AK8PEGTG50Personal Entertainment Organizer with Bluetooth

Formatted Declarations Date: 6 March, 2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 Type of Equipment: Personal Entertainment Organizer Model No.: PEG-TG50/U FCC ID : AK8PEGTG50 To Whom It May Concern: We, SONY CORPORATION declares that the device does not have capability of installing an 802.11 device in its Memory Stick slot and that there are no other possible locations to install an 802.11 device. Basis for above statement is as follows; -The device is not originally designed for use of 802.11 Wireless LAN Card. -There is no software to access to 802.11 for the device. -There is no adopter for inserting LAN card to this device. Thank you for your attention to this matter. Masaharu Abe Manager Product Safety Sect. Quality Assurance Dept. VAIO Network Computer Company Mobile Network Company

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 21, 2003 RE: FCC ID: AK8PEGTG50 Attention: Keijiro Kumagai / Hiroka Umeyama / Kanako Sanda I have a few comments on this Application. 1. The label and label area on the device appear more than sufficiently large enough to contain the 2- condition statement as required in 15.19(a)(3). Please provide a corrected label or please explain why the statement is not on the device. Please note that only those reasons provided in 15.19(a)(5) are acceptable or valid reasons not to place this statement on the product. While you may place the statement in the manual as well, it is required that, unless the exceptions of 15.19(a)(5) can be met, this statement MUST be on the product. Since this exception does not appear to apply to this device (i.e. it is large enough and there is sufficient room), please provide a corrected label with this statement. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

1.Back Surface A of PEG-TG50/UIf Label Statement is attached or printed to Back Surface A, it will touch the Cradle and came off. FCC ID Label 1. Back Surface A 2.Back Surface B 3.On the Bluetooth window Cradle Every time, user set the product on the cradle, red circular part of cradle will touch the Back Surface A. Therefore, Label or Print of Back Surface A will come off and not last for a long time. 2.Back Surface B of PEG-TG50/U FCC ID Label 1.Back Surface A 2.Back Surface B 3.On the Bluetooth Window Logo mark of the product “CLIE” will be on this place, so that label statement cannot be attached or printed in this area. 3.Bluetooth Window on the back surface of PEG-TG50/U FCC ID Label 1.Back Surface A 2.Back Surface B 3.On the Bluetooth Window -Characteristic of Bluetooth can be ruined by label.-Label statement cannot be printed directly to component. Because figure of the component is not suitable for printing the statement. 4.Foreface of PEG-TG50/U There is no place for attaching or printinglabel statement foreface of this product. 5. Front Cover of PEG-TG50/U Front cover can be removed easily and user do not always carry the product with the front cover.

Product Overview 1. Specifications 2. Product view SONY CONFIDENTIAL SONY Personal Entertainment Organizer (CLIE) PEG-TG50/U SONY Personal Entertainment Organizer (CLIE) PEG-TG50/U OSPalm OS ver.5 CPUIntel PXA250 200MHz External input/output Interface connecter IrDA(1.2) IR Port for AV Control Memory Stick slot Bluetooth(1.1) DisplayTFT color LCD with backlight Audio functions FM synthesizer ADPCM Sound Voice memo Audio recording format ATRAC3 MP3 ADPCM Audio Input Internal monaural microphone Auido Output Headphones: Stereo mini-jack Monaural Speaker SONY CONFIDENTIAL 1.Specifications Product Overview SONY CONFIDENTIAL Product Overview 2. Product View 126 mm 71.6 mm 12.5mm Front sideRear side

TOP BOTTOM RIGHT SIDE LEFT SIDE Product photos SONY CONFIDENTIAL 1. Front side (Front cover closed) BOTTOM RIGHT SIDE LEFT SIDE Product photos SONY CONFIDENTIAL 2. Front side (Front cover opened) TOP BOTTOM RIGHT SIDE LEFT SIDE Product photos SONY CONFIDENTIAL 3. Rear side Bluetooth Antenna TOP BOTTOM RIGHT SIDE LEFT SIDE TOP BOTTOM REAR FRONT Product photos SONY CONFIDENTIAL 4. Left side (Front cover closed) TOP BOTTOM REAR FRONT Product photos SONY CONFIDENTIAL 5. Right side (Front cover closed) LEFT RIGHT REAR FRONT Product photos SONY CONFIDENTIAL 6. Top (Front cover closed) LEFT RIGHT REAR FRONT Product photos SONY CONFIDENTIAL 7. Bottom (Front cover closed)

FCC ID Label 2.Label location FCC ID Label SONY CONFIDENTIAL Rear side

Internal Photo Sony Corporation Model: PEG-TG50/U FCC ID: AK8PEGTG50 Viewing from front side of the set Viewing from rear side of the set 9. Bluetooth module / antenna (on PWB) Bluetooth module Bluetooth Antenna Internal Photo Sony Corporation Model: PEG-TG50/U FCC ID: AK8PEGTG50 Viewing from rear side of the set Viewing from rear side of the set 10. Bluetooth module /antenna location Bluetooth Antenna Bluetooth antenna Bluetooth module (another side)

Test report No. : 23EE0036-HO-1 Page : 14 of 59 Issued date : January 8, 2003 FCC ID : AK8PEGTG50 A-Pex International Co., Ltd. EMC Head Office Division. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 APPENDIX 1: Photographs of test setup Conducted Emission Test report No. : 23EE0036-HO-1 Page : 15 of 59 Issued date : January 8, 2003 FCC ID : AK8PEGTG50 A-Pex International Co., Ltd. EMC Head Office Division. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Spurious Emission (Radiated) Test report No. : 23EE0036-HO-1 Page : 16 of 59 Issued date : January 8, 2003 FCC ID : AK8PEGTG50 A-Pex International Co., Ltd. EMC Head Office Division. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8116 Facsimile : +81 596 24 8124 Other test except Conducted Emission and Spurious Emission (Radiated)
