A3LSWL-2460C802.11g Wireless LAN Module

SWL-2460C User’s Guide SAMSUNG 2.4GHz Wireless LAN Networking Soultions Introduction The MagicLan Utility is a user-mode utility designed to edit and add profiles for, as well as display and diagnostics pertaining to a selected SWL-2460C card (wireless adapter). See also: • System Requirements • Scan Available Networks • Profile Management • TCP/IP Configuration System Requirements • Laptop/ PC containing: • 16-bit PCMCIA slot • CF • 32 MB memory or greater • 300 MHz processor or higher • Windows XP Scan Available Networks Click the Refresh button on the Wireless Networks tab to scan for available infrastructure and ad hoc networks. Connecting to a different network • Highlight a network name and click the Configure button to connect an available netwo rk. If no configuration profile exists for that network, the Profile Management windo w opens to the General tab. Fill in the profile name and click OK to create the configuration profile for that network. Profile Management Configure the wireless network adapter (wireless card) from the Wireless Networks tab of the MagicLan Utility. • Add a profile • Edit a profile • Switch to a different profile • Remove a profile The wireless network adapter works in either infrastructure mode (which uses an access point) or ad hoc mode (a group of stations participating in the wireless LAN). Create or Modify a Configuration Profile To add a new configuration profile, click New on the Wireless Networks tab. To modify a configuration profile, select the configuration from the Profile list and click the Modify button. Profile Management: • Edit the General tab. • Edit the Security tab. • Edit the Advanced tab. To configure a profile for ad hoc or access point (infrastructure) mode, edit the Network Type field on the Advanced tab. Remove a Configuration Profile 1. Go to the Wireless Networks tab. 2. Select the profile to remove from the list of configuration profiles. 3. Click the Remove button. Switching to a different configuration profile 1. To switch to a different profile, go to the Wireless Networks tab. 2. Click on the profile name in the Profile List. 3. Click the Activate button. See also Scan Available Networks. General Tab In the MagicLan Utility, access the General tab by clicking Configure, New or Modify on the Wireless Networks tab. Edit the fields in the General tab to configure the configuration profile. Make sure to also edit the Security and Advanced tabs. Profile Name Identifies the configuration profile. This name must be unique. Profile names are not case sensitive. Network Names (SSID) The IEEE 802.11 wireless network name. This field has a maximum limit of 32 characters. Configure a SSID See also: • Configure a Profile for Ad Hoc Mode • Configure a Profile for Access Point (Infrastructure) Mode Ad Hoc Mode Profile Configuration To configure a profile in ad hoc mode, change the Network Type in Advanced tab. For ad hoc mode, modify the settings: • Network Name (on General Tab) • Transmit Power Level • 802.11b/g Preamble (if using 802.11b/g) • Wireless Mode When Starting an Ad Hoc Network Make sure to also edit the General and Security tabs. Infrastructure (Access Point) Mode Profile Configuration To configure a profile in infrastructure (access point) mode, change the Network Type in the Advanced tab. For access point mode, modify the settings: • Transmit Power Level • Power Save Mode • 802.11b/g Preamble (if using 802.11b/g) • Wireless Mode Make sure to also edit the General and Security tabs. Security Tab In the MagicLan Utility, access the Security tab by clicking New or Modify on the Wireless Networks tab. Click the Security tab in the Profile Management window. Edit the fields in the Security tab of Wireless Networks to configure the profile. To define the security mode, select the radio button of the desired security mode. Make sure to also edit the General and Advanced tabs. WPA Enables the use of Wi-Fi Protected Access (WPA). Choosing WPA opens the WPA-EAP drop-down menu. The options include: • TLS • TTLS • PEAP (EAP-MSCHAP V2) WPA WPAWPA WPA- -- -PSK PSKPSK PSK Enables WPA – PSK security. Click on the Configure button and fill in the WPA–PSK . 802.1x Enables 802.1x security. This option requires IT administration. Choosing 802.1x opens the 802.1x EAP type drop-down menu. The options include: • TLS • TTLS • PEAP (EAP-MSCHAP V2) • LEAP WEP Key (Static WEP) Enables the use of WEP keys that are defined on both the access point and the station. To define pre-shared encryption keys, choose the WEP Key radio button and click the Configure button to fill in the Define Pre-Shared Keys window. None No security (not recommended). Using TLS Security To use EAP-TLS security In the MagicLan Utility, access the Security tab in the Profile Management window. 1. On the Security tab, choose the WPA radio button. OR: On the Security tab, choose the 802.1x radio button. 2. Choose TLS from the drop-down menu. Enabling TLS security: To use EAP-TLS security, the machine must already have the EAP-TLS certificates downloaded onto it. Check with the IT manager. 1. If EAP-TLS is supported, choose TLS from the drop-down menu on the right, then click the Configure button. 2. Select the appropriate certificate authority from the list. The server/domain name and the login name are filled in automatically from the certificate information. Click OK. 3. Click OK. 4. Activate the profile. Using TTLS Security To use EAP-TTLS security In the MagicLan Utility, access the Security tab in the Profile Management window. 1. On the Security tab, choose the WPA radio button. OR: On the Security tab, choose the 802.1x radio button. 2. Choose TTLS from the drop-down menu. Enabling TTLS security: To use EAP-TTLS security, the machine must already have the EAP-TTLS certificates downloaded onto it. Check with the IT manager. 1. If EAP-TTLS is supported, choose TTLS from the drop-down menu on the right, then click the Configure button. 2. Select the appropriate certificate fr…

