Theory of Operation WIC213S IoT Module SAMSUNG ELECTRONICS 09/07/22 Introduction The WIC213S is a IoT Module for Home automation networks. Connected to the Monitor-remote control device, it acts as a pathway between remote home automation. Power is provided by External 5V power supply with 10pin zip type connector. Networking The WIC2131S is applied EFR32 IoT Multi-Protocol of Silicon Labs. The IoT Module delivers the information received from the remote control device to the main board with 10pin zip type connector. Power Source The WIC213S is powered by an external 5VDC@500mA regulated power source with 10pin zip type connector. Indication None. Expansion Ports None. Eurpoe US/Canada FCC approval This device complies with Part 15 of the FCC`s Rules. Operation is subject to the following two Conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undes- irable operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in aresidential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installedand used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this e- quipment doescause harmful interference to radio or television reception, which can be determ- ined by turning the equipment off and on, the user is encouraged to try to correct the interferenc e by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. -The OEM integrator is responsible for ensuring the end-user has no manual instruction to remove or install module. 3. Max RF output power e.i.r.p. 9.17 dBm. -The module is limited to installation in mobile or fixed applications. IC approval This device contains licence- exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic development Canada’s licenceexempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired oper ation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’ Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptib le d’ en compromettre le fonctionnement. IMPORTANT NOTE This device complies with FCC & IC radiation exposure limits set forth for an uncontrolled environ ment. This device should be installed and must not be colocated or operating in conjunction with any other antenna or transmitter. This device is intended only for OEM integrators under the following conditions: 1) This module may not be co-located with any other transmitters or antennas. 2) The antenna must be installed such that 20cm is maintained between the antenna and users. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end product for any additional compliance requirements with this module installed. In the event that these conditions cannot be met, then the FCC & IC authorizations are no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for reevaluating the end product including this module and obtaining separate FCC & IC authorizations. Cet appareil est conforme aux limites de la FCC et IC exposition aux radiations dans un environne ment non contrôlé. Cet appareil doit être installé et ne doit pas être co-localisées ou opérant en conjonction avec une autre antenne ouun autre émetteur. Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes : 1 ) L' antenne doit être installée de telle sorte que 20 cm est maintenue entre l'antenne et les utili sateurs . 2 ) Ce module ne peut pas être co-localisé avec d'autres émetteurs ou des antennes . Aussi longtemps q ue deux conditions précitées sont remplies, le test du transmetteur supplément aires ne serontpas tenus. Toutefois, l'intégrateur OEM est toujours responsable de tester leurs produits finis pour toutes lesexigences de conformité supplémentaires avec ce module installé. Dans le cas où ces conditions ne peuvent pas être remplies, alors la FCC et IC autorisations ne so nt plus considérés comme valides et l'ID de la FCC ne peut pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera responsable de réévaluer le produit final, y compris l'obtention de ce module et séparée de la FCC et IC Autorisations User Information Caution: Any changed or modifications not expressly approved by the party responsible for compl iance could void the user`s authority to operate this equipment. Attention: Toute changé ou modifications non expressément approuvés par la partie responsable de la conformité pourraient annuler l'utilisateur `autorité de faire fonctionner cet équipement. Supplemental User’s Manual INTEGRATION INSTRUCTIONS per FCC KDB 996369 D03, Section 2.0 2.2 List of applicable FCC rules The module has been certified for use under FCC Part 15.247 only 2. 3 Summarize the specific operational use condit…

Text truncated - open the document above for the full version.

Applicant/Grantee Samsung Electronics Co., Ltd. FCC ID: A3LWIC213S Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. OK Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. OK Y 3 The modular transmitter must have its own power supply regulation. A DC-DC converter is configured for internal supply of the module. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Connected to antenna with internal transmission line and matching. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not OK Y contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the Mark the FCC-ID certification number on the module label. Y application for equipment authorization. 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Module usage manuals were provided. Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. For RF exposure requests, ensure that RF specs are entered and adhered to within the approval source provided to all users fo this module. Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured.

Samsung Electronics Co., LTD. 129, Samsung -ro , Yeongtong-gu Suwon-City, Gyeonggi-do, 16677, Korea Date: January 05, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR IoT module / WIC213S / A3LWIC213S This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (below list) required to be submitted with this application be permanently withheld from public review. Permanent Confidential Request -. Schematics -. Block Diagram -. Operational Description SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Jenni Chun, General manager

Samsung Electronics Co., LTD. 129, Samsung -ro , Yeongtong-gu Suwon-City, Gyeonggi-do, 16677, Korea Date: January 05, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR IoT module / WIC213S / A3LWIC213S To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (below list) required to be submitted with this application be short-term Confidentiality f or a period of 180 days after grant is issued. Short-Term Confidential Request -. External Photos -. Internal Photos -. Test set-up photo -. User Manual SPECIFY REASON FOR REQUEST (i.e. These documents contain detailed system and equipment descriptions and related information about the product, which we considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, we feel that this information would be of benefit to our competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Jenni Chun, General manager

