A4E-ICPTRWSMulti-function cup holder

ICP多功能杯座 将沙发木板相应位置开孔 将2个M8螺杆旋入产品主体上 将主体装入开孔中 装上垫片及蝶形螺母并扭紧 安装说明 第一步 第四步 第三步 第二步 操作说明 电性参数 （主体参考开孔尺寸L199*W115mm） 1.接通29V2A电源给产品通电。 2.本产品一共有八个触摸按键和一个机械按键，各按键操作如下： 该机械按键为电源键，按下此键后所有功能全部关闭（包括无线充电 和USB充电）且所有按键灯熄灭，再按一次开启电源，所有功能恢复且按键 灯亮蓝光。 长按此键为座部推杆打开。 长按此键为头部、腰部、座部推杆全部收回。 长按此键为腰部推杆伸出。 长按此键为腰部推杆收回。 长按此键为头部推杆伸出。 长按此键为头部推杆收回。 短按此键为翻盖打开，再次短按为翻盖闭合。 长按此键为锁定其他触摸按键，锁定后其他触摸按键灯熄灭且触控无 效，锁键灯为红色，再次长按解锁，所有触摸按键功能恢复且按键灯变回 蓝色。 3.翻盖打开后有一条无线充电的插槽，将手机置于插槽内即可开始无线充电， 放置时应将手机背面对着倾斜面，反之无法充电，开始充电时会伴有一声“嘀” 的提示音且电源键由蓝光变成绿光，若未有提示音及灯光指示请查看手机是 否放置正确。 4.翻盖打开后中间圆口为杯座放置区。 5.触摸按键中间带有一个USB快充充电口，并带有滑动式防尘盖，不充电时 请关闭滑盖以免灰尘进入。 输入：29V2A USB输出：18W 无线充输出：5W 额定功率：58W 注意事项 1. 本产品运输途中由于震荡等因素可能导致产品翻盖轻微弹开，属于正常， 此现象会在通电并且完成一次翻盖开合后正常闭合。 2. 翻盖运行时尽量不要频繁操作翻盖开合按键，避免频繁快速转向导致内 部马达过热受损从而降低产品的使用寿命。 3.如翻盖由于人为摁压处于半打开或半关闭状态，操作翻盖开合按键时会出 现空转或者未完全闭合，属于正常现象。此时只要多按一次翻盖按键使其完 全打开和完全闭合运行到底即可恢复。 4.本产品外观采用拉丝工艺，请勿用尖锐物品划伤表面。 5.为了保证翻盖的寿命，请勿随意手动翻转或摁压翻盖。 6.使用时请撕下翻盖内面的保护膜。 7.请谨防细微物品（如钢针）或液体进入无线充电槽，如不慎让液体进入， 请立即关闭电源断电，将抽取式内盒取出，待液体风干再重新启动；查看 细微物品是否掉落在内盒内，如若掉入底部，请联系厂家。 8.本产品不使用时请关闭电动翻盖以及USB防尘盖。 9.如遇到按键失灵、翻盖卡死等现象，请断电2分钟后重启。 10.儿童请在家长的监护下使用。 ICP multifunction cup holder Make holes in the corresponding position of the sofa board Screw two M8 screws into the product Install the product into the hole Install gasket and butterfly nut and twist tightly Installation instruction Step 1 Step 4 Step 3 Step 2 Operating instruction Specification （Opening size L199*W115mm） 1.Connect the 29V2A power supply to power ups the product. 2.This product has 8 touch buttons and 1 mechanical button. The operation all button is as follows ： This mechanical button is the power button. After pressing this button, all functions are turned off (including wireless charging and USB charging) and all button lights are off. Pressing it again to turn on the power, all functions are restored and all touch button lights are blue. Long press this button to open the seat actuator. Long press this button for the head actuator, waist actuator and seat actuator are all recovered. Long press this button to extend the waist actuator. Long press this button for waist actuator retraction. Long press this button to extend the head actuator. Long press this button for head actuator retraction. Short press this button to open the flip cover, short press again to close the flip cover. Long press this button to lock other touch buttons. After the lock, the other touch button lights are off and the touch control is invalid. The lock button lights turn red，Long press again to unlock, all touch button functions are restored and the button light turns blue. 3.After the flip cover is opened, there is a slot for wireless charging. Put the phone in the slot to start wireless charging. When placing the phone, the back of the phone should face the inclined plane, otherwise it cannot be charged，When charging, there will be a prompt tone and the power button will change from blue light to green light. If there is no prompt tone and light indication, please check whether the mobile phone is correctly placed. 4.After the flip cover is opened, the middle round hole is the cup holder placement area. Input:29V2A USB output:18W Wireless charging output:5W Rated power:58W Notes 1. The flip cover of the product may pop slightly during transportation due to shock and other factors, which is normal. This phenomenon does not occur after power on and the flip cover is opened and closed once. 2. When the product is powered on, do not operate the flip cover opening and closing button frequently when it is running, so as to avoid frequent and rapid steering that may lead to overheating and damage of the internal motor, thus reducing the service life of the product. 