A3LTWIN2000VCR

Video Cassette Recorder Owner’s Manual SV-D142P SV-D52P Safety Instructions ii Note to CATV system installer: This reminder is provided to call CATV system installer's attention to Article 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I) that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical. Caution:FCC regulations state that any unauthorized changes or modifications to this equipment may void the user's authority to operate it. Caution:To prevent electric shock, match wide blade of plug to wide slot, fully insert. Attention:Pour eviter les chocs electriques, introduire la lame le plus large de la fiche dans la borne correspondante de la prise et pousser jusqu’au fond. Important:One Federal Court has held that unauthorized recording of copyrighted TV programs is an infringement of U.S. copyright laws. Certain Canadian programs may be copyrighted and any unauthorized recording in whole or in part may be a violation of these rights. To prevent damage which may result in fire or electric shock hazard, do not expose this appliance to rain or moisture. RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates high voltage is present inside. It is dangerous to make any kind of contact with any inside part of this product. This symbol alerts you that important literature concerning operation and maintenance has been included with this product. As an ENERGYSTAR Partner, Samsung Electronics America, Inc. has determined that this product or product model meets the ENERGY STAR guidelines for energy efficiency Important Safety Instructions 1. Read Instructions-All the safety and operating instructions should be read before the product is operated. 2. Retain Instructions-The safety and operating instructions should be retained for future reference. 3. Heed Warnings-All warnings on the product and in the operating instructions should be adhered to. 4. Follow Instructions-All operating and using instructions should be followed. 5. Cleaning-Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 6. Attachments-Do not use attachments not recommended by the product manufacturer as they may cause hazards. 7. Water and Moisture-Do not use this product near water-for example near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like. 8.Accessories-Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product. Any mounting of the product should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manu- facturer. Safety Instructions iii 9.Cart Usage-Aproduct and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 10.Ventilation-Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. 11.Power Sources-This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions. 12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product. 13.Outdoor Antenna Grounding-If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA70 provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharg e unit, size of grounding conductors, location of antennadischarge unit, connection to grounding electrodes, and requirements for the grounding electrode. 14.Lightning-For added protection for this product during a lightning storm or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges. 15.Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. 16.Overloading-Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. 17.Object and Liquid Entry-Never push objects of any kind into this product through openings …

Text truncated - open the document above for the full version.

