Tablet Device SGPT12&SGPT13 Series &SGPT13  GB Important product information Owner’s Record The model number and serial number are located on the rear panel of your tablet device. Record the model and serial numbers in the space provided here, and keep in a secure location. Refer to the model and serial numbers when you call your Sony Service Center. Model Number: Serial Number: Regulatory Information (USA) If you have questions about this product, you can write to the Sony Customer Information Service Center at 12451 Gateway Blvd., Fort Myers, FL 33913, USA or find Sony Customer Service on the Web site at: http://esupport.sony.com/US/ for customers in USA or http://www.sony.ca/support/ for customers in Canada. Declaration of Conformity Trade Name: SONY Model No.:SGPT1311 Responsible Party:Sony Electronics Inc. Address:16530 Via Esprillo, San Diego, CA 92127 U.S.A. Telephone No.: (For FCC-related matters only) 858-942-2230 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.  The following FCC statements apply only to the version of this model manufactured for sale in the USA. Other versions may not comply with FCC technical regulations, and the FCC statements are not applicable in Canada, including the Province of QUEBEC. FCC Information (USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. Only peripherals (input/output devices, terminals, printers, etc.) that comply with FCC Class B limits may be attached to this product. Operation with noncompliant peripherals is likely to result in interference to radio and television reception. All cables used to connect peripherals must be shielded and grounded. Operation with cables connected to peripherals that are not shielded and grounded may result in interference to radio and television reception.  GB FCC/IC Radio Frequency Exposure The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research. This equipment has been tested and found to comply with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. (FCC) Please refer to the SAR test report that was uploaded at FCC website. (IC) Please refer to the information that consult Safety Code 6, obtainable from Health Canada’s Website. This device and its antenna(s) must not be co-located or operating with any other antenna or transmitter except Grant condition. RSS-General Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. For the  GHz band only To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. The County Code Selection feature is disabled for products marketed in the US/Canada. For product available in the USA/ Canada markets, only channel 1~11 can be operated. Selection of other channels is not possible. Industry Canada Notice This Class B digital apparatus complies with Canadian ICES-003. Specifications of the supplied battery pack Model numberSGPBP03 Maximum Charge Current3.0 A Maximum Charge Voltage4.242 V  For models with the wireless WAN function only Telephone Consumer Protection Act of 1991 (United States) The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device, including FAX machines, to send any mess…

Text truncated - open the document above for the full version.

Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 1 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 720510 1. External Photograph of EUT Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 2 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 3 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 List of Accessory: Specification of Accessory AC Adapter Brand Name SONY Model Name SGPAC5V6 Battery Brand Name SONY Model Name SGPBP03 USB Cable Brand Name SONY Model Name SGPUC2 WWAN Module Brand Name Huawei Model Name EM820W WLAN & Bluetooth Module Brand Name SAMSUNG Model Name SWB-A51H Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 4 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 720510 Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 5 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 6 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311

