A3LWDG720MWi-Fi Transmitter Module

Manual For WDG720M SAMSUNG ELECTRONICS CO., Ltd. Wi-Fi module(2.4GHz, 5GHz, a/b/g/n) - Model name : WDG720M - Operation Temperature : -10°C ~ +70°C - Power : +5V ±5% (+4.75V ~ +5.25V) 1. Introduction WDG720M is a USB embedded module compliant with IEEE802.11n standard. Thecore chipset is from MTK, part number is RT3572L. 2. Operational Description WDG720M is the 802.11a/b/g/n RF Module, that acts as a communication hub for users of a wirelessdevice to connect to a wired LAN. MIMO type Product type: WLAN (11b mode: 1TX, 1RX, 11g mode: 1TX, 1RX, 11n mode: 2TX, 2RX) Time base of the transmission frequency For IF and RF frequency, Crystal is a clock reference. Synthesizer Synthesizer inside Transceiver. Internal voltage controlled oscillator (VCO) provides the desired LOsignal base on the phase-locked loop (PLL) with a relatively wide tuning range for this application. Transmission Base-band Processing (BBP) IC has DSSS (BPSK/QPSK/CCK) and OFDM (BPSK/QPSK/16QAM/64QAM) modulation function, it provides transmission data rate are 1, 2, 5.5, 11Mbps on DSSS and 6, 12, 18, 24, 36, 48, 54 Mbps on OFDM. Digital data signal will be converted toanalog (TX IQ) signals through DAC in BBP IC, TX IQ pass through to low pass filter. TX I/Q signaluse direct conversion (zero-IF) architecture converter to generate carrier frequency signal. TransceiverIC and internal PA magnify output power. Receiver Reverse direction isolation of LNA inside Transceiver IC suppresses unwanted radiation. Then RFsignal will bedirectly down to IF signal (RX IQ) and high frequency spurious emissions are suppressed by LPF. Atlast RX IQ signal will be demodulated digital data. Base band Processing 1. Channel selection is controlled by BBP IC to support data modulation: - DSSS (BPSK/QPSK/CCK) - OFDM (BPSK/QPSK/16QAM/64QAM) Power Control Level It uses closed-loop power control function to limit RF output power level. Transmit/Receive Switch EUT has Transmit/Receive Switch and Antenna switch. End user can’t select any power setting. Channel Selection Restriction For product available in the USA/Canada/Taiwan market, only channel 1~11 can be operated. Selectionof other channels is not possible. But product also could be available in the Europe/Japan market,channel 1~13 can be operated under the manufacturer change the different driver. Data Rate Control The operation date rate is changing during data transfer base on the optimization of driver. Discontinue Transmitting with absence of Data or operational failure states “The device shall automatically discontinue transmission in case of either absence of information totransmit or operational failure. These provisions are not intended to preclude the transmission of controlor signaling information or the use of repetitive codes used by certain digital technologies to completeframe or burst intervals. Applicants shall include in their application for equipment authorization adescription of how this requirement is met.” Data transmission is always initiated by software, which isthen passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. These are the only waysthe digital baseband portion will turn on the RF transmitter, which it then turns off at the end of thepacket. Therefore, the transmitter will be on only while one of the aforementioned packets is beingtransmitted. Product Details > Data Modulation OFDM (BPSK / QPSK / 16QAM / 64QAM) > Frequency : 2.4GHz and 5GHz > 802.11 a/b/g/n MIMO Type >Power : +5V ±5% (+4.75V ~ +5.25V) Approval Statement CE Statement Hereby, we declare that this device is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC. FCC approval This device complies with Part 15 of the FCC`s Rules. Operation is subject to the following two Conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesirable operation. To satisfy FCC exterior labeling requirements, the following text must be placed on the exterior of the end product. Contains Transmitter module FCC ID: A3LWDG720M This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. IC approval This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). L'opération est soumise aux deux conditions suivantes: (1) cet appareil ne peut causer d'interférences, et (2) cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil. The host device must be labeled to display the Industry C…

Text truncated - open the document above for the full version.

Samsung Electronics Co., Ltd. 19 Chapin Rd., Building D, Pine Brook, New Jersey, United States Date: April 25, 2014 Letter of Authorization We, the undersigned, hereby authorize Digital EMC Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: A3LWDG720M including signing of all documents relating to these matters. Any and all acts carried out by Digital EMC Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Samsung Electronics Co., Ltd. . “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Sang Kyung (Peter), Ra General Manager

Digital EMC Co., Ltd. 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 449-935 Date: April 25, 2014 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards;

Samsung Electronics Co., Ltd. 19 Chapin Rd., Building D, Pine Brook, New Jersey, United States Date: April 25, 2014 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: A3LWDG720M To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Samsung Electronics Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Samsung Electronics Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description SHORT-TERM 5 Internal Photos 6 External Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Sang Kyung (Peter), Ra General Manager

