AK8PCG4121DLPersonal Computer

4-297-146-11(1)  For customers in USA and Canada Pour les utilisateurs aux Etats-Unis et au Canada Owner’s Record The model number and serial number are located on the bottom, the back panel, or inside the battery compartment of your VAIO® computer. Record the model and serial numbers in the space provided here, and keep in a secure location. Refer to the model and serial numbers when you call your Sony Service Center. Model Number: Serial Number: Notice © 2011 Sony Electronics Inc. Reproduction in whole or in part without written permission is prohibited. All rights reserved. This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval. SONY ELECTRONICS INC. PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR SUCH OTHER INFORMATION. IN NO EVENT SHALL SONY ELECTRONICS INC. BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL, THE SOFTWARE, OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF. SONY CANNOT WARRANT THAT THE FUNCTIONS DESCRIBED IN THIS GUIDE WILL BE UNINTERRUPTED OR ERROR-FREE. SONY ALSO ASSUMES NO RESPONSIBILITY, AND SHALL NOT BE LIABLE FOR ANY DAMAGES TO, OR VIRUSES THAT MAY INFECT, YOUR COMPUTER EQUIPMENT, OR OTHER PROPERTY ON ACCOUNT OF YOUR ACCESS TO, USE OF, OR BROWSING IN ANY DESCRIBED WEB SITE, OR YOUR DOWNLOADING OF ANY MATERIALS, DATA, TEXT, IMAGES, VIDEO, OR AUDIO FROM ANY DESCRIBED WEB SITE. WEB SITE INFORMATION IS OBTAINED FROM VARIOUS SOURCES AND MAY BE INACCURATE. COPIES OF COPYRIGHTED INFORMATION MAY ONLY BE MADE FOR LEGALLY PERMISSIBLE PURPOSES. Sony Electronics Inc. reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein is governed by the terms of a separate user license agreement. This product contains software owned by Sony and licensed by third parties. Use of such software is subject to the terms and conditions of license agreements enclosed with this product. Some of the software may not be transported or used outside the United States. Software specifications are subject to change without notice and may not necessarily be identical to current retail versions. Certain product(s) included with this computer may include features such as copy protection and content management technology. USE OF THE SOFTWARE PRODUCT(S) REQUIRES AGREEMENT TO APPLICABLE END USER AGREEMENTS AND FULL COMPLIANCE WITH APPLICABLE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and privacy policies will be detailed during initial launch of the software product(s), or upon certain reinstallations of the software product(s), or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply). Updates and additions to software may require an additional charge. Subscriptions to online service providers may require a fee and credit card information. Financial services may require prior arrangements with participating financial institutions. 4 Important information for Canadian customers: Your new VAIO® computer includes certain software versions or upgrades, and Internet services or offers that are available to U.S. customers only. Sony, VAIO, and the VAIO logo are trademarks or registered trademarks of Sony Corporation. All other trademarks are trademarks or registered trademarks of their respective owners. The Wireless LAN functionality, which is incorporated into selected models only, has passed Wi-Fi certification and complies with the interoperability specifications established by WFA (Wi-Fi Alliance). Reverse engineering or disassembly is prohibited. End User / Product Activation Requirements Certain software product(s) included with this computer may include features such as copy protection and content management technology. Use of the software product(s) requires agreement to applicable end user agreements and full compliance with applicable product activation procedures. Product activation procedures and privacy policies will be detailed during initial launch of the software product(s), or upon certain reinstallations of the software product(s) or reconfiguration of the computer, and may be completed by Internet or telephone (toll charges may apply).  Safety Information and Caution For questions regarding your product or for the Sony Service Center nearest you, visit the Sony online support Web site at http://esupport.sony.com/EN/VAIO/ for customers in USA or at http://www.sony.ca/support/ for customers in Canada.  T o prevent fire or shock hazard, do not expose your computer to rain or moisture.  T o avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.  T urning off your computer with the power button or the power switch does not disconnect the computer completely from mains voltage. To disconnect it completely, unplug the AC adapter or the power cable from mains. The socket-outlet shall be installed near the equipment and shall be easily accessible.  D o not use your computer directly on your lap. The temperature of the base of the unit will rise during normal operation and over time could result in discomfort or burns.  D o not place the AC adapter in contact with your skin. Remove the AC adapter away from your body if it becomes warm and causes discomfort.  D o not block the air exhaust or intake vents while the computer is in operation.  B locking the air vents leads to restriction on air circulation, which can cause internal overheating, resulting in deformation of the computer, a malfunction, or a fire hazard.  O bserve the following precautions to p…

Text truncated - open the document above for the full version.