3. If the flip cover is in the half-open or half-closed state due to manual press, idling or incomplete closure will occur when operating the flip cover opening and closing button, which is a normal phenomenon. It can be restored by pressing the flip cover button once more to make it open and closed fully. 4.The appearance of this product adopts wire drawing process, do not scratch the surface with sharp objects. 5.To ensure the service life of the flip cover, do not manually flip or press the flip cover. 6.Tear off the protective film on the inside of the cover when you use it. 7.Please be careful of small items (such as steel needles) or liquid entering the wireless charging tank. If liquid enters the wireless charging tank accidentally, please immediately turn off the power and power off, remove the extractable inner box, and restart it after the liquid dries. Check whether small items fall into the inner box. If they fall into the bottom, contact the manufacturer. 8.Please close the electric flip cover and USB dust cover when the product is not in use. 9.If buttons fail or the flip cover is stuck, power off the device for 2 minutes and restart it. 10.Children should be used under the supervision of parents. 5.There is a USB quick charging port in the middle of the touch button, and there is a sliding dust cover, please close the slide cover when you don’t charging to avoid dust. FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarante…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of ProcessLETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: THREE STONES MEDIA LLC FRN: 0033401761 Contact Name: Sijie Zhang Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Telephone No: +1 267 909 3692 Email: [email protected] Applicant: Company name: eMoMo Technology Co.,Ltd Product Description: Multi-function cup holder Grantee code: A4E FCC ID: A4E-ICPTRWS Contact Name: Rosary Tang Address: 4th, Floor, Yong He Building , Tai Wan Industrial Park , Shi Yan Town ,Bao'an District,Shen Zhen, 518108, Guangdong,, 518108 China Telephone No: 86 755 27643116#809 Email: [email protected] [eMoMo Technology Co.,Ltd] certifies that, as of the date of this filing of the application with the TCB, [THREE STONES MEDIA LLC] is our designated US agent for service of process for the above referenced FCC ID. [eMoMo Technology Co.,Ltd] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [THREE STONES MEDIA LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicantis aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. 1/1 Date: 06/07/2023 Applicant’s Name: Rosary Tang US Agent’s Name: Sijie Zhang Title:Boss Title: President Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: eMoMo Technology Co.,Ltd Grantee code: A4E FCC ID: A4E-ICPTRWS Contact Name: Rosary Tang Address: 4th, Floor, Yong He Building , Tai Wan Industrial Park , Shi Yan Town ,Bao'an District,Shen Zhen, 518108, Guangdong,, 518108 China Telephone No: 86 755 27643116#809 Fax No: N/A Email: [email protected] i. [eMoMo Technology Co.,Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [eMoMo Technology Co.,Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. eMoMo Technology Co.,Ltd certifies that, as of the date of the filing of theapplication, the applicant is not identified on the Covered List as an entity producing “covered”equipment. Date: 06/28/2023 Applicant’s Name: Rosary Tang Title:Boss Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

