A4X-WPC15-1TCNAWireless Charging Pad

Wireless Charging Pad WPC15-1TCNA User Manual CONETNES 1.0 INTRODUCTION ............................................................... 1 2.0 Features .............................................................................. 1 3.0 Specifications .................................................................... 1 4.0 Package contents ............................................................ 1 5.0 OPERATION........................................................................ 2 Apple watch Charger 1 Wireless Charging Pad DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or using this product. Please keep this manual for future reference. 1.0 INTRODUCTION This product is a high-performance Wireless Charging Pad. This product is suitable for mobile phones and airpods. Connect the wireless to a power charger, and then you can charge your device supported wireless charging by put it on the charger directly. 2.0 FEATURES  Transmitting terminal input: 5V/9V/12V/1.5A  Transmitting terminal output: 5W/7.5W/10W/15W  Intelligent indicator to show working condition  Compliant with QI, CE, FCC standards  It is light, smart and convenient to use 3.0 SPECIFICATIONS Input 5V/9V/12V/1.5A Output 5W/7.5W/10W/15W Operation Temperature Range 0~40°C Storage Temperature Range -20 ~ 70°C Operation Humidity 10% ~ 80% RH Storage Humidity 5% ~ 95% RH Size D102mm*H10.5MM Weight 80g±3g 4.0 PACKAGE CONTENTS Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton:  Main unit×1  User Manual×1 Apple watch Charger 2  Adapter×1 5.0 OPERATION Operation Procedures 1. Connect charger to the power adapter. 2. Place your device on the charger, and the light will flash one time, and then the blue light will be on during standby. 3. Please take out the device after it is fully charged. Note: green light for flashing when malfunction occurs. Operation Notes 1. For optimum performance, please use charger according to this user manual. 2. Please connect the Wireless Charging Pad to a power adapter which output 12V/2.5A, 3. Please unplug the charger after using. 4. Do not use the charger with an electronic product which is not in conformity with the specifications, so as to avoid any problem caused by specification mismatching. 5. It’s normal that charger will be a little overheated in the use process. 6. When the charger stops working under some accidents, you need to check whether the device is compatible with this charger. 7. Do not let the Wireless Charging Pad close to fire, such as stove, candles and etc. 8. Do not let the Wireless Charging Pad soak into liquid, such as swimming pool, bathtub, etc. 9. Do not wash the Wireless Charging Pad with corrosive cleaner. 10. If the wireless charger cannot work properly, please contact the store or distributor in your area. FCC Warning This device complies with Part 18 of the FCC Rules. Refer to FCC Part 18.213(c) and KDB 784748 Anner A section A.5: Max. Electric Field Emissions: 3.3455V/m Max. Magnetic Field Emissions: 0.8003 A/m (b) The maintenance of the system is the responsibility of the manufacturer. (c) To prevent interference, the product should be as far away from devices operating at the same frequency as possible. Apple watch Charger 3 RF exposure considerations This equipment complies with the FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body. This equipment meets the exemption from the routine evaluation limits in section 2.5 of RSS-102. It should be installed and operated with a minimum distance of 20cm between the radiator and any part of your body. Cet équipement est conforme à l'exemption des limites d'évaluation habituelle de la section 2.5 de la norme RSS-102. Il doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et toute partie de votre corps. Caution: Use the Product in the environment with the temperature Between 0°C and 50°C; Otherwise, it may damage your product. Products can only be used below 2000m altitude For the following equipment: Product Name: Wireless Charging Pad Brand Name: CE-LINK, amazonbasics Model No.: WPC15-1TCNA Dongguan CE LINK LIMITED E-mail: [email protected] hereby declares that this [Name: Wireless Charging Pad, Model: WPC15-1TCNA] is in compliance with Radio Equipment Regulations 2017 (SI 2017 No. 1206, as amended by SI 2019 No. 696). Adapter shall be installed near the equipment and shall be easily accessible. This product is intended for sale and application in a business environment. The RF distance between body and product is 20cm Frequency Range: 105-205kHz (UK) RF Output Power: 36.82dBuA/m(@3m) (UK) Apple watch Charger 4 IC WARNING This device contains licence-exempt transmitter(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. P/N

