A3LSX021ANDIGITAL SET TOP BOX

Warning Power Insert the power plug firmly.Do not connect multiple devices to a single outlet simultaneously. Do not touch the main body, power cable, or power plug with wet hands. If video/sound cable generates heat after connection, pull out the power cord and contact customer service immediately. installation/Maintenance Do not install in humid or dusty areas, and avoid installing near heating devices. To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Keep flammable substances or sprays away from the set-top box. Pull out the power plug during thunderstorms or when not used for a prolonged period of time. Do not place heavy objects on this product. Pull out the power plug at once and contact customer service if unusual noise, smell, or smoke comes out. Do not cover the top. general Check if the coaxial cable is correctly grounded before connecting to the set-top box. Ask the installation engineer to check if the set-top box to be connected is correctly grounded. Class 1 LED Product.This product complies with 21 CFR Chapter 1, subchapter J This product contains chemicals known to the State of California to cause cancer and reproductive toxicity. Caution Power Connect your TV after powering off the TV and the set-top box by pulling out the power plug. Before connecting the power source, permanent protective earth connection to the cable distribution should be made. The socket-outlet shall be installed near the equipment and shall be easily accessible The Mains plug is used as a disconnect device and shall stay readily operable at any time. Do not insert the power plug before connecting the power cable to the product. installation/Maintenance Install the product correctly complying with the instructions in the user guide. No connection to an antenna. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquid, such as vases, shall be placed on the apparatus. Do not remove the CableCARD™ from the set-top box. Do not spray water directly on the unit and do not use chemical solvents such as wax, mosquito spray, alcohol or detergent. Do not place any metal items such as pins, paper clips or coins on the top of the product. Do not place the product on unstable support. Risk of electric shock, Do NOT OPEN. Do not disassemble, repair, or remodel. Wipe the product with a soft and dry cloth when cleaning. The purpose of Safety Concerns is to ensure users’ safety and to prevent property losses. Please read this document carefully for proper use. © 2013 SAMSUNG ELECTRONICS Co., Ltd. All rights reserved. SX021AN* * : M (Motorola) C (CISCO) EnErgYStar qualified model only - Your Samsung Set-top Box is ENERGYSTAR qualified in its factory default settings. Change to certain features, settings and functionality in this Set-top Box can change the power consumption, possibly beyond the limits required for ENERGYSTAR qualification. - As an ENERGY STAR partner, Samsung has detemined that this product or product models meets the ENERGY STAR guidelines for energy efficiency. FCC Class B notice This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. notE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC rF radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. user information Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. If necessary, consult with your dealer or an experienced radio/television technician for additiona suggestions. You may find the booklet called How to Identify and Resolve Radio/TV Interference Problems helpful. This Booklet was prepared by the Federal Communications Commission. It is available from the U.S. Government Printing Office. Washington, DC 20402, Stock Number 004-000-00345-4. the party responsible for product compliance : SAMSUNG ELECTRONICS CO., LTD. America QA Lab of Samsung 3351 Michelson Drive Suite #290, Irvine, CA92612 USA open Source announcement You may obtain the complete corresponding source code from us for a period of three years after our last shipment of this product by sending email to: oss.request@samsung. com or find a copy of the source at http://opensource.samsung.com/ important Safety instructions Read these operati…

Text truncated - open the document above for the full version.

Rev 11/20/07 129, Samsung-ro, YeongTong-Gu, Suwon-Si, Gyeonggi-Do, Korea, 443-742 Tel No : +82-31-277-2787 Fax No : +82-31-277-2784 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: A3LSX021AN Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Parts List Operational description Block Diagram(SX021ANM).pdf Schematics(SX021ANM).pdf Part List(SX021ANM).pdf Operational Description(SX021ANM).pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name - - Sincerely, Jaywoo Lee / Engineer Samsung Electronics Co., Ltd.

