A52-AP868Remote Control Device

1 ONETOUCH TRANSMITTER OPERATION MANUAL DOWN 1 st CHANNEL Press and holdand follow byto enter setting mode of remote. STEP A: ASSIGNING TRANSMITTER TO MOTOR  Insert motor power plug(240V AC), switch on  Key in 5-dig ID  Indicator on/off (Motor moves)  STEP B: Configure and Cancel SINGLE channel control (on a 6 CHANNEL transmitter)  Press and hold one of to select individual channel  After 5s, indicator slowly blink then release to confirm  (Cancel channel control)  Press and hold one of to select individual channel  After 12s, indicator fast blink then release to confirm STEP C: SETTING UPPER AND LOWER LIMITS (C1) Setting UPPER limit and shade reverse function  Press to set shade to desired position  (Reverse shade direction) Press and hold and follow by  (Micro adjustment) Press and hold and follow by  Press and hold and follow by to confirm upper limit (Motor moves to indicate confirmation) (C2) Setting LOWER limit and shade reverse function  Press to set shade to desired position  (Micro adjustment) Press and hold and follow by  Press and hold and follow by to confirm lower limit (Motor moves to indicate confirmation)  (Exit configuration mode) Press and holdand follow by (Motor moves down and up once) 4 th CHANNEL NEL CHANNEL 3 rd CHANNEL 6 th CHANNEL NEL CHANNEL 1 st SCENE NEL CHANNEL 2 nd SCENE NEL CHANNEL 5 th CHANNEL 2 nd CHANNEL INDICATOR STOP UP ALL 2 Other Configuration Options: ASSIGNING SPARE TRANSMITTERS(OPTIONAL FUNCTION) (B2) Configure MULTIPLE channel control (on a 6 CHANNEL transmitter)  Press and hold to select 1 st channel  After 5s, indicator slowly blink then release to confirm  Wait for LED to stop blinking  Press to select individual 2 nd ~ 6 th channel  After 5s, indicator slowly blink then release to confirm (B3) Configure GROUP channel control (on a 6 CHANNEL transmitter)  Make sure all of motor that is desired under setting mode  Press and hold orto select individual group  After 5s, indicator slowly blink then release to confirm (B4) Configure ALL channel control (on a 6 CHANNEL transmitter)  Make sure all of motor under setting mode  Press and holdto select all channel  After 5s, indicator slowly blink then release to confirm Continue with STEP C  Press and hold and follow byto enter sending mode (Master),indicator light on  Press and hold and follow byto enter receiving mode (Slave),indicator light on  Joint Master and Slave with USB cable(Master first)  Indicator light off ,Done 3 LOCK AND UNLOCK SCREEN FAQ Transmitter LEDs display red color Charge Motor response slow Charge Incorrect shade direction Enter into configuration mode for setting upper limit to correct shade direction CAUTION: Correction can only be made in setting upper limit mode  Press and hold and follow byfor 3s to lock screen  Press and hold and follow byfor 3s to unlock screen FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