19 Chapin Rd., Building D, Pine Brook, New Jersey, United States Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA April 21, 2014 Modular Approval Attestation for Remote Control Module. Applicant: Samsung Electronics Co Ltd FCC ID: A3LWDG720M No. FCC requirements EUT 1 Have its own RF shielding RF Block shielded by Metal Case 2 Have buffered modulation/data inputs (if such inputs are provided), Yes, the module has buffered data input. 3 The modular transmitter must have its own power supply regulation. We used self own power supply regulation. 4 Meet the antenna requirements of section 15.203 This module uses Internal PIFA antenna This module meets the antenna requirements of section 15.203 5 Be tested in a stand-alone configuration, i.e., the antenna, AC or DC power and data input/output lines must be connected to the module but, the module must not be inside another case during testing Yes, the EUT (module) was tested a stand alone configuration. 6 Be labeled with its own FCC ID number, and if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. The proposed FCC ID label format is to be placed on the module. If FCC ID label is not visible when module is install into the system, “Contains FCC ID: A3LWDG720M” shall be placed on the outside of final product. 7 The modular transmitter is manufactured so that the user can not influence the operation of the transmitter that will operate outside of the scope of the regulations. It complies with specific rules or operating requirements. And instruction is included User manual. 8 Address compliance with the Commission`s RF exposure limits in Sections 1.1310 and 2.1093. In addition, spread spectrum transmitters operation under Section 15.247 are required to address RF exposure compliance in accordance with Section 15.247(b)(4) The exposure condition of this module is compliant with the requirements. Please refer to MPE calculation. Sincerely, Name : Sang Kyung (Peter), Ra Title : General Manager Company : Samsung Electronics Co., Ltd.

FCCID: A3LWDG720M Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 1 / 3 View 1 FCCID: A3LWDG720M Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 2 / 3 View 2 FCCID: A3LWDG720M Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 3 / 3 View 3

FCC ID: A3LWDG720M Copyright Ⓒ 2014, Digital EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual.

FCCID: A3LWDG720M Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 1 / 2 View 1 FCCID: A3LWDG720M Copyright Ⓒ 2014, Digital EMC Co., Ltd. Page 2 / 2 View 2

The MPE calculation for this exposure is shown below. - 11 0dBm P = Power input to the antenna(mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna(20cm) Max. 15 0 5GHz Band DTS FCC ID:A3LWDG720M RF Exposure Calculation The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the us Power density at the specific separation Note =S S = Maximum power dencity(mW/cm 2 ) 2.4GHz Band DTS5GHz Band NII Target Power: P G / ( 4 R 2 π ) Target Power:dBmTarget Power:11 0dBm +dB / - dB+dB / - dB+dB / - dB dBm ~dBm ~dBm ~ Max. 7.013.0 dBmdBm17.07.0 11.0dBm Tolerance:24 dBm13.011.0 2 The power desity at 20cm does not exceed the 1.0mW/cm 2 . Conclusion : The exposure condition of this device is compliant with FCC rules. The maximum permissible exposure(MPE) of the general population/Uncontrolled for this device is 1.0 mW/cm 2 Max. target power & Tolerance 15.0 0.013 mW/cm 2 Aggregated PowerAggregated Power Calculated power density Max. mW/cm 2 0.014 mW/cm 2 Aggregated Power (P) Antenna gain (G) 4 Target Power: 16.000 dBm 0.036 Directional antenna gainDirectional antenna gainDirectional antenna gain Max.20.000 dBm 100.000 mW Max. numeric 16.000 dBm 39.811 mW39.811 mW Aggregated Power 1.808 numeric1.648 2.570 dBiMax. 1.546 numeric 2.167 dBiMax.1.891 dBi Target Power: Tolerance:4 dBmTarget Power:11.0dBm Tolerance:2 Copyright ⓒ 2014, Digital EMC Co., Ltd.