eMoMo Technology Co.,Ltd Family models declaration letter. 7/11/2023 We Company: eMoMo Technology Co.,Ltd Address: 4th, Floor, Yong He Building , Tai Wan Industrial Park , Shi Yan Town ,Bao'an District,Shen Zhen, 518108, Guangdong,, 518108 China Product: Multi-function cup holder Model Name: A4E-ICPTRW(S) Family Model: ICPTRW(S)、ICPTRWA(S)、ICPRRWMH(S)、ICPRRWMH(DG)、 ICPRRWMH(G)、ICPRRWMH(C)、ICPRRW(S)、ICPRRWA(S)、ICP33W(S)、ICP33WM(S) All the model are the same circuit and RF module, except the color. We (eMoMo Technology Co.,Ltd) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.), same mechanical structure and design (including product enclosure, materials, etc.), the only difference is the model color. Thanks Sincerely, Signature [Name] Rosary Tang [Title] Boss [email protected]

C5266091_X8_Ed.1 1/1 Letter of Authorization < eMoMo Technology Co.,Ltd > Company: eMoMo Technology Co.,Ltd Address: 4th, Floor, Yong He Building , Tai Wan Industrial Park , Shi Yan Town ,Bao'an District,Shen Zhen, 518108, Guangdong,, 518108 China Product Name: Multi-function cup holder Model Number: A4E-ICPTRW(S), ICPTRW(S)、ICPTRWA(S)、 ICPRRWMH(S)、ICPRRWMH(DG)、ICPRRWMH(G)、ICPRRWMH(C)、 ICPRRW(S)、ICPRRWA(S)、ICP33W(S)、ICP33WM(S) FCC Identifier:A4E-ICPTRWS We authorize LGAI Technological Center S.A., Ronda de la Font delCarme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Rosary Tang Date: 06/07/2023 Title: Boss Signature of applicant:

C5266091_X10_Ed.2 1/1 < eMoMo Technology Co.,Ltd > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046Date: 06/07/2023 Subject: Request for Confidentiality FCC ID: A4E-ICPTRWS To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location Attestation Statement External Photos Block Diagram Schematics Test Report Test Setup Photos User’s Manual NOTE 1 Internal Photos NOTE 1 Parts List / Tune Up / BOM List RF Exposure Info Operational Description Cover Letter(s) FCC Software Security Requirements for UNII devices NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. C5266091_X10_Ed.2 1/1 It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Rosary Tang Title: Boss

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9

1.5A Model No.: ICPTRW(S) Input: 29V DC, 2A USB Output: 5V 3A ,9V 2A , 12V Wireless Charging Output: DC 5V, 5W FCC ID:A4E-ICPTRWS The device complied with Part15 and Part 18 of the FCC Rule. Operation is subject to the following two conditions (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation. MADE IN CHINA 43mm 60mm E510674 Multi-function cup holder Model No.: ICPTRW(S) Input: 29V DC, 2A Output: USB Output: 5V 3.6A Max Wireless Charging Output: DC 5V, 5W FCC ID:A4E-ICPRRWMHS ThedevicecompliedwithPart15 and Part 18 of the FCC Rule.Operationis subject to the following two conditions (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation. MADE IN CHINA 45mm 97mm E510674 Multi-function cup holder MADE IN CHINA ThedevicecompliedwithPart15 and Part 18 of the FCC Rule.Operationis subject to the following two conditions (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation. E510674 Model No.: ICPTRW(S) Input: 29V DC, 2A Output: USB Output: 5V 3.6A Max Wireless Charging Output: DC 5V, 5W FCC ID:A4E-ICPRRWMHS location:

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Induction coil 1 Induction coil 2

