A4X-PD35UMPP25Two-in-one Travel Charger

35W Travel Charger with 25W Wireless Charger User Manual Contents 1.0 Introduction ................................................... 1 2.0 Features ........................................................ 1 3.0 Specifications ................................................. 3 4.0 Package Contents ........................................... 4 5.0 Operation ....................................................... 4 6.0 Connection Diagram ........................................ 5 35W Travel Charger with 25W Wireless Charger 1 35W Travel Charger with 25W Wireless Charger DEAR CUSTOMER, Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or using this product. Please keep this manual for future reference. 1.0 INTRODUCTION This product is a high-performance travel charger. Type-C port output support 35W. Wireless Charger output support 25W. It is compatible with various USB protocols (such as iPhone and other smart phones). It is helpful for long-distance travel as well as convenient for business! 2.0 FEATURES  Internal chip allows 100-240VAC of input voltage  Type-C port output supports 35W Wireless charger output support 25W  Precise current-limiting output, overload protection and automatic restart after troubleshooting make the product safer and give you more peace of mind.  Over Current Protection 35W Travel Charger with 25W Wireless Charger 2  Over Voltage Protection  Short Circuit Protection with Auto-recovery  Over Temperature Protection with Auto-recovery  Product shell is made of fireproof material.  Intelligent and convenient to use. 35W Travel Charger with 25W Wireless Charger 3 3.0 SPECIFICATIONS Input 100～240V AC 50/60Hz 1.2A USB C:9V3A,12V3A,15V2.33A Input Frequency 50/60Hz Standby Input Power 0.8W Output Type-C: 5V3A, 9V/3A, 12V2.91A, 15V2.33A PPS:5-11V/3A Wireless charger: 25W USB C+Wireless:20W+15W Over Current Protection Yes Over Voltage Protection Yes Short Circuit Protection Yes Over Temperature Protection Yes Port Type-C Port & Wireless charger Socket US Operating Temperature Range -10～25°C Storage Temperature Range -20～85°C Operating Relative Humidity 20%～90% RH Storage Relative Humidity 5%～95% RH Ripple And Noise ≤ 200mVp-p Rise Time 20ms Turn-on Delay 3s Line Regulation ±3% Efficiency Output ≥ 82% Color 35W Travel Charger with 25W Wireless Charger 4 Size(L*W*H) 59.9mm *59.9mm* 40mm Weight 183.2g User Manual English Version 4.0 PACKAGE CONTENTS Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton:  Main unit×1  User Manual×1 5.0 OPERATION Operation Procedures 1. Plug the travel charger into a socket. 2. Plug one Type-C connector of the cable into the Type-C interface of travel charger and plug the other connector of the cable into the electronic device (mobile phone, tablet PC, etc) 3. Please unplug the travel charger after the electronic device is fully charged. Operation Notes 1. For optimum performance, please use the travel charger according to the user manual. 2. Please plug the travel charger into socket which voltage range should be 100-240VAC. 3. Please unplug the travel charger after using. 35W Travel Charger with 25W Wireless Charger 5 Note: Our products have protection functions and the two tips above are suggestions just for safety. 4. Do not use the travel charger with an electronic product which is not in conformity with the specifications, so as to avoid any problem caused by specification mismatching. 5. It’s normal that travel charger will be a little overheated in the use process. 6. When the travel charger stops working under over-current, over- temperature or short-circuit protection, please unplug the device after it automatically returns to work, then you need to check whether the device is compatible with this charger. 7. Do not let the travel charger close to fire, such as stove, candles and etc. 8. Do not let the travel charger soak into liquid, such as swimming pool, bathtub, etc. 9. Do not wash the travel charger with corrosive cleaner. 10. If the travel charger cannot work properly, please contact the store or distributor in your area. 6.0 Connection Diagram 35W Travel Charger with 25W Wireless Charger 6 FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and opera…

Text truncated - open the document above for the full version.

