A8260060Remote Controller for Toy

C ONOFF AB 1 x 9V 6LR61 Battery (Not Included) NO. 60060 AGE 5+ 1797 Made in China ©2011 PLAYMIND LTD. Room 413-415, Houston Centre, 63 Mody Road, Tsim Sha Tsui East, Kowloon, Hong Kong 2011 Rev. 1.0 Email : [email protected] Visit us at : www.playmindltd.com 1. Alkaline battery is recommended. 2. Non-rechargeable batteries are not to be recharged. 3. Rechargeable batteries are to be removed from the toy before being charged. 4. Rechargeable batteries are only to be charged under adult supervision. 5. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. 6. Do not mix old and new batteries. 7. Only batteries of the same or equivalent types as reommended are to be used. 8. Batteries are to be inserted with the correct polarity. 9. The supply terminal are not to be short-circuited. 10. If batteries are loose, bend out the contacts for a tighter fit. 11. Exhausted batteries are to be removed from the toy and be disposed of immediately: never dispose of batteries in fire. 12. If storing product for long periods of time, make sure to remove batteries. 13. Check the product periodically for signs of damage to electrical parts; do not play with product until damage has been properly assessed. If the unit malfunctions, please remove the batteries for one minute and reinstall again. If the malfunctions persist, please replace with new batteries. BATTERIES SHOULD BE INSTALLED BY ADULTS ONLY. Battery Caution Content For BuggyFor Transmitter Battery Requirement 3 x AAA / LR03 Batteries (Not Included) 1 x 9 V / 6LR61 Battery (Not Included) Don’t Put In Trash. Recycle or Dispose as Hazardous Waste. Transmitter Antenna Buggy x 1 pc x 1 pc x 1 pc ................. ........... ...................... AGES 5+ A/B/C Band Switch ON/OFF Switch Band Switch Band Switch OPEN 3 x AAA / LR03 Batteries (Not Included) Make sure the Band Switch is selected at the same position (A, B or C) on the car and on the transmitter. (Pic.2) (Pic.4) (Pic.3) (Pic.1) C ONOFF AB C ONOFF AB Battery Installation- Transmitter 1. Make sure the power switch is on OFF position. 2. Open the battery door (Pic.4). 3. Put 1 x 9V battery in the battery compartment as per the polarities shown inside (Pic.4). 4. Close the battery door. Battery Installation- Buggy 1. Make sure the power switch is on OFF position (Pic.1) 2. Use a screwdriver to loosen the screw on the battery case anti-clockwise (Pic.2). 3. Open the battery door (Pic.2). 4. Put 3 x AAA batteries in the battery compartment as per the polarities shown inside (Pic.3). 5. Close the battery door and tighten the screw clockwise. RC RTR BUGGY 1:24 FULL FUNCTION RADIO CONTROL 6LR61 6LR61 OFF

External Photo Front View of the product Rear View of the product Battery compartment Battery Cover

Internal Photo Front View of the product (Internal) Rear View of the product (Internal) Inner Circuit Top View Inner Circuit Bottom View
