132Q_IRX-6700_US 4-470-538-11 (1) Quick Start Guide Please read this manual and Safety Regulations carefully before using the product. Keep them in a safe place. Initial Setup 1 Check supplied items 2 Connect AC adapter 3 Turn on your VAIO® computer 4 Raise LCD screen 5 Connect to the Internet Printed in Japan © 2013 Sony Corporation 7 Locate User Guide 8 Sign in with Microsoft account Parts and Controls Plug the power cord and the AC adapter into an AC outlet and the computer. Be sure to connect the AC adapter to your computer when using it for the first few times to ensure the battery becomes fully charged. Press and hold down the power button. The startup process will take a few minutes. No action is required until the setup window appears. 1 2 Grasp the top center edge of the LCD screen and raise it to use the keyboard. Connect to the Internet to automatically activate Windows. 1 Open the charms by pointing to the top right corner of the screen, then move the pointer down and click the Settings charm. 2 Click (the network icon). 3 Select the desired network (SSID) and click Connect. For details on the security key and other settings, refer to the manual of the network device or the information from your Internet service provider. To download and use apps from Windows Store, you need to use a Microsoft account instead of a local account. You can create a Microsoft account by following the steps below. 1 Open the charms by pointing to the top right corner of the screen, then move the pointer down and click the Settings charm. 2 Click Change PC settings, Users, and Switch to a Microsoft account. 3 Follow the on-screen instructions. When app updates are available, a number appears on the Store tile on the Start screen. Click the tile to start Store and update Windows Store apps. An introductory version of the User Guide is available on your computer. To update to the complete version, connect to the Internet and follow the steps below. 1 Open the charms by pointing to the top right corner of the screen, then move the pointer down and click the Search charm. 2 Click Apps, enter “VAIO Manual” in the search box, and then click the icon. The User Guide appears. 3 Close the User Guide, and after a while, open again by following the same steps. The complete version will be available. Be sure to use VAIO Update before updating. 4-470-538-11 (1) Personal Computer VAIO Duo 13 SVD132 Support websites http://esupport.sony.com/US/VAIO/ (USA) http://www.sony.ca/support/ (Canada: English) http://fr.sony.ca/support/ (Canada: French) http://esupport.sony.com/LA/VAIO/ (Latin American area) http://esupport.sony.com/BR/VAIO/ (Brazil) 6 Complete important tasks  Perform Windows Update and VAIO Update  Click the Search charm and Settings, then search Windows Update.  Click the Search charm and Apps, then search VAIO Update.  Create your Recovery Media Press the ASSIST button to start VAIO Care, then click Advanced Tools. Recovery Media are not supplied with your computer. Refer to the supplied Recovery, Backup and Troubleshooting Guide before creating the Recovery Media.  Register your computer Press the ASSIST button to start VAIO Care, then click About your VAIO. Care and Handling Tips Computer Handling Do not exert pressure on your computer, especially the LCD/touch screen or the AC adapter cable. Ventilation Place your computer on hard surfaces such as a desk or table. Proper air circulation around vents is important to prevent overheating. Liquid Damage Protect your computer from contact with liquids.  AC adapter  1  Power cord  Digitizer stylus  2  VGA adapter  3 1 The USB port on the AC adapter is intended exclusively for battery charging. Do not use it for any other purpose. 2 The digitizer stylus is available for pen- based input. Refer to the on-screen User Guide for detailed information on how to use the stylus. 3 Not supplied with all models. Availability depends on your computer’s specifications. Features and specifications may vary and are subject to change without notice. A Built-in front camera / indicator Ambient light sensor LCD screen / touch screen C Power button B (Back) Micro SIM card slot  Internal dual microphones Battery off button “Memory Stick Duo” / SD memory card combined slot HDMI output port USB port x 2 (Compliant with the USB 3.0 standard. The port with the mark supports USB charging.) Headset compatible headphone jack DC IN port Charge indicator E ASSIST buttonStarts VAIO Care while your computer is on - easily tune-up and self support the computer. Internal stereo speaker VOL (Volume) buttons F (Bottom) Touch mark Built-in rear camera / indicator A hole for pen hook G Pen stand H Windows button Touch pad Press the bottom left of the touch pad to click. D Internal stereo speaker  On selected models only. CG A B H FDE