DECLARATION OF CONFORMITY According to FCC Part 15 Applicant Name : Samsung Electronics Co., Ltd. Address : 129, Samsung-ro, YeongTong-Gu, Suwon-Si, Gyeonggi-Do, Korea, 443-742 Telephone : +82-31-277-2787 Declares that Product : Digital Set Top Box Model Name : SX021ANM, SX021ANC Report Number : CTK-2014-00195 This device complies with Part 15 of the FCC rules. Operations is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Test Laboratory: CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Designation Number : 805871 Tel : +82-31-339-9970 Fax : +82-31-624-9501 Responsible Party: Company Name : Samsung Electronics Co., Ltd. Company Address : 129, Samsung-ro, YeongTong-Gu, Suwon-Si, Gyeonggi-Do, Korea, 443-742 Phone : +82-31-277-2787 Fax : +82-31-277-2784 Name : Jaywoo Lee Signature :

129, Samsung-ro, YeongTong-Gu, Suwon-Si, Gyeonggi-Do, Korea, 443-742 Tel No : +82-31-277-2787 Fax No : +82-31-277-2784 Special Power of Attorney I, Sang Kyung (Peter) Ra of SAMSUNG Electronics Co., Ltd. hereby appoint Jaywoo Lee of SAMSUNG Electronics Co., Ltd. to represent me to act on my behalf to do any and all of the following : Sign on my behalf the agency, anti-drug and confidentiality cover letters and apply to FCC for the products. (FCC ID: A3LSX021AN) The right, powers and authority in fact to exercise any and all of the rights and powers herein granted shell commence and be in full force from 03/03/2014 and continue to e effective unless specifically terminated by either party. Dated 03/03/2014, Sang Kyung (Peter) Ra Sincerely, NAME: Sang Kyung(Peter), Ra TITLE: Head of QA Lab (General Manager) Applicant: Samsung Electronics America, Inc Address: 19 Chapin Rd, Building D. Pine Brook, NJ 07058

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT External Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Label Photographs

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-624-9501 www.e-ctk.com Antenna