N User Guide Personal Computer VPCSA Series / VPCSB Series / VPCSC Series 2 nN Contents Before Use .......................................................................... 4 Finding More about Your VAIO Computer .................... 5 Ergonomic Considerations ............................................ 9 Getting Started.................................................................. 11 Locating Controls and Ports ........................................ 12 About the Indicator Lights ........................................... 20 Connecting a Power Source ....................................... 21 Using the Battery Pack................................................ 23 Shutting Down Your Computer Safely ........................ 32 Using the Power Saving Modes .................................. 33 Keeping Your Computer in Optimum Condition .......... 36 Using Your VAIO Computer.............................................. 39 Using the Keyboard..................................................... 40 Using the Touch Pad................................................... 43 Using Special-function Buttons ................................... 44 Using the Quick Web Access Function ....................... 45 Using the Built-in Camera ........................................... 47 Using the Optical Disc Drive ....................................... 48 Using "Memory Stick".................................................. 55 Using Other Modules / Memory Cards ........................ 62 Using the Internet ........................................................ 66 Using the Network (LAN) ............................................ 67 Using the Wireless LAN...............................................69 Using the Wireless WAN .............................................74 Using the International Roaming Service ....................76 Using the BLUETOOTH Function................................79 Using Fingerprint Authentication .................................85 Using the TPM .............................................................90 Using Peripheral Devices ................................................100 Connecting a Port Replicator.....................................101 Connecting External Speakers or Headphones ........108 Connecting an External Display ................................109 Selecting Display Modes ...........................................116 Using the Multiple Monitors Function ........................117 Connecting a USB Device .........................................119 Customizing Your VAIO Computer..................................121 Selecting Performance Modes ..................................122 Setting the Password.................................................124 Using Intel(R) VT .......................................................130 Using the VAIO Control Center .................................131 Using the VAIO Power Management.........................132 Protecting Data from Unauthorized Use ....................133 Protecting the Hard Disk............................................135 3 nN Upgrading Your VAIO Computer .................................... 136 Adding and Removing Memory ................................. 137 Precautions ..................................................................... 143 Safety Information ..................................................... 144 Care and Maintenance Information ........................... 147 Handling Your Computer........................................... 148 Handling the LCD Screen ......................................... 150 Using the Power Source ........................................... 151 Handling the Built-in Camera .................................... 152 Handling Discs .......................................................... 153 Using the Battery Pack.............................................. 154 Handling "Memory Stick"........................................... 155 Handling the Built-in Storage Device ........................ 156 Using Fingerprint Authentication ............................... 157 Using the TPM .......................................................... 158 Troubleshooting .............................................................. 159 Computer Operations................................................ 161 System Update / Security.......................................... 167 Recovery / Recovery Media ...................................... 168 Partition ..................................................................... 172 Battery Pack.............................................................. 173 Built-in Camera ......................................................... 175 Networking (LAN/Wireless LAN) ............................... 177 Wireless WAN ........................................................... 