132Q_Safety_6700_US 4-470-539-11 (1) 4-470-539-11(1) 132Q_Safety_6700_US 4-470-539-11 (1) 132Q_Safety_6700_US 4-470-539-11 (1) 3 For customers in USA and Canada Pour les utilisateurs aux Etats-Unis et au Canada Owner’s Record The model number and serial number are located on the bottom, the back panel, or inside the back panel or the battery compartment of your VAIO® computer. Record the model and serial numbers in the space provided here, and keep in a secure location. The model and serial numbers will be required when calling the Sony Service Center. Model Number: Serial Number: Notice © 2013 Sony Electronics Inc. Reproduction in whole or in part without written permission is prohibited. All rights reserved. This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written approval. SONY ELECTRONICS INC. PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR SUCH OTHER INFORMATION. IN NO EVENT SHALL SONY ELECTRONICS INC. BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL, THE SOFTWARE, OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF. SONY CANNOT WARRANT THAT THE FUNCTIONS DESCRIBED IN THIS GUIDE WILL BE UNINTERRUPTED OR ERROR-FREE. SONY ALSO ASSUMES NO RESPONSIBILITY, AND SHALL NOT BE LIABLE FOR ANY DAMAGES TO, OR VIRUSES THAT MAY INFECT YOUR COMPUTER EQUIPMENT, OR OTHER PROPERTY ON ACCOUNT OF YOUR ACCESS TO, USE OF, OR BROWSING IN ANY DESCRIBED WEB SITE, OR YOUR DOWNLOADING OF ANY MATERIALS, DATA, TEXT, IMAGES, VIDEO, OR AUDIO FROM ANY DESCRIBED WEB SITE. WEB SITE INFORMATION IS OBTAINED FROM VARIOUS SOURCES AND MAY BE INACCURATE. COPIES OF COPYRIGHTED INFORMATION MAY ONLY BE MADE FOR LEGALLY PERMISSIBLE PURPOSES. Sony Electronics Inc. reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein is governed by the terms of a separate user license agreement. This product contains software owned by Sony and licensed by third parties. Use of such software is subject to the terms and conditions of license agreements enclosed with this product. Some of the software may not be transported or used outside the United States. Software specifications are subject to change without notice and may not necessarily be identical to current retail versions. Certain product(s) included with this computer may include features such as copy protection and content management technology. USE OF THE SOFTWARE PRODUCT(S) REQUIRES AGREEMENT TO APPLICABLE END USER AGREEMENTS AND FULL COMPLIANCE WITH APPLICABLE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and privacy policies will be detailed during initial launch of the software product(s), or upon certain reinstallations of the software product(s), or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply). Updates and additions to software may require an additional charge. Subscriptions to online service providers may require a fee and credit card information. Financial services may require prior arrangements with participating financial institutions. 132Q_Safety_6700_US 4-470-539-11 (1) 4 Important information for Canadian customers: Your new VAIO® computer includes certain software versions or upgrades, and Internet services or offers that are available to U.S. customers only. Sony, VAIO, and the VAIO logo are trademarks or registered trademarks of Sony Corporation. All other trademarks are trademarks or registered trademarks of their respective owners. The Wireless LAN functionality, which is incorporated into selected models only, has passed Wi-Fi certification and complies with the interoperability specifications established by WFA (Wi-Fi Alliance). Reverse engineering or disassembly is prohibited. End User / Product Activation Requirements Certain software product(s) included with this computer may include features such as copy protection and content management technology. Use of the software product(s) requires agreement to applicable end user agreements and full compliance with applicable product activation procedures. Product activation procedures and privacy policies will be detailed during initial launch of the software product(s), or upon certain reinstallations of the software product(s) or reconfiguration of the computer, and may be completed by Internet or telephone (toll charges may apply). 132Q_Safety_6700_US 4-470-539-11 (1) 5 Safety Information and Caution For questions regarding your product or for the Sony Service Center nearest you, visit the Sony online support web site at http://esupport.sony.com/US/VAIO/ for customers in USA or at http://www.sony.ca/support/ for customers in Canada.  To prevent fire or shock hazard, do not expose your computer to rain or moisture.  To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.  Turning off your computer with the  (power) button does not disconnect the computer completely from mains voltage. To disconnect it completely, unplug the AC adapter or the power cable from mains. The socket-outlet shall be installed near the equipment and shall be easily accessible.  Do not use your computer directly on your lap. The temperature of the base of the unit will rise during normal operation and over time could result in discomfort or burns.  Do not place the AC adapter in contact with your skin. Remove the AC adapter away from your body if it becomes warm and causes discomfort.  Do not block the air exhaust or intake vents while the computer is in operation.  Blocking the air vents leads to r…