Samsung Electronics 5-1 5. Schematic Diagrams 5-25-35-45-55-65-85-105-125-135-145-155-165-175-185-19  Block Identification of Main PCB - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-1 S.M.P.S. (120 Voltage) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-2 S.M.P.S. (Free Voltage) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-3 Power - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - (SV-D180UM/D130UM/D125UM/D120UM/D70UM/D65UM/D60UM SV-D180P/D100UP/D60P/D50UP/D141P/D61P/D151P/D142P/D52P/D35B) 5-4 Power - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - (SV-D95UM/D95UMA/D95UMV/D45UM/D45UMA/D45UMV/D55UP/D45UP/D45UPA/D45UPV SV-D95P/D95PA/D95PV/D45P/D45PA/D45PV/D55P/D23P/D15B/D15M/SP-D15G) 5-5 Logic - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5-6 Audio/Video - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-7 Hi-Fi/MTS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -5-8 TM-Block/Input-Output (SV-D180UM/D180P) - - - - - - - - - - - - - - - - - - - - - - - 5-9 TM-Block/Input-Output - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - (SV-D130UM/D125UM/D120UM/D95UMA/D95UMV/D70UM/D65UM/D60UM/D45UM.D45UMA SV-D45UMV/D100UP/D60P/D55UP/D50UP/D45UP/D45UPA/D45UPV/D141P/D95P/D95PA/D95PVSV-D61P/D45P/D45PA/D45PV/D151P/D55P/D35B/D15B/D15M/SP/D15G/D142P/D52P/D23P) 5-10 Display (LED-Module) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-11 Display (LED-Lamp) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-12 Remote-Control (Jog/Shuttle) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-13 Remote-Control (Multi-TV) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-14 Remote-Control (VCR Only) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Schematic Diagrams5-2 Samsung Electronics For schematic Diagram- Resistors are in ohms, 1/8W unless otherwise noted. Note Special note : Most semiconductor devices are electrostatically sensitive and therefore require the special handling techniques described unde r the “electrostatically sensitive (ES) devices” section of this service manual.Note : Do not use the part number shown on this drawing for ordering. The correct part number is shown in the parts list (may be sligh tly different or amended since this drawing was prepared).Important safety notices : Components identified with the mark have the special characteristics for safety. When replacing any of these components. Use only the same type.  Block Identification of Main PCB Schematic Diagrams Samsung Electronics 5-3 5-1 S.M.P.S. (120 Voltage) Schematic Diagrams5-4 Samsung Electronics 5-2 S.M.P.S. (Free Voltage) Schematic Diagrams Samsung Electronics 5-5 5-3 Power (SV-D180UM/D130UM/D125UM/D120UM/D70UM/D65UM/D60UM/D180P/D100UP/D60P/D50UP/D141P/D61P/D151P/D142P/D52P/D35B) Schematic Diagrams5-6 Samsung Electronics 5-4 Power (SV-D95UM/D95UMA/D95UMV/D45UM/D45UMA/D45UMV/D55UP/D45UP/D45UPA/D45UPV/D95P/D95PA/D95PV/D45P/D45PA/D45PV/D55P/D23P/D1 5B/D15M/SP-D15G) Schematic Diagrams Samsung Electronics 5-7 5-5 Logic Schematic Diagrams5-8 Samsung Electronics * These values are measured with a Hi-Fi standard tape.