181 BLUETOOTH Technology .........................................182 Optical Discs..............................................................185 Display .......................................................................190 Printing ......................................................................195 Microphone ................................................................196 Speakers ...................................................................197 Touch Pad .................................................................199 Keyboard ...................................................................200 Floppy Disks ..............................................................201 Audio/Video ...............................................................202 "Memory Stick" ..........................................................204 Peripherals ................................................................205 Trademarks .....................................................................206 Notice ..............................................................................209 4 nN Before Use > Before Use…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 10

Report No.: SA110617D07 1 Report Format Version 4.0.0 RF EXPOSURE REPORT REPORT NO.: SA110617D07 MODEL NO.: PCG-4121DL, PCG-4121EL FCC ID: AK8PCG4121DL APPLICANT: SONY Corporation ADDRESS: 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 7 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No.: SA110617D07 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD....................................................................................3 1. CERTIFICATION..............................................................................................4 2. RF EXPOSURE LIMIT.....................................................................................5 3. MPE CALCULATION FORMULA.....................................................................5 4. CLASSIFICATION............................................................................................5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER...................6 Report No.: SA110617D07 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA110617D07 Original release Jul. 22, 2011 Report No.: SA110617D07 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Personal Computer BRAND NAME: SONY MODEL NO.: PCG-4121DL, PCG-4121EL APPLICANT: SONY Corporation TESTED: Jun. 24 ~ 30, 2011 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: PCG-4121DL) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: SA110617D07 5 Report Format Version 4.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA110617D07 6 Report Format Version 4.0.0 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FOR WLAN: MODULATION MODE FREQUENCY BAND (MHz) MAX CONDUCTED POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 802.11b 2412-2462 17.0 0.59 20 0.0114 1.00 802.11g 2412-2462 20.4 0.59 20 0.0250 1.00 802.11n (20MHz) 2412-2462 21.6 0.59 20 0.0329 1.00 802.11n (40MHz) 2422-2452 20.7 0.59 20 0.0268 1.00 802.11a 5180-5240 15.3 0.80 20 0.0081 1.00 802.11n (20MHz) 5180-5240 14.3 0.80 20 0.0064 1.00 802.11n (40MHz) 5190-5230 14.4 0.80 20 0.0066 1.00 802.11a 5260-5320 15.0 0.80 20 0.0076 1.00 802.11n (20MHz) 5260-5320 14.3 0.80 20 0.0064 1.00 802.11n (40MHz) 5270-5310 14.1 0.80 20 0.0061 1.00 802.11a 5500-5700 14.4 0.80 20 0.0066 1.00 802.11n (20MHz) 5500-5700 14.2 0.80 20 0.0063 1.00 802.11n (40MHz) 5510-5670 12.6 0.80 20 0.0044 1.00 802.11a 5745-5825 18.6 -1.04 20 0.0173 1.00 802.11n (20MHz) 5745-5825 18.6 -1.04 20 0.0173 1.00 802.11n (40MHz) 5755-5795 19.2 -1.04 20 0.0199 1.00 FOR BLUETOOTH: FREQUENCY BAND (MHz) MAX POWER (dBm) MAXIMUM ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2402-2480 6.5 0.59 20 0.0010 1.00 Report No.: SA110617D07 7 Report Format Version 4.0.0 FOR WWAN: MODE MAX RADIATED POWER (dBm) SOUCE-TIME AVERAGE POWER(dBm) MPE (mW/cm 2 ) LIMIT (mW/cm 2 ) GPRS 850 29.2 23.2 0.042 0.55 EGPRS 850 23.0 17.0 0.010 0.55 GPRS 1900 29.6 23.6 0.046 1.00 EGPRS 1900 25.5 19.5 0.018 1.00 MODE MAX RADIATED POWER (dBm) MPE (mW/cm 2 ) LIMIT (mW/cm 2 ) CDMA 850 22.4 0.035 0.55 CDMA 1900 23.8 0.048 1.00 WCDMA 850 21.0 0.025 0.55 WCDMA 1900 26.6 0.091 1.00 CONCULSION: Both of the modules can transmit simultaneously, the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density 1. WLAN(2.4G)+Bluetooth+GPRS 850 =0.0329 /1+ 0.0010 /1+ 0.042 /0.55 = 0.1103 2. WLAN(2.4G)+Bluetooth+EGPRS 850 =0.0329 /1+ 0.0010 /1+ 0.010 /0.55 = 0.0521 3. WLAN(2.4G)+Bluetooth+GPRS 1900 =0.0329 /1+ 0.0010 /1+ 0.046 /1.00 = 0.0799 4. WLAN(2.4G)+Bluetooth+EGPRS 1900 =0.0329 /1+ 0.0010 /1+ 0.018 /1.00 = 0.0519 5. WLAN(2.4G)+Bluetooth+CDMA 850 =0.0329 /1+ 0.0010 /1+ 0.035 /0.55 = 0.0975 6. WLAN(2.4G)+Bluetooth+CDMA 1900 =0.0329 /1+ 0.0010 /1+ 0.048 /1.00 = 0.0819 7. WLAN(2.4G)+Bluetooth+WCDMA 850 =0.0329 /1+ 0.0010 /1+ 0.025 /0.55 = 0.0794 8. WLAN(2.4G)+Bluetooth+WCDMA 1900 =0.0329 /1+ 0.0010 /1+ 0.091 /1.00 = 0.1249 9. WLAN(5.0G)+Bluetooth+GPRS 850 =0.0199 /1+ 0.0010 /1+ 0.042 /0.55 = 0.0973 10. WLAN(5.0G)+Bluetooth+EGPRS 850 =0.0199 /1+ 0.0010 /1+ 0.010 /0.55 = 0.0391 11. WLAN(5.0G)+Bluetooth+GPRS 1900 =0.0199 /1+ 0.0010 /1+ 0.046 /1.00 = 0.0669 12. WLAN(5…

Text truncated - open the document above for the full version.