Text truncated - open the document above for the full version.

Sony Corporation Nagano Business Center 5432 Toyoshina, Azumino-shi, Nagano, 399-8282 JAPAN Date: April 22, 2013 UL CCS 47173 Benicia Street, Fremont, CA 94538 Reference: Applicant: Sony Corporation FCC ID: AK8SVD132A1WL To whom it may concern: We, the undersigned, hereby authorize Yoshinobu Asai of Application Section, WiSE Japan, UL Verification Service, UL Japan, Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Japan, Inc. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. The application for the subject equipment has not been submitted to another TCB for certification. Sincerely Yours, Ryui Tatsumi Senior manager Product Safeety Sec. Quality Assureance Dept. CS Quality Div. VAIO & Mobile business Group

Sony Corporation Nagano Business Center 5432 Toyoshina, Azumino-shi, Nagano, 399-8282 JAPAN UL CCS 47173 Benicia Street, Fremont, CA 94538 Subject: Request for Confidentiality FCC ID: AK8SVD132A1WL To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Parts List Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days from the date of grant: External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Ryui Tatsumi Senior manager Product Safeety Sec. Quality Assureance Dept. CS Quality Div. VAIO & Mobile business Group April 22, 2013

Country Label Serial Label N ame Plate include FCC/IC ID

Photo Broadcom Corporation 802.11a/b/g/n WLAN + Bluetooth Card [Model: BCM94321NG1630] Top with shield Bottom Photo Broadcom Corporation 802.11a/b/g/n WLAN + Bluetooth Card [Model: BCM94321NG1630] Top without shield

ME906V SECRET Page1, Total2 External Photos of ME906V ME906V SECRET Page2, Total2 ME906V SECRET Page1, Total2 Internal Photos of ME906V ME906V SECRET Page2, Total2