Text truncated - open the document above for the full version.

’

Samsung Electronics CO., LTD. 416, Maetan 3-Dong, Yeongtong-Gu, Suwon City, Gyeonggi-Do, Korea 443-742 Federal Communications Commission Authorization and Evaluation Division FCC ID : A3LSWL-2460C Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Jae-Hong Park / Senior Engineer SAMSUNG ELECTRONICS CO., LTD. Tel : 82-31-200-0194 Fax : 82-31-277-8290

FCC ID: A3LSWL-2460C Modular Approval Request Letter ESTECH CO., LTD. JAN 26, 2006 Dear Application Examiner, SAMSUNG ELECTRONICS CO., LTD. Wireless Card, FCC ID: A3LSWL-2460C, would like to have your authorization for Module Approval specific to the mobile device such as Printer and similar equipment. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The Radio portion of this module has been shielded, please see the external photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip AR5213. 3. “The modular transmitter must have its own power supply regulation.” The chips IF converter and RF/IF converter which will influence the frequency radiation, have to be 2.5VDC powered. The CF card interface provides 3.3VDC, so there are regulators in front of these chips, the part number of this regulator is ͽ΅ʹͤͥͧ͡Ͷ ́͟ ͑ 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the external photos or test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a CF card to PCMCIA adapter card. Please see section Photographs of Test Configuration in the test report. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: A3LSWL-2460C 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Jay Kim / Engineering Manager Manager of Telecom division ESTECH CO., LTD