Report No.: RF110617D07-1 1 Report Format Version 4.0.0 FCC TEST REPORT (15.247) (For WLAN) REPORT NO.: RF110617D07-1 MODEL NO.: PCG-4121DL, PCG-4121EL FCC ID: AK8PCG4121DL RECEIVED: Jun. 17, 2011 TESTED: Jun. 23 ~ Jul. 15, 2011 ISSUED: Jul. 22, 2011 APPLICANT: SONY Corporation ADDRESS: 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 139 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110617D07-1 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.................................................................................5 1. CERTIFICATION..............................................................................................6 2. SUMMARY OF TEST RESULTS......................................................................7 2.1 MEASUREMENT UNCERTAINTY...................................................................7 3. GENERAL INFORMATION..............................................................................8 3.1 GENERAL DESCRIPTION OF EUT.................................................................8 3.2 DESCRIPTION OF TEST MODES..................................................................11 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST............................................12 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.................13 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS................................17 3.4 DESCRIPTION OF SUPPORT UNITS...........................................................17 4. TEST TYPES AND RESULTS (FOR 2.4GHZ BAND).....................................18 4.1 CONDUCTED EMISSION MEASUREMENT.................................................18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT...............................18 4.1.2 TEST INSTRUMENTS...................................................................................18 4.1.3 TEST PROCEDURES....................................................................................19 4.1.4 DEVIATION FROM TEST STANDARD..........................................................19 4.1.5 TEST SETUP.................................................................................................20 4.1.6 EUT OPERATING CONDITIONS...................................................................20 4.1.7 TEST RESULTS.............................................................................................21 4.2 RADIATED EMISSION MEASUREMENT......................................................23 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT....................................23 4.2.2 TEST INSTRUMENTS...................................................................................24 4.2.3 TEST PROCEDURES....................................................................................25 4.2.4 DEVIATION FROM TEST STANDARD..........................................................25 4.2.5 TEST SETUP.................................................................................................26 4.2.6 EUT OPERATING CONDITIONS...................................................................26 4.2.7 TEST RESULTS.............................................................................................27 4.3 6DB BANDWIDTH MEASUREMENT.............................................................41 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT..........................................41 4.3.2 TEST INSTRUMENTS...................................................................................41 4.3.3 TEST PROCEDURE......................................................................................41 4.3.4 DEVIATION FROM TEST STANDARD..........................................................41 4.3.5 TEST SETUP.................................................................................................42 4.3.6 EUT OPERATING CONDITIONS...................................................................42 4.3.7 TEST RESULTS.............................................................................................43 4.4 MAXIMUM OUTPUT POWER........................................................................47 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT.........................47 4.4.2 INSTRUMENTS.............................................................................................47 4.4.3 TEST PROCEDURES....................................................................................47 4.4.4 DEVIATION FROM TEST STANDARD..........................................................48 4.4.5 TEST SETUP.................................................................................................48 4.4.6 EUT OPERATING CONDITIONS...................................................................48 Report No.: RF110617D07-1 3 Report Format Version 4.0.0 4.4.7 TEST RESULTS.............................................................................................49 4.5 POWER SPECTRAL DENSITY MEASUREMENT.........................................50 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT......................50 4.5.2 TEST INSTRUMENTS...................................................................................50 4.5.3 TEST PROCEDURE......................................................................................50 4.5.4 DEVIATION FROM TEST STANDARD..........................................................51 4.5.5 TEST SETUP.................................................................................................51 4.5.6 EUT OP…

Text truncated - open the document above for the full version.