Test report No. : 10004954H-O-R3 Page : 2 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 REVISION HISTORY Original Test Report No.: 10004954H-O Revision Test report No. Date Page revisedContents - (Original) 10004954H-O May 7, 2013 - - 1 10004954H-O-R1 May 9, 2013 P.37, 353 Correction of useful frequency. 2412-2462MHz → 2422-2452MHz 1 10004954H-O-R1 May 9, 2013 P.37, 353 Correction of SAR value 0.00663W/Kg → 0.00633W/kg 0.042W/Kg → 0.0042W/Kg 1 10004954H-O-R1 May 9, 2013 P.96 Correction of SAR value of WLAN 2.4G Top side 0.042W/Kg → 0.0042W/Kg 1 10004954H-O-R1 May 9, 2013 P.248, 353 Deletion of 2nd Repeat data. 1 10004954H-O-R1 May 9, 2013 P.4, 353 Correction of EUT size. H: 210/ W:330/ D: 24.5mm 2 10004954H-O-R2 May 13, 2013 P.95 Correction of Calculation of Estimated SAR Bottom(Laptop) and Bottom side. 2 10004954H-O-R2 May 13, 2013 P. 96 Correction of Stand alone SAR(1g) [W/kg] of Bottom(Laptop) and Bottom side. (Bluetooth) 3 10004954H-O-R3 May 20, 2013 P. 4, 7 Added the information about NFC module in section 2.2 3 10004954H-O-R3 May 20, 2013 P. 29 Power result of LTE band IV 1.4MHz band width 16QAM 1710.7MHz(Low ch/ 19957ch) had a clerical error. Incorrect: 23.01 dBm This data was changed. Correct: 22.98 dBm Power result of LTE band IV 5MHz band width 16QAM 1712.5MHz(Low ch/ 19975ch) had a clerical error. Incorrect: 23.02 dBm This data was changed. Correct: 22.99 dBm 3 10004954H-O-R3 May 20, 2013 P.20 to P.23 Correction to “Average burst power” from “Average frame power”. In Power result sheet of GSM850 and PCS1900 3 10004954H-O-R3 May 20, 2013 P.353 to P.369 Addition of APPENDIX 5: Details about KDB 616217 D04 application of Proximity Sensor. Correction of Angle the sensor sets back to normal. Addition of distance from antenna to phantom in Triggered full power(P.363). Addition of Hotspot position (P.356 to P.358). 3 10004954H-O-R3 May 20, 2013 P.96 Addition of following note: *4 Since result of SUM∑SAR1g of Body exceeded 1.6 W/kg, the method of SAR to Peak Location Separation Ratio was applied. Refer to clause 10.2. (In Section 10.2 Result of SUM∑SAR1g of Body sheet) 3 10004954H-O-R3 May 20, 2013 P.342 Addition of NFC antenna position in the figure of antenna location. Addition of following note in Appendix 4 clause 2 Position of antenna: *The module and antenna of NFC is installed in this EUT. The SAR test of this test report was measured using the sample with NFC module and antenna. Test report No. : 10004954H-O-R3 Page : 3 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 SECTION 1: Customer information ................................................................................................................................................................... 4 SECTION 2: Equipment under test (E.U.T.) ..................................................................................................................................................... 4 2.1 Identification of E.U.T. ...................................................................................................................................... 4 2.2 Product description ............................................................................................................................................ 4 SECTION 3 : Test standard information ........................................................................................................................................................... 8 3.1 Test Specification ............................................................................................................................................... 8 3.2 Procedure ........................................................................................................................................................... 9 3.3 Exposure limit .................................................................................................................................................... 10 3.4 Test Location ..................................................................................................................................................... 10 SECTION 4 : Test result ...................................................................................................................................................................................... 11 4.1 Stand-alone SAR result ...................................................................................................................................... 11 4.2 Simultaneous transmission SAR result .............................................................................................................. 12 SECTION 5 : Description of the operating mode .............................................................................................................................................. 13 5.1 Output power operating modes .......................................................................................................................... 13 5.2 Confirmation before SAR testing (Output power measurement results) ............................................................ 20 5.3 Detail for Power tolerance ................................................................................................................................. 58 5.4 SAR testing operating modes ............................................................................................................................. 59 5.5 Confirmation after SAR testing .......................................................................................................................... 62 SECTION 6 SA…

Text truncated - open the document above for the full version.

