A4X-PODIUMAPODIUM 3-IN-1 WIRELESS CHARGER

Charging Instructions: 1. Connect USB-C Cable to Wireless charger and Wall Adapter. 2. Plug Wall Adapter into wall outlet. 3. Adjust hinges to desired position and start charging. Note: Always connect to power using a Nimble USB-C Wall Charger, for the safest, most eicient charging experience. Other Wall Chargers will work but the output should be at least 35W. Instructions de Chargement: 1. Connectez le câble USB-C au chargeur sans fil et à l'adaptateur mural. 2. Branchez l'adaptateur mural dans une prise de courant. 3. Ajustez les charnières à la position souhaitée et commencez à charger. Remarque : Connectez toujours à l'alimentation en utilisant un chargeur mural USB-C Nimble pour une expérience de charge la plus sûre et la plus eicace. D'autres chargeurs muraux fonctionneront, mais la puissance de sortie devrait être d'au moins 35W. Charging Apple Watch: Charge laying flat or lift hinge to charge in Nightstand Mode. Chargement de l'Apple Watch: Chargez-la à plat ou soulevez la charnière pour charger en mode Table de nuit. Charging iPhone: Charge laying flat or lift hinge to use as a stand or charge in Nightstand Mode. Chargement de l'iPhone: Chargez-le à plat ou soulevez la charnière pour l'utiliser comme support ou pour charger en mode Table de nuit. Charge 3 devices at the same time. Chargez 3 appareils en même temps. gonimble.com/FAQs gonimble.com/pages/global-compliance EN IMPORTANT SAFETY INSTRUCTIONS Warning: Read all instructions and warnings prior to using this product. Improper use of this product may result in product damage, excess heat, toxic fumes, fire or explosion, for which damages you ("Purchaser"), and not Nimble for Good, PBC. ("Manufacturer") are responsible. • Do not store device in high-temperature environment, including heat caused by intense sunlight or other forms of heat. Do not place device in fire or other excessively hot environments. Exposure to fire or temperature above 212°F (100°C) may cause explosion. • Do not expose the wireless charger to rain or snow. • Do not use the wireless charger in excess of its output rating. Overloading outputs above rating may result in a risk of fire or injury to persons. • Do not disassemble this product or attempt to re-purpose or modify it in any manner. • Do not attempt to replace any part of this device. • Use of a power supply or charger not recommended by Nimble may result in a risk of fire or injury to persons. • If this device is accessible to, or may be used by a minor, purchasing adult agrees to be solely responsible for providing supervision, instruction, and warnings. Purchaser agrees to defend, indemnify, and hold Manufacturer harmless for any claims or damages arising from unintended use or misuse by a minor. • All products have gone through a thorough quality assurance inspection. If you find that your device is excessively hot, is emitting odor, is deformed, abraded, cut, or is experiencing or demonstrating an abnormal phenomenon, immediately stop all product use and contact Manufacturer. • Switch off the wireless charger when not in use. The wireless charger will automatically switch off when disconnected from its wall charger. • To disconnect the charging pad from line voltage, pull the AC adapter from the AC outlet. • The AC outlet shall be installed near the charging pad and shall be easily accessible. • To comply with FCC RF exposure compliance requirements, the wireless charger must be used with a separation distance of at least 20 cm from all persons. •To comply with IC RF exposure compliance requirements, the wireless charger must be used with a separation distance of at least 10 cm from all persons. SAVE THESE INSTRUCTIONS Legal: Manufacturer shall not in any way be liable to you or to any third party for any damages you or any third party may suffer as a result of use, intended or unintended, or misuse of this product in conjunction with any device or accessory other than the appropriate device for which this product is designed. Manufacturer will not be responsible for any damages you or any third party may suffer as a result of misuse of this product as outlined above. Purchaser agrees to defend, indemnify, and hold Manufacturer harmless for any claims or damages arising from unintended use or misuse, including use with an unintended device. This device complies with part 15 of the FCC Rules and RSS-Gen of IC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. CAUTION: To comply with the limits of the Class B digital device, pursuant to Part 15 of the FCC Rules, this device must be used with certified peripherals and shielded cables. All peripherals must be shielded and grounded. Operation with non-certified peripherals or non-shielded cables may result in…

Text truncated - open the document above for the full version.