CE LINK LIMITED Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-09-05 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: A4X-PD35UMPP25 CE LINK LIMITED certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. CE LINK LIMITED certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, Signed: Printed name: yonghuan wang Title: Engineer Company Name: CE LINK LIMITED Date:9/5/2026 CE LINK LIMITED Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-09-05 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: A4X-PD35UMPP25 CE LINK LIMITED certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signed: Printed name: yonghuan wang Title: Engineer Company Name: CE LINK LIMITED Date:9/5/2026

1/1 CELINKLIMITED USAGENTLETTEROFATTESTATION ReferenceNo.2026UL0272 USAgent: CompanyName:TTSMARKETINC. FRN:0036806057 ContactName:MaverickLim Address:1178BroadwaySte324,NewYork,NY10001,USA TelephoneNo:001-(646)305-2908 Email:[email protected] TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasUSagent representativeonbehalfofthe(TTSMARKETINC.)notedbelowforallfutureFCC certification/registrationsobtainedduringtheperiodofthisagreement,whichendsatthe specifieddatebelow. AsperUSagent,weareawareoftherequirementsinvolvedasoutlinedinFCCEquipment AuthorizationProgramintheirReportandOrderFCC22-84andtheclause§2.911Application requirements. Applicant Companyname:CELINKLIMITED FRN:0021335963 Granteecode:A4X FCCID:A4X-PD35UMPP25 ContactName:yonghuanwang Address:22DongkangRoad,DalingshanTown,DongguanCity,GuangdongProvince, China TelephoneNo:0769-89920666ext:8525 FaxNo:0769-89920666 Email:[email protected] TheApplicantacknowledgetheacceptanceofitsobligationtomaintainanagentfor serviceofprocessintheUnitedStatesfornolessthanoneyearaftereitherthe granteehaspermanentlyterminatedallmarketingandimportationoftheapplicable equipmentwithintheU.S.,ortheconclusionofanyCommission-related administrativeorjudicialproceedinginvolvingtheequipment,whicheverislater. Date:9/8/2026 Applicant’sName:yonghuanwangUSAgent’sName:MaverickLim Title:Engineer Title:Manager SignatureSignature

CE LINK LIMITED Date：9/5/2026 Product Model Number: PD35U-1TGA-MPP25 FCC ID: A4X-PD35UMPP25 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following:  Testing  Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Printed name: yonghuan wang Title: Engineer Email: [email protected] Telephone: 0769-89920666 ext: 8525 On behalf of: CE LINK LIMITED

CE LINK LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 5, 2026 Subject; Request for Confidentiality FCC ID: A4X-PD35UMPP25 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: yonghuan wang Title: Engineer

External Photos M/N: PD35U-1TGA-MPP25 External Photos M/N: PD35U-1TGA-MPP25 External Photos M/N: PD35U-1TGA-MPP25 External Photos M/N: PD35U-1TGA-MPP25

7.7mm 9.7mm

Internal Photos M/N: PD35U-1TGA-MPP25 Internal Photos M/N: PD35U-1TGA-MPP25 Coil Antenna Internal Photos M/N: PD35U-1TGA-MPP25 Internal Photos M/N: PD35U-1TGA-MPP25