Application Bluetooth Zigbee WLAN (IEEE 802.11 b/g) ISM 2.4GHz Wireless Devices Features PIFA Structure Small Size (3.0*1.5*1.2mm 3 ) Easy Optimizing with external lumped matching components SMT Available under Pb-free Condition RoHSCompliant DATASHEET DocumentDatasheet TypeDielectricChip Antenna Application2.4GHz Part No.AMAN301512ST01 Revision1.1 Notes The contents of this datasheet are subject to change without notice. Please confirm the specifications and delivery conditions when placing your order. AMOTECH AMOTECH Co., Ltd. Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 2 Rev. NoDateTitleContentsPage 0’08.09.30New Published 1’09.03.24Data Added Efficiency data8 Changed carrier tape width (W16mm →W12mm)12 1.1’09.04.07FormatChangeddocument format Table of Content Revision History 1.Specifications 3 1.1 Electrical Specifications 3 1.2 Mechanical Specifications 3 1.3 Appearance and Material 3 2. PCB Design for Test 4 2.1 Evaluation BoardDimension 4 2.2 PCB Design Guide 4 3. Measurement Result 5 3.1 Typical Measurement Result (VSWR/RL,Smithchart) 5 3.2 Typical Measurement Result(Gain, Radiation Pattern) 6 4. Reliability 7 5. Soldering Reflow Profile 7 6. Packaging 8 6.1 Carrier Tape Dimension 8 6.2 PackagingQuantity 8 6.3 Packaging Label 8 Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 3 NoItemSpec.Remark 1Frequency Range [GHz]2.4 ~2.485 2VSWRMax 3.0:1 3Peak Gain [dBi]typ. 3.4 4Total Avg. Gain [dBi]typ. -0.8 5Efficiency [%]typ. 82 6PolarizationLinear 7Impedance [Ω]Nominal 50 The results are measured on the 50x50mm 2 evaluation board(EVB). See Page 6. for more detail gain parameter NoItemSpec.Remark 1Dimensions (LxWxH)3.0x1.5x1.2 mm 3 2Unit Weighttyp. 20 mg 3Operating Temperature-35 ~ +85 °C 1.1 Electrical Specifications 1.2 Mechanical Specifications NoItemFunctionMaterial ① Marking Feeding Index Ink ② MarkingWeek numberInk ③ ElectrodeRadiation ElementAg ④ Ceramic Body - Ceramic 1.3 Appearance & Material 1. Specifications ② ③ ① ④ [unit : mm] Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 4 2.1 Evaluation Board Dimension 2.2 PCB Design Guide 2. PCB Design for Test ② ③ ① NoPin Assignment ① Feeding ②GND ③ GND Matching Component 50 Ohm Feeding Line [unit : mm] Evaluation board size ~ 50x50 Fill Cut Area (GND Clearance) ~ 7.5x3.3 [PCB Solder Land] Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 5 3.1 Typical Measurement Result (VSWR/RL, Smithchart) 3. Measurement Result The results are measured on the 50x50mm 2 evaluation board(EVB). ② ③ ① NoMatching Value ①1.0 nH ②3.3 nH ③ 1.2 pF Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 6 [Azimuth plane @2.45GHz ] [Elevation1 plane @2.45GHz ] [Elevation2 plane @2.45GHz ] [3D Radiation Pattern] x y z -y Azimuth E1 E2 3.2 Typical Measurement Result (Gain, Radiation Pattern) Peak Gain (dBi) Avg. Gain (dBi) Total Avg. Gain (dBi) Efficiency (%) Azimuth-0.54-2.46 -0.882 Elevation 13.29-1.80 Elevation 22.81-0.74 Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 7 NoItemTest ConditionTest Requirements 1 Adhesive Strength of Termination 1.Applied force on SMT chip till detached point from PCB. 1. No mechanical damage by applied force 2. Strength (F) > 3 kgf 2 Thermal Shock (Cycle) 1. Step 1 : -40 ±3°C, 30 min Step 2 : +125 ±3°C, 30 min 2. Number of cycle : 30 1. No visual damage 2. Within electric spec (VSWR) 3 High Temperature Resistance 1. Temperature : +125 ±5°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) 4 Low Temperature Resistance 1. Temperature : -40 ±5°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) 5Humidity 1. Humidity : 85 % RH Temperature : +85 ±3°C 2. Time : 1000 ±24 hrs 1. No visual damage 2. Within electric spec (VSWR) F SMD PAD PCB 4. Reliability 5. Soldering Reflow Profile Datasheet / Dielectric Chip Antenna / 2.4GHz AMAN301512ST01 (Rev 1.1) 8 ItemSpec.ItemSpec.ItemSpec. A01.80 ±0.10P04.00 ±0.10E1.75 ±0.10 B03.30 ±0.10P14.00 ±0.10F5.50 ±0.10 K01.35 ±0.10P22.00 ±0.10W12.00 ±0.30 D01.55 ±0.05--t0.30 ±0.05 Item QuantityDimension Reel2,500eaΦ7” * 12mm Inner Box7,500 ea (3 reel)185 * 185 * 68 (mm 3 ) Outer Box137,500 ea (5 Inner Box)365 * 200 * 200 (mm 3 ) Outer Box2105,000 ea (14 Inner Box)390 * 390 * 280 (mm 3 ) 6.1 Carrier Tape Dimension 6.2 Packaging Quantity 6.3 Packaging Label 6. Packaging AMOTECH Co., Ltd. 5BL-1Lot, 617, Namchon-Dong, Namdong-Gu, Incheon, Korea Dielectric Chip Antenna P/N : AMAN301512ST01 Lot No : Quantity : 2,500 pcs Date : 2009/04/09