Samsung Electronics Co., LTD. 129, Samsung -ro , Yeongtong-gu Suwon-City, Gyeonggi-do, 16677, Korea Date: January 05, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Ms. Lena Lim / Assistant Manager of Eurofins KCTL Inc to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Jenni Chun, General manager

This test report shall not be reproduced, except in full, without the written approval External photos of EUT PIFA Antenna This test report shall not be reproduced, except in full, without the written approval Connected to TEST JIG

5 PCB Overview _ TEST Condition 100pF/Murata Matching Value PCB-Ground Connection ANT & PCB

※ Illustrator에서 작성됨. PI Label PI(Polyimide) Material (Scale 100%) WIC213S REV00) 22.09.26 임시발행 K J T22.09.2600 ±0.1mm Silk colorBlack (배열 참고이미지) 2mm 3mm 16mm 9.4mm ※ ARTIK동일재질. IV40330-00014 2.6mm 13.4mm 1.3mm NCC : XXXXXXXXXXXXX BNXX-XXXXXX R-C-SEC-XXXXXXX FCC ID : A3LWIC213S IC : 649E-WIC213S Power Source : DC 5V Made in China ANATEL : XXXXX-XX-XXXXX CONATEL PY XXXX-XX-XX-XXXX S/N : WIC213SXXXXXXXX MODEL : WIC213S X-XXXXX <Label location_Front of device>

This test report shall not be reproduced, except in full, without the written approval Internal photos of EUT

verify No.368385076314 Eurofins KCTL Co.Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0023-A Page (2) of (9) KCTL-TIR001-003/7 (220705) KP22-06226 REPORT REVISION HISTORY Date Revision Page No 2023-01-09 Originally issued - 2023-01-12 Updated 1 This report shall not be reproduced except in full, without the written approval of Eurofins KCTL Co.,Ltd. This document may be altered or revised by Eurofins KCTL Co.,Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by Eurofins KCTL Co.,Ltd. will constitute fraud and shall nullify the document. This test report is certified according to KS Q ISO/IEC 17025 and KOLAS recognition. General remarks for test reports Statement concerning the uncertainty of the measurement systems used for the tests (may be required by the product standard or client) Internal procedure used for type testing through which traceability of the measuring uncertainty has been established: Procedure number, issue date and title: Calculations leading to the reported values are on file with the testing laboratory that conducted the testing. Statement not required by the standard or client used for type testing Eurofins KCTL Co.Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0023-A Page (3) of (9) KCTL-TIR001-003/7 (220705) KP22-06226 CONTENTS 1. General information ......................................................................................................4 2. Device information ........................................................................................................4 2.1. Frequency/channel operations................................................................................5 3. RF Exposure .................................................................................................................6 3.1. Test results..............................................................................................................9 Eurofins KCTL Co.Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0023-A Page (4) of (9) KCTL-TIR001-003/7 (220705) KP22-06226 1. General information Client : Samsung Electronics Co., Ltd. Address : 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Rep. of Korea Manufacturer : Samsung Electronics Co., Ltd. Address : 129, Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Rep. of Korea Factory1 : PT Samjin Address : Bekasi International Industrial Estate JL. Inti Raya. Blok C2 No. 10, Kel. Sukaresmi, Kec. Cikarang Selatan, Kab. Bekasi, Provinsi Jawa Barat, 17530 Indonesia Factory2 : SEONG JI SAI GON COMPANY LIMITED Address : No.02, St.3A, Bien Hoa II industrial Zone, Long Binh Tan Ward, Bien Hoa City, Dong Nai Province, VietNam Factory3 : SEONG JI SAI GON COMPANY LIMITED Address : Nha xuong C, D, Lo.X2, Khu Cong Nghiep Ho Nai, Xa Ho Nai3, Huyen Trang Bom, Tinh Dong Nai, VietNam Factory4 : Qingdao Samjin Electronics Co., Ltd. Address : NO.27 TONGKANG ROAD, TONGHE TOWN, PINGDU CITY, QINGDAO, CHINA Factory5 : Samjin Thai Co., Ltd. Address : 180/4 Moo 3, T.Bueng, A.Sriracha, Chonburi 20230 Laboratory : Eurofins KCTL Co.,Ltd. Address : 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Accreditations : FCC Site Designation No: KR0040, FCC Site Registration No: 687132 VCCI Registration No. : R-20080, G-20078, C-20059, T-20056 Industry Canada Registration No. : 8035A KOLAS No.: KT231 2. Device information Equipment under test : IoT module Model : WIC213S Modulation technique : DSSS_O-QPSK Number of channels : 16 ch Power source : DC 5 V Antenna specification : PIFA Antenna Antenna gain : 1.36 ㏈i Frequency range : 2 405 ㎒ ~ 2 480 ㎒ Software version : 6.0.2 Hardware version : 1.0 Test device serial No. : N/A Operation temperature : -10 °C ~ 50 °C Eurofins KCTL Co.Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0023-A Page (5) of (9) KCTL-TIR001-003/7 (220705) KP22-06226 2.1. Frequency/channel operations This device contains the following capabilities: Zigbee Ch. Frequency (㎒) 11 2 405 . . . . 18 2 440 . . . . 25 2 475 26 2 480 Table 2.1.1. Zigbee mode Eurofins KCTL Co.Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR23-SRF0023-A Page (6) of (9) KCTL-TIR001-003/7 (220705) KP22-06226 3. RF Exposure FCC Regulation This document is prepared to show compliance with the RF Exposure requirements as required in §1.1310 of the FCC rules and Regulations. The limit for Maximum Permissible Exposure (MPE), specified in FCC §1.1310, is listed in Table 1-1. According to FCC §1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b). Table 1 – Limits for Maximum Permissible Exposure (MPE) Frequency Range (㎒) Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [㎽/㎠] Averaging Time [minute] (A) Limits for Occupational / Controlled Exposure 0.3 ~ 3.0 614 1.63 *100 6 3.0 ~ 30 1842/f 4.89/f *900/f 2 6 30 ~ 300 61.4 0.163 1.0 6 300 ~ 1 500 / / f/300 6 1 500 ~ 15 000 / / 5 6 (B) Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19/f *180/f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1 500 / / f/1 500 30 1 500 ~ 15 000 / / 1.0 30 f=frequency in ㎒, *= plane-wave equivalent power density Per the guidance of KDB 680106, the E-field and H-field limits shown in the table above are extended down to 100 ㎑ [FCC] MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given dista…

