A3LXE700T1ANike Tablet

1 2 3 4 5 User Guide Getting Started Using the Computer Settings and Upgrade Backup / Restore Appendix Contents Start 1 Chapter 1. Getting Started Contents Chapter 1. Getting Started 3 Before You Start 6 Safety Precautions 21 Proper Posture During Computer Use 24 Overview 28 Turning the Computer On and Off Chapter 2. Using the Computer 35 Using the Touch Screen (For Windows 7 touch screen models only) 41 Entering Letters Using the Touch Screen (For Windows 7 touch screen models only) 43 Using the Touch Launcher (For Windows 7 touch screen models only) 44 Using the Touch Supporter (For Windows 7 touch screen models only) 46 Using the camera 48 Keyboard (Optional) 50 Micro SD Card Slot (Optional) 52 Connecting an External Display Device 57 Connecting an External Digital Device 58 Adjusting the Volume 60 Wired Network (Optional) 63 Wireless Network (Optional) 67 Using the Slate PC Dock (Optional) Chapter 3. Settings and Upgrade 71 LCD Brightness Control 73 Easy Settings (Optional) 74 BIOS Setup 76 Changing the Boot Priority 77 Battery Chapter 4. Backup / Restore 83 Samsung Recovery Solution (Optional) Chapter 5. Appendix 96 Important Safety Information 98 Replacement Parts and Accessories 100 Regulatory Compliance Statements 115 WEEE Symbol Information 116 Product Specifi cations 118 Glossary 122 Index Before You Start 3 Safety Precautions 6 Proper Posture During Computer Use 21 Overview 24 Turning the Computer On and Off 28 Chapter 1. Getting Started 3 Chapter 1. Getting Started Before You Start Before reading the User Guide, fi rst check the following information. Optional items, some devices and software referred to in • the User Guide may not be provided and/or changed by upgrade. Note that the computer environment referred in the User Guide may not be the same as your own environment. The pictures used for the cover and the main body in the • User Manual are those of the representative model of each series and may diff er from the actual appearance of the product. This guide decribes procedures for using both the mouse • and the touch screen. The User Guide describes information on the basis of the • touch screen. This manual has been written for the Windows 7 operating • system. The descriptions and fi gures may diff er depending on the installed operating system. The User guide supplied with this computer may vary • depending on your model. Using the software The software described in the main text can be launched • using the following menu path. - Start > All Programs - Start > All Programs > Samsung When the programs are not installed, select • Samsung Recovery Solution > System Software to install the programs. (Only for models supplied with Samsung Recovery Solution) Safety Precaution Notations IconNotationDescription Warning Failure to follow instructions marked with this symbol, may cause personal injury and or fatality. Caution Failure to follow instructions marked with this symbol, may cause slight injury to yourself or damage your property. 4 Chapter 1. Getting Started Before You Start Text Notations IconNotationDescription Caution Content included in this section includes information required about the function. Note Content included in this section includes helpful information to use the function. Copyright © 2011 Samsung Electronics Co., Ltd. Samsung Electronics Co., Ltd. owns the copyright of this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, without the consent of Samsung Electronics Co., Ltd. The information in this document is subject to change without notice due to improving the performance of the product. Samsung Electronics shall not be liable for any data loss. Please take care to avoid losing any important data and backup your data to prevent any such data loss. Precautions for Operating System Support If a problem occurs because of the reinstallation of other operating systems(OS) or a previous version of an OS pre-installed on this computer, or a software that does not support the OS, the company will not provide technical support, a replacement or refund, and if our service engineer visits you due to this problem, a service charge will be applied. Performance Restrictions Online games and some games(3D,2D) may not be supported and Full HD video and some high bit rate HD video playback may be slow and stutter on this computer. 45 Chapter 1. Getting Started About the Product Capacity Representation Standard About the capacity representation of the storage The capacity of the storage device (HDD, SSD) of the manufacturer is calculated assuming that 1KB=1,000 Bytes. However, the operating system (Windows) calculates the storage device capacity assuming that 1KB=1,024 Bytes, and therefore the capacity representation of the HDD in Windows is smaller than the actual capacity due to the difference in capacity calculation. (E.g. For a 80GB HDD, Windows represents the capacity as 74.5GB, 80x1,000x1,000x1,000 byte/(1,024x1,024x1,024)byte = 74.505GB) In addition, the capacity representation in Windows may be even smaller because some programs such as Recovery Solution may reside in a hidden area of the HDD. About Memory Capacity Representation The memory capacity reported in Windows is less than the actual capacity of memory. This is because BIOS or a video adapter uses a portion of memory or claims it for further use. (E.g. For 1GB(=1,024MB) memory installed, Windows may report the capacity as 1,022MB or less) For more information, refer to the Samsung Recovery Solution section. Before You Start 6 Chapter 1. Getting Started Installation Related Do not install the product in places exposed to humidity such as a bathrooms. There is a danger of electric shock. Use the product within the operating conditions specifi ed in the Manufacturers User Guide. Keep the plastic bags out of the reach of children. There is a danger of suff ocation. Safety Precautions Keep a distance of 15cm or more between the comp…

