A3LWCA731MWi-Fi/BT Transceiver

Version 1.0 XuGuang Tech page 1 of 12 Operation Description of WCA731M 1. Introduction WCA731M is a Wi-Fi / Bluetooth Combo module compliant with IEEE802.11 a.b.g.n.ac MAC/baseband/radio and Bluetooth 5.0 optimized for low-power applications. The core chipset is from MediaTek part number MT7668AUN. 2. Hardware Architecture: 2.1 Main Chipset Information Item Vendor Part Number IEEE802.11 a.b.g.n.ac mac/baseband/radio Bluetooth 5.0 MediaTek MT7668AUN 3. Product Details -Data Modulation DSSS:CCK,BPSK,QPSK for 802.11b OFDM:BPSK,QPSK,16QAM,64QAM,256QAM for 802.11a,g,n,ac FHSS:GFSK,OQPSK, 8DPSK, π/4DPSK for Bluetooth -Frequency Range 2400-2497MHz 5150-5350MHz 5470-5725MHz 5725-5825MHz Version 1.0 XuGuang Tech page 2 of 12 - IEEE 802.11n HT20 - IEEE 802.11n HT40 Version 1.0 XuGuang Tech page 3 of 12 -IEEE 802.11ac -Output Power tolerance Output power ± 1.0dBm -Simultaneous transmission BT BT LE 2.4GHz Wi-Fi 5GHz Wi-Fi BT O O O BT LE O O O 2.4GHz Wi-Fi O O X 5GHz Wi-Fi O O X -Recommended Operating conditions Min Typ. Max Unit Operating voltage 4.5 5 5.5 V Operating temperature(ambient) -20 25 50 °C Version 1.0 XuGuang Tech page 4 of 12 -AS Information Company Name: CHENGDU XUGUANG TECHNOLOGY CO.,LTD. Fax: +86-28-84841628 Tel: +86-28-84841628 Add: 2 section of park road Longquanyi Chengdu China -Certification Information 1) Name(Model name): 2) Certification ID: 3) Company Name: 4) Production date 5) Vendor: Version 1.0 XuGuang Tech page 5 of 12 FCC MODULAR APPROVAL INFORMATION EXAMPLES for Manual This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Version 1.0 XuGuang Tech page 6 of 12 OEM INTEGRATION INSTRUCTIONS: This device is intended only for OEM integrators under the following conditions: The module must be installed in the host equipment such that 20 cm is maintained between the antenna and users, and the transmitter module may not be co-located with any other transmitter or antenna. The module shall be only used with the internal on-board antenna that has been originally tested and certified with this module. External antennas are not supported. As long as these 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). The end-product may need Verification testing, Declaration of Conformity testing, a Permissive Class II Change or new Certification. Please involve a FCC certification specialist in order to determine what will be exactly applicable for the end-product. Validity of using the module certification: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization for this module in combination with the host equipment is no longer considered valid and the FCC ID of the module cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. In such cases, please involve a FCC certification specialist in order to determine if a Permissive Class II Change or new Certification is required. Upgrade Firmware: The software provided for firmware upgrade will not be capable to affect any RF parameters as certified for the FCC for this module, in order to prevent compliance issues. End product labeling: This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: A3LWCA731M”. Information that must be placed in the end user manual: The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user's manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. Version 1.0 XuGuang Tech page 7 of 12 FCC MODULAR APPROVAL INFORMATION EXAMPLES for Manual This device complies with Part 15 of the F…

Text truncated - open the document above for the full version.