FCC ID: A4E-ICPTRWS 1.Measuring Standard FCC Part 1(1.1310) and Part 2(2.1091), KDB 680106 D01v03r01 RF Exposure Wireless Charging App v03 1.2. Requiments Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable and are defined as follows: o Fixed Installations: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. o Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR §2.1091. o Portable Devices: a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC's Rules (47 CFR§2.1093). The FCC also categorizes the use of the device as based upon the user’s awareness and ability to exercise control over his or her exposure. The two categories defined are Occupational/ Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows: Occupational/Controlled Exposure: In general, occupational/controlled exposure limits are applicable to situations in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure and can exercise control over their exposure. This exposure category is also applicable when the exposure is of a transient nature due to incidental passage through a location where the exposure levels may be higher than the general population/uncontrolled limits, but the exposed person is fully aware of the potential for exposure and can exercise control over his or her exposure by leaving the area or by some other appropriate means. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF safety program. If appropriate, warning signs and labels can also be used to establish such awareness by providing prominent information on the risk of potential exposure and instructions on methods to minimize such exposure risks. General Population/Uncontrolled Exposure: The general population / uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their employment may not be made fully aware of the potential for exposure or cannot exercise control over their exposure. Members of the general public would come under this category when exposure is not employment-related; for example, in the case of a wireless transmitter that exposes persons in its vicinity. Warning labels placed on low-power consumer devices such as cellular telephones are not considered sufficient to allow the device to be considered under the occupational/controlled category, and the general population/uncontrolled exposure limits apply to these devices. 1.3 Test configuration 1, The field strength of both E-field was measured at 15cm, H-field was measured at 15cm surrounding the device, and 20 cm away from the surface from all coils using the equipment list above for determining compliance with the MPE requirements of FCC Part 1.1310. 2, The RF power density was measured at Under maximum load test 3, Maximum E-field measurements was made 15cm from each side of the EUT and H-field measurements was made 15cm from surrounding the EUT and 20 cm away from the surface from all coils. Along the side of the EUT and still 20cm away from the edge of the EUT, the field probes were positioned at the location where there is maximum field strength. The maximum E-field and H-field is reported below. 4, This device uses a wireless charging circuit for power transfer operating at the frequency of 111–175kHz. Thus, the 300kHz limits were used: E-field Limit = 614 (V/m); H-field limit = 1.63 (A/m). 1.4 Test Setup 2. Limits 3. MEASURING DEVICE、UNCERTAINTY AND TEST EQUIPMENT 3.1For MPE Measurement Equipment Manuf acturer Model No. Serial No. Last calibration Calibrated until Cal. Interval E-Field Probe(100kHz-3GHz) Narda EF0391 Q15221 Mar 27, 2023 Mar 28, 2024 1 Year H-Field Probe(300KHz-30MHz) Narda HF3061 Q15835 Mar 27, 2023 Mar 28, 2024 1 Year Broadband Field Meter Narda NBM-550 Q201455 Mar 27, 2023 Mar 28, 2024 1 Year Load Apple iPhone 8 Plus N/A N/A N/A N/A 3.2 For UNCERTAINTY 4. Measuring Results EUT: Multi-function cup holder Model Name. : A4E-ICPTRW(S) Temperature: 24 °C Relative Humidity: 56% Pressure: 1010hPa Test Date: 2023-06-05 Test Voltage: DC 29V from Adapter half-load: Table 1. H-Field MPE Data-Top EUT Side E (A/m) Limits (A/m) Max load 0.365 1.63 Table 2. H-Field MPE Data- Surrounding EUT Side B(A/m) A(A/m) C (A/m) D(above) (A/m) Limits (A/m) Max load 0.363 0.366 0.371 0.363 1.63 Table 3. E-Field MPE E-Field Measurement (15cm) EUT Side B(V/m) A(V/m) E(V/m) C (V/m) D(above) (V/m) Limits (V/m) Max load 2.145 2.144 2.151 2.169 2.186 614 empty load: Table 1. H-Field MPE Data-Top EUT Side E(A/m) Limits (A/m) Max load 0.329 1.63 Table 2. H-Field MPE Data- Surrounding EUT Side B(A/m) A(A/m) C (A/m) D(above) (A/m) Limits (A/m) Max load 0.328 0.329 0.339 0.331 1.63 Table 3. E-Field MPE E-Field Measurement (15cm) EUT Side B…

Text truncated - open the document above for the full version.