GreenPeak GP710 IEEE 802.15.4 Communications Controller 1 This document is property of GreenPeak Technologies B.V. Reproduction or disclosure in whole or in part to parties other than the GreenPeak Technologies B.V. client or partner who is the original receiver of this document is permitted only with the written and express consent of GreenPeak Technologies B.V. GreenPeak Technologies reserves the right to make changes at any time without notice to improve the design. Datasheet GreenPeak GP710 GreenPeak GP710 IEEE 802.15.4 Communications Controller GP_P006_DS_03945 ** PRELIMINARY ** V 0.11 * SUBJECT TO CHANGE * Copyright © 2012 GreenPeak Technologies B.V. Page 2 of 26 Table of Contents 1 Introduction ................................................................................................................................................. 3 2 Features ...................................................................................................................................................... 3 3 Block Diagram ............................................................................................................................................ 4 4 Functional Description ................................................................................................................................ 4 4.1 Radio and PHY ................................................................................................................................................... 4 4.1.1 2.4 GHz Transceiver ..................................................................................................................................... 4 4.1.2 Radio Configurations ..................................................................................................................................... 4 4.1.3 Wi-Fi Robustness .......................................................................................................................................... 6 4.1.4 Packet-in-Packet Resynchronization............................................................................................................. 6 4.1.5 RSSI and Link Quality Indication ................................................................................................................... 6 4.2 Medium Access Control (MAC)........................................................................................................................... 6 4.3 Security Engine................................................................................................................................................... 6 4.4 Host Interface ..................................................................................................................................................... 6 4.4.1 Dual Stack / Dual PAN Support .................................................................................................................... 7 4.4.2 Control Signals .............................................................................................................................................. 7 4.4.3 SPI Slave Interface ....................................................................................................................................... 7 4.5 Timing and Control ........................................................................................................................................... 10 5 Electrical Characteristics .......................................................................................................................... 11 5.1 Absolute Maximum Ratings .............................................................................................................................. 12 5.2 Recommended Operating Conditions ............................................................................................................... 12 5.3 Current Consumption ........................................................................................................................................ 13 5.4 Receiver Characteristics ................................................................................................................................... 14 5.5 Transmitter Characteristics ............................................................................................................................... 15 5.6 Digital Timing Characteristics ........................................................................................................................... 16 5.7 Wake-up and Standby Timing Characteristics .................................................................................................. 17 5.8 Crystal Oscillator Specifications ....................................................................................................................... 18 5.8.1 The 16 MHz Crystal Oscillator .................................................................................................................... 18 5.9 Reset Characteristics ........................................................................................................................................ 19 5.9.1 Host-controlled Reset .................................................................................................................................. 19 5.9.2 Power On Reset Circuit ............................................................................................................................... 19 6 Device Information .................................................................................................................................... 20 6.1 QFN40 Package ............................................................................................................................................... 20 6.1.1 QFN40 Pin Assignments ............................................................................................................................…

Text truncated - open the document above for the full version.

CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 1 of 2 RF EXPOSURE EVALUATION Applicant : Samsung Electronics Co., Ltd. Applicant Address : 129, Samsung-ro, YeongTong-Gu, Suwon-Si, Gyeonggi-Do, Korea, 443-742 Kind of Product : Digital Set Top Box Basic Model name : SX021ANM Variant Model name : SX021ANC Antenna type : Chip antenna * 2 Gain : 3.4 dBi Frequency Range : 2405 – 2480 MHz Number of channels : 16 CTK Co., Ltd. (Ho-dong), 113, Yejik-ro, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 2 of 2 ** MPE Calculations ** The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 2.52 + 3.4 = 7.42 dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (3.4 / 10) G = 2.188 Power density at the specific separation: S = PG/(4R 2 π) S = (2.52 * 2.188)/(4 * 20 2 * π) S =0.0011 mW/cm 2 Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density at 20cm does not exceed the 1 mW/cm 2 limit. Estimated safe separation: R = √(PG / 4π) R = √(2.52 * 2.188 / 4π) R = 0.66 cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE)