CE LINK LIMITED Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date:09-20-2024 FCC ID: A4X-PODIUMA Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing CE LINK LIMITED certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing CE LINK LIMITED certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates)as an entity producing “covered” equipment. Applicant: CE LINK LIMITED Address: 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China Contact Person: Changhong Chen Tel.: (86) 755-27247356 Email: [email protected] Sincerely, Signature:

CE LINK LIMITED * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 9/20/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: A4X-PODIUMA Applicant of FRN: 0021335963 Per section 2.911(d)(7) of the FCC rules, CE LINK LIMITED certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: NIMBLE FOR GOOD, PBC. FCC Registration Number (FRN): 0030768691 Physical U.S. Company Address: 3195 RED HILLAVE., LOFT F, 2ND FLOOR, COSTA MESA, CA 92626 COSTA MESA,CA 92626 United States Contact Person: Julie Kao Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Signed: Printed name: Changhong Chen Printed name: Julie Kao Title: Engineer Title: Product manager Company Name: CE LINK LIMITED Company Name: NIMBLE FOR GOOD, PBC. Date: 9/20/2024 Date: 9/20/2024

manufacturer：Dongguan FANYA Electronics Co., LTD address：No.194, East Technology Road, Liu Wu, Shijie Town, Dongguan City model：FY4022024080901

manufacturer：DONGGUAN KIMCHEN INDUSTRY INTL LIMITED address：No. 2 Xisha Road, Shijie Town, Dongguan City, Guangdong, China model：20.5*39.5*0.08*80P*11TS*7MM

Manufacture/factory:apple inc Address: One Apple Park Way, Cupertino, California, United States Diameter:28.79mm Thickness:6.23mm

CE LINK LIMITED Date：2024.9.20 Product Model Number: NB-WP-3N1TRY FCC ID：A4X-PODIUMA To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following:  Testing  Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Changhong Chen Contact Listed on FCC Wesbite Title: Engineer Email: [email protected] Telephone: (86) 755-27247356 On behalf of: CE LINK LIMITED

CE LINK LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 23, 2024 Subject; Request for Confidentiality FCC ID: A4X-PODIUMA To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Changhong Chen Title:Engineer

CE LINK LIMITED Covered Equipment Certification Attestation Letter Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: A4X-PODIUMA CE LINK LIMITED is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Signed: Printed name: Changhong Chen Title: Engineer Company Name: CE LINK LIMITED Date: 9/20/2024

External Photos M/N: NB-WP-3N1TRY External Photos M/N: NB-WP-3N1TRY External Photos M/N: NB-WP-3N1TRY External Photos M/N: NB-WP-3N1TRY External Photos M/N: NB-WP-3N1TRY External Photos M/N: NB-WP-3N1TRY

