A3LWCA736MWi-Fi/BT Transceiver

Version 1.0 XuGuang Tech page 1 of 15 Operation Description of WCA736M 1. Introduction WCA736M is a Wi-Fi / Bluetooth Combo module compliant with IEEE802.11 a.b.g.n.ac MAC/baseband/radio and Bluetooth 5.0 optimized for low-power applications. The core chipset is from MediaTek part number MT7668AUN. 2. Hardware Architecture: 2.1 Main Chipset Information Item Vendor Part Number IEEE802.11 a.b.g.n.ac mac/baseband/radio Bluetooth 5.0 MediaTek MT7668AUN Version 1.0 XuGuang Tech page 2 of 15 3. Operational Description WCA736M is the 802.11a/b/g/n /ac +Bluetooth 5.0 Combo Module that acts as a communication controller for users of a wireless device to connect to SMART TV - Features >IEEE 802.11ac Draft compliant. >Dual-band 2.4GHz /5 GHz >Dual-stream spatial multiplexing up to 600Mbps data rate >Support 20, 40, 80MHz channel with optional SGI(256QAM modulation) >On-chip power amplifiers and low –noise amplifiers for both bands >Complies with Bluetooth Core Specification Version 5.0 >Supports BT/Wi-Fi coexistence. >Adaptive frequency hopping (AFH) for reducing radio frequency interference - Time base of the RF frequency For IF and RF frequency, 40MHz crystal is a clock reference. - Synthesizer Synthesizer inside Transceiver. Internal voltage controlled oscillator (VCO) provides the desired LO signal base on the phase-locked loop (PLL) with a relatively wide tuning range for this application. Internal fractional nPLL allows support for a wide range of reference clock frequencies - Wi-Fi Transmission Baseband data is modulated and up converted to the 2.4GHz ISM and 5-GHz U-NII bands, respectively. Linear on chip power amplifier are included, which are capable of delivering high output powers while Meeting IEEE802.11ac and IEEE802.a/b/g/n specifications without the need for external PAs. When using the internal PAs, closed-loop output power control is completely integrated. Base-band Processing (BBP) IC has DSSS (BPSK/QPSK/CCK) and OFDM (BPSK/QPSK/16QAM/64QAM/25QAM) modulation function, it provides transmission data rate are 1, 2, 5.5, 11Mbps on DSSS and 6, 12, 18, 24, 36, 48, 54 Mbps on OFDM. Digital data signal will be converted to analog (TX IQ) signals through DAC in BBP IC, TX IQ pass through to low pass filter. TX I/Q signal use direct conversion (zero-IF) architecture converter to generate carrier frequency signal. Transceiver IC and internal PA magnify output power. - Wi-Fi Receiver The MT7668AUN has a wide dynamic range, direct conversion receiver that employs high-order on-chip channel filtering to ensure reliable operation in the noisy 2.4GHz ISM band or the entire 5GHz U-NII band .Control signals are available that can support the use of optional LNAs for each band,which can increase the receive sensitivity by several decibels. Reverse direction isolation of LNA inside Transceiver IC suppresses unwanted radiation. Then RF signal will be directly down to IF signal (RX IQ) and high frequency spurious emissions are suppressed by LPF. At last RX IQ signal will be demodulated digital data. Version 1.0 XuGuang Tech page 3 of 15 -Bluetooth Low Energy The WCA736M support the Bluetooth 4.2 LE and 5.0 BLE 2Mbps - Link Control Layer The link control layer is part of the Bluetooth link control functions that are implemented in dedicated logic in the link control unit (LCU). Each task performs a different state in the Bluetooth Link Controller. - Wideband speech The WCA736M provides supports for wideband speech (WBS) using on-chip SmartAudio technology. The WCA736M can perform modified Sub Band Codec (mSBC) encoding and decoding of linear 16bitsat 16kHz(256kbps rate) transferred over USB interface. - Adaptive Frequency Hopping The WCA736M gathers link quality statistics on a channel by basis to facilitate channel assessment and Channel map selection. The link quality is determined using both RF and baseband signal processing to Provide a more accurate frequency-hop map. 4. Product Details -Data Modulation DSSS:CCK,BPSK,QPSK for 802.11b OFDM:BPSK,QPSK,16QAM,64QAM,256QAM for 802.11a,g,n,ac FHSS:GFSK,OQPSK, 8DPSK, π/4DPSK for Bluetooth -Frequency Range 2400-2497MHz 5150-5350MHz 5470-5725MHz 5725-5825MHz Version 1.0 XuGuang Tech page 4 of 15 - IEEE 802.11n HT20 - IEEE 802.11n HT40 Version 1.0 XuGuang Tech page 5 of 15 -IEEE 802.11ac -Output Power tolerance Output power ± 1.0dBm -Simultaneous transmission BT BT LE 2.4GHz Wi-Fi 5GHz Wi-Fi BT O O O BT LE O O O 2.4GHz Wi-Fi O O X 5GHz Wi-Fi O O X -Recommended Operating conditions Min Typ. Max Unit Operating voltage 4.5 5 5.5 V Operating temperature(ambient) -20 25 50 °C Version 1.0 XuGuang Tech page 6 of 15 -AS Information Company Name: CHENGDU XUGUANG TECHNOLOGY CO.,LTD. Fax: +86-28-84841628 Tel: +86-28-84841628 Add: 2 section of park road Longquanyi Chengdu China -Certification Information 1) Name(Model name): WCA736M 2) Certification ID: FCC- A3LWCA736M / IC- 649E-WCA736M 3) Company Name: Samsung Electronics Co Ltd 4) Production date 5) Vendor: Version 1.0 XuGuang Tech page 7 of 15 6) Product Description DEVICE TYPE Wi-Fi/BT Transceiver Temperature Range -20 °C ~ 50 °C OPERATING FREQUENCY Bluetooth LE 2 402 MHz ~ 2 480 MHz Bluetooth 2 402 MHz ~ 2 480 MHz WLAN 2.4 GHz 2 412 MHz ~ 2 472 MHz (802.11b/g/n(HT20)) 2 422 MHz ~ 2 462 MHz (802.11n(HT40)) 5 150 MHz ~ 5 250 MHz Band 5 180 MHz ~ 5 240 MHz (802.11a/n(HT20)/ac(VHT20)) 5 190 MHz ~ 5 230 MHz (802.11n(HT40)/ac(VHT40)) 5 210 MHz (802.11ac(VHT80)) 5 250 MHz ~ 5 350 MHz Band 5 260 MHz ~ 5 320 MHz (802.11a/n(HT20)/ac(VHT20)) 5 270 MHz ~ 5 310 MHz (802.11n(HT40)/ac(VHT40)) 5 290 MHz (802.11ac(VHT80)) 5 470 MHz ~ 5 725 MHz Band 5 500 MHz ~ 5 720 MHz (802.11a/n(HT20)/ac(VHT20)) 5 510 MHz ~ 5 710 MHz (802.11n(HT40)/ac(VHT40)) 5 530 MHz 5 690 MHz (802.11ac(VHT80)) 5 725 MHz ~ 5 850 MHz Band 5 745 MHz ~ 5 825 MHz (802.11a/n(HT20)/ac(VHT20)) 5 755 MHz ~ 5 795 MHz (802.11n(HT40)/ac(VHT40)) 5 775 MHz (802.11ac(VHT80)) MODULATION TYPE Bluetooth LE GFSK for 1 Mbps / 2 Mbps Bluetooth GFSK for 1Mbps, π /4-DQPSK for 2Mbps…

