A3LWIS12ABGNXWLAN Adapter

English-1 2010~2012 Wireless LAN Adapter WIS12ABGNX Features • Compatible with IEEE 802.11a/b/g and 802.11n • Supports USB 2.0 • Compact and Lightweight Pocket-Sized Design • Supports 2010~2012 SAMSUNG TVs with Smart TV and AllShare • Supports 2010~2012 SAMSUNG Blu-ray Disc Players / Home Theater Systems (For more information, please refer to the TV / Blu-ray Disc Player / Home Theater Systems User Manual.) • Compatibility may be limited to certain models and regions. Accessory • USB right angle adapter (only for Blu-ray Disc Players / Home Theater Systems) • Use extension cable to insert the Wireless LAN Adapter into the TVs / Blu-ray Disc Players / Home Theater Systems’ USB port. • Use extension cable. Installing the Adapter • Insert the Wireless LAN Adapter into the TVs / Blu-ray Disc Players / Home Theater Systems’ USB port. • For installation precautions and instructions, refer to the TVs / Blu-ray Disc Players / Home Theater Systems User Manual. - TV: “Network Connection → Wireless” section - Blu-ray Disc Player / Home Theater System: “Network Setup → Wireless Network” section Safety Precautions • Do not let children swallow the product or play with the plastic bag. Keep the product and the plastic bag out of the reach of children. • Do not let water or other liquids come into contact with the product, as it may result in damage. • Keep the product away from direct sunlight, fire or a heat source such as a heater. This may reduce the product lifetime or result in fire. Warranty: 1 Year • If the product is not working properly due to a performance defect that appears under normal circumstances within the warranty period, please visit the retailer where you purchased it. (Please contact Samsung service center in Argentina, Brazil, Chile, Colombia, Mexico and Panama.) Specifications (WIS12ABGNX) StandardIEEE 802.11 a/b/g/n Host InterfaceUSB 2.0 Frequency Range 2.412 ~ 2.4835GHz 5.15 ~ 5.850GHz Security64/128bit WEP, WPA /WPA2, 802.1x, WPS Output Power 802.11a: 11dBm at 54Mbps 802.11b: 17dBm at 11, 5.5, 2, and 1Mbps 802.11g: 14dBm at 54Mbps 802.11n(2.4GHz): 14dBm (20MHz) / 12dBm (40MHz) 802.11n(5GHz): 11dBm (20MHz) / 9dBm (40MHz) Data Rate 802.11a/g: 54,48,36,24,18,12,9 and 6Mbps 802.11b: 11,5.5,2 and 1Mbps 802.11n: up to 300Mbps (40MHz / spatial streams: 2) Sensitivity 802.11a: –68dBm at 54Mbps 802.11b: –84dBm at 11Mbps 802.11g: –68dBm at 54Mbps 802.11n: –68dBm (20MHz) / –65dBm (40MHz) Power consumption TX: 500mA at continuous transmit mode (2 Tx chains on ) RX: 300mA at continuous receive mode (2 Rx chains on ) Dimensions (L X W X D) 3.3 X 1.047 X 0.63 inches (84 X 26.6 X 16 mm) PRODUCTSupported Models (Except for D5003) LEDC5000 and above, D5000 ~ D64**, E4500, E5500, E5700 LCDC550 and above, D530 and above PDPC550 and above, D550 ~ D64**, E490 Blu-ray Disc PlayerC5*** Series, D53** ~ D55**, BD-E5500 Home Theater SystemC5*** Series, D51** ~ D53**, HT-E4200, HT-E4500, HT-EM45C Ideal For802.11n (5GHz)802.11n (2.4GHz)802.11 a/b/g streaming HD video recommended not recommendednot recommended recommendedrecommended streaming SD video music, photo - Ne twork conditions and environmental factors (including but not limited) volume of network traffic, building materials and construction, may lower actual data throughput rate. - Environmental conditions will affect wireless signal coverage. - Video clips with lower than 20Mbps bit-rates are recommended for the wireless video streaming. English-2 2010~2012 Wireless LAN Adapter WIS12ABGNX Caractéristiques • Compatible avec IEEE 802.11a/b/g et 802.11n • Compatible avec USB 2.0 • Appareil de poche compact et léger • Prend en charge les modèles de téléviseurs 2010~2012 SAMSUNG équipés des fonctions Smart TV et AllShare. • Compatible avec les lecteurs Blu-ray ou systèmes de cinéma maison SAMSUNG 2010~2012 (Pour de plus amples renseignements, consultez le manuel d’utilisation du lecteurs TV / Blu-ray ou du systèmes de cinéma maison.) • La compatibilité peut se limiter à certains modèles et à certaines régions. Accessoire • Adaptateur à angle droit pour clé USB (seulement pour les lecteurs Blu-ray ou systèmes de cinéma maison) Installation de l’adaptateur • Insérez l’adaptateur LAN sans fil dans le port USB du téléviseur, du lecteurs Blu-ray ou du systèmes de cinéma maison. • Pour obtenir les précautions et les instructions pour l’installation, consultez le manuel d’utilisation du téléviseur, du lecteurs Blu-ray ou du systèmes de cinéma maison. - Téléviseur : Section « Connexion réseau → Sans fil » - Lecteur Blu-ray ou système de cinéma maison : Section « Configuration du réseau - Réseau sans fil » Mesures de précaution • Ne pas laisser les enfants jouer avec l’emballage en plastique et veiller à ce qu’ils ne portent pas le produit à la bouche. Conserver le produit et l’emballage en plastique hors de la portée des enfants. • Éviter que le produit n’entre en contact avec de l’eau ou des substances étrangères. Cela risque d’endommager le produit. • Ne pas exposer le produit directement à la lumière du soleil, à une flamme ou à une source de chaleur comme un appareil de chauffage. Cela peut réduire la durée de vie du produit ou causer un incendie. Garantie : un an • Si le produit ne fonctionne pas correctement en raison d’une défectuosité qui se manifeste, dans des circonstances normales, pendant la durée de validité de la garantie, veuillez vous rendre au détaillant où vous avez effectué l’achat. Spécifications (WIS12ABGNX) NormeIEEE 802.11 a/b/g/n Interface de l’ordinateur central USB 2.0 Plage de fréquences 2,412 ~ 2,4835 GHz 5,15 ~ 5,850 GHz Sécurité64/128 bits WEP, WPA /WPA2, 802.1x, WPS Puissance de sortie 802.11a : 11 dBm à 54 Mbps 802.11b : 17 dBm à 11, 5,5, 2 et 1 Mbps 802.11g : 14 dBm à 54 Mbps 802.11n (2,4 GHz) : 14 dBm (20 MHz) / 12 dBm (40 MHz) 802.11n (5 GHz) : 11 dBm (20 MHz) / 9 dBm (40 MHz) Débit des données 802.11a/g : 54, 48, 36, 24, 18, 12, 9 et 6 Mbps 802.11b : 11, 5,5, 2 et 1 Mbps 802.11n : jusqu’à 300 Mbps (40 MHz / flux spatiaux …

