Applicant: Sony Computer Entertainment Inc. Type of Equipment : Computer Entertainment System *WLAN part Model No. : CECH-4201x FCC ID: AK8DUTD1000 Sony Computer Entertainment Inc. declares that Model : CECH-4201x β complies with FCC radiation exposure requirement specified in the FCC Rule 2.1091 (for mobile). RF Exposure Calculations: β The following information provides the minimum separation distance for the highest gain antenna provided with the βCECH-4201xβ as calculated from FCC OET Bulletin 65 Appendix A, Table (B) Limits for General Population / Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0mW/cm^2 uncontrolled exposure limit. The Friis formula used was: S = (P * G) / (4* Ο * r 2 ) Where P = 147.91 mW (Maximum peak output power) G = 2.00 Numerical Antenna gain; equal to3.00 dBi r =20.0 c m For: CECH-4201xS =0.05871 mW/cm 2 No. : 10014382H RF Exposure / MPE Calculation
Test report No. : 10014382H-A-R1 Page : 1 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 13-EM-F0429 RADIO TEST REPORT Test Report No. : 10014382H-A-R1 Applicant : Sony Computer Entertainment Inc. Type of Equipment : Computer Entertainment System Model No. : CECH-4201x FCC ID : AK8CBEH19S1 Test regulation : FCC Part 15 Subpart C: 2013 *WLAN Part Test Result : Complied 1. This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc. 2. The results in this report apply only to the sample tested. 3. This sample tested is in compliance with the above regulation. 4. The test results in this report are traceable to the national or international standards. 5. This test report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. 6. This report is a revised version of 10014382H-A. 10014382H-A is replaced with this report. Date of test: June 11 to June 28, 2013 Representative test engineer: Takumi Shimada Engineer of WiSE Japan, UL Verification Service Approved by: Masanori Nishiyama Manager of WiSE Japan, UL Verification Service NVLAP LAB CODE: 200572-0 This laboratory is accredited by the NVLAP LAB CODE 200572-0, U.S.A. The tests reported herein have been performed in accordance with its terms of accreditation. *As for the range of Accreditation in NVLAP, you may refer to the WEB address, http://www.ul.com/japan/jpn/pages/services/emc/about/ma rk1/index.jsp#nvlap Test report No. : 10014382H-A-R1 Page : 2 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 REVISION HISTORY Original Test Report No.: 10014382H-A Revision Test report No. Date Page revised Contents - (Original) 10014382H-A July 18, 2013 - - 1 10014382H-A-R1 July 23, 2013 P. 4 Correction of Section 2.2: Product Description Test report No. : 10014382H-A-R1 Page : 3 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 CONTENTS PAGE SECTION 1: Customer information ......................................................................................................... 4 SECTION 2: Equipment under test (E.U.T.) ........................................................................................... 4 SECTION 3: Test specification, procedures & results ............................................................................ 6 SECTION 4: Operation of E.U.T. during testing .................................................................................... 9 SECTION 5: Conducted Emission .......................................................................................................... 11 SECTION 6: Radiated Spurious Emission ............................................................................................ 12 SECTION 7: Antenna Terminal Conducted Tests ................................................................................ 13 APPENDIX 1: Data of EMI test .............................................................................................................. 14 Conducted Emission ......................................................................................................................... 14 6dB Bandwidth ................................................................................................................................. 22 Maximum Peak Output Power .......................................................................................................... 24 Radiated Spurious Emission ............................................................................................................. 26 Conducted Spurious Emission .......................................................................................................... 39 Power Density ................................................................................................................................... 45 99%Occupied Bandwidth ................................................................................................................. 47 APPENDIX 2: Test instruments ............................................................................................................. 48 APPENDIX 3: Photographs of test setup ............................................................................................... 50 Conducted Emission ......................................................................................................................... 50 Radiated Spurious Emission ............................................................................................................. 51 Worst Case Position .......................................................................................................................... 52 Test Configuration and peripherals ................................................................................................... 53 Test report No. : 10014382H-A-R1 Page : 4 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 SECTION 1: Customer information Company Name Sony Computer Entertainment Inc. Brand Name SONY Address 1-7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan Telephone Number +81-3-6748-6333 Facsimile Number +81-3-6748-6383 Contact Person Kiyoto Sasaki SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type ofβ¦
Text truncated - open the document above for the full version.
Test report No. : 10014382H-A-R1 Page : 50 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 APPENDIX 3: Photographs of test setup Conducted Emission Photo 1 Photo 2 Test report No. : 10014382H-A-R1 Page : 51 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Radiated Spurious Emission Photo 1 Photo 2 Test report No. : 10014382H-A-R1 Page : 52 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Worst Case Position Antenna 0 (Horizontal: Y-axis/ Vertical:Y-axis) Antenna 1 (Horizontal: X-axis/ Vertical:Y-axis) X-axis Y-axis Test report No. : 10014382H-A-R1 Page : 53 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Test Configuration and peripherals AC120V/60Hz 1 1 E F AC120V/60Hz A C G D AC120V/60Hz 2 3 4 5 6 7 8 9 : Standard Ferrite Core B * Cabling and setup were taken into consideration and test data was taken under worse case conditions. Test report No. : 10014382H-A-R1 Page : 54 of 54 Issued date : July 18, 2013 Revised date : July 23, 2013 FCC ID : AK8CBEH19S1 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Description of EUT and Support equipment No. Item Model number Serial number Manufacturer Remarks A Computer Entertainment System CECH-4201x 4000009 for CE/RE* 4000010 for AT* Sony Computer Entertainment Inc. EUT B Wireless Controller CECHZC2U A No.9 Sony Computer Entertainment Inc. - C PlayStation Portable PSP-2000 03-27401801- 2221217-PSP2000 Sony Computer Entertainment Inc. - D Display VW26L HDTV20F LFMBBAI1333183 VIZIO - E Laptop PC 2371-AEJ KV-FYV57 05/02 IBM - F AC Adaptor 02K6810 11S02K6810Z1Z3BJ 58822N IBM - G Keyboard SCPH-10240 - Sony Computer Entertainment Inc. - *CE: Conducted Emission, RE: Radiated Spurious Emission, AT: Antenna terminal conducted test List of cables used No. Name Length (m) Cable Shielding Connector Shielding Remarks 1 LAN Cable 2.8 Unshielded Unshielded - 2 DC Cable 1.8 Shielded Shielded One ferrite core (standard attachment) 3 AC Cable 1.0 Unshielded Unshielded - 4 USB Cable 2.0 Shielded Shielded - 5 USB Cable 1.5 Shielded Shielded - 6 AC Cable 1.5 Unshielded Unshielded - 7 HDMI Cable 2.0 Shielded Shielded - 8 AV Multi Cable 1.5 Shielded Shielded One ferrite core (standard attachment) 9 AC Cable 1.7 Unshielded Unshielded - End of Report
4383-326 Asama-cho, Ise-shi Β· Mie-ken Β· Japan
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.41 GHz - 2.46 GHz | 148.00 mW |
