AK8CFIZAC1Wireless Controller

Specifications Design and specifications are subject to change without notice. Input power rating5 V 1,200 mA Battery typeBuilt-in lithium-ion battery Battery voltage3.7 V Battery capacity1,050 mAh External dimensions Approx. 141 × 39 × 191 mm (width x height × depth) WeightApprox. 322 g (11.4 oz) Operating temperature5 °C to 35 °C (41°F to 95°F) Included USB cable Company: SONY / Part No.: 1-018-350-**, 1-018-351-** * represents a number between 0 and 9. System and device software • The device software of this product is licensed to you under the terms of a separate end user license agreement. For details, visit playstation.com/legal/product-ssla/. • Always update the system software of your PlayStation®5 console and the device software of this product to the latest version. Limited warranty Sony Interactive Entertainment LLC (“SIE LLC”) warrants to the original purchaser that this product shall be free from defects in material and workmanship for a period of one (1) year from the date of purchase. This warranty does not apply to any consumables (such as batteries). For defects in material or workmanship within the warranty period, upon showing a proof of purchase, SIE LLC agrees for a period of one (1) year to either repair or replace this product with a new or factory recertified product at SIE LLC’s option. For the purpose of this Limited Warranty, “factory recertified” means a product that has been returned to its original specifications. Visit playstation.com/help/ or call 1-800-345-7669 to receive a return authorization and shipping instructions. As the original purchaser, you will be responsible for inbound shipping costs and any packaging materials required. SIE LLC will then return the repaired or replaced product at no cost to you including return shipping. This warranty shall not be applicable and shall be void if the defect in the SIE LLC product has arisen through abuse, unreasonable use, mistreatment, neglect, or means other than from a defect in materials or workmanship. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES AND NO OTHER REPRESENTATIONS OR CLAIMS OF ANY NATURE SHALL BE BINDING ON OR OBLIGATE SIE LLC. ANY IMPLIED WARRANTIES APPLICABLE TO THIS PRODUCT, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE ONE (1) YEAR PERIOD DESCRIBED ABOVE. IN NO EVENT WILL SIE LLC BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM POSSESSION, USE OR MALFUNCTION OF THE SIE LLC PRODUCT. SOME STATES OR PROVINCES DO NOT ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS AND SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATIONS OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSION MAY NOT APPLY TO YOU. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province. This warranty is valid only in the United States and Canada. EN Health and Safety Before using the product and/or accessories, carefully read this manual and any manuals for compatible hardware. Retain instructions for future reference. Parents, guardians of children, or caregivers should read this manual for safe use. Assistance may be needed to set up some parts of the product. The product and accessories have been designed with the highest concern for safety. However, any electrical device, if used improperly, has the potential for causing fire, electrical shock, or personal injury. Observe all warnings, precautions and instructions. WARNING RADIO WAVES Radio waves may affect electronic equipment or medical devices (for example, pacemakers), which may cause malfunctions and possible injuries. • If you use a pacemaker or other medical device, consult your doctor or the manufacturer of your medical device before using the wireless networking feature (Bluetooth® and wireless LAN). • Do not use the wireless networking feature in the following locations: –Areas where wireless network use is prohibited, such as in hospitals. Abide by medical institution regulations when using the console on their premises. –Areas near fire alarms, automatic doors and other types of automated equipment. MAGNETS AND DEVICES This product has magnets which may interfere with pacemakers, defibrillators and programmable shunt valves or other medical devices. Do not place this product close to such medical devices or persons who use such medical devices. Consult your doctor before using this product if you use such medical devices. LITHIUM-ION BATTERY Do not handle damaged or leaking lithium-ion batteries. If the material comes into contact with the skin, eyes, or clothes, immediately rinse the affected area with clean water and consult your doctor. The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not leave the battery charging for a prolonged period of time when the product is not in use. YOUNG CHILDREN INJURIES CHOKING HAZARD – Small parts. Keep the product and accessories out of the reach of young children. Young children may swallow small parts or may wrap the cable around themselves, which may inflict injury. NEVER DISASSEMBLE OR MODIFY THE PRODUCT OR ACCESSORIES unless you are authorized to do so in a SIE-published product document, support guide or similar tutorial. There is a risk of fire, electrical shock, or injury. Precautions Taking breaks • Avoid prolonged continuous use of this product. Generally we recommend that you take 15-minute breaks for every hour of play. • Avoid playing when you are tired or need sleep and stop playing immediately if you begin to feel tired. • If you experience any of the following health problems, discontinue use of the product immediately. If symptoms persist, consult a doctor. –Dizziness, nausea, fatigue or symptoms similar to motion sickness –Discomfort or pain in a part of the body, such as eyes, ears, hands, or arms Light bar Do not stare at the light bar on the product when it is blinking. Stop using t…