Text truncated - open the document above for the full version.

1 2 3 4 5 User Guide Getting Started Using the Computer Settings and Upgrade Backup / Restore Appendix Contents Start 6263 Chapter 2. Using the computer A wireless network (Wireless LAN) environment is a network environment that enables communicating between multiple computers at home or a small-size offi ce through wireless LAN devices. The descriptions below are for computer models with • a Wireless LAN card or device. A Wireless LAN device is optional. The pictures in this manual may diff er from the actual product depending on your wireless LAN device model. If the wireless LAN is turned off , select • Easy Settings > Wireless Network and set it to ON. What is an Access Point ( AP)? An AP is a network device that bridges wired and wireless LANs, and corresponds to a wireless hub in a wired network. Connect the computer with the wireless LAN function to the AP to use to the network connection. Wireless Network (Optional) 64 Chapter 2. Using the computer Wireless Network (Optional) Connecting to a Wireless LAN If there is an AP, you can connect to the Internet via the AP using the Wireless LAN connection method provided by Windows. These descriptions are written based on Windows 7, the latest operating system. Therefore, some descriptions and fi gures may diff er from your operating system. But as the usage is similar to other Windows operating systems, you can use these descriptions for reference. 1 If you click the Network Connections icon in the system tray, a list of available APs appears. If you select an AP to connect to, the Connect button appears. AP List 2 Click Connect. If a network key is set for the AP, enter the network key and then click Connect. For the network key, please ask your network administrator. 3 When Connected to the AP is displayed, click the Close button. You can access the network. 6465 Chapter 2. Using the computer Wireless Network (Optional) Connecting to a Wireless LAN through Easy Settings (Optional) You can access a wireless LAN using Easy Settings. These descriptions are for Windows 7 and for supported models only. 1 Launch the Easy Settings. 2 Confi gure the Wireless Network and set the Wi-Fi device to ON. If this option is set to ON, the Wi-Fi function will run. AP List z x c Normal Wireless Network Status If the wireless LAN icon is displayed in the system tray of the Taskbar, it indicates that the computer is connected to the Internet properly (see below). 66 Chapter 2. Using the computer Wireless Network (Optional) Abnormal Wireless Network Status When the wireless LAN is not connected If the wireless LAN icon is displayed with an “X” in the system tray of the Taskbar, it indicates that the wireless LAN device is turned off or that there are no available APs. Or the wireless LAN is disconnected. When you are not connected to the Internet This is indicated by the wireless LAN icon in the system tray of the Taskbar. In this case, you have to check the IP address settings. Please contact your network administrator and reconfi gure the IP address. When APs are found but your computer is not connected to the Internet This is the case when an AP with a weak signal has been set to a high priority. Connect to an AP with a strong signal by clicking it. An AP with a strong signal strength The currently connected AP. The signal strength is low. Click 6667 Chapter 2. Using the computer Using the Slate PC Dock (Optional) The Slate PC Dock supports various notebook computers so that compatible peripherals can be connected to the computer. You have to purchase the Slate PC Dock additionally. ► Rear 12345 1DC Jack A jack to connect the AC adapter that supplies power to the computer. 2 Wired LAN Port Connect the Ethernet cable to this port. 3 Digital Video/ Audio Port (HDMI) (Optional) You can connect an HDMI cable to this port. Using this port, you can enjoy digital video and audio on the TV. You cannot use both this port and the Micro HDMI port on the computer at the same time. To use the Micro HDMI port on the computer, separate the Slate PC Dock. 4USB Port You can connect USB devices to the USB port such as a keyboard/mouse, digital camera, etc. 5 Headphone Jack A jack used to connect the headphones. Connecting and using a Headphone Jack Using the Headphone jack 1 Right-click over the Volume Control icon in the notifi cation area at the bottom right of the Desktop and select Playback Devices. (Alternatively, click the Control Panel > Hardware and Sound > Sound > Playback tab.) 2 Select the Speakers(USB audio), click Set Default and click OK. Restrictions When the Slate PC Dock is connected to the computer, you cannot use the microphone (USB audio) or the Line-In (USB audio) item of the recording device. 68 Chapter 2. Using the computer Installing/Removing Before installing a computer to the docking station, make sure to disconnect all the cables connected to the computer. Although you can separate the computer from the Slate PC Dock regardless of whether the computer is on or off , separating it when the computer is off is recommended. Installing the computer You can only use the Slate PC Dock with a Samsung computer that supports this feature. 1 Insert your fi nger into the groove on the side of the Slate PC Dock to open the top cover of the Slate PC Dock. 2 Align the computer connector of the Slate PC Dock and the Slate PC Dock port at the bottom of the computer and connect them. Computer Connector Using the Slate PC Dock (Optional) 6869 Chapter 2. Using the computer Separating the Computer 1 Turn the computer off. 2 Pull the computer upward by hand while holding the Slate PC Dock firmly with the other hand. Using the Slate PC Dock (Optional) LCD Brightness Control 71 Easy Settings (Optional) 73 BIOS Setup 74 Changing the Boot Priority 76 Battery 77 Chapter 3. Settings and Upgrade 71 Chapter 3. Settings and Upgrade LCD Brightness Control Using the Easy Settings, you can control the LCD brightness. The screen brightness is automatically set to the brightest …