CE LINK LIMITED 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China --------------------------------------------------------------------------------------------------------------------- Date: 2022-08-01 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: A4X-WPC15-1TCNA Confidentiality Request To whom it may concern, Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of the information accompanying this application as outlined below: ☒ Block Diagram ☐ Tune-Up Information ☒ Operational Description ☐ Security Information ☒ Schematics ☐ Software Defined Radio (SDR) Information ☒ Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, CE LINK LIMITED ------------------------------- (Changhong Chen) (Engineer)

CE LINK LIMITED 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China -------------------------------------------------------------------------------- (FCC ID：A4X-WPC15-1TCNA) POWER OF ATTORNEY DATE: 2022-08-01 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group (Shenzhen) Co., Ltd. Jandy So on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, CE LINK LIMITED are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, CE LINK LIMITED ------------------------------- (Changhong Chen) (Engineer)

Reference No.: WTX22X06133153W Page 2 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX22X06133153W Page 3 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX22X06133153W Page 4 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTX22X06133153W Page 5 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7

Reference No.: WTX22X06133153W Page 1 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTX22X06133153W Page 6 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTX22X06133153W Page 7 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Antenna View

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 14 TEST REPORT Reference No. .................... : WTX22X06133153W002 FCC ID ................................ : A4X-WPC15-1TCNA Applicant ........................... : CE LINK LIMITED Address ............................. : 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China. Manufacturer ..................... : Dongguan CE LINK LIMITED Address ............................. : 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China. Product Name ................... : Wireless Charging Pad Model No.. .......................... : WPC15-1TCNA Standards .......................... : KDB 680106 D01 V03 Date of Receipt sample .... : 2022-06-30 Date of Test........................ : 2022-06-30 to 2022-07-22 Date of Issue ..................... : 2022-07-22 Test Report Form No. ....... : WTX_KDB 680106 D01 V03W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Jack Huang Silin Chen Reference No.: WTX22X06133153W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 14 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 AUXILIARY EQUIPMENT LIST AND DETAILS ........................................................................................................... 5 1.3 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 6 2. RF EXPOSURE TEST REPORT ............................................................................................................................ 7 2.1 STANDARD APPLICABLE ......................................................................................................................................... 7 2.2 TEST CONDITIONS .................................................................................................................................................. 7 2.3 TEST PROCEDURE ................................................................................................................................................... 8 2.4 TEST RESULT.......................................................................................................................................................... 9 2.5 MEASUREMENT UNCERTAINTY ............................................................................................................................ 12 2.6 TEST PHOTOS ....................................................................................................................................................... 13 APPENDIX PHOTOGRAPHS ................................................................................................................................... 14 Reference No.: WTX22X06133153W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 3 of 14 Report version Version No. Date of issue Description Rev.00 2022-07-22 Original / / / Reference No.: WTX22X06133153W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 4 of 14 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Factory 1#: SuiChuan CE LINK LIMITED Address of factory: SuiChuan county industrial park east zone, Ji’an city Jiangxi province,China. Factory 2#: CE LINK VIET NAM COMPANY LIMITED. Address of factory Lot CNSG04&CNSG06 Van Trung Industrial Zone, Viet Yen district, Bac Giang Province, Vietnam General Description of EUT Product Name: Wireless Charging Pad Trade Name: CE-LINK, amazonbasics Model No.: WPC15-1TCNA Adding Model(s): B0872RLX6Z Note: The test data is gathered from a production sample, provided by the manufacturer. The appearance of others models listed in the report is different from main-test model WPC15-1TCNA, but the circuit and the electronic construction do not change, declared by the manufacturer. Technical Characteristics of EUT Frequency Range: 105~205KHz Modulation Type: ASK Antenna Type: Coil Antenna Antenna Gain: 0dBi Rated Voltage: Input: 5V, 9V, 12V Rated Current: Input: 2A, 2A, 1.5A