Text truncated - open the document above for the full version.

Letter of Authorization Company : Samsung Electronics Co Ltd Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, 07058, Product Name Model Number FCC Identifier United States : Wi-Fi/BT Transceiver : WCA736M : A3LWCA736M W e authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. W e declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Jenni Chun Date: July 06, 2021 T itle: General Manager Si gnature of applicant:

Samsung Electronics Co Ltd FCC – Modular Approval Request Rev 2.0 Modular Transmitter Approval Request Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Company name: Samsung Electronics Co Ltd FCC ID: A3LWCA736M Gent lemen, In accordance with 47CFR 15.212 Modular Transmitters and KDB 996369 D01 ‘Module Certification Guide v01r04’. FCC ID A3LWCA736M has been examined against the following requirements. Requirement per 15.212 and KDB 996369 D01 ‘Modular Certification Guide v01r04 Explanation from Grantee (do not write yes/no, but explain why product complies/how it is achieved) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly Yes The radio portion of the module has been shielded, Refer to the external photos. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Yes The module has buffered modulation/data inputs. Refer to the Block Diagram. The module must contain power supply regulation on the module Yes This module is equipped internal power regulators. Refer to the Block Diagram. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) Yes This module is equipped with an onboard Chip Antenna. Refer to the internal photo The module must demonstrate compliance in a stand-alone configuration Yes This module was tested in a stand-alone configuration. Refer to the test setup photos The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) Yes The module has its permanently affixed FCC ID label and the FCC ID label is shield cover. Refer to the FCC ID Label Location. The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee Yes The module complies with all specific rules applicable to the transmitter. The module must comply with RF exposure requirements Yes Refer to the EMF Test Report. Name: Jenni Chun Date: July 06, 2021 Tit le: General Manager Si gnature of applicant:

Samsung Electronics Co Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 06, 2021 Subject; Request for Confidentiality FCC ID: A3LWCA736M To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Security Requirement In addi tional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Si ncerely, Signature: Name: Jenni Chun Title: General Manager

Page 1 of 2 IDENTIFICATION LABEL: PROPOSED FCC ID LABEL The FCC ID shall be permanently affixed on the Shield case. A3LWCA736M 649E-WCA736M Page 2 of 2 Authorized Person - Print Name: Jenni Chun Date: July 06, 2021 Signature:

PCB Antenna

Page 1 of 18 Report No. : OT-215-RWD-097 This Report is not correlated with the authentication of KOLAS It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMF TEST REPORT Test Report No. : OT-215-RWD-097 Reception No. : 2104002159 Applicant : Samsung Electronics Co Ltd Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, 07058, United States Manufacturer : Samsung Electronics Co Ltd Address : 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do 16677, Korea Type of Equipment : Wi-Fi/BT Transceiver FCC ID. : A3LWCA736M Model Name : WCA736M Serial number : N/A Total page of Report : 18 pages (including this page) Date of Incoming : May 10, 2021 Date of issue : May 28, 2021 SUMMARY The equipment complies with the regulation; FCC PART 15 SUBPART C Section 15.247 and FCC PART 15 SUBPART E Section 15.407 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Tested by Ju Yun Park / Manager ONETECH Corp. Reviewed by Ha-Ram Lee / Manager ONETECH Corp. Approved by Ki-Hong, Nam / General Manager ONETECH Corp. Page 2 of 18 Report No. : OT-215-RWD-097 This Report is not correlated with the authentication of KOLAS It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................................................. 4 2. GENERAL INFORMATION ............................................................................................................................................ 5 2.1 PRODUCT DESCRIPTION ................................................................................................................................................. 5 3. EUT MODIFICATIONS .................................................................................................................................................. 10 4. MAXIMUM PERMISSIBLE EXPOSURE .................................................................................................................... 11 4.1 RF EXPOSURE CALCULATION ..................................................................................................................................... 11 4.2 EUT DESCRIPTION ....................................................................................................................................................... 11 4.3 CALCULATED MPE SAFE DISTANCE FOR WLAN ...................................................................................................... 12 4.3.1 DATA for Antenna 0 ............................................................................................................................................. 12 4.3.2 DATA for Antenna 1 ............................................................................................................................................. 14 4.3.3 DATA for Multiple Transmit ................................................................................................................................ 15 4.4 CALCULATED MPE SAFE DISTANCE FOR BLUETOOTH LE ....................................................................................... 17 4.5 CALCULATED MPE SAFE DISTANCE FOR BLUETOOTH ............................................................................................. 17 4.6 DATA FOR INTERMODULATION TRANSMIT ............................................................................................................... 19 Page 3 of 18 Report No. : OT-215-RWD-097 This Report is not correlated with the authentication of KOLAS It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) Revision History Rev. No. Issue Report No. Issued Date Revisions Section Affected 0 OT-215-RWD-097 May 28, 2021 Initial Release All Page 4 of 18 Report No. : OT-215-RWD-097 This Report is not correlated with the authentication of KOLAS It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 1. VERIFICATION OF COMPLIANCE Applicant : Samsung Electronics Co Ltd Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, 07058, United States Contact Person : Jenni Chun / General Manager Telephone No. : 973-808-6375 FCC ID : A3LWCA736M Model Name : WCA736M Brand Name : Serial Number : N/A Date : May 28, 2021 EQUIPMENT CLASS DTS – DIGITAL TRNSMISSION SYSTEM Unlicensed National Information infrastructure(UNII) E.U.T. DESCRIPTION Modular Transmitter, Wi-Fi/BT Transceiver THIS REPORT CONCERNS Original Grant MEASUREMENT PROCEDURES ANSI C63.10: 2013 TYPE OF EQUIPMENT TESTED Pre-Production KIND OF EQUIPMENT AUTHORIZATION REQUESTED Certification EQUIPMENT WILL BE OPERATED UNDER FCC RULES PART(S) FCC PART 15 SUBPART C Section 15.247 KDB 558074 D01 15.247 Meas Guidance v05r02 FCC PART 15 SUBPART E Section 15.407 789033 D02 General UNII Test Procedures New Rules v02r01 Modifications on the Equipment to Achieve Compliance None Final Test was Conducted On 3 m, Semi Anechoic Chamber -. The above equipment was tested by ONETECH Corp. for compliance with the requirement set forth in the FCC Rules and Regulations. This said equipment in the configuration described in this report, shows the maximum emis…