* 5p-p means 5 volts peak to peak. It ’ s a kind of data or clock wave form. * The value under 0.5 volt is regarded as 0 volt. Unit : Volt Pin No. Power Off Stop(EE) Play Pin No. Power Off Stop(EE) Play Pin No. Power Off Stop(EE) Play Pin No. Power Off Stop(EE) Play 1 0 5 or 0 5p-p 26 5 5 5p-p 51 5 5 5 76 2.5 2.5 0 2 0 5 or 0 5p-p 27 0 0 0 52 2.8 2.8 2.8 77 0 2.5 0 3 0 0 0 28 0 0 0 53 2.5 2.5 2.5 78 0 0 0 4 0 0 0 29 PB:1.3, EE:2.2, REC:5 54 0 0 0 79 0 5 2.5 5 30 SP:0, LP:0, SLP:0 55 0 0 0 80 0 0 3 6 31 0 0 0 56 0 0 0 81 0 2.2p-p 2.2p-p 7 32 2 5 0 57 5 5 5 82 5 5 5 8 33 5 5 5p-p 58 5 5 5 83 0 0 0 9 34 0 5p-p 5p-p 59 5 5 5 84 0 0 0 10 35 0 0 5p-p 60 0 0 0 85 0 0 0 11 36 5 5 5 61 0 0 0 86 0 0 0 12 37 Clock data 62 0 0 0 87 5 5 5 13 0 0 0 38 63 0 5 5 88 5 5 5 14 39 0 0 0 64 0 0 0 89 15 5 VCR:5, TV:0 40 Clock data 65 0 5p-p 5p-p 90 16 Safety Tab, YES:5, NO:0 41 66 0 5p-p 5p-p 91 17 42 5 5 5 67 0 5 5p-p 92 18 43 0 0 5p-p 68 0 0 0 93 5p-p data for LED display 19 0 0 0 44 0 0 5p-p 69 2.5 2.5 2.5 94 20 0 0 0 45 5 5 0 70 2.5 2.5 2.5 95 21 0 0 0 46 5 5 0 71 0 0 0 96 22 0 0 0 47 Video out signal 72 2.5 2.5 2.5 97 23 0 5p-p 5p-p 48 0 0 0 73 5 5 5 98 0 5p-p 5p-p 24 0 0 0 49 Video input signal 74 2.5 2.5 2.5 99 0 5 0 25 5 5 5 50 75 2.5 2.5 2.5 100 0 1 0 IC601 VOLTAGE TABLE IC601 MN101D02F/MN101D02D None input : 5, Any input : 5p-p 5p-p data for LED display 5V when the front video jack is inerted 5p-p for Hi-Fi/EEPROM/PLL data,clock Schematic Diagrams Samsung Electronics 5-9 5-6 Audio/Video Schematic Diagrams5-10 Samsung Electronics Unit : Volt Pin No. Power Off Stop(EE) Play Pin No. Power Off Stop(EE) Play Pin No. Power Off Stop(EE) Play Pin No. Power Off Stop(EE) Play 1 2.5 2.5 2.5 25 3 3 3 51 0 0.8 0.8 76 Audio from TM-block 2 2.5 2.5 2.5 26 2.2 2 2.2 52 0.8 2.3 2.3 77 0 0 0 3 2.5 2.5 2.5 27 0 0 0 53 0 0 0 78 Audio from L2(front) 4 2.5 2.5 2.5 28 1.2 1.6 1.6 54 1 5 5 79 0 2.4 2.4 5 0 0 0 29 0 1 1 55 0 0.3 0.3 80 Audio from L1(rear) 6 2.5 2.5 2.5 30 0 0 0 56 1 5 5 81 0 0 0 7 2.5 2.5 2.5 32 0 0 0 57 1 5 5 82 0 0.7 0.7 8 1.8 1.8 1.8 33 0.4 5p-p 5p-p 58 1 3.6 3.6 83 0 0.7 0.7 9 0 0 0 34 0 5p-p 5p-p 59 0 0 0 84 0 0.7 0.7 10 5 5 5 35 0.8 Video Out Video Out 60 0.9 3.8 3.8 85 0 0.7 0.7 11 2.2 3.1 0 36 0 1 1 61 0.5 4 4 86 0 0 0 12 5 5 0 37 1.3 1.3 1.3 62 0 2.7 2.7 87 0 5 5 13 0 0.8p-p 0.8p-p 38 Video from L1(rear) 63 0 2 2 88 0 4.4 1.8 14 0 0.8p-p 0.8p-p 39 0 3.5 3.5 64 0.7 2.2 2.2 89 0 4.4 1.8 15 0 0.8 0 40 Video from L2(front) 65 0 4 4 90 0 4.4 1.8 16 5 5 0.3 41 0 0.2 5 66 0 2 0 91 0 4.4 1.8 17 2.2 2.2 0 4…

Text truncated - open the document above for the full version.

FCC CFR47 PART 15 TV INTERFACE DEVICE TEST REPORT FOR VCR MODEL : SV-D142P FCC ID: A3LTWIN2000 REPORT NUMBER: 99U0743-1 ISSUE DATE: JANUARY 04, 2000 Prepared for SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 TABLE OF CONTENTS PAGE 1.VERIFICATION OF COMPLIANCE ................................................................................................................... 2 2.PRODUCT DESCRIPTION .................................................................................................................................... 3 3.TESTED SYSTEM DETAILS................................................................................................................................. 6 4.TEST FACILITY...................................................................................................................................................... 6 5.ACCREDITATION AND LISTING....................................................................................................................... 6 6.MEASUREMENT INSTRUMENTATION ........................................................................................................... 6 7.MEASURING INSTRUMENT CALIBRATION .................................................................................................. 7 8.UNITS OF MEASUREMENT................................................................................................................................. 