Text truncated - open the document above for the full version.

CFR 47 §2.911 (d)(5) Attestation Date: May 24, 2023 FCC ID: AK8CFIZAC1 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Sony Group Corporation (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sony Group Corporation (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Miho Nakamura Sony Interactive Entertainment Inc. Signed on behalf of Kazuyuki Hori, Sony Group Corporation

Date: 5/22/2023 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation Grantee Code: AK8 Grantee FRN: 0003739166 To whom it may concern: FCC US Agent Sony Electronics Inc. FCC FRN: 0033408097 Mr. Mark Arthurs 16535 Via Esprillo San Diego California, 92127 [email protected] This letter is to confirm that we have accepted the responsibility to act as US Agent on behalf of Sony Group Corporation (“the applicant”) for the above referenced Grantee Code. We are aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7) and Report and Order FCC 22-84 paragraph 63. Sincerely, Mark Arthurs Staff EMC Engineer Sony Electronics Inc.

Sony Group Corporation Date: 5/22/2023 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation Grantee Code: AK8 Grantee FRN: 0003739166 Sony Group Corporation (“the applicant”) as required by section 2.911(d)(7), designates the f ollowing agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. U.S. Agent Information: Mr. Mark Arthurs Sony Electronics Inc. FCC FRN: 0033408097 16535 Via Esprillo San Diego California, 92127 [email protected] Sincerely yours, Name: Kazuyuki Hori Job Title: Chief EMC/RF Compliance Specialist Company Name: Sony Group Corporation

Date: May 24, 2023 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Applicant: Sony Group Corporation FCC ID: AK8CFIZAC1 To whom it may concern: We, the undersigned, hereby authorize Shuichi Ohyama of UL Japan, Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Japan, Inc. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. The application for the subject equipment has not been submitted to another TCB for certification. Sincerely Yours, Miho Nakamura Sony Interactive Entertainment Inc. Signed on behalf of Kazuyuki Hori, Sony Group Corporation

Request for Confidentiality Date: May 24, 2023 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Applicant : Sony Group Corporation FCC ID : AK8CFIZAC1 To whom it may concern: Please be advised that the following information is to be held confidential on behalf of us, referring to the FCC rules 0.457 and 0.459: Block Diagram Theory of Operation Schematics The application contains technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, Miho Nakamura Sony Interactive Entertainment Inc. Signed on behalf of Kazuyuki Hori, Sony Group Corporation

Request for Short-Term Confidentiality Date: May 24, 2023 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 FCC ID : AK8CFIZAC1 Applicant : Sony Group Corporation To whom it may concern: Please be advised that the following information is to be held in confidence for 180 days from the date of the Grant of Equipment Authorization and behalf of us, referring to the FCC rules 0.457 and 0.459: External Photos Internal Photos Test Setup Photos User Manual The application contains technical information, which we deem to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, ____________________________________ Miho Nakamura Sony Interactive Entertainment Inc. Signed on behalf of Kazuyuki Hori, Sony Group Corporation