Text truncated - open the document above for the full version.

Page 1 of 87 Report No.: OT-215-RWD-098 This Report is not correlated with the authentication of KOLAS It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) RADIO PERFORMANCE TEST REPORT Test Report No. : OT-215-RWD-098 Reception No. : 2104002159 Applicant : Samsung Electronics Co Ltd Address : 19 Chapin Rd., Building D, Pine Brook, New Jersey, 07058, United States Manufacturer : Samsung Electronics Co Ltd Address : 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do 16677, Korea Type of Equipment : Wi-Fi/BT Transceiver FCC ID. : A3LWCA736M Model Name : WCA736M Serial number : N/A Total page of Report : 87 pages (including this page) Date of Incoming : May 10, 2021 Date of issue : May 28, 2021 SUMMARY The equipment complies with the regulation; FCC PART 15 SUBPART C Section 15.247 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Tested by Ju Yun Park / Manager ONETECH Corp. Reviewed by Ha-Ram Lee / Manager ONETECH Corp. Approved by Ki-Hong, Nam / General Manager ONETECH Corp. Page 2 of 87 Report No.: OT-215-RWD-098 This Report is not correlated with the authentication of KOLAS It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................................................. 6 2. TEST SUMMARY .............................................................................................................................................................. 7 2.1 TEST ITEMS AND RESULTS ............................................................................................................................................. 7 2.2 ADDITIONS, DEVIATIONS, EXCLUSIONS FROM STANDARDS ........................................................................................... 7 2.3 RELATED SUBMITTAL(S) / GRANT(S) ............................................................................................................................ 7 2.4 PURPOSE OF THE TEST ................................................................................................................................................... 7 2.5 TEST METHODOLOGY .................................................................................................................................................... 7 2.6 TEST FACILITY ............................................................................................................................................................... 7 3. GENERAL INFORMATION ............................................................................................................................................ 8 3.1 PRODUCT DESCRIPTION ................................................................................................................................................. 8 4. EUT MODIFICATIONS .................................................................................................................................................. 13 5. SYSTEM TEST CONFIGURATION ............................................................................................................................. 14 5.1 JUSTIFICATION ............................................................................................................................................................. 14 5.2 PERIPHERAL EQUIPMENT ............................................................................................................................................ 14 5.3 MODE OF OPERATION DURING THE TEST .................................................................................................................... 14 5.4 CONFIGURATION OF TEST SYSTEM ............................................................................................................................. 17 5.5 ANTENNA REQUIREMENT ............................................................................................................................................ 17 6. PRELIMINARY TEST .................................................................................................................................................... 17 6.1 AC POWER LINE CONDUCTED EMISSIONS TESTS ....................................................................................................... 17 6.2 GENERAL RADIATED EMISSIONS TESTS ..................................................................................................................... 17 7. MINIMUM 20 DB BANDWIDTH .................................................................................................................................. 18 7.1 OPERATING ENVIRONMENT ......................................................................................................................................... 18 7.2 TEST SET-UP ................................................................................................................................................................. 18 7.3 TEST DATE ................................................................................................................................................................... 18 7.4 TEST DATA FOR 1 MBPS ............................................................................................................................................... 19 7.5 TEST DATA FOR 2 MBPS ................................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 3 - DFS Page 2 of 3 - Conducted Emission Test Page 3 of 3 - Radiated Emission Test (Below 1 GHz) - Radiated Emission Test (Above 1 GHz)