6.25 mm 28.2 mm Bottom Pad PANTONE Cool Gray 5 C Liquid Silicone Body Top Glacier (Pantone 651C) Body Top Lavender (Pantone 270C) Body White Recycled Plastic with Soft Touch Finish Qi2 Hinge & Housing Aluminum with Satin Chrome Finish Qi2 Pad / Cover White Liquid Silicone USBC Port Black Nimble - Podium 3-in-1 Wireless Charger - Apple - Glacier/Lavender CMF Artwork Spec R.2 7/31/24 Wireless Charger Glacier / Lavender Iridescent Product Dimensions: 229.38mm W x 85.38mm H x 20.7mm DMaterial / Color:Body Top - Glacier (Pantone 651C) & Lavender (Pantone 270C), Gloss Finish Body Bottom - White Recycled Plastic with Soft Touch Finish Qi2 Pad / Cover - White Liquid Silicone Qi2 Hinged & Housing - Aluminum with Satin Chrome FinishApple Watch Hinge & Housing - Aluminum with Satin Chrome FinishBottom Pad - PANTONE Cool Gray 5 C Liquid Silicone USBC Port - Black Nimble Logo Logo Dimensions: 28.2mm W x 6.25mm H Pad Printed: Chrome Finish Logo Dimensions: 44.69mm W x 10mm H Debossed: Depth 0.5mm Gloss Finish Inside Cert Pad Print Print Area: TBD Position: Bottom Silicone Pad Color: PANTONE Cool Gray 6 C Font: TBD 229.38 mm 85.38 mm 20.7 mm 11.25 mm 5.5 mm Cert Pad Printing PANTONE Cool Gray 6 C Watch Hinge & Housing Aluminum with Satin Chrome Finish Qi2 Hinge & HousingAluminum with Satin Chrome Finish Watch Hinge & HousingAluminum with Satin Chrome Finish Qi2 Pad / Cover White Liquid Silicone Debossing 0.5mm Depth, Gloss Finish Inside 10 mm 44.69 mm 10 mm 44.69 mm Nimble Logo Chrome Finish 62.5*16.3mm 3mm 72.75mm Complies with IMDA Standards DA108197 FCC ID: A4X-PODIUMA Nimble for Good, PBC gonimble.com ©2024   M/N: NB-WP-3N1TRY SN: XXXXXXX X00001 Designed in California. Made in Vietnam. Input: 5V 3A, 9V 3A, 12V 3A; Output: Qi2 15W, Airpods 5W, iWatch 3.5W Podium 3-in-1 Wireless Charger ANATEL:XXXXXXX CMS Distribution LTD C/O AvestaAvesta 2-4 Rue Benjamin Franklin 94370, SUCY EN BRIE, France 䐘俠ҭ朅֘ 垹ֺ 忼ҵ忼ӟ ૞ԧ娸ଭ R-R-XXXX XXXXX XXXXXX R-NZ IC: 26077-PODIUMA Complies with IMDA Standards DA108197 FCC ID: A4X-PODIUMA Nimble for Good, PBC gonimble.com ©2024   M/N: NB-WP-3N1TRY SN: XXXXXXX X00001 Designed in California. Made in Vietnam. Input: 5V 3A, 9V 3A, 12V 3A; Output: Qi2 15W, Airpods 5W, iWatch 3.5W Podium 3-in-1 Wireless Charger ANATEL:XXXXXXX CMS Distribution LTD C/O AvestaAvesta 2-4 Rue Benjamin Franklin 94370, SUCY EN BRIE, France 䐘俠ҭ朅֘ 垹ֺ 忼ҵ忼ӟ ૞ԧ娸ଭ R-R-XXXX XXXXX XXXXXX R-NZ IC: 26077-PODIUMA

Internal Photos M/N: NB-WP-3N1TRY Internal Photos M/N: NB-WP-3N1TRY Coil-Airpods Internal Photos M/N: NB-WP-3N1TRY Internal Photos M/N: NB-WP-3N1TRY Internal Photos M/N: NB-WP-3N1TRY Internal Photos M/N: NB-WP-3N1TRY Coil-Phone Coil-Watch