Sony Group Corporation Special Power of Attorney I, Kazuyuki Hori of Sony Group Corporation, hereby appoint Miho Nakamura of Sony Interactive Entertainment Inc. to represent me to act on my behalf to do any and all of the following. Sign on my behalf the agency, anti-drug and confidentiality cover letters and apply to FCC for the products. The rights, powers and authority in fact to exercise any and all of the rights and powers herein granted shall commence and be in full force from April 1, 2021 and continue to be effective unless specifically terminated by either party. Dated April 1, 2021 Kazuyuki Hori Company: Sony Group Corporation Country: Japan

©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment

Marking Content:Model:CFI-ZAC1FCC ID: AK8CFIZAC1IC: 409B-CFIZAC1Height of ID : 1.51mm +0.1/-0.0mm The markings are laser engraved and durable enough

©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment Side-B Side-A RF Block ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment ©Sony Interactive Entertainment

Test Report No. 14757979H-C-R1 Page 1 of 63 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 SAR TEST REPORT Test Report No. 14757979H-C-R1 Customer Sony Interactive Entertainment Inc. Description of EUT Wireless Controller Model Number of EUT CFI-ZAC1 FCC ID AK8CFIZAC1 Test Regulation FCC47CFR 2.1093 Test Result Complied Issue Date June 6, 2023 Remarks The highest reported SAR (1 g) Body : 0.11 W/kg Representative Test Engineer Approved By Tomohisa Nakagawa Engineer Takayuki Shimada Leader CERTIFICATE 5107.02 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan, Inc. There is no testing item of "Non-accreditation". Report Cover Page - Form-ULID-003532 (DCS:13-EM-F0429) Issue# 22.0 Test Report No. 14757979H-C-R1 Page 2 of 63 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 ANNOUNCEMENT REVISION HISTORY Original Test Report No. 14757979H-C This report is a revised version of 14757979H-C. 14757979H-C is replaced with this report. Revision Test report No. Date Page Revised Contents - (Original) 14757979H-C May 12, 2023 - 1 14757979H-C-R1 June 6, 2023 Cover page - Corrected The highest reported SAR (1 g) of Remarks column: < 0.10 W/kg → 0.11 W/kg Section 4.2 - Corrected highest reported SAR: 0.08 → 0.11 Section 5 - Added duty to Table 1 Section 10.1 - Corrected a typographical error: SCP → SPC Section 12.1 - Corrected Duty in the table: 100 → 76.9  This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc.  The results in this report appl y only to the sample tested. (Laboratory was not involved in sampling.)  This sample tested is in compliance with the limits of the above re gulation.  The test results in this test report are traceable to the national or international standards.  This test report must not be used by the customer to claim product certification, approval, or endorsement b y the A2LA accreditation body.  This test report covers SAR technical requirements. It does not cover administrative issues such as Manual or non-SAR test related Requirements. (if applicable)  The all test items in this test report are conducted b y UL Japan, Inc. Ise EMC Lab.  The opinions and the interpretations to the result of the description in this report are outside scopes where UL Japan, Inc. has been accredited.  The information provided from the customer for this report is identified in Section 1.  