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 25, 2006 RE: Samsung Electronics Co. Ltd. FCC ID: A3LSWL-2460 I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) Please provide label artwork for this equipment as it is intended to be marketed. 2.) It appears that a daughterboard (U1?) is attached to the main board. FCC rules specify that the underside of all PC boards must be photographed. Please supply additional Internal Photos of this part. 3.) Kindly note that only 11 channels are legal in North America. Will this device be restricted to Channels 1 to 11? If so, kindly provide some evidence addressing this issue. 4.) Are you seeking modular approval for this device? If so, then for a full Modular Approval the device is required to be tested outside of its host (typically on an extender card). If it is intended for a specific host or model, then a Limited Modular Approval (LMA) may apply. Regardless, the requirements of publication DA 00-1407 must be followed. Please address. 5.) Page 1 of the Test Report appears to have incorrectly listed the power. Kindly review. 6.) Restricted Band emissions (47CFR 15.205) do not appear to be addressed. This is especially critical in the band just above 2483.5MHz. Please provide radiated emissions data for the restricted bands below 2390MHz (set to Ch1) and above 2483.5MHz (set to Ch 11). Be sure to check across all data modes and bit rates. 7.) Is the RF power measurement peak, average or RMS? What data rates produced the highest power? The Test Report does not appear to specify. 8.) Since page 1 of the Test Report appears to address Canada requirements, are you also seeking Canada approval? If so, we will need a completed Canada application form. 9.) Assuming that this is a LMA application intended to be installed in a specific host, please provide photographic proof that the antenna is installed at a distance of 20cm or greater from the user’s lab during normal usage. 10.) Please add a photograph of the antenna (or antennas) intended for use with this device to the External Photograph exhibit. 11.) The video bandwidth settings used on OFDM and CCK are not consistent in Section 8.4. Please be sure to use appropriate and consistent instrument settings. Be sure to check for “worst case” of all the data rates. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2 January 25, 2006 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 February 4, 2006 RE: Samsung Electronics Co. Ltd. FCC ID: A3LSWL-2460 I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) The labeling for this device is still incorrect. It appears that you might be seeking a full unrestricted Modular Approval for this device. Both FCC and IC regulations require that the module itself be labeled, not just the printer into which this device may be installed. In addition, there is no Canada labeling with CN number available. Please provide labeling for the module itself complete with FCC ID and Canada identifiers. 2.) The Modular Approval letter is not clear in its intentions. Are you seeking a full unrestricted Modular Approval or a Limited Modular Approval (LMA) restricted to specific models and types of printers? Please review your modular approval request letter. 3.) The Test Report in section 13.2 shows an antenna gain that does not match the reported antenna gain shown in the RF Exposure exhibit. Please review. 4.) Please confirm that only channels 1-11 will be used for product shipped to North America. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Data Sheet Doc no: BB-WLAN2460-01 Version 0.2 Date: 11.13.2004 Page : 1 / 11 © Copyright Samsung Electro-mechanics Ltd. copying of this document prohibited, all rights reserved. DATE OF ISSUE : 11 / 13 / 2004 DATA SHEET (Preliminary) Digital Module Division WLAN R&D G. WRITTEN CHECKED APPROVED Jeon-Ho Lee Jin-O Yoo Eon Hwang CUSTOMER PRODUCT NAME Embedded Wireless LAN Module MODEL NAME SWL-2460C Part Number ISSUED BY CHECKED BYAPPROVED BY Head Office & Sales Dept. 314, Maetan-3Dong, Yeongtong-Gu Suwon, Kyunggi-Do, Korea TEL : +82 (0)31 210 6579 FAX : +82 (0)31 210 5529 Homepage : http://www.sem.samsung.co.kr Data Sheet Doc no: BB-WLAN2460-01 Version 0.2 Date: 11.13.2004 Page : 2 / 11 © Copyright Samsung Electro-mechanics Ltd. copying of this document prohibited, all rights reserved. Contents 0Document........................................................................................................................... 3 0.1Declaration......................................................................................................................................3 0.2Revision History.............................................................................................................................3 1Specification for WLAN CF embedded module.............................................................. 4 1.1Identification..................................................................................................................................4 1.2Hardware Specifications...............................................................................................................4 1.2.1Card standard............................................................................................................................ 4 1.2.2RF Characteristics..................................................................................................................... 4 1.2.3Mechanical specification........................................................................................................... 5 1.2.4Recommended pad design (top view)....................................................................................... 6 1.2.5Regulation................................................................................................................................. 7 1.2.6Environmental requirements..................................................................................................... 7 2Software specifications.................................................................................................... 8 2.1OS Support & Driver.....................................................................................................................8 2.1.1Available drivers........................................................................................................................ 8 2.2Security...........................................................................................................................................8 3RF test results.................................................................................................................... 9 Appendix 1. Host Interface Pin Map........................................................................................ 10 Appendix 2. Block Diagram.................................................................................................... 11 Data Sheet Doc no: BB-WLAN2460-01 0 Document 0.1 Declaration This specification is intended for Samsung 54Mbps embedded wireless LAN module. 0.2 Revision History 10/05/2004 Created 11/13/2004 Current Consumption spec was changed Page 4 Version 0.2 Date: 11.13.2004 Page : 3 / 11 © Copyright Samsung Electro-mechanics Ltd. copying of this document prohibited, all rights reserved. Data Sheet Doc no: BB-WLAN2460-01 1 Specification for WLAN CF embedded module 1.1 Identification 1.Samsung Product name 54Mbps WLAN CF embedded module 2.Samsung Model name SWL-2460C 3.Samsung Part number 1.2 Hardware Specifications 1.2.1 Card standard 1. Interface Standard Compact Flash Specification electrically compliant 2. Form Factor Customized Size 3. Operating voltage VCC : 3.0V ~ 3.6V VCCD : 1.8V ~ 3.3V 1.2.2 RF Characteristics RF Characteristics Min Typ Max 1. Specification Compliance IEEE 802.11b/g standard protocol (CSMA/CA) 2. Antenna External single antenna support 3. Frequency Range2.412Ghz~2.484Ghz 11b 14dBm 16dBm 18dBm 4. TX output power 11g 11dBm 11b - Transmit : 350mA - Receive : 265mA - Standby : 1mA - Transmit : 370mA - Receive : 275mA - Standby : 1mA 5. Current consumption (At max Throughput) 11g - Transmit : 470mA - Receive : 275mA - Standby : 1mA - Transmit : 485mA - Receive : 285mA - Standby : 1mA 6. Maximum input level -5dBm 11b - 85dBm - 84dBm 7. RX sensitivity 11g -70dBm Note : Sensitivity is based upon 1024 Bytes frame length, 11 Mbps(54Mbps) data rate, 8% (10%) PER Version 0.2 Date: 11.13.2004 Page : 4 / 11 © Copyright Samsung Electro-mechanics Ltd. copying of this document prohibited, all rights reserved. Data Sheet Doc no: BB-WLAN2460-01 1.2.3 Mechanical specification 1. Dimension 15151.7 2. Weight 1g 3. Pin outs 52pin + 8 GND pattern SMT Type 4. Antenna Connector SMT pads (Pin No.51) 1 ↓ Version 0.2 Date: 11.13.2004 Page : 5 / 11 © Copyright Samsung Electro-mechanics Ltd. copying of this document prohibited, all rights reserved. Data Sheet Doc no: BB-WLAN2460-01 1.2.4 Recommended pad design (top view) This is not a final version. Please check the latest version in doing your design. The pattern is symmetrical and some numbers are omitted. Refer to the appendix 1 for the pin numbering. Blue patterns are ground patterns and should be a part of main analogue ground plain. Blue patterns are excluded from pin numbering. Place thermal through holes on blue patterns to diffuse the heat from the WLAN module. 0.875 8.35 3.25 0.875 6.45 0.875 8.075 10.475 In doing your metal mask, make this hole size half of the PCB GND patterns to prevent …