Report No.: RF110617D07 1 Report Format Version 4.0.0 FCC TEST REPORT (15.407) (For WLAN) REPORT NO.: RF110617D07 MODEL NO.: PCG-4121DL, PCG-4121EL FCC ID: AK8PCG4121DL RECEIVED: Jun. 17, 2011 TESTED: Jun. 24 ~ Jul. 16, 2011 ISSUED: Jul. 22, 2011 APPLICANT: SONY Corporation ADDRESS: 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 131 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110617D07 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.................................................................................4 1. CERTIFICATION............................................................................................5 2. SUMMARY OF TEST RESULTS....................................................................6 2.1 MEASUREMENT UNCERTAINTY..................................................................6 3. GENERAL INFORMATION.............................................................................7 3.1 GENERAL DESCRIPTION OF EUT...............................................................7 3.2 DESCRIPTION OF TEST MODES...............................................................10 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................11 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL...............12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS..............................15 3.4 DESCRIPTION OF SUPPORT UNITS.........................................................15 4. TEST TYPES AND RESULTS......................................................................16 4.1 CONDUCTED EMISSION MEASUREMENT...............................................16 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT.............................16 4.1.2 TEST INSTRUMENTS.................................................................................16 4.1.3 TEST PROCEDURES..................................................................................17 4.1.4 DEVIATION FROM TEST STANDARD........................................................17 4.1.5 TEST SETUP...............................................................................................18 4.1.6 EUT OPERATING CONDITIONS.................................................................18 4.1.7 TEST RESULTS...........................................................................................19 4.2 RADIATED EMISSION MEASUREMENT....................................................23 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT..................................23 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS23 4.2.3 TEST INSTRUMENTS.................................................................................24 4.2.4 TEST PROCEDURES..................................................................................25 4.2.5 DEVIATION FROM TEST STANDARD........................................................25 4.2.6 TEST SETUP...............................................................................................26 4.2.7 EUT OPERATING CONDITION...................................................................26 4.2.8 TEST RESULTS...........................................................................................27 4.3 MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT.................58 4.3.1 LIMITS OF MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT58 4.3.2 TEST INSTRUMENTS.................................................................................58 4.3.3 TEST PROCEDURE....................................................................................59 4.3.4 DEVIATION FROM TEST STANDARD........................................................59 4.3.5 TEST SETUP...............................................................................................59 4.3.6 EUT OPERATING CONDITIONS.................................................................59 4.3.7 TEST RESULTS...........................................................................................60 4.4 PEAK POWER EXCURSION MEASUREMENT..........................................65 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT........................65 4.4.2 TEST INSTRUMENTS.................................................................................65 4.4.3 TEST PROCEDURE....................................................................................65 4.4.4 DEVIATION FROM TEST STANDARD........................................................66 4.4.5 TEST SETUP...............................................................................................66 Report No.: RF110617D07 3 Report Format Version 4.0.0 4.4.6 EUT OPERATING CONDITIONS.................................................................66 4.4.7 TEST RESULTS...........................................................................................67 4.5 PEAK POWER SPECTRAL DENSITY MEASUREMENT............................73 4.5.1 LIMITS OF PEAK POWER SPECTRAL DENSITY MEASUREMENT..........73 4.5.2 TEST INSTRUMENTS.................................................................................73 4.5.3 TEST PROCEDURES..................................................................................73 4.5.4 DEVIATION FROM TEST STANDARD........................................................74 4.5.5 TEST SETUP...............................................................................................74 4.5.6 EUT OPERATING CONDITIONS...................................…