For test report (s) referred in this report, the latest version (including any revisions) is always referred. Test Report No. 14757979H-C-R1 Page 3 of 63 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Reference: Abbreviations (Including words undescribed in this report) AAN Asymmetric Artificial Network GPS Global Positioning System AC Alternating Current Hori. Horizontal AM Amplitude Modulation ICES Interference-Causing Equipment Standard AMN Artificial Mains Network I/O Input/Output Amp, AMP Amplifier IEC International Electrotechnical Commission ANSI American National Standards Institute IEEE Institute of Electrical and Electronics Engineers Ant, ANT Antenna IF Intermediate Frequency AP Access Point ILAC International Laboratory Accreditation Conference ASK Amplitude Shift Keying ISED Innovation, Science and Economic Development Canada Atten., ATT Attenuator ISN Impedance Stabilization Network AV Average ISO International Organization for Standardization BPSK Binary Phase-Shift Keying JAB Japan Accreditation Board BR Bluetooth Basic Rate LAN Local Area Network BT Bluetooth LCL Longitudinal Conversion Loss BT LE Bluetooth Low Energy LIMS Laboratory Information Management System BW BandWidth LISN Line Impedance Stabilization Network C.F Correction Factor MRA Mutual Recognition Arrangement Cal Int Calibration Interval N/A Not Applicable CAV CISPR AV NIST National Institute of Standards and Technology CCK Complementary Code Keying NS No signal detect. CDN Coupling Decoupling Network NSA Normalized Site Attenuation Ch., CH Channel OBW Occupied BandWidth CISPR Comite International Special des Perturbations Radioelectriques OFDM Orthogonal Frequency Division Multiplexing Corr. Correction PER Packet Error Rate CPE Customer premise equipment PK Peak CW Continuous Wave P LT long-term flicker severity DBPSK Differential BPSK POHC(A) Partial Odd Harmonic Current DC Direct Current Pol., Pola. Polarization DET Detector PR-ASK Phase Reversal ASK D-factor Distance factor P ST short-term flicker severity Dmax maximum absolute voltage change during an observation period QAM Quadrature Amplitude Modulation DQPSK Differential QPSK QP Quasi-Peak DSSS Direct Sequence Spread Spectrum QPSK Quadrature Phase Shift Keying DUT Device Under Test r.m.s., RMS Root Mean Square EDR Enhanced Data Rate RBW Resolution BandWidth e.i.r.p., EIRP Equivalent Isotropically Radiated Power RE Radio Equipment EM clamp Electromagnetic clamp REV Reverse EMC ElectroMagnetic Compatibility RF Radio Frequency EMI ElectroMagnetic Interference RFID Radio Frequency Identifier EMS ElectroMagnetic Susceptibility RNSS Radio Navigation Satellite Service EN European Norm RSS Radio Standards Specifications e.r.p., ERP Effective Radiated Power Rx Receiving ETSI European Telecommunications Standards Institute SINAD Ratio of (Signal + Noise + Distortion) to (Noise + Distortion) EU European Union S/N Signal to Noise ratio EUT Equipment Under Test SA, S/A Spectrum Analyzer Fac. Factor SG Signal Generator FCC Federal Communications Commission SVSWR Site-Voltage Standing Wave Ratio FHSS Frequency Hopping Spread Spectrum THC(A) Total Harmonic Current FM Frequency Modulation THD(%) Total Harmonic Distortion Freq. Frequency TR, T/R Test Receiver FSK Frequency Shift Keying Tx Transmitting Fund Fundamental VBW Video BandWidth FWD Forward Vert. Vertical GFSK Gaussian Frequency-Shift Keying WLAN Wireless LAN GNSS Global…