Page 1 of 6 Report No. ESTE-R2609014 FCC 47 CFR MPE REPORT CE LINK LIMITED Two-in-one Travel Charger Model Number: PD35U-1TGA-MPP25 FCC ID: A4X-PD35UMPP25 Applicant: CE LINK LIMITED Address: 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2609014 Date of Test: Jul. 06, 2026 to Aug. 28, 2026 Date of Report: Sep. 03, 2026 Page 3 of 6 Report No. ESTE-R2609014 1. Summary of test 1.1. Summary of test result No. Description of Test Item FCC Standard Section Results 1 Maximum Permissible Exposure Part 1.1307(b)&1.1310 PASS 1.2. Test Mode 1.3. Test Equipment List Equipment Manufacturer Model No. Serial No. Last Cal. Next Cal. Electric and Magnetic Field Probe-Analyzer Narda S.T.S./PMM EHP-200A EST-E106 June 11,26 June 10,27 Test Software Narda EHP200-TS Rel 1.92 N/A N/A Note: Test uncertainty: ±1.62 dB (H-field);±1.64 dB (E-field) at a level of confidence of 95%. 1.4. Assistant equipment used for test Item Equipment Brand Model Name/Type No. FCC ID Series No. 1 Wireless load - YBZ BPP - - Item Shielded Type Ferrite Core Length Model Name/Type No. Note - - - - - - Test Item Test Mode Maximum Permissible Exposure Wireless Charging with 5W Wireless Charging with 7.5W Wireless Charging with 10W Wireless Charging with 15W Wireless Charging with 25W Standby Note: All modes have been tested. The report only reflects the worst case of full load test data. Page 4 of 6 Report No. ESTE-R2609014 2. Maximum Permissible Exposure 2.1. Limit Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm2) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *100 6 3.0-30 1842/f 4.89/f *900/f 2 6 30-300 61.4 0.163 1.0 6 300-1,500 f/300 6 1,500-100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 f/1500 30 1,500-100,000 1.0 30 Note:f = frequency in MHz * = Plane-wave equivalent power density. 2.2. Test Setup Page 5 of 6 Report No. ESTE-R2609014 2.3. Test Procedure a. The test was performed on 360 degree turn table in anechoic chamber. b. The probe was placed at 20 cm surrounding, for test setup. c. The highest emission level was recorded and compared with limit as soon as measurement of each point; A, B, C, D, E were completed. 2.4. Test Result for Test setup : E-field strength Frequency Range 110.5~205kHz 360kHz Test Mode Standby 5W 7.5W 10W 15W 25W Position A(V/m) 0.326 1.241 1.132 1.388 2.116 2.059 Position B(V/m) 0.364 1.515 1.103 1.229 2.863 2.594 Position C(V/m) 0.359 1.064 1.009 1.167 2.887 2.418 Position D(V/m) 0.372 1.352 1.168 1.238 2.774 2.591 Position E(V/m) 0.385 2.726 2.957 2.034 3.712 3.984 Limits (V/m) 614 H-field strength Frequency Range 110.5~205kHz 360kHz Test Mode Standby 5W 7.5W 10W 15W 25W Position A(A/m) 0.038 0.069 0.066 0.068 0.079 0.072 Position B(A/m) 0.042 0.070 0.063 0.062 0.075 0.069 Position C(A/m) 0.039 0.061 0.067 0.069 0.072 0.073 Position D(A/m) 0.041 0.070 0.060 0.068 0.071 0.074 Position E(A/m) 0.045 0.086 0.089 0.085 0.094 0.098 Limits (A/m) 1.630 Page 6 of 6 Report No. ESTE-R2609014 3. Test photo Position E End of Test Report

东莞市汉文电子科技电子有限公司 Han Wen TECHNOLOGY LTD 地址 : 东莞市石碣镇石单南路128号 TEL: 0769-81804939 FAX: 0769-81381716 样品规格承认书 SAMPLE SPECIFICATION FOR APPROVAL 客户名称 /Customer 东莞市海能电子有限公司 客户编号 /Part Name H281410000507 编号 /Part Name A-2020-019 规格 /Part No. 42.5xT0.8x20.5x39.5x8.4uHx0.08x80Px11TS-L8mm 版本 /Rev. A0 制定日期 /Date 2025-12-25 客户承认签章 / Customer Approved And Signature 本厂确认 / Han wen Approved 郭汉平 1. 送样的原因 / Sample Submission Reason ̈ 1.新规格/New SPEC ̈ 2.New Material/追加材料 ̈ 3.ECR/变更 ̈ 4.改善包装。 2. 变更的规格说明 / Request For New SPEC. 原规格 / Current 希望变更规格 / Request 变更理由 / Reason 备注 /Remark: 1. 本产品符合环境关联物质的管理规定要求 . Above product comply to li yin Environmental material system requirement. 2. 如未回传，则以贵司下订单为样品通过 ! In Event Of No Sign Back,We Will Under Take P.O. As Acceptance To Sample Approval! Form No.:HWQSPE002 Rev:01 产品规格 Product Specification 客 户 A-2020 客户编号 H281410000507 日期 2025-12-25 文件编号 HW-1225001 产品编号 A-2020-019 产品规格 42.5xT0.8x20.5x39.5x8.4uHx0.08x80P x11TS-L8mm 版本 A0 页码 1/2 1. 外观 & 尺寸 (Unit: mm)： 图纸产品正面产品反面 A 小磁片外径 B 线圈内径 C 线圈外径 D 磁片外径 E 总厚度 F 引线长度 G NTC 出线长度 H 引线 (NTC) 焊锡长度 19.5±0.5 20.5±0.5 39.5±1.0 42.5±0.5 2.1MAX 8±1.010±1.03±1.0 量出线位置 不含离型纸 2. 电气特性: No.ParameterSpecification（加磁片）Test Instrument 1Ls8.4uH ±10%100KHZ/1V(uH) 3.材料表： 材料名称规格厂商 线材0.08*80P 热风绞线ZY 锡高温无铅锡YX 硬磁 42.5(±0.5)*5.3±0.3*0.8±0.1mm（开L字槽双槽和中 孔）背附φ41±0.5*0.1±0.02mm （普通双面胶无孔带 手撕位） LX/KL/HKQ 小磁片19.5±0.5*0.75±0.05mm(侧U槽)LX/KL/HKQ 双面胶φ18±0.5*0.1±0.02mm(普通双面胶无槽带手撕位)XR/WY NTC 10K3435K±1%(小头）黑头直径小于1.05mm，L=26mm 上 锡3±1mm YTD 胶水白胶MY 备注： 确认栏/Approval 制作审核核准 客户确认 林诗艳何正宾郭汉平