Version 1.0 XuGuang Tech page 1 of 12 Operation Description of WCA734M 1. Introduction WCA734M is a Wi-Fi / Bluetooth Combo module compliant with IEEE802.11 a.b.g.n.ac MAC/baseband/radio and Bluetooth 5.0 optimized for low-power applications. The core chipset is from MediaTek part number MT7668AUN. 2. Hardware Architecture: 2.1 Main Chipset Information Item Vendor Part Number IEEE802.11 a.b.g.n.ac mac/baseband/radio Bluetooth 5.0 MediaTek MT7668AUN 3. Product Details -Data Modulation DSSS:CCK,BPSK,QPSK for 802.11b OFDM:BPSK,QPSK,16QAM,64QAM,256QAM for 802.11a,g,n,ac FHSS:GFSK,OQPSK, 8DPSK, π/4DPSK for Bluetooth -Frequency Range 2400-2497MHz 5150-5350MHz 5470-5725MHz 5725-5825MHz Version 1.0 XuGuang Tech page 2 of 12 - IEEE 802.11n HT20 - IEEE 802.11n HT40 Version 1.0 XuGuang Tech page 3 of 12 -IEEE 802.11ac -Output Power tolerance Output power ± 1. 0dBm -Simultaneous transmission BT BT LE 2.4GHz Wi-Fi 5GHz Wi-Fi BT O O O BT LE O O O 2.4GHz Wi-Fi O O X 5GHz Wi-Fi O O X -Recommended Operating conditions Min Typ. Max Unit Operating voltage 4.5 5 5.5 V Operating temperature(ambient) -20 25 50 °C Version 1.0 XuGuang Tech page 4 of 12 -AS Information Company Name: CHENGDU XUGUANG TECHNOLOGY CO.,LTD. Fax: +86-28-84841628 Tel: +86-28-84841628 Add: 2 section of park road Longquanyi Chengdu China -Certification Information 1) Name(Model name): 2) Certification ID: 3) Company Name: 4) Production date 5) Vendor: Version 1.0 XuGuang Tech page 5 of 12 FCC MODULAR APPROVAL INFORMATION EXAMPLES for Manual This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Version 1.0 XuGuang Tech page 6 of 12 OEM INTEGRATION INSTRUCTIONS: This device is intended only for OEM integrators under the following conditions: The module must be installed in the host equipment such that 20 cm is maintained between the antenna and users, and the transmitter module may not be co-located with any other transmitter or antenna. The module shall be only used with the internal on-board antenna that has been originally tested and certified with this module. External antennas are not supported. As long as these 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). The end-product may need Verification testing, Declaration of Conformity testing, a Permissive Class II Change or new Certification. Please involve a FCC certification specialist in order to determine what will be exactly applicable for the end-product. Validity of using the module certification: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization for this module in combination with the host equipment is no longer considered valid and the FCC ID of the module cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. In such cases, please involve a FCC certification specialist in order to determine if a Permissive Class II Change or new Certification is required. Upgrade Firmware: The software provided for firmware upgrade will not be capable to affect any RF parameters as certified for the FCC for this module, in order to prevent compliance issues. End product labeling: This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: A3LWCA731M”. Information that must be placed in the end user manual: The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user's manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. Version 1.0 XuGuang Tech page 7 of 12 FCC MODULAR APPROVAL INFORMATION EXAMPLES for Manual This device complies with Part 15 of the …

Text truncated - open the document above for the full version.

Samsung Electronics Co Ltd Date: September 21, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: New Family Listing Declaration Please review the attached exhibits supporting our request for applying New Family Listing to the FCC ID: A3LWCA731M for Company Name: Samsung Electronics Co Ltd Product Description: Wi-Fi/BT Transceiver Base model: WCA731M Additional model(s): WCA734M The only difference between the base model WCA731M and the additional model(s) WCA734M is as follows: Model Name Differences WCA731M Basic Model WCA734M The difference from the basic model is the removal of mic part. Should you have any questions, please contact us. Sincerely, Name: Jenni Chun Title: General Manager

Letter of Authorization Company : Samsung Electronics Co Ltd Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, 07058, United States Product Name : Wi-Fi/BT Transceiver Model Number : WCA731M Multiple Model : WCA734M FCC Identifier : A3LWCA731M We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Jenni Chun Date: September 21, 2020 Title: General Manager Signature of applicant:

Samsung Electronics Co Ltd FCC – Modular Approval Request Rev 2.0 Modular Transmitter Approval Request Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Company name: Samsung Electronics Co Ltd FCC ID: A3LWCA731M Gentlemen, In accordance with 47CFR 15.212 Modular Transmitters and KDB 996369 D01 ‘Module Certification Guide v01r04’. FCC ID:A3LWCA731M has been examined against the following requirements. Requirement per 15.212 and KDB 996369 D01 ‘Modular Certification Guide v01r04 Explanation from Grantee (do not write yes/no, but explain why product complies/how it is achieved) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly Yes The radio portion of the module has been shielded, Refer to the external photos. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Yes The module has buffered modulation/data inputs. Refer to the Block Diagram. The module must contain power supply regulation on the module Yes This module is equipped internal power regulators. Refer to the Block Diagram. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) Yes This module is equipped with an onboard Chip Antenna. Refer to the internal photo The module must demonstrate compliance in a stand-alone configuration Yes This module was tested in a stand-alone configuration. Refer to the test setup photos The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) Yes The module has its permanently affixed FCC ID label and the FCC ID label is shield cover. Refer to the FCC ID Label Location. The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee Yes The module complies with all specific rules applicable to the transmitter. The module must comply with RF exposure requirements Yes Refer to the EMF Test Report. Name: Jenni Chun Date: September 21, 2020 Title: General Manager Signature of applicant:

Samsung Electronics Co Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 21, 2020 Subject; Request for Confidentiality FCC ID: A3LWCA731M To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirement In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jenni Chun Title: General Manager