Text truncated - open the document above for the full version.

Specification of Antenna 1. Information •Antenna Type:IFA •Model Name:none (PWB Printed Antenna) •Antenna Gain:3.4 dBi max •Frequency Range:2400-2480 MHz •Outline 㸸 •Measurement Location: Sony Interactive Entertainment Inc. Anechoic Chamber 1-7-1 Konan Minato-ku Tokyo Japan •Measurement date : 2023/4 •Test personal : Kota Hatano •Equipment :ETS-L Antenna Measurement System Keysight E5071C(Calibration date: 2022/11) •Measurement Software : EMQuest Data Acquisition and Analysis Software 12.75mm 2.60mm 2. Test Method Antenna gain is measured in “ETS-L Antenna Measurement anechoic chamber”. This system consists of Dual-polarized antennas arranged in a ring and RF path switch control box. Network analyzer E5071C is connected to this chamber. DUT is put on a turn table located in center of the chamber as pictured below. Characteristics of the horizontal and vertical polarization are acquired in all direction by switching antennas and rotation of the turn table. DUT Dual-polarized antennas in a ring XY Plane YZ Plane ZX Plane 3. Radiation Pattern X Y Y Z X Z X Y Z

Test Report No. 14757979H-A Page 1 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 RADIO TEST REPORT Test Report No. 14757979H-A Customer Sony Interactive Entertainment Inc. Description of EUT Wireless Controller Model Number of EUT CFI-ZAC1 FCC ID AK8CFIZAC1 Test Regulation FCC Part 15 Subpart C Test Result Complied Issue Date May 9, 2023 Remarks - Representative Test Engineer Approved By Kiyoshiro Okazaki Engineer Takayuki Shimada Leader CERTIFICATE 5107.02 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan, Inc. There is no testing item of "Non-accreditation". Report Cover Page - Form-ULID-003532 (DCS:13-EM-F0429) Issue# 22.0 Test Report No. 14757979H-A Page 2 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 ANNOUNCEMENT REVISION HISTORY Original Test Report No.: 14757979H-A Revision Test Report No. Date Page Revised Contents - (Original) 14757979H-A May 9, 2023 -  This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc.  The results in this report appl y only to the sample tested. (Laboratory was not involved in sampling.)  This sample tested is in compliance with the limits of the above re gulation.  The test results in this test report are traceable to the national or international standards.  This test report must not be used by the customer to claim product certification, approval, or endorsement b y the A2LA accreditation body.  This test report covers Radio technical requirements. It does not cover administrative issues such as Manual or non-Radio test related Requirements. (if applicable)  The all test items in this test report are conducted b y UL Japan, Inc. Ise EMC Lab.  The opinions and the interpretations to the result of the description in this report are outside scopes where UL Japan, Inc. has been accredited.  The information provided from the customer for this report is identified in Section 1.  For test report (s) referred in this report, the latest version (including any revisions) is always referred. Test Report No. 14757979H-A Page 3 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Reference: Abbreviations (Including words undescribed in this report) A2LA The American Association for Laboratory Accreditation ICES Interference-Causing Equipment Standard AC Alternating Current IEC International Electrotechnical Commission AFH Adaptive Frequency Hopping IEEE Institute of Electrical and Electronics Engineers AM Amplitude Modulation IF Intermediate Frequency Amp, AMP Amplifier ILAC International Laboratory Accreditation Conference ANSI American National Standards Institute ISED Innovation, Science and Economic Development Canada Ant, ANT Antenna ISO International Organization for Standardization AP Access Point JAB Japan Accreditation Board ASK Amplitude Shift Keying LAN Local Area Network Atten., ATT Attenuator LIMS Laboratory Information Management System AV Average MCS Modulation and Coding Scheme BPSK Binary Phase-Shift Keying MRA Mutual Recognition Arrangement BR Bluetooth Basic Rate N/A Not Applicable BT Bluetooth NIST National Institute of Standards and Technology BT LE Bluetooth Low Energy NS No signal detect. BW BandWidth NSA Normalized Site Attenuation Cal Int Calibration Interval NVLAP National Voluntary Laboratory Accreditation Pro gram CCK Complementary Code Keying OBW Occupied Band Width Ch., CH Channel OFDM Orthogonal Frequency Division Multiplexing CISPR Comite International Special des Perturbations Radioelectriques P/M Power meter CW Continuous Wave PCB Printed Circuit Board DBPSK Differential BPSK PER Packet Error Rate DC Direct Current PHY Physical Layer D-factor Distance factor PK Peak DFS Dynamic Frequency Selection PN Pseudo random Noise DQPSK Differential QPSK PRBS Pseudo-Random Bit Sequence DSSS Direct Sequence Spread Spectrum PSD Power Spectral Density EDR Enhanced Data Rate QAM Quadrature Amplitude Modulation EIRP, e.i.r.p. Equivalent Isotropically Radiated Power QP Quasi-Peak EMC ElectroMagnetic Compatibility QPSK Quadri-Phase Shift Keying EMI ElectroMagnetic Interference RBW Resolution Band Width EN European Norm RDS Radio Data System ERP, e.r.p. Effective Radiated Power RE Radio Equipment EU European Union RF Radio Frequency EUT Equipment Under Test RMS Root Mean Square Fac. Factor RSS Radio Standards Specifications FCC Federal Communications Commission Rx Receiving FHSS Frequency Hopping Spread Spectrum SA, S/A Spectrum Analyzer FM Frequency Modulation SG Signal Generator Freq. Frequency SVSWR Site-Voltage Standing Wave Ratio FSK Frequency Shift Keying TR Test Receiver GFSK Gaussian Frequency-Shift Keying Tx Transmitting GNSS Global Navigation Satellite System VBW Video BandWidth GPS Global Positioning System Vert. Vertical Hori. Horizontal WLAN Wireless LAN Test Report No. 14757979H-A Page 4 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 CONTENTS PAGE SECTION 1: Customer Information ......................................................................................... 5 SECTION 2: Equipment Under Test (EUT) .............................................................................. 5 SECTION 3: Test Specification, Procedures & Results ........................................................ 6 SECTION 4: Operation of EUT during testing ........................................................................ 9 SECTION 5: Conducted Emission ......................................................................................... 11 SECTION 6: Radiated Spurious Emission ............................................................................ 12 SECTION 7: Antenna Terminal Conducted Tests ................................................................ 14 APPENDIX 1: Test data ...........................…