Text truncated - open the document above for the full version.

Page No. : 2 Samsung Electronics Co., LTD. 416, Maetan-3Dong, Paldal-Gu, Suwon City, Kyungki-Do, Korea 442-373 Tel: 82-10-5691-9410 Fax: 82-31-277-2784 Power of Attorney Date: 2011/11/30 Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Sporton International Inc. Address : No.8, Lane 724, Bo-ai St., Jhubei City, HsinChu County 302, Taiwan, R.O.C. Name : Leo Huang Job Title : Manager e-mail : [email protected] I am therefore responsible for the contents of the application. Brand name and model type of the specified radio equipment: SAMSUNG / WIS12ABGN FCC ID: A3LWIS12ABGNX Product name: Wireless LAN Adapter Note: The registered grantee contact is not available, Jaywoo Lee is signing for grantee contact. He can be reached at email : [email protected]. FCC Grantee contact person information. Applicant’s company name : Samsung Electronics Co., LTD. Applicant’s company address : 416, Maetan 3-Dong, Yeongtong-Gu, SUWON-SI, GYEONGGI-DO 443-742 REP. OF KOREA Signature : _____________________________ Signed for Peter Ra Job Title and Dept. : Peter Ra / General Manager E-Mail : [email protected] Tel. : 82-10-5691-9410