FCC ID: AK8SGPT1311 EUT Back Label Location

VAIO 共通設計部門3部 VAIO 共通設計部門3部 Data Matrix W=4,h=4 IR MARK h=3 基 清刷参照 h=4 CF:REPRODUCTION PROOF h=4 清刷参照 h=5.4 CF:REPRODUCTION PROOF h=5.4 PRODUCT NAME 6.3 52.2 L=11 Sony Logotype A 現地調達 海外購入部品 ・この部品は設計製造委託品内にある部品であり、検定及び寸法管理は各部品で行わないものとする。寸法及び形状参照したい時はベンダー提出のInspection Sheetを参照の事。 NOTE 1) FOR DETAILS OF DIMENSIONS AND SHAPE REFER TO 3D DATA. 2) THIS PART SHOULD NOT CONTAIN ANY SUBSTANCES WHICH ARE SPECIF IED IN SS-00259-01 3) PURCHASE RECYCLED RESINS AND WIRE RODS ONLY FROM THE BUSINES S PARTNERS AL5052 t0.8 K,S 1 1 4-437-912-ABOVE 1 1 EC EXXXXX NBX-0315(1) NBX-0315(BASE) P/N RELEASE BACK COVER MN 0315 (U)BACK COVER MN 0315 (U) 水谷 12.04.23 水谷 12 04 23 12.04.23 THAT SONY APPROVES AS GREEN PARTNERS. 4) UNLESS OTHERWISE SPECIFIED SHAPE SHOULD BE REFERED TO 3D DAT A 5) FOR ROLLING DIRECTION, STAMPING DIRECTION AND OTHERS CONSULT ATION TO BE DONE SEPARATELY. 6) NO DENT, DEFORMATION, SCRATCHES ON THE APPERANCE.7) PAINT/PAINTED PARTS QUALITY : ALL THE SPECIFICATIONS FOR MT- 1 IN STM-1208 SHOULD BE SATISFIED. 8) ALL THE SPECIFICATIONS FOR GRADE-1 IN STM-1274 SHOULD BE SAT ISFIED. 9) EACH CHARACTERISTICS SPECIFIED IN ITEM 7.STM-1077 SHALL BE S ATISFIED. 10) SONY PROVIDES ARTWORKS. +0.1 0 SAND BLASTING+ ANODIZING(SILVER) LASER PRINTING NEW SONY ID TYPE HRC 1.2 記載文字 ／ WRITTEN LETTER NEW SONY ID TYPE HR 1.2 清刷参照 (Reproduction proof) 字高 LETTER HIGHT (MODEL NO.,Reference on the ABOVE) タイプフェース／TYPE FACE SGPT1311 5V -41-51 A2USS SGPT122US/S A3USS SGPT123US/S SGPT121US/S Product Name A1USS 末尾 -01-11 NBX-0315 -21-31 A1CAS SGPT121CA/S A2CAS SGPT122CA/S A3CAS SGPT123CA/S FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 SGPT1311 AK8SGPT1311 409B-SGPT1311

Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 7 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 720510 3. Internal Photograph of EUT Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 8 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 9 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 10 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 WWAN Module Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 11 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 12 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 WLAN & Bluetooth Module Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 13 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 14 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 WWAN Main Antenna <Tx / Rx> Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 15 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 WWAN Aux. & GPS Antenna <Rx> Photographs of EUT Report No.: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 16 of 16 TEL : 886-3-327-3456 Report Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 WLAN & Bluetooth Antenna <Tx / Rx>

Photographs of EUT Report No: EP261317 Brand Name: SONY / Model Name: SGPT1311 SPORTON INTERNATIONAL INC. Page Number : 1 of 1 TEL : 886-3-327-3456 Issued Date : Jul. 13, 2012 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : AK8SGPT1311 IC : 409B-SGPT1311 Antenna location Length Width WWAN Main Antenna <TX / RX> 7.0 cm 2.1cm WWAN Aux. & GPS Antenna <RX> 5.4 cm 1.2cm Bluetooth & WLAN Antenna <TX / RX> 1.7 cm 1.2cm WLAN & Bluetooth Antenna <TX / RX> 15.3 cm 16 cm 2.4 cm 0.3 cm 0.1 cm 2.4 cm WWAN Aux. &GPS Antenna <RX> WWAN Main Antenna <TX / RX> 10.7 cm