Rated Power: Output: 5W, 10W, 15W Reference No.: WTX22X06133153W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 5 of 14 1.2 Auxiliary Equipment List and Details Auxiliary Equipment List and Details Description Manufacturer Model Serial Number Adapter Xiaomi MDY-11-EX / Smart phone Apple IPhone 12 Pro Max Special Cable List and Details Cable Description Length (M) Shielded/Unshielded With Core/Without Core USB-CC Cable 0.53 Unshielded Without Ferrite Reference No.: WTX22X06133153W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 6 of 14 1.3 Test Equipment List and Details Description Manufacturer Model Serial No. Cal Date Due Date ELECTRIC AND MAGNETIC FIELD ANALYZER Narda EHP-200AC 180ZX10226 2021-05-20 2024-05-19 Reference No.: WTX22X06133153W002 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 7 of 14 2. RF Exposure Test Report 2.1 Standard Applicable According to §1.1310 system operating under the provisions of this section shall be operating in a manner that t…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 30 TEST REPORT Reference No. .................... : WTX22X06133153W001 FCC ID ................................ : A4X-WPC15-1TCNA Applicant ........................... : CE LINK LIMITED Address ............................. : 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China. Manufacturer ..................... : Dongguan CE LINK LIMITED Address ............................. : 22 Dongkang Road, Dalingshan Town, Dongguan City, Guangdong Province, China. Product Name ................... : Wireless Charging Pad Model No... ......................... : WPC15-1TCNA Standards .......................... : FCC Part 18 Date of Receipt sample .... : 2022-06-30 Date of Test........................ : 2022-06-30 to 2022-07-22 Date of Issue ..................... : 2022-07-22 Test Report Form No. ....... : WTX_Part 18W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Jack Huang Silin Chen Reference No.: WTX22X06133153W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 30 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 TEST STANDARDS ................................................................................................................................................... 5 1.3 TEST METHODOLOGY ............................................................................................................................................. 5 1.4 TEST FACILITY ....................................................................................................................................................... 5 1.5 EUT SETUP AND OPERATION MODE ...................................................................................................................... 6 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................. 7 1.7 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 8 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 9 3. CONDUCTED EMISSIONS .................................................................................................................................. 10 3.1 STANDARD APPLICABLE ....................................................................................................................................... 10 3.2 TEST PROCEDURE ................................................................................................................................................. 10 3.3 BASIC TEST SETUP BLOCK DIAGRAM ................................................................................................................... 10 3.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 10 3.5 TEST RECEIVER SETUP ......................................................................................................................................... 11 3.6 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 11 4. RADIATED EMISSIONS ....................................................................................................................................... 18 4.1 TEST PROCEDURE ................................................................................................................................................. 18 4.2 TEST RECEIVER SETUP ......................................................................................................................................... 20 4.3 CORRECTED AMPLITUDE & MARGIN CALCULATION ............................................................................................ 20 4.4 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 20 4.5 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 20 APPENDIX PHOTOGRAPHS ................................................................................................................................... 30 Reference No.: WTX22X06133153W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 3 of 30 Report version Version No. Date of issue Description Rev.00 2022-07-22 Original / / / Reference No.: WTX22X06133153W001 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 4 of 30 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Factory 1#: SuiChuan CE LINK LIMITED Address of factory: SuiChuan county industrial park east zone, Ji’an city Jiangxi province,China. Factory 2#: CE LINK VIET NAM COMPANY LIMITED. Address of factory Lot CNSG04&CNSG06 Van Trung Industrial Zone, Viet Yen district,…

Text truncated - open the document above for the full version.

Reference No.: WTX22X06133153W Page 8 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission View (Below 30MHz) Reference No.: WTX22X06133153W Page 9 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission View (30MHz to 1GHz)
