AK8PCG41312LLaptop PC with WWAN, LTE, WLAN and Bluetooth

N User Guide Personal Computer VPCZ2 Series 2 nN Contents Before Use .......................................................................... 4 Finding More about Your VAIO Computer .................... 4 Ergonomic Considerations ............................................ 7 Getting Started.................................................................. 10 Locating Controls and Ports ........................................ 10 About the Indicator Lights ........................................... 16 Connecting a Power Source ....................................... 17 Using the Battery Pack................................................ 19 Shutting Down Your Computer Safely ........................ 24 Using the Power Saving Modes .................................. 25 Keeping Your Computer in Optimum Condition .......... 26 Using Your VAIO Computer.............................................. 29 Using the Keyboard..................................................... 30 Using the Touch Pad................................................... 32 Using Special-function Buttons ................................... 34 Using the Quick Web Access Function ....................... 35 Using the Built-in Camera ........................................... 37 Using the Optical Disc Drive ....................................... 38 Using "Memory Stick".................................................. 43 Using Other Modules / Memory Cards ........................ 47 Using the Internet ........................................................ 50 Using the Network (LAN) ............................................ 51 Using the Wireless LAN...............................................52 Using the Wireless WAN .............................................55 Using the International Roaming Service ....................59 Using the BLUETOOTH Function................................59 Using the GPS Function ..............................................63 Using Fingerprint Authentication .................................64 Using the TPM .............................................................67 Using Peripheral Devices ..................................................74 Using the Noise Canceling Headphones .....................74 Connecting a Docking Station .....................................79 Connecting External Speakers or Headphones ..........87 Connecting an External Display ..................................88 Selecting Display Modes .............................................91 Using the Multiple Monitors Function ..........................92 Connecting a USB Device ...........................................93 Customizing Your VAIO Computer....................................96 Setting the Password...................................................96 Using the VAIO Control Center .................................101 Using the VAIO Power Management.........................101 Precautions .....................................................................103 Safety Information .....................................................103 Care and Maintenance Information ...........................105 3 nN Handling Your Computer........................................... 106 Handling the LCD Screen ......................................... 108 Using the Power Source ........................................... 109 Handling the Built-in Camera .................................... 109 Handling Discs .......................................................... 109 Using the Battery Pack.............................................. 110 Handling "Memory Stick"........................................... 110 Handling the Built-in Storage Device ........................ 111 Using Fingerprint Authentication ............................... 112 Using the TPM .......................................................... 112 Troubleshooting .............................................................. 114 Computer Operations................................................ 115 System Update / Security.......................................... 120 Recovery / Recovery Media ...................................... 120 Partition ..................................................................... 123 Battery Pack.............................................................. 123 Built-in Camera ......................................................... 125 Networking (LAN/Wireless LAN) ............................... 127 Wireless WAN ........................................................... 130 BLUETOOTH Technology......................................... 131 Optical Discs ............................................................. 134 GPS........................................................................... 137 Display ...................................................................... 137 Printing ...................................................................... 140 Microphone ................................................................141 Speakers ...................................................................142 Touch Pad .................................................................143 Keyboard ...................................................................144 Floppy Disks ..............................................................144 Audio/Video ...............................................................145 "Memory Stick" ..........................................................147 Peripherals ................................................................148 Docking Station .........................................................148 Trademarks .....................................................................150 Notice ..............................................................................153 4 nN Before Use > Finding More about Your VAIO Computer Before Use Congratulations on your purchase of this VAIO ® computer and welcome to the on-screen User Guide. Sony …

Text truncated - open the document above for the full version.