SPORTON International Inc. PAGE NUMBER : 1 OF 2 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255 Photographs of EUT SPORTON International Inc. PAGE NUMBER : 2 OF 2 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255

SPORTON International Inc. PAGE NUMBER : 1 OF 7 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255 Photographs of EUT SPORTON International Inc. PAGE NUMBER : 2 OF 7 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 3 OF 7 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 4 OF 7 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 5 OF 7 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 6 OF 7 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : 7 OF 7 TEL : 886-2-2696-2468 ISSUED DATE : Dec. 13, 2011 FAX : 886-2-2696-2255

Report No.: FR1N2329 FCC ID: A3LWIS12ABGNX Page No. : B1 of B3 Appendix B. Maximum Permissible Exposure Report No.: FR1N2329 FCC ID: A3LWIS12ABGNX Page No. : B2 of B3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.25 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR1N2329 FCC ID: A3LWIS12ABGNX Page No. : B3 of B3 1.3. Calculated Result and Limit For 5GHz UNII Band: Antenna Type : Printed Antenna Max Conducted Power for IEEE 802.11n 40 : 22.64 dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.67 2.3281 22.6440 183.8243 0.085183 1 Complies For 5GHz ISM Band: Antenna Type : Printed Antenna Max Conducted Power for IEEE 802.11a: 23.01 dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.67 2.3281 23.0092 199.9512 0.092656 1 Complies For 2.4GHz Band: Antenna Type : Printed Antenna Max Conducted Power for IEEE 802.11b/g: 22.97 dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result -0.48 0.8954 22.9700 198.1527 0.035314 1 Complies

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company Samsung Electronics Co., LTD. Applicant Address 416, Maetan 3-Dong, Yeongtong-Gu, SUWON-SI, GYEONGGI-DO 443-742 REP. OF KOREA FCC ID A3LWIS12ABGNX Manufacturer’s company Samsung Electronics Co., LTD. Manufacturer Address 416, Maetan 3-Dong, Yeongtong-Gu, SUWON-SI, GYEONGGI-DO 443-742 REP. OF KOREA Product Name Wireless LAN Adapter Brand Name SAMSUNG Model Name WIS12ABGNX Test Rule Part(s) 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz / 5725 ~ 5850MHz Received Date Nov. 23, 2011 Final Test Date Dec. 03, 2011 Submission Type Original Equipment Statement Test result included is only for the IEEE 802.11n, IEEE 802.11b/g part and IEEE 802.11a (5725 ~ 5850MHz) of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2009 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR1N2329AB Report Format Version: 01 Page No. : i of ii FCC ID: A3LWIS12ABGNX Issued Date : Dec. 13, 2011 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................5 3.3. Table for Filed Antenna.......................................................................................................................................................................6 3.4. Table for Carrier Frequencies .............................................................................................................................................................7 3.5. Table for Test Modes ...........................................................................................................................................................................8 3.6. Table for Testing Locations................................................................................................................................................................10 3.7. Table for Supporting Units .................................................................................................................................................................10 3.8. Test Configurations ...........................................................................................................................................................................11 4. TEST RESULT ................................................................................................................................................... 14 4.1. AC Power Line Conducted Emissions Measurement.........................................................................................................................14 4.2. Peak Output Power Measurement ....................................................................................................................................................18 4.3. Average Output Power Measurement ..............................................................................................................................................21 4.4. Power Spectral Density Measurement ..............................................................................................................................................24 4.5. 6dB Spectrum Bandwidth Measurement ..........................................................................................................................................33 4.6. Radiated Emissions Measurement ....................................................................................................................................................40 4.7. Band Edge Emissions Measurement .................................................................................................................................................66 4.8. Antenna Requirements .....................................................................................................................................................................78 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................... 79 6. TEST LOCATION.............................................................................................................................................. 81 7. TAF CERTIFICATE OF ACCREDITATION ............................................................................................................. 82 APPENDIX A. TEST PHOTOS ........................................................................................................................ A1 ~ A6 APPENDIX B. MAXIMUM PERMISSIBLE EXPOSURE .......................................................................................... B1 ~ …