Page 1 of 6 Report No. ESTE-R2409197 FCC 47 CFR MPE REPORT CE LINK LIMITED Podium 3-in-1 Wireless Charger Model Number: NB-WP-3N1TRY FCC ID: A4X-PODIUMA Applicant: CE LINK LIMITED Address: 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2409197 Date of Test: Aug. 23, 2024~ Sep. 18, 2024 Date of Report: Sep. 19, 2024 Page 3 of 6 Report No. ESTE-R2409197 1. Summary of test 1.1. Summary of test result No. Description of Test Item FCC Standard Section Results 1 Maximum Permissible Exposure Part 1.1307(b)&1.1310 PASS 1.2. Test Mode 1.3. Test Equipment List Equipment Manufacturer Model No. Serial No. Last Cal. Next Cal. Electric and Magnetic Field Probe-Analyzer Narda S.T.S./PMM EHP-200A EST-E106 June 13,24 1 Year Test Software Narda EHP200-TS Rel 1.92 N/A N/A Note: Test uncertainty: ±1.62 dB (H-field);±1.64 dB (E-field) at a level of confidence of 95%. 1.4. Assistant equipment used for test Item Equipment Brand Model Name/Type No. FCC ID Series No. 1 Adapter - HKAP3891B-36US - - 2 Wireless load - YBZ MPP - - 3 iWatch - A1889 - - 4 Wireless load - YBZ BPP - - Item Shielded Type Ferrite Core Length Model Name/Type No. Note 1 NO NO 1.5m - DC Cable Test Item Test Mode Maximum Permissible Exposure Phone: 15W+Airpods 5W+iWatch 3.5W Full load Half load No load Phone: 15W Full load Half load Airpods 5W Full load Half load iWatch 3.5W Full load Half load Note: All modes have been tested. The report only reflects the worst case of 15W+5W+3.5W full load test data. Page 4 of 6 Report No. ESTE-R2409197 2. Maximum Permissible Exposure 2.1. Limit Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm2) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *100 6 3.0-30 1842/f 4.89/f *900/f 2 6 30-300 61.4 0.163 1.0 6 300-1,500 f/300 6 1,500-100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 f/1500 30 1,500-100,000 1.0 30 Note:f = frequency in MHz * = Plane-wave equivalent power density. 2.2. Test Setup Page 5 of 6 Report No. ESTE-R2409197 2.3. Test Procedure a. The test was performed on 360 degree turn table in anechoic chamber. b. The probe was placed at 20 cm surrounding, for test setup. c. The highest emission level was recorded and compared with limit as soon as measurement of each point; A, B, C, D, E were completed. 2.4. Equipment Approval Considerations Inductive wireless power transfer applications with supporting field strength results and meeting all of the following requirements are not required to submit a KDB inquiry for devices approved using SDoC or a PAG for equipment approved using certification to address RF exposure compliance. 1 Power transfer frequency is less than 4 MHz YES; the device operated in the frequency range from 110.5-205KHz; 326.5KHz; 360KHz. 2 Output power from each primary coil is less than or equal to 15 watts YES; the maximum output power of the primary coil is 15W. 3 The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. YES; The EUT has three source primary coils 4 Client device is placed directly in contact with the transmitter. YES; Client device is placed directly in contact with the transmitter. 5 Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). YES; Mobile exposure conditions only. 6 The aggregate H-field strengths anywhere at or beyond 20 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. YES; The EUT field strength levels are 50% x MPE limts. Page 6 of 6 Report No. ESTE-R2409197 2.5. Test Result for Test setup : E-field strength Test Direction Measuring Distance Test Frequency 110.5-205KHz 326.5KHz 360KHz Position A(V/m) 20cm 0.950 0.320 0.374 Position B(V/m) 20cm 1.193 0.336 0.465 Position C(V/m) 20cm 0.934 0.315 0.529 Position D(V/m) 20cm 0.507 0.354 0.513 Position E(V/m) 20cm 0.849 0.345 1.706 Limits (V/m) 614 H-field strength Test Direction Measuring Distance Test Frequency 110.5-205KHz 326.5KHz 360KHz Position A(A/m) 20cm 0.089 0.044 0.048 Position B(A/m) 20cm 0.086 0.048 0.045 Position C(A/m) 20cm 0.094 0.041 0.046 Position D(A/m) 20cm 0.056 0.046 0.043 Position E(A/m) 20cm 0.081 0.047 0.048 Limits (A/m) 1.630 3. Test photo Position E End of Test Report

