Page 4 of 19 KTL Dallas, INC.FCC PART 18, SUBPART C INDUSTRIAL, SCIENTIFIC, MEDICAL EQUIPMENT VERIFICATION PROJECT NO.: 9L00403EUS EQUIPMENT: HERA3b MW/Convection Oven Section 2.Equipment Under Test (E.U.T.) Manufacturer:TurboChef Technologies, Inc. Model No.:HERA3b MW/Convection Oven Serial No.:None Production UnitPre-Production Unit The E.U.T. was received October 20, 1999, in good condition. Description of E.U.T.: The E.U.T. (Equipment Under Test) is a counter top microwave oven used as a fast cook oven for consumer use. Clock, Oscillator, Highest Frequencies Utilized: 1. 100 kHz (Blower Controller Switching Power Supply) 2. 2145 MHz (Microwave Magnetron) 3. 4 MHz uP (Power Board) 4. 8 MHz uP (Blower Controller) 5. 20 MHz up (Display Board) Modifications Incorporated in E.U.T.: The EUT has not been modified from what is described by the brand name and unique type identification stated above. X

KTL Dallas, Inc. Safety - EMC - Telecom - ISO Guide 25 DUPLICATE ORIGINAL ENGINEERING TEST REPORT ON MODEL: HERA3b MW/CONVECTION OVEN IN ACCORDANCE WITH: FCC PART 18, SUBPART C INDUSTRIAL, SCIENTIFIC, MEDICAL EQUIPMENT VERIFICATION REPORT NO.: 9L0403EUS.DUP TEST FOR: TURBOCHEF TECHNOLOGIES, INC. 10500 METRIC DRIVE, SUITE 128 DALLAS, TEXAS 75243 TESTED BY: KTL DALLAS, INC. 802 N. KEALY LEWISVILLE, TEXAS 75057-3136 NVLAP LAB CODE: 100426-0 DECEMBER 1999 This document contains 19 pages including this one. KTL Dallas, Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Dallas, Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL Dallas, Inc.FCC PART 18, SUBPART C INDUSTRIAL, SCIENTIFIC, MEDICAL EQUIPMENT VERIFICATION PROJECT NO.: 9L00403EUS.DUP EQUIPMENT: HERA3b MW/Convection Oven Page 2 of 19 TABLE OF CONTENTS Section 1. Summary of Test Results General Abstract Section 2. Equipment Under Test (E.U.T.) Description of E.U.T. Modifications Incorporated in E.U.T. Justification Exercise Program Section 3. Equipment Configuration Equipment Configuration List Inter-connection Cables Configuration of the Equipment Under Test (E.U.T.) Block Diagram Section 4. Powerline Conducted Emissions Testing was not applicable. Section 5. Radiated Emissions Test Conditions Test Results Specification Limits Test Data-Radiated Emissions Radiated Emissions Photographs Operating Frequency Data Operating Frequency Photographs Test Data-Microwave Radiated Emissions Microwave Radiated Photographs Section 6. Sample Calculations Radiated Emissions Radiated Emissions Below 30 MHz Section 7. Block Diagrams Radiated Emissions Section 8. Test Equipment List KTL Dallas, Inc.FCC PART 18, SUBPART C INDUSTRIAL, SCIENTIFIC, MEDICAL EQUIPMENT VERIFICATION PROJECT NO.: 9L00403EUS.DUP EQUIPMENT: HERA3b MW/Convection Oven Page 3 of 19 Section 1.Summary of Test Results General: All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 18, Subpart C for Industrial, Scientific, Medical Equipment. These tests were conducted using measurement procedures of ANSI C63.4-1992. Abstract: Name Of TestPara. No.Results Conducted Emissions18.307N/A* Radiated Emissions18.305 (b)Complies *Conducted Emissions testing is not applicable to microwave ovens per the FCC. THIS REPORT APPLIES ONLY TO THE ITEM (S) TESTED AND DOES NOT CONSTITUTE ENDORSEMENT BY THE UNITED STATES OF AMERICA. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. NONE. NVLAP Lab Code: 100351-0 TESTED BY:Ricky HillDATE:11/20/99 Ricky Hill, EMC Technician APPROVED BY:DATE: Dale L. Reynolds, EMC Group Manager KTL Dallas, Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Dallas, Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested and does not constitute endorsement by the United States of America. KTL Dallas, Inc.FCC PART 18, SUBPART C INDUSTRIAL, SCIENTIFIC, MEDICAL EQUIPMENT VERIFICATION PROJECT NO.: 9L00403EUS.DUP EQUIPMENT: HERA3b MW/Convection Oven Page 4 of 19 Section 2.Equipment Under Test (E.U.T.) Manufacturer:TurboChef Technologies, Inc. Model No.:HERA3b MW/Convection Oven Serial No.:None Production UnitPre-Production Unit The E.U.T. was received on October 20, 1999, in good conduction. Description of E.U.T.: The E.U.T. (Equipment Under Test) is a counter top microwave oven used as a fast cook oven for consumer use. Clock, Oscillator, Highest Frequencies Utilized: 1. 100 kHz 2. 2145 Hz Microwave 3. 4 MHz uP (Power Board) 4. 8 MHz uP 5. 20 MHz uP (Control Bd) Modifications Incorporated in E.U.T.: The EUT has not been modified from what is described by the brand name and unique type identification stated above. KTL Dallas, Inc.FCC PART 18, SUBPART C INDUSTRIAL, SCIENTIFIC, MEDICAL EQUIPMENT VERIFICATION PROJECT NO.: 9L00403EUS.DUP EQUIPMENT: HERA3b MW/Convection Oven Page 5 of 19 Justification: The E.U.T. was configured for testing as per typical installation. Position and bundling of cables were investigated to establish maximum amplitude of emissions. The following combinations were investigated to establish worst case configuration: (1) Stand alone, AC line powered oven. Exercise Program: The E.U.T. exercise program used during radiated and conducted testing was designed to exercise the various system components in a manner similar to typical use. Exercise Mode: (1) Cook temp = 400°F, Convection air velocity = 60%, Microwave power = 100%. KTL Dallas, Inc.FCC PART 18, SUBPART C INDUSTRIAL, SCIENTIFIC, MEDICAL EQUIPMENT VERIFICATION PROJECT NO.: 9L00403EUS.DUP EQUIPMENT: HERA3b MW/Convection Oven Page 6 of 19 Section 3.Equipment Configuration Equipment Configuration List: ItemDescriptionManufacturerModel No. Serial No.Rev.FCC ID Status (A)*MW/Convection OvenTurboChef Tech., Inc.HERANone3bACVJJW * = E.U.T. (Equipment-Under-Test) or part of E.U.T. *FCC ID STATUS 1. FCC DOC2. FCC A/B Verification 3. None – (If performing FCC testing, contact lab manager) 4. Certification (include FCC ID in parenthesis) Inter-connection Cables: No cables used. Configuration of the Equipment Under Test (E.U.T.): A KTL Dallas, Inc.FCC PART 18, SUBPART C INDUSTRIAL, …