Page 1 of 12 Basic Model (WCA731M) Page 2 of 12 Page 3 of 12 Page 4 of 12 Page 5 of 12 Page 6 of 12 Page 7 of 12 Multiple Model (WCA734M) Page 8 of 12 Page 9 of 12 Page 10 of 12 Page 11 of 12 Page 12 of 12

Page 1 of 6 Basic Model (WCA731M) Page 2 of 6 Page 3 of 6 Chip Antenna 0 WLAN Chip Antenna 1 WLAN Chip Antenna BT Page 4 of 6 Multiple Model (WCA734M) Page 5 of 6 Page 6 of 6 Chip Antenna 0 WLAN Chip Antenna 1 WLAN Chip Antenna BT

Page 1 of 17 Report No. : OT-209-RWD-050 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) ELECTROMAGNETIC EMISSION C OMPLIANCE REPORT FOR LOW-POWER, NON-LICENSED TRANSMITTER Test Report No. : OT-209-RWD-050 Reception No. : 2008003235 Applicant : Samsung Electronics Co Ltd Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, 07058, United States Manufacturer : Samsung Electronics Co Ltd Address : 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do 16677, Korea Type of Equipment : Wi-Fi/BT Transceiver FCC ID. : A3LWCA731M Model Name : WCA731M Multiple Model Name : WCA734M Serial number : N/A Total page of Report : 17 pages (including this page) Date of Incoming : August 20, 2020 Date of issue : September 21, 2020 SUMMARY The equipment complies with the regulation; FCC PART 15 SUBPART C Section 15.247 and FCC PART 15 SUBPART E Section 15.407 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Tested by Ju Yun Park / Assistant Manager ONETECH Corp. Reviewed by Tae-Ho, Kim / Senior Manager ONETECH Corp. Approved by Ki-Hong, Nam / General Manager ONETECH Corp. Page 2 of 17 Report No. : OT-209-RWD-050 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................................................. 4 2. GENERAL INFORMATION ............................................................................................................................................ 5 2.1 PRODUCT DESCRIPTION ................................................................................................................................................. 5 2.2 ALTERNATIVE TYPE(S)/MODEL(S); ALSO COVERED BY THIS TEST REPORT. ....................................... 10 3. EUT MODIFICATIONS .................................................................................................................................................. 10 4. MAXIMUM PERMISSIBLE EXPOSURE .................................................................................................................... 11 4.1 RF EXPOSURE CALCULATION ..................................................................................................................................... 11 4.2 EUT DESCRIPTION ....................................................................................................................................................... 11 4.3 CALCULATED MPE SAFE DISTANCE FOR WLAN ...................................................................................................... 12 4.3.1 DATA for Antenna 0 ............................................................................................................................................. 12 4.3.2 DATA for Antenna 1 ............................................................................................................................................. 13 4.3.3 DATA for Multiple Transmit ................................................................................................................................ 14 4.4 CALCULATED MPE SAFE DISTANCE FOR BLUETOOTH LE ....................................................................................... 16 4.5 CALCULATED MPE SAFE DISTANCE FOR BLUETOOTH ............................................................................................. 16 4.6 DATA FOR INTERMODULATION TRANSMIT ............................................................................................................... 17 Page 3 of 17 Report No. : OT-209-RWD-050 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) Revision History Rev. No. Issue Report No. Issued Date Revisions Section Affected 0 OT-209-RWD-050 September 21, 2020 Initial Release All Page 4 of 17 Report No. : OT-209-RWD-050 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 1. VERIFICATION OF COMPLIANCE Applicant : Samsung Electronics Co Ltd Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, 07058, United States Contact Person : Youngjoong Noh / Principal Engineer Telephone No. : +82-31-277-0598 FCC ID : A3LWCA731M Model Name : WCA731M Brand Name : Serial Number : N/A Date : September 21, 2020 EQUIPMENT CLASS DTS – DIGITAL TRNSMISSION SYSTEM Unlicensed National Information infrastructure(UNII) E.U.T. DESCRIPTION Modular Transmitter, Wi-Fi/BT Transceiver THIS REPORT CONCERNS Original Grant MEASUREMENT PROCEDURES ANSI C63.10: 2013 TYPE OF EQUIPMENT TESTED Pre-Production KIND OF EQUIPMENT AUTHORIZATION REQUESTED Certification EQUIPMENT WILL BE OPERATED UNDER FCC RULES PART(S) FCC PART 15 SUBPART C Section 15.247 KDB 558074 D01 15.247 Meas Guidance v05r02 FCC PART 15 SUBPART E Section 15.407 789033 D02 General UNII Test Procedures New Rules v02r01 Modifications on the Equipment to Achieve Compliance None Final Test was Conducted On 3 m, Semi Anechoic Chamber -. The above equipment was tested by ONETECH Corp. for compliance with the requirement set forth in the FCC Rules and Regulations. This said equipment in the configuration described in this report, shows the maximu…