Text truncated - open the document above for the full version.

1 I N PA Q Te c h n o l o g y C o . , L t d . Last updated in 2022.12.15 Copyright © by Passive System Alliance | All rights reserved. WIC213S Antenna Passive Review P/N : WA-M-LA-02-081 [PIFA Type Antenna] 2 Content Details -TEST Equipment -Measuring Process -TEST condition -VSWR & Smith Chart / 3D Gain data -2D Radiation Pattern & Gain -3D Radiation pattern 3 TEST EQUIPMENT Network analyzerAnechoic Chamber MakerMODELMakerSIZETestable Frequency Agilent5071B ENA MTG3m *3m * 6m0.4GH ~ 6GHz HPHP8753E Chamber outside Network Analyzer Chamber inside 1Chamber inside 2 4 Measuring Process 챔버테스트방법 1. 안테나는단말기에장착된상태에서테스트된다. 2. 안테나는무반사실챔버안에서테스트된다. 3. 챔버시스템안에다이폴안테나또는혼안테나를 서로정면을마주보게하여챔버 4. 소프트웨어를실행시켜Calibration을한다. 5. Positioner쪽의다이폴안테나또는혼안테나를 제거하고거기에측정하고자하는단말기를고정한다. 6. 챔버소프트웨어를실행시킨다. 7. 측정후데이터를확인한다. DUT 테스트방법 1. 안테나를DUT에장착을한후coaxial cable을DUT 보드에연결한다. 2. Network analyzer를Calibration 한후DUT에연결된 coaxial cable을Port에연결한다. (측정시DUT는비전도성테이블위에서테스트되어야함.) 3. Network Analyzer의Port에DUT에연결된coaxial cable을 연결한다. 4. Point Marker를해당주파수대역으로설정한다. 5. 테스트: Smith Chart & VSWR DUT 6 VSWR & Smith Chart / 3D Gain data [Smith Chart & VSWR][3D Gain data] Freq.[MHz]Eff.[%]Avg.[dBi]Peak[dBi] 2400 39.39-4.050.34 2415 41.63-3.810.46 2430 38.44-4.15-0.01 2450 53.33-2.731.36 2460 50.28-2.991.07 2480 43.84-3.580.42 2485 45.73-3.40.56 7 2D Radiation Pattern & Gain 8 3D Radiation Pattern 9 本資料均屬機密，僅供指定之收件人使用，未經寄件人許可不得揭露、複製或散佈本信件。 This message and any attachments are confidential and may be legally privileged. Any unauthorized review, use or distribution by anyone other than the intended recipient is strictly prohibited. If you are not the intended recipient, please immediately notify the sender, completely delete this documents, and destroy all copies. Your cooperation will be highly appreciated. Thank you