Page 1 of 44 Report No. ESTE-R2609013 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of CE LINK LIMITED Two-in-one Travel Charger Model Number: PD35U-1TGA-MPP25 FCC ID: A4X-PD35UMPP25 Applicant: CE LINK LIMITED Address: 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2609013 Date of Test: Jul. 06, 2026 to Aug. 28, 2026 Date of Report: Sep. 03, 2026 Page 2 of 44 Report No. ESTE-R2609013 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION .......................................................................................................... 3 1. GENERAL INFORMATION ................................................................................................................ 4 1.1. Description of Device (EUT) ......................................................................................................... 4 2. SUMMARY OF TEST ........................................................................................................................ 5 2.1. Summary of test result .................................................................................................................. 5 2.2. Test Facilities .................................................................................................................................. 6 2.3. Measurement uncertainty ............................................................................................................. 7 2.4. Assistant equipment used for test ............................................................................................... 7 2.5. Block Diagram ................................................................................................................................ 7 2.6. Test Mode ....................................................................................................................................... 8 2.7. Test Equipment List ....................................................................................................................... 9 3. RADIATED EMISSION ................................................................................................................... 10 3.1. Limit ................................................................................................................................................ 10 3.2. Test Setup ..................................................................................................................................... 11 3.3. Spectrum Analyzer Setting ......................................................................................................... 11 3.4. Test Procedure ............................................................................................................................. 12 3.5. Test Result .................................................................................................................................... 13 4. 20DB OCCUPIED BANDWIDTH .................................................................................................... 25 4.1. Limit ................................................................................................................................................ 25 4.2. Test Setup ..................................................................................................................................... 25 4.3. Spectrum Analyzer Setting ......................................................................................................... 25 4.4. Test Procedure ............................................................................................................................. 25 4.5. Test Condition .............................................................................................................................. 25 4.6. Test Result .................................................................................................................................... 26 5. AC POWER LINE CONDUCTED EMISSIONS ................................................................................. 29 5.1. Limit ................................................................................................................................................ 29 5.2. Test Setup ..................................................................................................................................... 29 5.3. Spectrum Analyzer Setting ......................................................................................................... 29 5.4. Test Procedure ............................................................................................................................. 29 5.5. Test Result .................................................................................................................................... 30 6. ANTENNA REQUIREMENTS .......................................................................................................... 34 6.1. Limit ................................................................................................................................................ 34 6.2. Test Result .................................................................................................................................... 34 7. TEST SETUP PHOTO .............................................................................................................. 35 8. EUT PHOTO .............................................................................................................................. 37 Page 4 of 44 Report No. ESTE-R2609013 1. GENERAL INFORMATION 1.1. Description of Device (EUT) Product Name : Two-in-one Travel Charger Model Number : PD35U-1TGA-MPP25 Software Version : N/A Hardware Version : N/A Operation Frequency : 5W/7.5W/10W: 110.5kHz-205kHz 15W/25W: 360kHz …

Text truncated - open the document above for the full version.

Conducted Test Radiated Test (9kHz-30 MHz) Radiated Test (30MHz-1GHz) Exposure Test Position E