Page 1 of 40 Report No. ESTE-R2409196 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of CE LINK LIMITED Podium 3-in-1 Wireless Charger Model Number: NB-WP-3N1TRY FCC ID: A4X-PODIUMA Applicant: CE LINK LIMITED Address: 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2409196 Date of Test: Aug. 23, 2024~ Sep. 18, 2024 Date of Report: Sep. 19, 2024 Page 2 of 40 Report No. ESTE-R2409196 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION .......................................................................................................... 3 1. GENERAL INFORMATION ................................................................................................................ 4 1.1. Description of Device (EUT) ......................................................................................................... 4 2. SUMMARY OF TEST ........................................................................................................................ 5 2.1. Summary of test result .................................................................................................................. 5 2.2. Test Facilities .................................................................................................................................. 6 2.3. Measurement uncertainty ............................................................................................................. 7 2.4. Assistant equipment used for test ............................................................................................... 7 2.5. Block Diagram ................................................................................................................................ 7 2.6. The test mode was selected for the final test as listed below. ................................................ 8 2.7. Test Equipment List ....................................................................................................................... 9 3. RADIATED EMISSION ................................................................................................................... 10 3.1. Limit ................................................................................................................................................ 10 3.2. Test Setup ..................................................................................................................................... 11 3.3. Spectrum Analyzer Setting ......................................................................................................... 11 3.4. Test Procedure ............................................................................................................................. 12 3.5. Test Result .................................................................................................................................... 13 4. AC POWER LINE CONDUCTED EMISSIONS ................................................................................. 23 4.1. Limit ................................................................................................................................................ 23 4.2. Test Setup ..................................................................................................................................... 23 4.3. Spectrum Analyzer Setting ......................................................................................................... 23 4.4. Test Procedure ............................................................................................................................. 23 4.5. Test Result .................................................................................................................................... 24 5. ANTENNA REQUIREMENTS .......................................................................................................... 26 5.1. Limit ................................................................................................................................................ 26 5.2. Test Result .................................................................................................................................... 26 6. TEST SETUP PHOTO .............................................................................................................. 27 7. EUT PHOTO .............................................................................................................................. 29 Page 4 of 40 Report No. ESTE-R2409196 1. GENERAL INFORMATION 1.1. Description of Device (EUT) Note: For a more detailed features description, please refer to the manufacturer’s specifications or the user's manual. Product Name : Podium 3-in-1 Wireless Charger Model Number : NB-WP-3N1TRY Operation Frequency : Phone: 110.5-205kHz;360kHz Airpods: 110.5-205 kHz iWatch: 326.5 kHz Max Wireless Charge Power : Phone: 15W Max Airpods: 5W Max iWatch: 3.5W Max Max Field Strength of Fundamental : 72.04dBμV/m Modulation Type : ASK Antenna Type : Induction coil Sample Type : Prototype production Page 5 of 40 Report No. ESTE-R2409196 2. SUMMARY OF TEST 2.1. Summary of test result No. Description of Test Item FCC Standard Section Results 1 Radiated Emission 15.205 15.209 PASS 2 AC Power Line Conducted Emissions 15.207 PASS 3 Antenna Requirement 15.203 PASS Note:“N/A” denotes test is not applicable in this test report. Page 6 of 40 Report No. ESTE-R2409196 2.2. Test Facilities EMC Lab : Accredited by CNAS, CHINA Registration No.: L5288 This Accreditation is valid until: November 12, 2029 Recognized by FCC, USA Designation Number: CN1215 This Recognition is valid until: January 31, 2026 Accredited by A2LA, USA Registration No.: 4366.01 This Accreditation is valid until: January 31, 2026 Recognized by Industry Canada CAB identifier No.: CN0035 This R…

Text truncated - open the document above for the full version.

M/N: NB-WP-3N1TRY Conducted Emissions Test Radiated Test (Below 30MHz) Radiated Test (Above 30MHz)