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/4 System Check_Body_835MHz_120604 DUT: D835V2-SN:499 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_850_120604 Medium parameters used: f = 835 MHz; σ = 0.963 mho/m; ε r = 54.5; ρ = 1000 kg/m 3 Ambient Temperature：22.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(5.68, 5.68, 5.68); Calibrated: 2011/6/22 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn910; Calibrated: 2011/12/7 - Phantom: ELI 4.0_Front; Type: QD 0VA 002 AA; Serial: TP-1131 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.64 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 51 V/m; Power Drift = 0.189 dB Peak SAR (extrapolated) = 3.68 W/kg SAR(1 g) = 2.52 mW/g; SAR(10 g) = 1.65 mW/g Maximum value of SAR (measured) = 2.73 mW/g 0 dB = 2.73mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/21 System Check_Body_835MHz_120621 DUT: D835V2-SN:499 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_850_120621 Medium parameters used: f = 835 MHz; σ = 0.993 mho/m; ε r = 54.7; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN3661; ConvF(9.64, 9.64, 9.64); Calibrated: 2012/1/27 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn495; Calibrated: 2012/4/23 - Phantom: ELI 4.0_Front; Type: QD 0VA 002 AA; Serial: TP-1131 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.75 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 52.7 V/m; Power Drift = 0.023 dB Peak SAR (extrapolated) = 3.73 W/kg SAR(1 g) = 2.54 mW/g; SAR(10 g) = 1.67 mW/g Maximum value of SAR (measured) = 2.75 mW/g 0 dB = 2.75mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/29 System Check_Body_835MHz_120629 DUT: D835V2-SN:499 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: MSL_850_120629 Medium parameters used: f = 835 MHz; σ = 0.996 mho/m; ε r = 55.4; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.5 °C DASY4 Configuration: - Probe: ET3DV6 - SN1787; ConvF(6.08, 6.08, 6.08); Calibrated: 2012/5/29 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn913; Calibrated: 2011/12/23 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1026 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.75 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 54.6 V/m; Power Drift = -0.036 dB Peak SAR (extrapolated) = 3.57 W/kg SAR(1 g) = 2.54 mW/g; SAR(10 g) = 1.69 mW/g Maximum value of SAR (measured) = 2.75 mW/g 0 dB = 2.75mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/4 System Check_Body_1900MHz_120604 DUT: D1900V2-SN:5d041 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: MSL_1900_120604 Medium parameters used: f = 1900 MHz; σ = 1.53 mho/m; ε r = 51.9; ρ = 1000 kg/m 3 Ambient Temperature：22.6 °C; Liquid Temperature：21.6 °C DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(4.32, 4.32, 4.32); Calibrated: 2011/6/22 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn910; Calibrated: 2011/12/7 - Phantom: ELI 4.0; Type: QDOVA001BA; Serial: 1029 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 10.7 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 84.7 V/m; Power Drift = -0.123 dB Peak SAR (extrapolated) = 16.8 W/kg SAR(1 g) = 10 mW/g; SAR(10 g) = 6.19 mW/g Maximum value of SAR (measured) = 10.8 mW/g 0 dB = 10.8mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/21 System Check_Body_1900MHz_120621 DUT: D1900V2-SN:5d041 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: MSL_1900_120621 Medium parameters used: f = 1900 MHz; σ = 1.55 mho/m; ε r = 52.9; ρ = 1000 kg/m 3 Ambient Temperature：22.3 °C; Liquid Temperature：21.3 °C DASY5 Configuration: - Probe: EX3DV4 - SN3661; ConvF(7.89, 7.89, 7.89); Calibrated: 2012/1/27 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn495; Calibrated: 2012/4/23 - Phantom: ELI 4.0; Type: QDOVA001BA; Serial: 1029 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 12.1 mW/g Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 87.6 V/m; Power Drift = 0.073 dB Peak SAR (extrapolated) = 20.1 W/kg SAR(1 g) = 10.6 mW/g; SAR(10 g) = 5.39 mW/g Maximum value of SAR (measured) = 12 mW/g 0 dB = 12mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/29 System Check_Body_1900MHz_120629 DUT: D1900V2-SN:5d041 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: MSL_1900_120629 Medium parameters used: f = 1900 MHz; σ = 1.52 mho/m; ε r = 54.8; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.5 °C DASY4 Configuration: - Probe: ET3DV6 - SN1787; ConvF(4.58, 4.58, 4.58); Calibrated: 2012/5/29 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn913; Calibrated: 2011/12/23 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1026 - Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Pin=250mW/Area Scan (61x61x1): Measurement gri…

Text truncated - open the document above for the full version.