Safety Information Renseignements relatifs à la sécurité Información de Seguridad Informações sobre Segurança Personal Computer / Ordinateur personnel / Computadora Personal / Computador Pessoal VPCZ2 Series IMPORTANTE! Por favor lea detalladamente este manual de instrucciones antes de conectar y operar este equipo. Recuerde que un mal uso de su aparato podría anular la garantía. 2 For customers in USA and Canada Pour les utilisateurs aux Etats-Unis et au Canada Owner’s Record The model number and serial number are located on the bottom, the back panel, or inside the battery compartment of your VAIO ® computer. Record the model and serial numbers in the space provided here, and keep in a secure location. Refer to the model and serial numbers when you call your Sony Service Center. Model Number: Serial Number: Notice © 2011 Sony Electronics Inc. Reproduction in whole or in part without written permission is prohibited. All rights reserved. This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval. SONY ELECTRONICS INC. PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR SUCH OTHER INFORMATION. IN NO EVENT SHALL SONY ELECTRONICS INC. BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL, THE SOFTWARE, OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF. SONY CANNOT WARRANT THAT THE FUNCTIONS DESCRIBED IN THIS GUIDE WILL BE UNINTERRUPTED OR ERROR-FREE. SONY ALSO ASSUMES NO RESPONSIBILITY, AND SHALL NOT BE LIABLE FOR ANY DAMAGES TO, OR VIRUSES THAT MAY INFECT, YOUR COMPUTER EQUIPMENT, OR OTHER PROPERTY ON ACCOUNT OF YOUR ACCESS TO, USE OF, OR BROWSING IN ANY DESCRIBED WEB SITE, OR YOUR DOWNLOADING OF ANY MATERIALS, DATA, TEXT, IMAGES, VIDEO, OR AUDIO FROM ANY DESCRIBED WEB SITE. WEB SITE INFORMATION IS OBTAINED FROM VARIOUS SOURCES AND MAY BE INACCURATE. COPIES OF COPYRIGHTED INFORMATION MAY ONLY BE MADE FOR LEGALLY PERMISSIBLE PURPOSES. Sony Electronics Inc. reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein is governed by the terms of a separate user license agreement. This product contains software owned by Sony and licensed by third parties. Use of such software is subject to the terms and conditions of license agreements enclosed with this product. Some of the software may not be transported or used outside the United States. Software specifications are subject to change without notice and may not necessarily be identical to current retail versions. 3 Certain product(s) included with this computer may include features such as copy protection and content management technology. USE OF THE SOFTWARE PRODUCT(S) REQUIRES AGREEMENT TO APPLICABLE END USER AGREEMENTS AND FULL COMPLIANCE WITH APPLICABLE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and privacy policies will be detailed during initial launch of the software product(s), or upon certain reinstallations of the software product(s), or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply). Updates and additions to software may require an additional charge. Subscriptions to online service providers may require a fee and credit card information. Financial services may require prior arrangements with participating financial institutions. Important information for Canadian customers: Your new VAIO ® computer includes certain software versions or upgrades, and Internet services or offers that are available to U.S. customers only. Sony, VAIO, and the VAIO logo are trademarks or registered trademarks of Sony Corporation. All other trademarks are trademarks or registered trademarks of their respective owners. The Wireless LAN functionality, which is incorporated into selected models only, has passed Wi-Fi certification and complies with the interoperability specifications established by WFA (Wi-Fi Alliance). Reverse engineering or disassembly is prohibited. End User / Product Activation Requirements Certain software product(s) included with this computer may include features such as copy protection and content management technology. Use of the software product(s) requires agreement to applicable end user agreements and full compliance with applicable product activation procedures. Product activation procedures and privacy policies will be detailed during initial launch of the software product(s), or upon certain reinstallations of the software product(s) or reconfiguration of the computer, and may be completed by Internet or telephone (toll charges may apply). 4 Safety Information and Caution For questions regarding your product or for the Sony Service Center nearest you, visit the Sony online support Web site at http://esupport.sony.com/EN/VAIO/ for customers in USA or at http://www.sony.ca/support/ for customers in Canada. ❑ To prevent fire or shock hazard, do not expose your computer to rain or moisture. ❑ To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. ❑ Turning off your computer with the power button or the power switch does not disconnect the computer completely from mains voltage. To disconnect it completely, unplug the AC adapter or the power cable from mains. The socket-outlet shall be installed near the equipment and shall be easily accessible. ❑ Do not use your computer directly on your lap. The temperature of the base of the unit will rise during normal operation and over time could result in discomfort or burns. ❑ Do not place the AC adapter in contact with your skin. Remove the AC adapter awa…

Text truncated - open the document above for the full version.

Sony Corporation 1-7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan Date:04/11/2011  FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046  RE:LetterorAuthorizationforFCCID:AK8PCG41312L  ToWhomItMayConcern:  We the undersigned, hereby authorizePCTEST Engineering Laboratory Inc. to act on our behalf in all mannersrelatingtoapplicationforequipmentauthorization,includingsigning ofalldocumentsrelatedto thesematters. AnyandallactscarriedoutbyPCTESTEngineeringLaboratoryInc.,onourbehalfshallhavethesameeffect asactsofourown.  ThisauthorizationfromSonyCorporationisvalidfor120daysfromthedateoftheletter.     Regards,       RyuiTatsumi SeniorManager QualityAssuranceDepartment.No1 CS&QualityDivision VAIO&MobileBusinessGroup SONYCorporation.

