Meter Reading AF = Antenna Factor CL = Cable Loss AP = Antenna Pad AG=Amplifier Gain If MR is 30dB, AF 12dB, CL 5dB, AP 10dB, AG 35dB The result (MR) is 30 + 12 + 5 + 10 –35 = 22dBuV/m Conducted emission The field strength is calculated by adding the LISN factor, cable loss from the measured reading. The sample calculation is as follows : FS = MR + LF + CL MR = Meter Reading LF = LISN Factor CL = Cable Loss If MR is 30dB, LISN insertion loss Factor 1dB, CL 1dB The result (MR) is 30 + 1 + 1 = 32dBuV ERI Electromagnetic research institute 80, JEIL-RI, YANGJI-MYUN, YOUNGIN-CITY, KYUNGGI-DO, KOREA TEL: 82 31 336 1186 FAX : 82 31 336 1184 homepage : This test report shall not be reproduced except in full, Without the written approval. 4. Description of e.u.t. 4.1 Product Description Manufactured By SAMSUNG ELECTRONICS Co., Ltd. Address 416 Maetan 3 Dong, Paldal-Ku, Suwon City, Kyungki Do, Korea, 442-742 Test Requested By SAMSUNG ELECTRONICS Co., Ltd. Model SW-232 Serial Number: N/A Power Supply DC 5V/12V Electric Current 1.5A Colck Frequency MICOM : 18MHz, EN/DEC : 33.86MHz General Description This EUT(Equipment Under Test) is CD-Re…