DEMC1402-00360 FCC ID: A3LWDG720M Report No.: DRTFCC1406-0724 IC: 649E-WDG720M TRF-RF-221(00)140218 Page 2 / 228 Copyright ○ C 2014, Digital EMC Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1406-0724 Jun. 03, 2014 Initial issue DEMC1402-00360 FCC ID: A3LWDG720M Report No.: DRTFCC1406-0724 IC: 649E-WDG720M TRF-RF-221(00)140218 Page 3 / 228 Copyright ○ C 2014, Digital EMC Co., Ltd. Table of Contents 1. EUT DESCRIPTION .................................................................... 4 2. INFORMATION ABOUT TESTING .............................................. 5 2.1 Test mode .......................................................................................................................... 5 2.3 Auxiliary equipment ......................................................................................................... 5 2.4 Tested environment ......................................................................................................... 5 2.5 EMI suppression Device(s) / Modifications ................................................................... 5 3. SUMMARY OF TESTS ................................................................ 6 4. TEST METHODOLOGY .............................................................. 7 4.1 EUT configuration ............................................................................................................ 7 4.2 EUT exercise ..................................................................................................................... 7 4.3 General test procedures .................................................................................................. 7 4.4 Description of test modes ............................................................................................... 7 5. INSTRUMENT CALIBRATION .................................................... 8 6. FACILITIES AND ACCREDITATIONS ........................................ 8 6.1 Facilities ............................................................................................................................ 8 6.2 Equipment ......................................................................................................................... 8 7. ANTENNA REQUIREMENTS ..................................................... 8 8. TEST RESULT ............................................................................ 9 8.1 6dB bandwidth .................................................................................................................. 9 8.2 Maximum peak conducted output power ..................................................................... 37 8.3 Maximum power spectral density ................................................................................. 43 8.4 Out of band emissions at the band edge / conducted spurious emissions ............. 71 8.5 Radiated spurious emissions ..................................................................................... 184 8.6 Power-line conducted emissions ............................................................................... 193 8.7 Occupied bandwidth .................................................................................................... 198 9. LIST OF TEST EQUIPMENT ................................................... 225 APPENDIX I................................................................................. 226 DEMC1402-00360 FCC ID: A3LWDG720M Report No.: DRTFCC1406-0724 IC: 649E-WDG720M TRF-RF-221(00)140218 Page 4 / 228 Copyright ○ C 2014, Digital EMC Co., Ltd. 1. EUT DESCRIPTION FCC Equipment Class Digital Transmission System(DTS) Product Wi-Fi Transmitter Model Name WDG720M Add Model Name N/A Power Supply DC 5 V Frequency Range 2.4 GHz Band ▪802.11b/g/n(HT20): 2412 MHz ~ 2462 MHz ▪ 802.11n(HT40): 2422 MHz ~ 2452 MHz 5.7 GHz Band ▪ 802.11a/n(HT20): 5745 MHz ~ 5825 MHz ▪ 802.11n(HT40): 5755 MHz ~ 5795 MHz Modulation Type CCK, DQPSK, DBPSK for DSSS 256QAM, 64QAM, 16QAM, QPSK BPSK for OFDM Transmissions category Completely uncorrelated signal Antenna Specification Antenna type: Internal Antenna Antenna gain ▪2.4GHz Band: ANT 1 : 2.19dBi& ANT 2 : 2.92dBi ▪5.7 GHz Band: ANT 1 : 2.48 dBi& ANT 2 : 1.21dBi Antenna configuration ▪802.11b/g/a: Single Transmitting (ANT 1 or ANT 2) ▪ 802.11n(MCS0 ~ 7) : Single Transmitting (ANT 1 or ANT 2) ▪ 802.11n(MCS8 ~ 15): Multiple Transmitting(ANT 1 and ANT 2) DEMC1402-00360 FCC ID: A3LWDG720M Report No.: DRTFCC1406-0724 IC: 649E-WDG720M TRF-RF-221(00)140218 Page 5 / 228 Copyright ○ C 2014, Digital EMC Co., Ltd. 2. INFORMATION ABOUT TESTING 2.1 Test mode Test mode Worst case data rate Tested Frequency(MHz) Lowest Middle Highest TM 1 802.11b 5.5 Mbps 2412 2442 2472 TM 2 802.11g 54 Mbps 2412 2442 2472 TM 3 802.11n(HT20) MCS 0 2412 2442 2472 TM 4 802.11n(HT40) MCS 0 2422 2437 2452 TM 5 802.11a 54 Mbps 5745 5785 5825 TM 6 802.11n(HT20) MCS 7 5745 5785 5825 TM 7 802.11n(HT40) MCS 7 5755 - 5795 The worst case data rate for each mode was determined as above table. All tests conducted in this report were made at the worst case data rate of each mode. 2.3 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note Laptop Satellite L510 3A033073Q Toshiba FCC DoC - - - - - 2.4 Tested environment Temperature : 21 o C ~ 24 o C Relative humidity content : 39% ~ 45 % R.H. Details of power supply : DC 5 V 2.5 EMI suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None DEMC1402-00360 FCC ID: A3LWDG720M Report No.: DRTFCC1406-0724 IC: 649E-WDG720M TRF-RF-221(00)140218 Page 6 / 228 Copyright ○ C 2014, Digital EMC Co., Ltd. 3. SUMMARY OF TESTS FCC Part Section(s) RSS Section(s) Parameter Limit Test Condition Status Note 1 I. Transmitter Mode (TX) 15.247(a) RSS-210 [A8.2] 6 dB Bandwidth > 500 kHz Conducted C 15.247(b) RSS-210 [A8.4] Transmitter Output Power < 1Watt C 15.247(d) RSS-210 [A8.5] Out of Band Emissions / Band Edge 20dBc in any 100kHz BW C 15.247(…