PCTEST Engineering Laboratory, Inc. Columbia, Maryland 21045-4844 Tel.: 410-290-6652 / Fax: 410-290-6654 © 2011 PCTEST Engineering Laboratory Inc. DATE: MAY 12, 2011 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Attestation Statement Sony Corporation FCC ID: AK8PCG41312L Original Certification Laptop Product To whom it may concern: On behalf of Sony Corporation, we attest that the attached NII/DTS/DSS power levels provided by Intel (FCC ID: PD962230ANH) are the tuned levels that will be implemented in the Sony product, FCC ID: AK8PCG41312L. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely,

Sony Corporation 1-7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan Date: 05/13/2011 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: DFS Declaration for FCC ID: AK8PCG41312L To Whom It May Concern: We, Sony Corporation, declare under our sole responsibility that the AK8PCG41311L equipped with the WLAN module with FCC ID: PD962230ANH comply with the statements made below. The PD962230ANH EEPROM will be programmed at the factory to only operate and actively scan on these specific channels, where it can initiate transmissions and act as a master device for the 2.4 Ghz band: Channels 1-11, 2412-2462MHz 802.11b mode Channels 1-11, 2412-2462MHz 802.11g mode Channels 1-11, 2412-2462MHz 802.11n mode (20MHz channel) Channels 3-9, 2422-2452MHz 802.11n mode (40MHz channel) The following channels will be programmed at the factory to passively scan and will only listen and cannot send a probe/beacon request to initiate communication on these specific channels. Ad-hoc mode is always disabled on these passive channels. Channels 12 &13, 2467 & 2472MHz 802.11b mode Channels 12 &13, 2467 & 2472MHz 802.11g mode Channels 12 &13, 2467 & 2472MHz 802.11n mode (20/40MHz channel) Channels 36-48, 5180-5240MHz 802.11a mode Channels 36-48, 5180-5240MHz 802.11n mode (20 MHz channel) Channels 38-46, 5190-5230MHz 802.11n mode (40MHz channel) Channels 52-64, 5260-5320MHz 802.11a mode Channels 52-64, 5260-5320MHz 802.11n mode (20 MHz channel) Channels 54-62, 5270-5310MHz 802.11n mode (40MHz channel) Channels 100-140, 5500-5700MHz 802.11a mode Channels 100-140, 5500-5700MHz 802.11n mode (20 MHz channel) Channels 102-134, 5510-5670MHz 802.11n mode (40MHz channel) Channels 149-165, 5745-5825 802.11a mode Channels 149-165, 5745-5825MHz 802.11n mode (20 MHz channel) Channels151-159, 5755-5795 802.11n mode(40MHz channel) This information, when programmed at the factory into the EEPROM, will not be accessible and cannot be changed by the end user or by host configuration settings. Regards,

Sony Corpor ation 1-7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan Date: 04/11/201 1 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: AK8PCG41312L To Whom It May Concern: Pursuant to sections 0.457 and 0. 459 of the Commission’s Rules (CFR 47) and section 552 (b) (4) of the Freedom of Information Act, Sony Corporation hereby request confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. We also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Sony Corporation temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and temporary confidential items are listed as follows: PERMANENT AND SHORT-TERM CONFIDEN TIALITY LIST Term Description PERMANENT CONFIDENTIALITY All Bloc k D iagr am s All Sc he matic s All P art Li st s and Tu ne Up Pr oce dur es All O per ati on al De scri pti on s All Ante n na In fo rm ati o n SHORT-TERM CONFIDENTIALITY All E xter nal Ph oto s All Intern al Ph oto s All T est-S etu p P h oto s All SA R Te st-Setu p Ph ot os All User' s Man u al and S afet y Gui de The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the grant for this application. Regards, Ryui Tatsumi Senior Manager Quality Assurance Department. No 1 CS & Quality Division VAIO & Mo bile Business Group SONY Co rporation.