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/4 #01 GSM850_GPRS12_Bottom Face_0cm_Ch251 DUT: 261317 Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:2 Medium: MSL_850_120604 Medium parameters used: f = 849 MHz; σ = 0.976 mho/m; ε r = 54.4; ρ = 1000 kg/m 3 Ambient Temperature：22.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(5.68, 5.68, 5.68); Calibrated: 2011/6/22 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn910; Calibrated: 2011/12/7 - Phantom: ELI 4.0_Front; Type: QD 0VA 002 AA; Serial: TP-1131 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Ch251/Area Scan (101x131x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 1.26 mW/g Ch251/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.66 V/m; Power Drift = 0.166 dB Peak SAR (extrapolated) = 1.91 W/kg SAR(1 g) = 1.23 mW/g; SAR(10 g) = 0.766 mW/g Maximum value of SAR (measured) = 1.35 mW/g 0 dB = 1.35mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/4 #03 GSM850_GPRS12_Bottom Face_0cm_Ch128 DUT: 261317 Communication System: GSM850; Frequency: 824.2 MHz;Duty Cycle: 1:2 Medium: MSL_850_120604 Medium parameters used : f = 824.2 MHz; σ = 0.953 mho/m; ε r = 54.7; ρ = 1000 kg/m 3 Ambient Temperature：22.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(5.68, 5.68, 5.68); Calibrated: 2011/6/22 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn910; Calibrated: 2011/12/7 - Phantom: ELI 4.0_Front; Type: QD 0VA 002 AA; Serial: TP-1131 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Ch128/Area Scan (101x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 1.25 mW/g Ch128/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 3.82 V/m; Power Drift = 0.118 dB Peak SAR (extrapolated) = 1.97 W/kg SAR(1 g) = 1.24 mW/g; SAR(10 g) = 0.751 mW/g Maximum value of SAR (measured) = 1.34 mW/g 0 dB = 1.34mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/4 #04 GSM850_GPRS12_Bottom Face_0cm_Ch189 DUT: 261317 Communication System: GSM850; Frequency: 836.4 MHz;Duty Cycle: 1:2 Medium: MSL_850_120604 Medium parameters used : f = 836.4 MHz; σ = 0.964 mho/m; ε r = 54.5; ρ = 1000 kg/m 3 Ambient Temperature：22.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(5.68, 5.68, 5.68); Calibrated: 2011/6/22 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn910; Calibrated: 2011/12/7 - Phantom: ELI 4.0_Front; Type: QD 0VA 002 AA; Serial: TP-1131 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Ch189/Area Scan (101x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 1.23 mW/g Ch189/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 4.17 V/m; Power Drift = 0.135 dB Peak SAR (extrapolated) = 2.05 W/kg SAR(1 g) = 1.24 mW/g; SAR(10 g) = 0.769 mW/g Maximum value of SAR (measured) = 1.34 mW/g 0 dB = 1.34mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/4 #04 GSM850_GPRS12_Bottom Face_0cm_Ch189_2D DUT: 7261317 Communication System: GSM850; Frequency: 836.4 MHz;Duty Cycle: 1:2 Medium: MSL_850_120 604 Medium parameters used : f = 836.4 MHz; σ = 0.964 mho/m; ε r = 54.5; ρ = 1000 kg/m 3 Ambient Temperature：22.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(5.68, 5.68, 5.68) ; Calibrated: 2011/6/22 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn910; Calibrated: 2011/12/7 - Phantom: ELI 4.0_Front; Type: QD 0VA 002 AA; Serial: TP-1131 - Software: DASY5 Version; SEMCAD X Version 13.4 Build 45 Ch189/Area Scan (101x51x1): Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (interpolated) = 1.23 mW/g Ch189/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 4.17 V/m; Power Drift = 0.135 dB Peak SAR (extrapolated) = 2.05 W/kg SAR(1 g) = 1.24 mW/g; SAR(10 g) = 0.769 mW/g Maximum value of SAR (measured) = 1.34 mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2012/6/4 #02 GSM850_GPRS12_Secondary Landscape_0cm_Ch251 DUT: 261317 Communication System: GSM850; Frequency: 848.8 MHz;Duty Cycle: 1:2 Medium: MSL_850_120604 Medium parameters used: f = 849 MHz; σ = 0.976 mho/m; ε r = 54.4; ρ = 1000 kg/m 3 Ambient Temperature：22.4 °C; Liquid Temperature：21.4 °C DASY5 Configuration: - Probe: ES3DV3 - SN3071; ConvF(5.68, 5.68, 5.68); Calibrated: 2011/6/22 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn910; Calibrated: 2011/12/7 - Phantom: ELI 4.0_…
