Order Number : GETEC-C1-11-274 FCC Part 15 subpart B Test Report Number : GETEC-E3-11-130 Page 1 / 1 EUT Type: POF USB to Ethernet Dongle FCC ID.: A4UUSB100 APPENDIX G : USER’S MANUAL MANUAL GAIAGRID USB-100 USB to Ethernet Dongle SEAHYUN KOREA CO.,LtD Contents Chapter 1 -Gaiagrid USB-100 SUMMARY -COMPONENTS Chapter 2 - Gaiagrid USB-100 BASIC INSTALLATON & DIAGRAM - THE WAY TO INSTALL (POF) Chapter 3 -SPECIFICATION 4장 -AS/ ETC Chapter 1. Gaiagrid USB-100 Summary •The GAIAGRID USB-100 is USB2.0 to 100Base-FX POF (Plastic Optical Fiber) converter. The GAIAGRID USB-100 is a high performance and highly integrated ASIC which enables low cost, small form factor, and simple plug-and- play Fast Ethernet network connection capability for desktop, notebook PC, Ultra-Mobile PC. The GAIAGRID USB-100 is fully compatible for IEEE 802.3u Fast Ethernet data communication standard . Chapter 1. Gaiagrid USB-100 Components -Gaiagrid USB-100 1EA -Drive Software CD 1EA Note. If there is no CD, you can download Drive software at Webpage. USB POF Optolock Chapter 2 - Gaiagrid USB-100 BASIC INSTALLATON & DIAGRAM POF GOF or UTP GOF ONU or ROUTER, or L3 switch POF switching HUB WAN Diagram Gaiagrid USB-100 You can install Gaiagrid USB-100 to PC as a Picture Chapter 2 - The way to install 1. Cut POF cable using POF Cutter 2. Pull POF PORT 3.Insert POF cable to POF PORT 4. Push POF PORT and Fix the cable 3장. SPECIFICATION Parameter GAIAGRID USB-100 Standard Compatibility 1.IEEE 802.3 Fast Ethernet 2.IEEE 802.3 Full Duplex Flow Control Date Rate 100Mbps Transmitting Length 50M at POF interface Interface connector Optolock POF transceiver Equipped Cable POF LED Indication Power status , FX link / active status Operating Environment Temperature : 0-50°C Humidity : 10-90% Storage Environment Temperature : -40-70°C Humidity : 10-90% (Non-condensing) Dimension (W*D*H) 60*25*19mm Total Weight 80g 4장. AS/ ETC 1.AS For additional information or to purchase the product, please contact us ; Seahyun Korea (www.Shyn.co.kr)