Test report No. : 10004954H-O-R3 Page : 249 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 APPENDIX 2 : System Validation 1. System validation result Body 750 Simulated Tissue Liquid Parameter confirmation Date Ambient Temp. [deg.c] Relative Humidity [%] Liquid type Liquid Temp. [deg.c] Measured Frequency [MHz] Parameters Target Value*1 Measured Deviation [%] Limit [%] εr 55.555.60.2+/-5 σ [mho/m] 0.960.960.1+/-5 εr 55.554.9-1.2+/-5 σ [mho/m] 0.960.94-2.4+/-5 εr: Relative Permittivity / σ : Coductivity *1 The Target value is a parameter defined in FCC OET65. 40750 DIELECTRIC PARAMETERS MEASUREMENT RESULTS 29-Mar23.5 MSL 750 24 1-Apr2439 MSL 750 23.5750 Date Ambient Temp. [deg.c] Relative Humidity [%] Liquid type Liquid Temp. [deg.c] Measured Frequency [MHz] Parameters Target Value*2 Measured Deviation [%] Limit*3 [%] εr 55.655.60.0+/-6 σ [mho/m] 0.960.960.1+/-6 εr 55.654.9-1.3+/-6 σ [mho/m] 0.960.94-2.4+/-6 εr: Relative Permittivity / σ : Coductivity *3 The limit is for deviation provided by manufacture. 39 MSL 750 23.5750 DIELECTRIC PARAMETERS MEASUREMENT RESULTS 29-Mar23.5 MSL 750 24 *2 The target value is the calibrated dipole Body TSL parameters. (D750V3 SN:1058, Measured Body TSL parameters) 40750 1-Apr24 System validation result (for calibration by manufacture) Forward Power 250mWConversion 1WDeviationLimit MeasuredCalculation[%][%] 29-Mar750.002.048.168.88-8.1+/-10 1-A pr750.002.138.528.88-4.1+/-10 *1 The taget value is the parameter defined in 1g SAR (normalizes to 1W) in manufacturer calibrated dipole (D750V3 SN:1 0 SYSTEM VALIDATION Date SAR 1g [W/kg] Target 1W *1 Frequency [MHz] Test report No. : 10004954H-O-R3 Page : 250 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 SystemPerformanceCheck-D750 Communication System: CW; Communication System Band: D750 (750.0 MHz); Frequency: 750 MHz;Duty Cycle: 1:1 Medium parameters used: f = 750 MHz; σ = 0.961 mho/m; ε r = 55.617; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration Probe: EX3DV4 - SN3825; ConvF(9.69, 9.69, 9.69); Calibrated: 2012/12/10; ${Probe: Calibration Date} Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn509; Calibrated: 2012/07/13 Phantom: ELI 4.0; Type: QDOVA001BA; Measurement SW: DASY52, Version 52.8 (3); Area Scan (61x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.63 W/kg Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 53.455 V/m; Power Drift = -0.09 dB Peak SAR (extrapolated) = 3.04 W/kg SAR(1 g) = 2.04 W/kg; SAR(10 g) = 1.35 W/kg Maximum value of SAR (measured) = 2.58 W/kg Date: 2013/03/29 Ambient Temp. : 24.0 degree.C. Liquid Temp.; 23.5 degree.C. Test report No. : 10004954H-O-R3 Page : 251 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 SystemPerformanceCheck-D750 Communication System: CW; Communication System Band: D750 (750.0 MHz); Frequency: 750 MHz;Duty Cycle: 1:1 Medium parameters used: f = 750 MHz; σ = 0.939 mho/m; ε r = 54.854; ρ = 1000 kg/m 3 Phantom section: Flat Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration Probe: EX3DV4 - SN3825; ConvF(9.69, 9.69, 9.69); Calibrated: 2012/12/10; ${Probe: Calibration Date} Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn509; Calibrated: 2012/07/13 Phantom: ELI 4.0; Type: QDOVA001BA; Measurement SW: DASY52, Version 52.8 (3); System Performance Check at Frequencies below 1 GHz/d=15mm, Pin=xx mW, dist=2.0mm (EX-Probe)/Area Scan (61x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.67 W/kg System Performance Check at Frequencies below 1 GHz/d=15mm, Pin=xx mW, dist=2.0mm (EX-Probe)/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 54.050 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 3.18 W/kg SAR(1 g) = 2.13 W/kg; SAR(10 g) = 1.4 W/kg Maximum value of SAR (measured) = 2.70 W/kg Date: 2013/04/01 Ambient Temp. : 24.0 degree.C. Liquid Temp.; 23.5 degree.C. Test report No. : 10004954H-O-R3 Page : 252 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 2. System validation result Body 900 Simulated Tissue Liquid Parameter confirmation Date Ambient Temp. [deg.c] Relative Humidity [%] Liquid type Liquid Temp. [deg.c] Measured Frequency [MHz] Parameters Target Value*1 Measured Deviation [%] Limit [%] εr 55.054.9-0.1+/-5 σ [mho/m] 1.051.02-2.7+/-5 εr 55.054.2-1.5+/-5 σ [mho/m] 1.051.050.4+/-5 εr: Relative Permittivity / σ : Coductivity *1 The Target value is a parameter defined in FCC OET65. 4-Apr2440 MSL 900 23.5900 51900 DIELECTRIC PARAMETERS MEASUREMENT RESULTS 14-Mar23.5 MSL 900 24 Date Ambient Temp. [deg.c] Relative Humidity [%] Liquid type Liquid Temp. [deg.c] Measured Frequency [MHz] Parameters Target Value*2 Measured Deviation [%] Limit*3 [%] εr 54.154.91.6+/-6 σ [mho/m] 1.081.02-5.4+/-6 εr 54.154.20.2+/-6 σ [mho/m] 1.081.05-2.4+/-6 εr: Relative Permittivity / σ : Coductivity *3 The limit is for deviation provided by manufacture. 40 MSL 900 23.5900 DIELECTRIC PARAMETERS MEASUREMENT RESULTS 14-Mar23.5 MSL 900 24 *2 The target value is the calibrated dipole Body TSL parameters. (D900V2 SN:155, Measured Body TSL parameters) 51900 4-Apr24 System valid…