Text truncated - open the document above for the full version.

Samsung Electronics Co Ltd 18600 Broadwick St., Rancho Dominguez, California 90220, United States Tel: 310-900-5250 ; Fax: 310-537-5500 Date: July 26, 2011 Power of Attorney To whom it may concern, Please be notified that I, Peter Ra, have designated Jones Tsai in Sporton International Inc. and John SC Lee in Samsung Electronics Co Ltd as the persons being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Jones Tsai in Sporton International Inc. and John SC Lee in Samsung Electronics Co Ltd on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This authorization is limited to the product of as following: FCC ID: A3LXE700T1A If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Contact Person: Peter Ra Company: Samsung Electronics Co Ltd TEL: 310-900-5250 FAX: 310-537-5500 E-mail: [email protected]

1/1 416 Maetan-Dong, Young-Tong-Gu, Suwon City, Gyungki-Do, 443-742 Korea Date: July 27, 2011 Federal Communications Commission Authorization and Evaluation Division RE : Certification Application FCC ID : A3LXE700T1A To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days:  External Photos (file: XE700T1A_ExtPho.pdf)  Internal Photos (file: XE700T1A_IntPho.pdf)  Test Setup Photos (file: XE700T1A_Tsup.pdf)  User Manual (file: XE700T1A_UserMan.pdf) The application contains technical information, which Samsung Electronics Co Ltd deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Sincerely, John SC Lee / Manager Samsung Electronics Co., Ltd. PC R& D Division

416 Maetan-Dong, Young-Tong-Gu, Suwon City, Gyungki-Do, 443-742 Korea Date: July 27, 2011 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 SUBJECT: FCC Application for FCC ID: A3LXE700T1A To Whom It May Concern: We, Samsung Electronics Co Ltd, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Sincerely yours, John SC Lee / Manager Samsung Electronics Co., Ltd. PC R& D Division

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B1 OF B5 TEL : 886-2-2696-2468 ISSUED DATE : Aug. 04, 2011 FAX : 886-2-2696-2255 APPENDIX B. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B2 OF B5 TEL : 886-2-2696-2468 ISSUED DATE : Aug. 04, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B3 OF B5 TEL : 886-2-2696-2468 ISSUED DATE : Aug. 04, 2011 FAX : 886-2-2696-2255

Nike Tab Bottom System Label ITS Design Group 11.07.19 97.54mm 40mm Align Center 10.8mm 12mm 24mm