7 9.ANTENNAS............................................................................................................................................................... 7 10.CONDUCTED EMISSION TEST PROCEDURE ...........................................................................................8 11. RADIATED EMISSION TEST PROCEDURE .................................................................................................... 8 12.AMBIENT CONDITIONS .................................................................................................................................. 9 13.EQUIPMENT MODIFICATIONS..................................................................................................................... 9 14.EUT SETUP PHOTOS ...................................................................................................................................... 10 15.TEST EQUIPMENT LIST................................................................................................................................ 12 16.TEST RESULT SUMMARY ............................................................................................................................ 13 17.CONFIGURATION BLOCK DIAGRAM ...................................................................................................... 23 Exhibits 1. Proposed FCC ID Label Format 2. Authorization Letter 3. User’s Manual 4. Schematic Diagram 5. EUT Photographs REPORT NO:99U0743-1 DATE: JANUARY 04, 2000 FCC ID: A3LTWIN2000 EUT: VCR 2 OF 23 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1.VERIFICATION OF COMPLIANCE COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA CONTACT PERSON: BEN KIM / MANAGER TELEPHONE NO:408-544-5124 MODEL NO/NAME: SV-D142P SERIAL NO:N/A DATE TESTED: JANUARY 04, 2000 TYPE OF EQUIPMENT:TV INTERFACE DEVICE MEASUREMENT DISTANCE:(X) 3 METER ( ) 10 METER FCC RULES:PART 15.115 MEASUREMENT PROCEDUREANSI C63.4: 1992 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUT YES NO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 21 for comments) NO TEST RESULTPASSED The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Reviewed By T. N. COKENIAS / ENGINEERING DIRECTOR COMPLIANCE CERTIFICATION SERVICES REPORT NO:99U0743-1 DATE: JANUARY 04, 2000 FCC ID: A3LTWIN2000 EUT: VCR 3 OF 23 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2.PRODUCT DESCRIPTION CHASSI S TYP EMETAL LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 14.318 MHz NUMBER OF PCB LAYERS1 LAYER POWER REQUIREMENTS110 V AC, 60 Hz NO. OF EXTERNAL I/O CONNECTORS 11 External Peripheral Devices Device TypeManufacturerModel NumberSerial No.FCC ID / DoC TVOPTIMUS16-13301316N/A NTSC PATTERN GENERATOR LEADER IN JAPAN N/A1060096N/A REPORT NO:99U0743-1 DATE: JANUARY 04, 2000 FCC ID: A3LTWIN2000 EUT: VCR 4 OF 23 COMPLIANCE CONSULTING SERVICESDOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. External I/O Cable Construction Description CABLE NO: 1 I/O Port: Antenna InNumber of I/O ports of this type: 1 Number of Conductors: 2 Connector Type: F Connector Capture Type: Screw-In Type of Cable used: Shielded Cable Connector Type: Molded Cable Length: 4 M Bundled During Tests: Yes Data Traffic Generated: Yes Remark: N/A CABLE NO: 2 I/O Port: RF OutNumber of I/O ports of this type: 1 Number of Conductors: 2 Connector Type: F Connector Capture Type: Screw-In Type of Cable used: Shielded Cable Connector Type: Molded Cable Length: 1 M Bundled During Tests: No Data Traffic Generated: Yes Remark: N/A …

Text truncated - open the document above for the full version.