PCTEST Engineering Laboratory, Inc. 6660 Dobbin Road Suite A Columbia, Maryland 21045-4844 Tel.: 410-290-6652 / Fax: 410-290-6654 © 2011 PCTEST Engineering Laboratory Inc. DATE: MAY 12, 2011 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Attestation Statement Sony Corporation FCC ID: AK8PCG41312L Original Certification Laptop Product To whom it may concern: On behalf of Sony Corporation, we confirm the following for this application: - Elliott labs Test report (for conducted measurement information that is applicable for this Sony product, FCC ID: AK8PCG41312L) - PCTEST Test report (for radiated measurements, and also MIMO additional conducted measurements per April 2011 Workshop Notes for MIMO devices) Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely,

LABEL ID AND LOCATION Label on the bottom of the device

FCC ID: AK8PCG41312L SAR COMPLIANCE REPORT Reviewed by: Quality Manager Filename: Test Dates: EUT Type: Page 1 of 42 0Y1103150536-R1.AK8 03/22/11 - 04/08/11 Laptop PC with WWAN, WLAN, LTE and Bluetooth © 2011 PCTEST Engineering Laboratory, Inc. REV 8.9M 03/14/2011 Applicant Name: Date of Testing: Sony Corporation 03/22/11 - 04/08/11 1-7-1 Konan Minato-ku Test Site/Location: Tokyo PCTEST Lab, Columbia, MD, USA Japan, 108-0075 Test Report Serial No.: 0Y1103150536 – R1.AK8 FCC ID: AK8PCG41312L APPLICANT: SONY CORPORATION EUT Type: Laptop PC with WWAN, WLAN, LTE and Bluetooth Application Type: Certification FCC Rule Part(s): Model(s): CFR §2.1093; FCC/OET Bulletin 65 Supplement C [June 2001] PCG-41312L Tx Frequency: 824.20 - 848.80 MHz (GSM 850) / 1850.20 - 1909.80 MHz (GSM 1900) 826.40 - 846.60 MHz (UMTS V) / 1852.4 - 1907.6 MHz (UMTS II) 824.70 - 848.31 MHz (Cellular CDMA) / 1851.25 - 1908.75 MHz (PCS CDMA) 779.5 - 784.5 MHz (LTE) / 2412 - 2462 MHz (WLAN 802.11b/g/n) 5180 - 5240 MHz (WLAN 802.11a/n) / 5260 - 5320 MHz (WLAN 802.11a/n) 5500 - 5700 MHz (WLAN 802.11 a/n) / 5745 - 5825 MHz (WLAN 802.11a/n) Conducted Power: 32.31 dBm GSM 850 / 30.24 dBm GSM 1900 22.85 dBm UMTS V / 22.75 dBm UMTS II 25.15 dBm Cell. CDMA / 24.77 dBm PCS CDMA 24.00 dBm LTE / 15.78 dBm 2.4 GHz WLAN 16.02 dBm 5.2 GHz WLAN 802.11a / 16.06 dBm 5.3 GHz WLAN 802.11a 16.86 dBm 5.5 GHz WLAN 802.11a / 15.01 dBm 5.8 GHz WLAN 802.11a Max. SAR Measurement: 0.12 W/kg GSM 850 Body SAR / 0.08 W/kg GSM 1900 Body SAR 0.06 W/kg UMTS V Body SAR / 0.08 W/kg UMTS II Body SAR 0.24 W/kg Cell. CDMA Body SAR / 0.14 W/kg PCS CDMA Body SAR 0.06 W/kg LTE Body SAR / 0.03 W/kg 2.4 GHz WLAN Body SAR 0.03 W/kg 5.2 GHz WLAN 802.11a / 0.03 W/kg 5.3 GHz WLAN 802.11a 0.06 W/kg 5.5 GHz WLAN 802.11a / 0.09 W/kg 5.8 GHz WLAN 802.11a Test Device Serial No.: Pre-Production [S/N: DVT 1559 1800003, DVT15590 1800006, DVT15590 1800004] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE C95.1-1992 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001), IEEE 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS); for North American frequency bands only. Note: This revised Test Report (S/N: 0Y1103150536 – R1.AK8) supersedes and replaces the previously issued test report on the same subject EUT for the same type of testing as indicated. Please discard or destroy the previously issued test report(s) and dispose of it accordingly. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test results reported herein relate only to the item(s) tested. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. +1.410.290.6652 / Fax +1.410.290.6554 http://www.pctestlab.com SAR COMPLIANCE EVALUATION REPORT FCC ID: AK8PCG41312L SAR COMPLIANCE REPORT Reviewed by: Quality Manager Filename: Test Dates: EUT Type: Page 2 of 42 0Y1103150536-R1.AK8 03/22/11 - 04/08/11 Laptop PC with WWAN, WLAN, LTE and Bluetooth © 2011 PCTEST Engineering Laboratory, Inc. REV 8.9M 03/14/2011 1 LTE SPECIFICATIONS PER KDB 941225 1) 2) LowMidHigh NA782 MHz (CH:23230)NA 779.5 MHz (CH:23206)N/A784.5 MHz (CH:23254) 4)(a) 5) 6) 7) 8) RF Output Power 32.31 dBm 30.24 dBm 22.85 dBm 22.75 dBm 25.13 dBm 23.77 dBm 5.8 dBm 15.78 dBm 16.86 dBm 11) 12) 13-15) 3) 835 MHz WCDMA Body 1900 MHz WCDMA Body 835 MHz GPRS/EDGE Body 1900 MHz GPRS/EDGE Body Descriptions, SAR Test Plan Proposal, SAR Test Data for Power Reduction N/A - Power Reduction Not Used 2.4 GHz WI-FI Body 9-10) (b) 1900 MHz CDMA Conducted power Table provided for 1RB (low and high offset), 50% RB (centered), 100% RB Body RF Exposure Configurations A-MPR (Additional MPR) disabled for SAR Testing? Non-LTE US Wireless Operating Modes/Band LTE Transmitter and Antenna Implementation Description of LTE Tx and Ant. Implementation KDB 941225 Pub LTE Information Body 2.4 GHz Bluetooth Simultaneous Tx conditions Power Reduction used for SAR Compliance? 5 GHz WI-FI Body Body LTE MPR Permanently implemented per 3GPP TS 36.101 section 6.2.3~6.2.5? (manufacturer attestation to be provided) 835 MHz CDMA LTE Voice available? Hotspot with LTE+WIFI FCC ID Form Factor Frequency Range of each LTE transmission band Channel Bandwidths H, M, L channel numbers and frequencies UE Category Band 13 10MHz BW: 5 MHz BW: Modulations Supported in UL Yes Yes Yes Yes No Voice 1 TX/RX Ant Operational Description AK8PCG41312L See Section 13 & Section 15 of the SAR Report No 5 MHz, 10 MHz BW Band 13: 779.5 - 784.5 MHz Laptop QPSK, 16QAM 3 FCC ID: AK8PCG41312L SAR COMPLIANCE REPORT Reviewed by: Quality Manager Filename: Test Dates: EUT Type: Page 3 of 42 0Y1103150536-R1.AK8 03/22/11 - 04/08/11 Laptop PC with WWAN, WLAN, LTE and Bluetooth © 2011 PCTEST Engineering Laboratory, Inc. REV 8.9M 03/14/2011 TABLE OF CONTENTS 1 LTE SPECIFICATIONS PER KDB 941225 ............................................................................................ 2 2 INTRODUCTION .................................................................................................................................... 4 3 TEST SITE LOCATION .......................................................................................................................... 5 4 SAR MEASUREMENT SETUP .............................................................................................................. 6 5 DA…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: AK8PCG41312L FCC Pt. 15.407 802.11a/n UNII MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1103150541.AK8 Mar. 31 - Apr. 4, 2011 850/1900 GSM/GPRS/EDGE/WCDMA/HSPA/CDMA/EvDO and Band 13 LTE Laptop with Bluetooth and WLAN Page 1 of 63 © 2011 PCTEST Engineering Laboratory, Inc. REV 1.1UAN 02/06/09 Applicant Name: Date of Testing: Sony Corporation Mar. 31 - Apr. 4, 2011 1-7-1 Konan Test Site/Location: Minato-ku PCTEST Lab, Columbia, MD, USA 108-0075 Test Report Serial No.: Japan 0Y1103150541.AK8 FCC ID: AK8PCG41312L APPLICANT: Sony Corporation Application Type: Certification Model(s): PCG-41312L EUT Type: 850/1900 GSM/GPRS/EDGE/WCDMA/HSPA/CDMA/EvDO and Band 13 LTE Laptop with Bluetooth and WLAN Max. RF Output Power: 30.41 mW (14.83 dBm) Conducted (802.11a UNII Band I) - 20MHz BW (Chain A) 31.7 mW (15.01 dBm) Conducted (802.11a UNII Band II) - 20MHz BW (Chain A) 36.14 mW (15.58 dBm) Conducted (802.11a UNII Band III) - 20MHz BW (Chain A) 30.13 mW (14.79 dBm) Conducted (802.11n UNII Band I) - 20MHz BW (Chain A) 30.55 mW (14.85 dBm) Conducted (802.11n UNII Band II) - 