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B4 OF B5 TEL : 886-2-2696-2468 ISSUED DATE : Aug. 04, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : B5 OF B5 TEL : 886-2-2696-2468 ISSUED DATE : Aug. 04, 2011 FAX : 886-2-2696-2255

SPORTON International Inc. Report Format Version: a FCC TEST REPORT Report No. : FR171128-01 FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.225 Equipment : Nike Tablet to Notebook (Tablet PC) Brand Name : Samsung Model No. : XE700T1A Filing Type : New Application Applicant Manufacturer : Samsung Electronics 416, Maetan-3dong, Yeongtong-gu, Suwon-cit y, Gyeonggi-do, 443-742, Korea FCC ID: A3LXE700T1A Received Date : Jul. 29, 2011 Final Test Date : Aug. 05, 2011 Statement The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Aug. 05, 2011 FAX : 886-2-2696-2255 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 Table of Contents 1. SUMMARY OF THE TEST RESULT ....................................................................................................................... 2 2. GENERAL INFORMATION ...................................................................................................................................... 3 2.1 Product Details .........................................................................................................................................................................................3 2.2 Accessories ..............................................................................................................................................................................................3 2.3 Table for Test Modes ...............................................................................................................................................................................3 2.4 Table for Testing Locations ......................................................................................................................................................................3 2.5 Table for Supporting Units .......................................................................................................................................................................3 2.6 Test Configurations ..................................................................................................................................................................................4 3. TEST RESULT ......................................................................................................................................................... 6 3.1 AC Power Line Conducted Emissions Measurement ..............................................................................................................................6 3.2 Field Strength of Fundamental Emissions and Mask Measurement ......................................................................................................12 3.3 20dB Spectrum Bandwidth Measurement .............................................................................................................................................15 3.4 Radiated Emissions Measurement ........................................................................................................................................................17 3.5 Frequency Stability Measurement .........................................................................................................................................................26 3.6 Antenna Requirements ..........................................................................................................................................................................28 4. LIST OF MEASURING EQUIPMENTS .................................................................................................................. 29 5. TEST LOCATION ................................................................................................................................................... 31 6. TAF CERTIFICATE OF ACCREDITATION ........................................................................................................... 32 APPENDIX A. TEST PHOTOS ........................................................................................................................ A1 ~ A7 APPENDIX B. PHOTOGRAPHS OF EUT ....................................................................................................... B1 ~ B5 SPORTON International Inc. Page No. : ii of ii TEL : 886-2-2696-2468 Issued Date : Aug. 05, 2011 FAX : 886-2-2696-2255 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 History of This Test Report Original Issue Date: Aug. 05, 2011 Report No.: FR171128-01 ■ No additional attachment. □ Additional attachment were issued as following record: Attachment No. Issue Date Description 15.205(a) 15.209(a) 47 CFR FCC Part 15 Subpart C Further, this requirement does not apply to intentional radiators that must be professionally installed. SPORTON International Inc. Page No. : 1 of 32 TEL : 886-2-2696-2468 Issued Date : Aug. 05, 2011 FAX : 886-2-2696-2255 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 CERTIFICATE OF COMPLIANCE according to 47 CFR FCC Part 15 Subpart C § 15.225 Equipment : Nike Tablet to Notebook (Tablet PC) Brand Name : Samsung Model No. : XE700T1A Applicant : Samsung Electronics 416, Maetan-3dong, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-742, Korea Sporton International as requested by the applicant to evaluate the EMC performance of the product sample received on Jul…

Text truncated - open the document above for the full version.

Page No. : A1 of A7 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 Appendix A. Test Photos Page No. : A2 of A7 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 1 Photographs of Conducted Emissions Test Configuration Adapter 1 Mode FRONT VIEW REAR VIEW Page No. : A3 of A7 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 SIDE VIEW Page No. : A4 of A7 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 Adapter 2 Mode FRONT VIEW REAR VIEW Page No. : A5 of A7 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 SIDE VIEW Page No. : A6 of A7 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz Adapter 1 Mode FRONT VIEW REAR VIEW Page No. : A7 of A7 FCC ID : A3LXE700T1A FCC TEST REPORT Report No. : FR171128-01 For radiated emissions 30MHz~1GHz Adapter 1 Mode FRONT VIEW REAR VIEW