FCC CFR47 PART 15 TV INTERFACE DEVICE TEST REPORT FOR VCR MODEL: SV-D142P FCC ID: A3LTWIN2000 REPORT NUMBER: 99U0743-1 ISSUE DATE: JANUARY 04, 2000 Prepared for SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE..................................................................................................................2 2. PRODUCT DESCRIPTION..................................................................................................................................3 3. TESTED SYSTEM DETAILS...............................................................................................................................6 4. TEST FACILITY....................................................................................................................................................6 5. ACCREDITATION AND LISTING.....................................................................................................................6 6. MEASUREMENT INSTRUMENTATION..........................................................................................................6 7. MEASURING INSTRUMENT CALIBRATION................................................................................................7 8. UNITS OF MEASUREMENT...............................................................................................................................7 9. ANTENNAS.............................................................................................................................................................7 10. CONDUCTED EMISSION TEST PROCEDURE..........................................................................................8 11. RADIATED EMISSION TEST PROCEDURE...................................................................................................8 12. AMBIENT CONDITIONS................................................................................................................................9 13. EQUIPMENT MODIFICATIONS...................................................................................................................9 14. EUT SETUP PHOTOS....................................................................................................................................10 15. TEST EQUIPMENT LIST..............................................................................................................................12 16. TEST RESULT SUMMARY...........................................................................................................................13 17. CONFIGURATION BLOCK DIAGRAM.....................................................................................................25 Exhibits 1. Proposed FCC ID Label Format 2. Authorization Letter 3. User’s Manual 4. Schematic Diagram 5. EUT Photographs REPORT NO:99U0743-1 DATE: JANUARY 04, 2000 FCC ID: A3LTWIN2000 EUT: VCR 2 OF 25 COMPLIANCE CONSULTING SERVICES DOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME: SAMSUNG ELECTRONICS CO., LTD. 416 MAETAN DONG, PALDAL GU SUWON SHI, KOREA CONTACT PERSON: BEN KIM / MANAGER TELEPHONE NO: 408-544-5124 MODEL NO/NAME: SV-D142P SERIAL NO: N/A DATE TESTED: JANUARY 04, 2000 TYPE OF EQUIPMENT: TV INTERFACE DEVICE MEASUREMENT DISTANCE: (X) 3 METER ( ) 10 METER FCC RULES: PART 15.115 MEASUREMENT PROCEDURE ANSI C63.4: 1992 EQUIPMENT AUTHORIZATION PROCEDURE CERTIFICATION MODIFICATIONS MADE ON EUT YES NO DEVIATIONS FROM MEASUREMENT PROCEDURE YES (refer to section 21 for comments) NO TEST RESULT PASSED The above equipment was tested by Compliance Certification Services for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Reviewed By T. N. COKENIAS / ENGINEERING DIRECTOR COMPLIANCE CERTIFICATION SERVICES REPORT NO:99U0743-1 DATE: JANUARY 04, 2000 FCC ID: A3LTWIN2000 EUT: VCR 3 OF 25 COMPLIANCE CONSULTING SERVICES DOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPE METAL LIST OF EACH OSC. OR XTAL. FREQ. (FREQ.>=1 MHz) 14.318 MHz NUMBER OF PCB LAYERS 1 LAYER POWER REQUIREMENTS 110 V AC, 60 Hz NO. OF EXTERNAL I/O CONNECTORS 11 External Peripheral Devices Device Type Manufacturer Model Number Serial No. FCC ID / DoC TV OPTIMUS 16-133 01316 N/A NTSC PATTERN GENERATOR LEADER IN JAPAN N/A 1060096 N/A REPORT NO:99U0743-1 DATE: JANUARY 04, 2000 FCC ID: A3LTWIN2000 EUT: VCR 4 OF 25 COMPLIANCE CONSULTING SERVICES DOCUMENT NO:CCSUP4027B 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089 USA TEL:(408) 752-8166 FAX:(408) 752-8168 This report shall not be reproduced except in full, without the written approval of CCS. External I/O Cable Construction Description CABLE NO: 1 I/O Port: Antenna In Number of I/O ports of this type: 1 Number of Conductors: 2 Connector Type: F Connector Capture Type: Screw-In Type of Cable used: Shielded Cable Connector Type: Molded Cable Length: 4 M Bundled During Tests: Yes Data Traffic Generated: Yes Remark: N/A CABLE NO: 2 I/O Port: RF Out Number of I/O ports of this type: 1 Number of Conductors: 2 Connector Type: F Connector Capture Type: Screw-In Type of Cable used: Shielded Cable Connector Type: Molded Cable Length: 1 M Bundled During Tests: No Data Traffic Generated: Yes Remark: N/A CABLE NO: 3 I/…

Text truncated - open the document above for the full version.