20MHz BW (Chain A) 35.48 mW (15.5 dBm) Conducted (802.11n UNII Band III) - 20MHz BW (Chain A) 25.06 mW (13.99 dBm) Conducted (802.11n UNII Band I) - 40MHz BW (Chain A) 27.16 mW (14.34 dBm) Conducted (802.11n UNII Band II) - 40MHz BW (Chain A) 26.49 mW (14.23 dBm) Conducted (802.11n UNII Band III) - 40MHz BW (Chain A) 39.99 mW (16.02 dBm) Conducted (802.11a UNII Band I) - 20MHz BW (Chain B) 35.48 mW (16.06 dBm) Conducted (802.11a UNII Band II) - 20MHz BW (Chain B) 40.36 mW (16.86 dBm) Conducted (802.11a UNII Band III) - 20MHz BW (Chain B) 39.99 mW (15.5 dBm) Conducted (802.11n UNII Band I) - 20MHz BW (Chain B) 48.53 mW (16.02 dBm) Conducted (802.11n UNII Band II) - 20MHz BW (Chain B) 47.53 mW (16.77 dBm) Conducted (802.11n UNII Band III) - 20MHz BW (Chain B) 26.98 mW (14.31 dBm) Conducted (802.11n UNII Band I) - 40MHz BW (Chain B) 32.73 mW (15.15 dBm) Conducted (802.11n UNII Band II) - 40MHz BW (Chain B) 35.32 mW (15.48 dBm) Conducted (802.11n UNII Band III) - 40MHz BW (Chain B) 34.07 mW (15.323 dBm) Aggregate Conducted (802.11n UNII Band I) - 20MHz BW 38.84 mW (15.893 dBm) Aggregate Conducted (802.11n UNII Band II) - 20MHz BW 42.17 mW (16.25 dBm) Aggregate Conducted (802.11n UNII Band III) - 20MHz BW 28.97 mW (14.619 dBm) Aggregate Conducted (802.11n UNII Band I) - 40MHz BW 29.29 mW (14.668 dBm) Aggregate Conducted (802.11n UNII Band II) - 40MHz BW 38.59 mW (15.865 dBm) Aggregate Conducted (802.11n UNII Band III) - 40MHz BW Frequency Range: 5180MHz – 5240MHz (UNII-I Band), 5260MHz – 5320MHz (UNII-II Band), 5500 – 5700MHz (UNII-III Band) FCC Classification: Unlicensed National Information Infrastructure (UNII) FCC Rule Part(s): Part 15.407 IC Specification: RSS-210 Issue 8 Test Device Serial No.: N/A This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63.4-2003. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Listed output power is conducted. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC PART 15.407 / IC RSS-210 802.11 a/n Reviewed by: FCC ID: AK8PCG41312L FCC Pt. 15.407 802.11a/n UNII MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1103150541.AK8 Mar. 31 - Apr. 4, 2011 850/1900 GSM/GPRS/EDGE/WCDMA/HSPA/CDMA/EvDO and Band 13 LTE Laptop with Bluetooth and WLAN Page 2 of 63 © 2011 PCTEST Engineering Laboratory, Inc. REV 1.1UAN 02/06/09 TABLE OF CONTENTS FCC PART 15.407 MEASUREMENT REPORT...................................................................................3 1.0 INTRODUCTION...........................................................................................................................4 1.1 SCOPE.........................................................................................................................................................................4 1.2 PCTEST TEST LOCATION......................................................................................................................................4 2.0 PRODUCT INFORMATION............................................................................................................5 2.1 EQUIPMENT DESCRIPTION..................................................................................................................................5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS...........................................................................................5 2.3 LABELING REQUIREMENTS..................................................................................................................................5 3.0 DESCRIPTION OF TEST..........................…

Text truncated - open the document above for the full version.