Text truncated - open the document above for the full version.

Compliance Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned OK, Pass = Passed, Fail = Failed, N/A = not applicable SAMSUNG ELECTRONICS CO., LTD. 416, Meatan-3-Dong, YoungTong-Gu, Suwon City, Korea 82-31-277-8818 Measurement facility registration number Engineer J.H.Kim Manager Engineer J.M.Yang 94696 (Signature) (Signature) Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2005 , ANSI C 63.4 2003 2005-12-13 ~ 2006-01-23 SWL-2460C NONE SAMSUNG ELECTRO MECHANICS CO., LTD. KOREA Report Number : ESTF150601-007 , Web : www. estech. co. kr Page 1 of 44 Report NumberESTF150601-007 Manufacturer Country of origin Applicant Product 23-Jan-06 Wireless Mini PCI Card 4 5 6 7 10 10 10 10 12 16 16 16 17 17 17 17 19 23 23 23 23 25 5.2 Test instruments and measurement setu p ...................................................... 5.3 Measurement results .................................................................................... 7. Transmitter Power Spectral Density ..................................................................... 7.1 Test procedure .......................................................................................... 5.4 Trace data ................................................................................................... 6. Maximum Peak Output Power ........................................................................... 6.1 Test procedure .......................................................................................... 6.2 Measurement results .................................................................................... 5. 6dB Bandwidth Measurement ........................................................................... 5.1 Test procedure .......................................................................................... Contents 1. Laboratory Information .................................................................................... 2. Descri ption of EUT .......................................................................................... 3. Test Standards ................................................................................................ 4. Measurement condition .................................................................................... 7.2 Test instruments and measurement setup ...................................................... 7.3 Measurement results .................................................................................... 7.4 Trace data ................................................................................................... 8. Band-Edge and Out of Band Emissions ............................................................... Report Number : ESTF150601-007 , Web : www. estech. co. kr Page 2 of 44 8.1 Test procedure .......................................................................................... 8.2 Test instruments and measurement setup ...................................................... 8.3 Measurement results .................................................................................... 8.4 Trace data of band-edge & out of emissioin ................................................... 27 27 27 28 36 10.1 Measurement equipment ........................................................................ 36 10.2 Environmental conditions ........................................................................ 36 37 39 43 44 44 44 Appendix 1. Spectral diagram 10.3 Test data ............................................................................................. ... 11. Photographs of test setup .............................................................................. 12. Photographs of EUT ....................................................................................... 13.1 Standard Applicable .............................................................................. 13.2 Anetenna connected construction ............................................................ ... 13. Antenna Requirement .................................................................................... Report Number : ESTF150601-007 , Web : www. estech. co. kr Page 3 of 44 10. Measurement of conducted emission ............................................................ 9. Measurement of radiated emission ............................................................... ... 9.1 Measurement equipment ........................................................................... 9.2 Environmental conditions ........................................................................... 9.3 Test data ................................................................................................ 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Korea (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the appl…

Text truncated - open the document above for the full version.

1.Setup for Radiated Test : 30 ~ 1000 MHz [ Front ] [ Rear ] 2. Setup for Radiated Test :Above 1000 MHz [ Front ] 3. Setup for Conducted Test : 0.15 ~ 30 MHz [ Front ] [ Rear ] 4. Setup for Conducted Test [ 6dB Bandwidth Measurement ] [ Band-Edge and Out of Band Emissions ]