承 认 书 SPECIFICATION FOR APPROVAL 客户名称（CUSTOM 一 么 么 科 技 有 限 公 司 客户料号（CUSTOMER P/N）:07-000136 品名（DESCRIPTION) : DATE:2021/4/18 规格（SPECIFICATION) ：52*52双线圈 REV.NO.:A0 鸿日昇威科技承认签核、盖章 部门 确认/日期审核/日期批准/日期 (盖公司公 章) 品质 董晚红 2021/4/18 吕惠 2021/4/18 韦函满 2021/4/18 工程何伟华 2021/4/18 韦立红 2021/4/18 韦立红 2021/4/18 备注： 一 么 么 科 技 承 认 签 核、盖章 部门 确认/日期审核/日期批准/日期 (盖公司公 章) 开发工 程 采购 品质 备注： 深 圳 市 鸿 日 昇 威 科 技 有 限 公 司 HRSW ELECTRONICS CO.,LTD ADD：深圳市龙华新区观澜环观中路48号1栋2楼 TEL：+86-755-23461055 FAX：+86-0755-28015170 page:1/3 SPECIFICATION FOR APPROVAL 1.MECHANICAL DIMENSION (UNIT:mm) 2.SCHEMATICS: 1.线圈贴磁片，磁片尺寸 52*52mm一体 2.线圈出线位置 缠胶纸 1-2Ts; 3.隔磁片底部要贴背胶 ABC D EF GHIK 52±1.052.5±1.0274±14.8Max47.5±117.6±151±126.5±138±1 3.WINDING： 1底1 STE P START-FINISHWIRE TYPETURNSTAPEREMARK N1S-F⌀0.08*105mm 2UEW-F9TS (Ref) 4.ELECTRICAL SPECIFICATION: ITEML1L2HI-POT TES T CON 线圈加磁片线圈加磁片 100KHz,0.25V100KHz,0.25V SPEC5.8uH±10% 6.4uH±10% 5.BILF OF MATERIAL： NO.ITEMMATERIAL SPECIFICATIONMANUFACTURERSGS NO. 1 丙铜丝包线0.08*105股NANJINGJINNINGCO,LTD 2 无铅锡条无铅锡条 QIAODO 3 磁片 G52*52锰锌硬磁片一体TAIYI CO.,LTD 4 胶水 黄胶9999LIANCHENG CO.,LTD 5 高温胶纸 8mm宽高温胶纸CUDAK CO.,LTD 6 背胶 51.5*51.5*0.8CUDAK CO.,LTD HRSW ELECTRONICS CO.,LTD PART NO TITLE 52*52双线圈 DRAWN BYCHECKED BY APPROVED BY 何伟华韦立红韦立红 page:2/3 SPECIFICATION FOR APPROVAL 6.SAMPLE TEST DATA 6.1DIMENSION TEST(UNIT:mm) TEST ITEM ABCDEFGHIK SPEC52±1.0 52.5±1.033±34±1 4.8Max47.5±117.6±151±126.5±138±1 1 52.352.7633.23.5 3.50 48.20 1851.6226.9838.87 2 52.652.83343.6 2.60 47.64 18.651.5726.8738.69 3 52.452.6933.63.8 2.50 48.02 17.9851.6526.8538.59 4 52.952.532.94 3.80 47.56 18.0551.9826.8238.64 5 52.352.8633.83.9 3.70 47.59 18.6851.3626.5938.95 6 7 8 9 10 MAX52.90 52.86 34.00 4.00 3.80 48.20 18.68 51.9826.9838.95 MIN52.30 52.50 32.90 3.50 2.50 47.56 17.98 51.3626.5938.59 AVERAGE52.50 52.73 33.50 3.76 3.22 47.80 18.26 51.63626.82238.75 6.2ELECTRICAL TEST TEST ITEM L1L2L3IDC QHI-POT S-F TEST COND 100KHz/0.25v SPEC 5.8uH ±10% 6.4uH ±10% 15.75 6.38 25.82 6.64 35.86 6.40 45.73 6.39 55.79 6.41 6 7 8 9 10 MAX5.86 6.64 MIN5.73 6.38 AVERAG E 5.79 6.44 HRSW ELECTRONICS CO.,LTD PART NO TITLE 52*52双线圈 DRAWN BYCHECKED BYAPPROVED BY 何伟华 韦立 红 韦立红 page:3/3