Text truncated - open the document above for the full version.

Test Report No. 14757979H-C-R1 Page 61 of 63 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 APPENDIX 4: Photographs of test setup Antenna position Test Report No. 14757979H-C-R1 Page 62 of 63 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Photographs of EUT Photo 1: EUT of rear view Photo 2: EUT of front view Photo 3: EUT extended Photo 4: EUT retracted (tested) Photo 5: EUT with button Photo 6: EUT without button (tested) The red circle is an about location of the antenna. Test Report No. 14757979H-C-R1 Page 63 of 63 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Photographs of setup Photo 7: Front Photo 8: Front Photo 9: Rear Photo 10: Rear Photo 11: Side1 Photo 12: Side1 Photo 13: Side2 Photo 14: Side2 End of Report

Test Report No. 14757979H-A Page 48 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 APPENDIX 3: Photographs of test setup Conducted Emission Photo 1 Photo 2 Test Report No. 14757979H-A Page 49 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Radiated Spurious Emission Photo 1 Photo 2 Test Report No. 14757979H-A Page 50 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Worst Case Position X-axis X*-axis Y-axis Y*-axis Z-axis Z*-axis Test Range Horizontal Vertical Below 1 GHz Y-axis Y- a x i s Above 1 GHz Y*-axis Y*-axis Test Report No. 14757979H-A Page 51 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Antenna Terminal Conducted Tests Photo 1 Photo 2 Test Report No. 14757979H-A Page 52 of 52 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Test Configuration and peripherals A B C D E F G AC 120 V / 60 Hz 1 2 3 4 5 6 7 : Standard Ferrite Core * Cabling and setup(s) were taken into consideration and test data was taken under worse case conditions. Description of EUT and Support Equipment No. Item Model number Serial Number Manufacturer Remarks A Wireless Controller CFI-ZAC1 No.0122 for CE, RE* No.0104 for AT* Sony Interactive Entertainment Inc. EUT B External Button - BTN01 Logitech - C External Button - BTN02 Logitech - D External Button - BTN03 Logitech - E External Button - BTN04 Logitech - F Laptop PC ThinkPad X230 R9-X86LK Lenovo - G AC Adapter - 11S92P1156Z1ZDXN88 CUJM Lenovo - List of Cables Used No. Name Length (m) Shield Remarks Cable Connector 1 Si gnal Cable 2.0 Unshielded Unshielded - 2 Si gnal Cable 2.0 Unshielded Unshielded - 3 Si gnal Cable 2.0 Unshielded Unshielded - 4 Si gnal Cable 2.0 Unshielded Unshielded - 5 USB Cable 1.5 Shielded Shielded - 6 DC Cable 1.8 Unshielded Unshielded - 7 AC Cable 0.8 Unshielded Unshielded - *CE: Conducted Emission test RE: Radiated Emission test AT: Antenna Terminal conducted test End of Report