Text truncated - open the document above for the full version.

Test report No. : 10004954H-O-R3 Page : 296 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 D1800V2 Calibration for Impedance and Return-loss 1. Test environment 2. Equipment used Control No. Instrument Manufacturer Model No Serial No Calibration Date * Interval(month) MNA-01 Network Analyzer Agilent/HP E8358A US41080381 2012/09/14* 12 EST-46 3.5mm Calibration Kit Agilent 85052D MY43252869 2012/08/13*12 MCC-141 Microwave Cable Junkosha MWX221 1203S212(1m) 2012/04/23*12 MDA-06 Dipole Antenna Schmid&Partner Engineering AG D1800V2 2d040 2010/12/09 * 36 MPSAM-02 SAM Phantom Schmid&Partner Engineering AG SAM Twin Phantom V4.0 1333 Pre Check MOS-24 Thermo-Hygrometer Custom CTH-201 0005 2012/05/14 * 12 HSL2450 Daily check MSL2450 Daily check SAR room Daily check 3. Test Result Impeadance,Transformed to feed pointHeadDeviationToleranceResult Calibration (SPEAG) 2010/12/0948.8 Ω-1.9jΩ--- Calibration(ULJ)2011/11/2348.93Ω-3.96jΩ0.13Ω-2.06jΩ+/-5Ω+/-5jΩComplied Return lossHeadDeviationToleranceResult Calibration (SPEAG) 2010/12/09-33.1dB--- Calibration(ULJ)2011/11/23-27.66dB5.44dB-33.1 *+/-20%Complied Impeadance,Transformed to feed poin tBodyDeviationToleranceResult Calibration (SPEAG) 2010/12/0944.4 Ω-2.2jΩ--- Calibration(ULJ)2011/11/2345.36Ω-3.36jΩ0.96Ω-1.16jΩ+/-5Ω+/-5jΩComplied Return lossBod yDeviationToleranceResult Calibration (SPEAG) 2010/12/09-24.0dB--- Calibration(ULJ)2011/11/23-24.44dB-0.44dB-24*+/-20%Complied *Tolerance : According to the KDB450824D02 Date November 30, 2012 Ambient Temperature 24.0 deg.C Relative humidity 50%RH Test report No. : 10004954H-O-R3 Page : 297 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 Measurement Plots <Head Liquid> <Body Liquid> Test report No. : 10004954H-O-R3 Page : 298 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 9. System Validation Dipole (D2450V2,S/N:713) Test report No. : 10004954H-O-R3 Page : 299 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 Test report No. : 10004954H-O-R3 Page : 300 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 Test report No. : 10004954H-O-R3 Page : 301 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 Test report No. : 10004954H-O-R3 Page : 302 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 Test report No. : 10004954H-O-R3 Page : 303 of 369 FCC ID : AK8SVD132A1WL Issued date : May 7, 2013 Revised date : May 20, 2013 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8999, Facsimile: +81 596 24 8124 Test report No. : 10004954H-O-R3 Page : 304 of 369 FCC ID : AK8SVD13…