Report No.: S23051102201001 Version.1.1Page 1 of 24 FCC Test Report FCC ID:A4E-ICPTRWS Product: Multi-function cup holder Trade Name: eMoMo Model Number: A4E-ICPTRW(S) Family Model: ICPTRW(S)、ICPTRWA(S)、 ICPRRWMH(S)、ICPRRWMH(DG)、 ICPRRWMH(G)、ICPRRWMH(C)、 ICPRRW(S)、ICPRRWA(S)、ICP33W(S)、 ICP33WM(S) Report No.: S23051102201001 Prepared for eMoMo Technology Co.,Ltd Fourth Floor, Yonghe Building, TaiWan Industrial Park Shiyan, Baoan, Shenzhen, Guangdong Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, SanweiCommunity,Xixiang Street, Bao’an District, Shenzhen P.R. China Tel:400-800-6106,0755-2320 0050 / 2320 0090 Website:http://www.ntek.org.cn Report No.: S23051102201001 Version.1.1Page 2 of 24 TEST RESULTCERTIFICATION Applicant’s name ................. : eMoMo Technology Co.,Ltd Address ................................. : Fourth Floor, Yonghe Building, TaiWan Industrial Park Shiyan, Baoan, Shenzhen, Guangdong Manufacturer's Name .......... : eMoMo Technology Co.,Ltd Address ................................. : Fourth Floor, Yonghe Building, TaiWan Industrial Park Shiyan, Baoan, Shenzhen, Guangdong Model and/or type reference : A4E-ICPTRW(S) Family Model: ICPTRW(S)、ICPTRWA(S)、ICPRRWMH(S)、 ICPRRWMH(DG)、ICPRRWMH(G)、ICPRRWMH(C)、 ICPRRW(S)、ICPRRWA(S)、ICP33W(S)、ICP33WM(S) Test sample number S230511022001 Standards ............................. : FCC part 15C ANSI C63.10:2013 KDB 680106 D01 RF Exposure Wireless Charging App v03r01 This device described above has been tested by ShenzhenNTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ShenzhenNTEK Testing Technology Co., Ltd., this document may be altered or revised by Shenzhen NTEK Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. The test results of this report relate only to the tested sample identified in this report. Date of Test ............................................ : Date (s) of performance of tests ............. : 12 May. 2023 ~ 12 Jun. 2023 Date of Issue ........................................... : 13 Jun. 2023 Test Result ............................................... : Pass Testing Engineer : (Allen Liu) Authorized Signatory : (Alex Li) Report No.: S23051102201001 Version.1.1Page 3 of 24 Table of Contents Page 1 . TEST SUMMARY 4 1.1 FACILITIES AND ACCREDITATIONS 5 1.2 LABORATORY ACCREDITATIONS AND LISTINGS 5 1.3 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST SETUP 9 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 10 2.4 MEASUREMENT INSTRUMENTS LIST 11 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION 12 3.1.2 TEST PROCEDURE 13 3.1.3 TEST SETUP 13 3.1.4 EUT OPERATING CONDITIONS 13 3.1.5 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 16 3.2.2 TEST PROCEDURE 17 3.2.3 TEST SETUP 18 3.2.4 TEST RESULTS 19 4. BANDWIDTH TEST 22 4.1TEST PROCEDURE 22 4.2TEST SETUP 22 4.3 TEST RESULT 23 5. ANTENNA APPLICATION 24 5.1 Antenna Requirement 24 5.2 Result 24 Report No.: S23051102201001 Version.1.1Page 4 of 24 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item FCC Rules Limit Judgment Remark FCC part 15C ANSI C63.10:2013 Conducted Emission §15.207 Class B PASS Radiated Emission §15.209 Class B PASS ANTENNA APPLICATION §15.203 / PASS 20dB BANDWIDTH §15.215 Class B PASS NOTE: (1)’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Report No.: S23051102201001 Version.1.1Page 5 of 24 1.1 FACILITIES AND ACCREDITATIONS All measurement facilities used to collect the measurement data are located at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.10 and CISPR Publication 22. 1.2 LABORATORY ACCREDITATIONS AND LISTINGS Site Description CNAS-Lab. : The Certificate Registration Number is L5516. IC-Registration : The Certificate Registration Number is 9270A-1. FCC- Accredited : Test Firm Registration Number:463705. Designation Number: CN1184 A2LA-Lab. : The Certificate Registration Number is 4298.01 This laboratory is accredited in accordance with the recognized International Standard ISO/IEC 17025:2005General requirements for the competence of testing and calibration laboratories. This accreditation demonstratestechnical competence for a defined scope and the operation of a laboratory quality management system (refer to joint ISO-ILAC-IAF Communiqué dated 8 January 2009). Name of Firm : Shenzhen NTEK Testing Technology Co., Ltd. Site Location : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen 518126 P.R. China. 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Conducted Emission Test ±2.80dB 2 All emissions, radiated(9KHz~30MHz) ±6dB 3 All emissions, radiated(30MHz~1GHz) ±2.64dB All emissions, radiated(＞1GHz) ±2.40dB 4 BANDWIDTH ±0.39% Report No.: S23051102201001 Version.1.1Page 6 of 24 Revision History Report No. Version Description Issued Date S23051102201001 Rev.01 Initial issue of report 13 Jun. 2023 Report No.: S23051102201001 Version.1.1Page 7 of 24 2. GENERAL INFORMATION 2.1GENERAL DESCRIPTION OF EUT Product Feature and Specification Equipment Multi-function cup holder Trade Name eMoMo FCC ID A4E-ICPTRWS Model No. A4E-ICPTRW(S…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
